DATASHEET
Snap Server™520
Storage performance with
flexible capacity expansion
Features
Best-In-Class Price/Performance
Capacities Ranging from
1TB to 66TB
Instant Capacity Expansion™
(I.C.E.)
Cross-Platform Support Right
out of the Box
Unified Block and File Support
Hot-Swappable Disk Drives
Integrated CA eTrust Antivirus
Software
Active Directory Service
(ADS) Integration
Integrated BakBone NetVault
Softwarewith an Upgrade to a
500GB Virtual Tape Library
Backup Agent and NDMP
Agent Support
Snapshot Technology
Optional Snap EDR Enterprise-
Class Data Replication,
Management, and Protection
Optional StorAssure Personal
Edition Client Backup Software
The Snap Server 520 by Adaptec combines
best-in-class performance with optional
capacity expansion that helps you maximize
your storage budget. With legendary Snap
Server ease of use and operation, an
integrated suite of data protection software,
and scalability to 66TB, it is ideal for any
size company that needs cost-effective, yet
scalable data storage for its growing
business.
Best-in-class performance
The Snap Server 520 is built on a 64-bit
system architecture with AMD Opteron™
technology and 512MB of memory for fast
throughput. It provides cost-effective
Serial ATA II (SATA II) disk drives and with
GuardianOS™ software it beats the
competition with the fastest random data
access speeds.
Availability
The Snap Server 520 integrates availability
features rarely found in a value-based
storage solution, including Ethernet teaming
failover,(combining two Ethernet ports on a
single address, which allows a path to fail
without taking down the network), hot-
swappable drives, and the ability to boot
from any drive. Two other rarely found
features are support for both four drives and
dual power supplies in a 1U system.
High scalability
The Snap Server 520 easily grows as your
data grows. Start with your choice of a 1TB,
2TB, or 3TB unit, and as needs change add
up to seven SANbloc S50 JBOD arrays by
Adaptec, to a maximum of 66TB. With
Instant Capacity Expansion (I.C.E.) the new
capacity is instantly available, without the
traditional RAID re-configuration downtime.
Block and file data storage
iSCSI target support built into the latest
version of the award-winning GuardianOS
platform allows you to storedatabase,
email, and other block data on the same
server whereyou store file data.
GuardianOS also provides automatic cross-
platform file sharing, Unicode support,
global hot sparesupport, and enhanced
quota management.
Integrated data protection
The Snap Server 520 includes a complete
suite of data protection software. It
integrates a WorkGroup Edition of BakBone
NetVault Server,which includes a free
upgrade to a 500GB Virtual Tape Library;
CA eTrust Antivirus Software, and support
for third-party backup agents. Optional
Snap Enterprise Data Replicator software by
Adaptec provides advanced data
protection, movement, and management for
any business. Optional StorAssurePersonal
Edition softwareby Adaptec provides
automated, easy-to-use, client backup for
desktop and laptop systems.
Centralized management
Simple installation and browser-based
management make Snap Servers ideal for
sites with little or no IT support staff. Snap
Server Manager software consolidates the
management of multiple units into a single
console.

SNAP SERVER 520 DATASHEET
www.snapserver.com
Snap Server 520 Specifications
Physical
•Width: 17.5 in (444.5 mm)
•Height: 1.75 in (44.45 mm) 1U
•Depth: 29.25 in (743 mm)
•Weight: 40 lbs (18.2 kg)
Note: 47 lbs (21.3 kg) is the shipping weight including
shipping carton and accessories
Mounting
•Custom 19” rack mount slide rails included
•Minimum rack depth 32” (812.8mm)
Agency Certifications
•UL, cUL, CE, FCC Class A, Nemko, TuV
Processor
•AMD Opteron processor, with 1MB L2 cache
and 1000MHz HyperTransport™
Memory
•512MB DDR 1 400 ECC RAM standard
•4DIMM sockets supporting up to 4GB DDR 1
400 ECC RAM
Drive Configuration
•4x250GB 7200 RPM hot-swappable SATA
drives (1TB raw capacity)
•4x500GB 7200 RPM hot-swappable SATA
drives (2TB raw capacity)
•4x750GB 7200 RPM hot-swappable SATA
drives (3TB raw capacity)
StandardLCD Display
•Backlit, 2 line, 16 character with system ID,
IP address
Network Interface
•Dual-Gigabit Ethernet Ports (autosensing
10/100/1000Base-T, dual RJ-45 network
connections)
•Support for stand-alone, failover, and load
balancing modes
Expansion Array Interface
•Requires optional Serial Attached SCSI host
bus adapter for expansion
•Supports up to 7 SANbloc S50 JBOD
expansion arrays
PCI-X Expansion Card Support
•Supports an additional full-height PCI-X
expansion card
Local Backup Interface
•Ultra320 SCSI 68-pin VHDCI (integrated) Power
•Power Supply: Single 400W supply; add a
second hot-swappable 400W power supply for
redundant failover
•Power Rating: 400W 100-240 VAC, 50-60Hz,
autosensing
•Input Current: 3.4A peak for 115VAC, 1.7A
peak for 230VAC
•Power Consumption: 390W peak
•Heat Dissipation: 1057 BTUs/hr avg.
Environmental Limits, Operating
•Temperature: 50° F to 95° F, (10° C to 35° C)
•Non-Condensing Humidity: 20% to 80%
•Vibration: 0.1G at 10-300Hz random for up to
120 minutes
•Shock: 6 pulses of 33G for up to 2ms
•Altitude: 0 ft to 10,000 ft (0 m to 3,048 m)
Environmental Limits, Non-operating
•Temperature: 14° F to 149° F, (-10° C to 65° C)
•Non-Condensing Humidity: 5% to 95%
•Vibration: 2G at 5-500Hz for up to 90 minutes
•Altitude: 0 ft to 35,000 ft (0 m to 10,668 m)
Included with Unit
•European and US power cable
•2xCat5 Ethernet cables
•Custom 19” rackmount slide rails
•GuardianOS and included features
•Evaluation licenses for optional software

SNAP SERVER 520 DATASHEET
Simplifying Data Storage
GuardianOS Specifications
Network Transport Protocols
•TCP/IP
•UDP/IP
•AppleTalk
Network File Protocols
•Microsoft Networks (CIFS/SMB)
•Linux/UNIX (NFS v2/3 over TCP & UDP)
•Apple (AFP v2/v3)
•Web (HTTP 1.1/HTTPS)
•File Transport Protocol (FTP)
Network Block Protocols
iSCSI Target Support
•Supports qualified iSCSI software and
hardware initiators (see details below).
iSCSI Software Initiator Support
•Windows: Microsoft iSCSI Initiator v1.03, v1.04,
v1.05, v1.06, v2.02
•Solaris: Cisco SN 5400 Series iSCSI Driver
v3.3.5
•Linux: RHEL 3 & 4 and SLES 9: Built-in
Initiator; Redhat 7.3 & 9.0: UNH-iSCSI Initiator
v1.5.3
•NetWare: NetWare Initiator 6.5 SP1
-emboot Bootable iSCSI Softwarefor Windows
-VMWare ESX v3.0 in-box iSCSI Initiator
iSCSI Hardware Initiator Support
•Intel PRO/1000T IP Storage Adapter v2.0, 2.1
•Alacritech SES1001 iSCSI Adapter
•QLogic QLA4010 iSCSI Initiator
Network Client Types
•Windows: 98, Me, NT 4.0, 2000, 2003, XP
•Macintosh: OS 8.x, 9.x, 10.x
•UNIX: Solaris 7, 8, 9; HP-UX 11; AIX 4.3.3, 5.x
•Linux: Red Hat Linux 7.x, 8.x, 9.x
Server Emulation
•Windows 2000/2003
•Windows NT 4.0
•AppleShare
•NFS v2/3
•FTP
Automatic IP Address Assignment
•Supports DHCP Client or Server for automatic
assignment of IP address
Network Security
•Microsoft Active Directory Service (ADS
Member Server)
•Kerberos Authentication v5
•Windows NT Domain (member server)
•File and Folder Access Control List (ACL)
Security for Users and Groups
•UNIX Network Information Service (NIS)
Support
•UID/GID mapping between NFS & CIFS
•Secure Sockets Layer (SSL) v2/v3 128-bit
Encryption
•Transport Layer Security (TLS) v1
•CHAP Authentication (iSCSI target level)
System Management
•CA eTrust Antivirus Software
•Browser-based User Interface for Remote
Administration
•Snap Server Manager Client-Based Setup
Utility (platform-independent)
•SNMP (MIB II and Host Resource MIB)
•User Disk Space Quotas for Windows,
Macintosh, and UNIX/Linux
•Group Disk Space Quotas for NIS Groups
•Environmental Monitoring
•Email Notification Alerts
•Network Time Protocol Support
RAID Options
The Snap Server 520 can be configured for
enhanced performance or maximum file
protection. Options include:
•RAID 5 (drive striping with parity): For each
array,the size of one drive is reserved for
parity. Provides the best combination of
performance and data protection.
•RAID 1 (drive mirroring): One or more drives
duplicate one drive for maximum data
protection.
•RAID 0 (drive striping): Large virtual drive with
data striped across all drives of the array to
provide maximum performance with no loss in
usable capacity.
•Global hot spare support.
•Instant Capacity Expansion (I.C.E.) logically
groups RAIDs for dynamic online scalability.
•RAID 1/5 background scanner constantly
monitors for disk media errors and if it’s
possible to repair the error,automatically
rewrites the “marginal” block.

SNAP SERVER 520 DATASHEET
www.snapserver.com
691 South Milipitas Boulevard
Milpitas, CA 95035
888.343.7627 Tel
408.262.2533 Fax
Copyright 2007 Adaptec, Inc. All rights reserved. Adaptec, the Adaptec logo, Snap Appliance, the Snap Appliance logo, Snap Server,Snap Disk, GuardianOS,
SnapOS, and Snap Server Storage Manager are trademarks of Adaptec, Inc., which may be registered in some jurisdictions. Microsoft and Windows are
registered trademarks of Microsoft Corporation, used under license. All other trademarks used are owned by their respective owners.
Information supplied by Adaptec, Inc., is believed to be accurate and reliable at the time of printing, but Adaptec, Inc., assumes no responsibility for any errors
that may appear in this document. Adaptec, Inc., reserves the right, without notice, to make changes in product design or specifcations. Information is subject
to change without notice.
P/N: 986902-014 Printed in U.S.A. 01/07 4315_2.2
GuardianOS Specifications (cont.)
Data Protection
•Snapshots: Snapshot technology enables
immediate or scheduled point-in-time images
of the file system.
•Enterprise-Class Replication: Optional Snap
EDR simplifies cross-platform management
and protection of distributed data.
•Continuous Data Protection: Optional
StorAssure Personal Edition automatically and
continuously protects data stored on desktop
and laptop systems.
•Local Backup: Integrated BakBone NetVault
WorkGroup Edition.
•Network Backup: Includes an upgrade to a
500GB VTL for disk-to-disk backup. Supports
VERITAS NetBackup/Backup Exec, CA
BrightStor ARCserve/Enterprise, Legato
NetWorker, BakBone Netvault, and Microsoft
Backup Software for Windows 98, Me, NT,
2000, 2003, XP. Compatible with Dantz
Retrospect for Macintosh.
•UPS Support: APC brand UPS with Network
Management Cards are supported for graceful
system shutdown.
Worldwide Warranty
Snap Server hardware and software are backed by world-class service and support to
protect your investment from downtime and provide you with complete peace of mind.
Standard services with the Snap Server 520 include:
•Three-year limited hardware warranty, return to depot
•90-day software support
Optional Support Programs
Today’s mission-critical environments require maximum uptime and rapid resolution should
problems arise. A comprehensive suite of service and support upgrade options help you
protect your business operations. Providing additional levels of technical service and
support, these services extend the standard protection packages already included with
Snap Servers. From extending your warranty phone support to complete same-day onsite
support, you can select the options that best fit your business and resource requirements.
For more information about services, please contact your distributor, or call us at
1-888-343-7627.
Models Part Number
Snap Server 520, 1TB 2196100
Snap Server 520, 2TB 2196200
Snap Server 520, 3TB 5325302032
Software Options
Snap EDR 5325301879
Snap EDR Advanced 5325301934
Snap EDR Express 5325301953
StorAssure Personal Edition 5325301972
SnapServer Manager license*
*Control of individual server is included, this license enables multi-server administration
5325301955
Accessories
SAS HBA card required for expansion 2219500
512MB memory module 2229500
1GB memory module 2229600
Power supply 2209100
Fan module 2209200
Front bezel 2208900
