Description
DescriptionDescription
Description Part Number
Part NumberPart Number
Part Number
HP StorageWorks
HP StorageWorksHP StorageWorks
HP StorageWorks
FC1142
FC1142FC1142
FC1142
4Gb PCI-E HBA
4Gb PCI-E HBA4Gb PCI-E HBA
4Gb PCI-E HBA
StorageWorks 4Gb, PCI-E-to-Fibre Channel Host Bus Adapter for Windows 2003,
Windows Server 2003, and Linux.
(Qlogic QLE2460)
AE311A
HP StorageWorks
HP StorageWorksHP StorageWorks
HP StorageWorks
FC1242
FC1242FC1242
FC1242
Dual Channel 4Gb PCI-E
Dual Channel 4Gb PCI-EDual Channel 4Gb PCI-E
Dual Channel 4Gb PCI-E
HBA
HBAHBA
HBA
StorageWorks Dual Channel 4Gb, PCI-E-to-Fibre Channel Host Bus Adapter for
Windows 2003, Windows Server 2003, and Linux.
(Qlogic QLE2462)
AE312A
HP StorageWorks
HP StorageWorksHP StorageWorks
HP StorageWorks
FC2142
FC2142FC2142
FC2142
4Gb PCI-E HBA
4Gb PCI-E HBA4Gb PCI-E HBA
4Gb PCI-E HBA
StorageWorks 4Gb, PCI-E-to-Fibre Channel Host Bus Adapter for Windows 2003,
Windows Server 2003, and Linux
(Emulex LPe 1150)
A8002A
HP StorageWorks
HP StorageWorksHP StorageWorks
HP StorageWorks
FC2242 Dual Channel
FC2242 Dual ChannelFC2242 Dual Channel
FC2242 Dual Channel
4Gb PCI-E HBA
4Gb PCI-E HBA4Gb PCI-E HBA
4Gb PCI-E HBA
StorageWorks Dual Channel 4Gb, PCI-E-to-Fibre Channel Host Bus Adapter for
Windows 2003, Windows Server 2003, and Linux
(Emulex PLe 11002)
A8003A
Product Description
Product DescriptionProduct Description
Product Description
The 4Gb PCI-E Fibre Channel Host Bus Adapter Family consists of single and dual channel Host Bus Adapters (HBAs) with an optical
LC type connector.
For supported Fibre Channel SAN Switches, please consult the SAN Design Reference Guide at the following WEB address:
http://h18006.www1.hp.com/products/storageworks/san/documentation.html
Key Features
Key FeaturesKey Features
Key Features
4Gb/s Fibre Channel link speed support
Automatic speed negotiation with existing 1Gb/s and 2Gb/s Fibre Channel SANs
Superior performance capable of sustaining up to 100,000 I/Os per second per channel
4-Gbps FC increases aggregate throughput rate to 1.6GB/s in full-duplex mode
Full fabric support with automatic topology and speed adaptation
Full support for both FC service Class 2 and 3
Support FC-Tape devices
RoHS compliance
Emulex HBAnyware™ and Qlogic SANsurferTM FC HBA Managers for centralized management and remote control of
distributed HBAs
Benefits At a Glance
Benefits At a GlanceBenefits At a Glance
Benefits At a Glance
Higher performance with lower price
Supports the Windows and Linux operating environments
Provides the flexibility and broad interoperability need for complex highly scalable SANs
QuickSpecs
HP StorageWorks 4Gb PCI-E Host Bus Adapters
HP StorageWorks 4Gb PCI-E Host Bus AdaptersHP StorageWorks 4Gb PCI-E Host Bus Adapters
HP StorageWorks 4Gb PCI-E Host Bus Adapters
Overview
DA - 12604 Worldwide — Version 1 — September 15, 2006 Page 1

Warranty
WarrantyWarranty
Warranty
3-0-0 Three-year parts exchange warranty. Additional Warranty protection can be purchased.
HP Global Services provides a three-year, limited warranty, fully supported by a worldwide network of resellers and service providers
toll-free 7 x 24 hardware technical phone support for the duration of the warranty. In addition, available service offerings include a
full range of HP Care Pack packaged hardware and software services.
NOTE:
NOTE:NOTE:
NOTE: Certain restrictions and exclusions apply. Consult the HP Customer Support Center for details.
QuickSpecs
HP StorageWorks 4Gb PCI-E Host Bus Adapters
HP StorageWorks 4Gb PCI-E Host Bus AdaptersHP StorageWorks 4Gb PCI-E Host Bus Adapters
HP StorageWorks 4Gb PCI-E Host Bus Adapters
Overview
DA - 12604 Worldwide — Version 1 — September 15, 2006 Page 2

Software Product Services
Software Product ServicesSoftware Product Services
Software Product Services Standalone telephone support
Rights to new license version
Media and documentation updates
Hardware Product
Hardware ProductHardware Product
Hardware Product
Services
ServicesServices
Services
Installation services
On-site maintenance (includes warranty support)
Response time upgrades during the warranty period
Post-warranty coverage
RAID setup and performance consulting via statement of work
For additional hardware installation and maintenance information, please refer to the URL listed below:
http://www.hp.com/hps/hardware/
Warranty Upgrade
Warranty UpgradeWarranty Upgrade
Warranty Upgrade
Options
OptionsOptions
Options
Response - Upgrade on-site response from next business day to same day 4 hours
Coverage - Extend hours of coverage from 9 hours x 5 days to 24 hours x 7 days
Duration - Select duration of coverage for a period of 1, 3, or 5 years
Additional Warranty protection and/or HP Installation packages can be purchased.
HP Care Pack Information
HP Care Pack InformationHP Care Pack Information
HP Care Pack Information Sample part numbers:
3 year, uplift to 5 x 9, Next Day Response FM-**XHW-36
3 year, uplift to 5 x 9, 4-hour Response FM-**4HR-36
3 year, uplift to 7 x 24, 4-hour Response FM-**724-36
Hardware Installation FM-**INS-IN
** Represents a two-digit, product-specific code
HP Care Pack is defined as an upgrade to the product warranty attribute, available for a specific
duration and hours of coverage.
HP Care Pack is not available for less than the product's warranty duration.
HP Care Pack is available for sale anytime during the warranty period for most products, but the
commencement date will be the same as the Warranty Start Date (delivery date to end user customer).
Proof of purchase may be required.
HP Care Pack services are prepaid.
If ordering this HBA for a non-HP server, manually add package band 8D4 and Installation HA113A1
band 527. If ordering this HBA as an add-on to an existing HP server, manually add Installation
HA113A1 band 527.
For additional HP Care Pack (hardware & software) information, as well as orderable part numbers,
please refer to the URL http://www.hp.com/hps/carepack/
NOTE:
NOTE:NOTE:
NOTE: Certain restrictions and exclusions apply. Consult the HP Customer Support Center for details.
QuickSpecs
HP StorageWorks 4Gb PCI-E Host Bus Adapters
HP StorageWorks 4Gb PCI-E Host Bus AdaptersHP StorageWorks 4Gb PCI-E Host Bus Adapters
HP StorageWorks 4Gb PCI-E Host Bus Adapters
Service and Support, HP Care Pack, and Warranty Information
DA - 12604 Worldwide — Version 1 — September 15, 2006 Page 3

Family Comparison Table
Family Comparison TableFamily Comparison Table
Family Comparison Table
FC1142SR /
AE311A
FC1242SR /
AE312A
FC2142SR /
A8002A
FC2242SR /
A8003A
FC1143SR / FC1243SR /
Number of
Number ofNumber of
Number of
channels
channelschannels
channels
Single Dual Single Dual
Port Speed
Port SpeedPort Speed
Port Speed 4Gb 4Gb 4Gb 4Gb
Slot type
Slot typeSlot type
Slot type
supported
supportedsupported
supported
PCI Express to
Fibre Channel
PCI Express to
Fibre Channel
PCI Express to
Fibre Channel
PCI Express to
Fibre Channel
OS Supported
OS SupportedOS Supported
OS Supported Windows 2003
Windows Server
2003
Linux
Windows 2003
Windows Server
2003
Linux
Windows 2003,
Windows Server
2003, Linux
Windows 2003,
Windows Server
2003, Linux
Servers
ServersServers
Servers
Supported
SupportedSupported
Supported
HP ProLiant
platforms
HP ProLiant
platforms
HP ProLiant
platforms
HP ProLiant
platforms
Array Platforms
Array PlatformsArray Platforms
Array Platforms
Supported
SupportedSupported
Supported
EVA3000,
EVA4000,
EVA5000,
EVA6000,
EVA8000,
XP Disk Arrays,
MSA1000,
MSA1500
EVA3000,
EVA4000,
EVA5000,
EVA6000,
EVA8000,
XP Disk Arrays,
MSA1000,
MSA1500
EVA3000,
EVA4000,
EVA5000,
EVA6000,
EVA8000,
XP Disk Arrays,
MSA1000
EVA3000,
EVA4000,
EVA5000,
EVA6000,
EVA8000,
XP Disk Arrays,
MSA1000
What's Included
What's IncludedWhat's Included
What's Included
in the Box?
in the Box?in the Box?
in the Box?
Environmental -
Environmental -Environmental -
Environmental -
Operating
OperatingOperating
Operating
Temperature
TemperatureTemperature
Temperature
32° to 131° F
(0° to 55° C)
32° to 131° F
(0° to 55° C)
32° to 113° F
(0° to 45° C)
32° to 113° F
(0° to 45° C)
Environmental -
Environmental -Environmental -
Environmental -
Storage
StorageStorage
Storage
Temperature
TemperatureTemperature
Temperature
-20° to 158° F
(-4° to 70° C)
-20° to 158° F
(-4° to 70° C)
-4 ° to 158° F
(-20° to 70° C)
-4 ° to 158° F
(-20° to 70° C)
Environmental -
Environmental -Environmental -
Environmental -
Relative Humidity
Relative HumidityRelative Humidity
Relative Humidity
- Operating
- Operating- Operating
- Operating
5% to 95% non-
condensing
10% to 90% non-
condensing
5% to 95% non-
condensing
5% to 95% non-
condensing
Product
ProductProduct
Product
Dimensions
DimensionsDimensions
Dimensions
(HxW)
(HxW)(HxW)
(HxW)
6.7 x 2.5 in
(16.93 cm x 5.15
cm)
6.60 x 2.54 in
(167.64 x 64.4
mm)
6.60 x 2.54 in
(167.64mm x
64.4 mm)
6.60 x 2.54
in/167.64mm x
64.4 mm
Media
MediaMedia
Media Multi-mode Optic Multi-mode Optic Multi-mode Optic Multi-mode Optic
Connector
ConnectorConnector
Connector Short wave laser
with LC type
connector
Short wave laser
with LC type
connector
Short wave laser
with LC type
connector
Short wave laser
with LC type
connector
© Copyright 2006 Hewlett-Packard Development Company, L.P.
The information contained herein is subject to change without notice.
The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and
services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial
errors or omissions contained herein.
