This document explains how to use the Adaptec®CI/O™
Management Software to perform the following operations:
■Install and use Adaptec CI/O Management Software
■View SCSI devices
■Create arrays and perform array, spare, and disk operations
■Replace drives
➤
Overview of Adaptec CI/O Management Software
1-2
➤
Conventions
1-3

1-2
Adaptec CI/O Management Software User’s Guide
Overview of Adaptec CI/O Management
Software
This User’s Guide explains how to use the Adaptec CI/O
Management Software most effectively. Use the Contents and Index
to find instructions for specific software commands. You can use the
Adaptec CI/O Management Software to perform the following
functions:
■Monitor the status of SCSI devices, arrays, and other devices
on the local system or remote server. The CI/O software sends
status updates (event notifications) from multiple remote
servers. You can simultaneously monitor servers running
under different operating systems.
■Set up regularly scheduled verification of fault-tolerant arrays
and testing of spares. We recommend that you respond
immediately to arrays in Critical status by promptly replacing a
failed disk using a spare.
■Use Adaptec CI/O Management Software, running either on
the local console or on a networked client, to add, delete, or
reconfigure arrays after the system has already been in use.
(You need special access rights to change the system
configuration.)
■Use the password feature to prevent unauthorized users from
changing your array configuration.
■Ensure that arrays are adequately protected with a spare pool
(recommended) or dedicated spares. You can create and delete
spares with the Adaptec CI/O Management Software.

1-3
Getting Started
Conventions
This document uses the following typographic conventions:
bold
Used for key names (… press the Enter key …) and for options
you are told to select (… select Configure SCSI Channels…).
Helvetica
Used for screen messages (…Save changes?…) and for text
that must be typed exactly as shown.
Helvetica Italics
Used for program and file names when referenced in the text
(… these changes are made to the
config.sys
file…).
This document includes three kinds of advisories:
Note:
Notes are reminders, tips, or suggestions that might
simplify the procedures included in this document.
Caution:
Cautions alert you to actions that might cause
damage to your system or your data.
❒
!

2-1
2
▼▼▼▼
Installing CI/O Software
In this Chapter
➤
Installing Adaptec CI/O Management Software on
Windows NT Server or Workstation
2-3
Stopping CI/O Array Management Service 4.00
2-9
Modifying Automatic Start of the Services
2-10
➤
Uninstalling the Adaptec CI/O Management Software
in Windows
2-11
➤
Installing Adaptec CI/O Management Software on a
Networked Windows 95/98 or NT Client
2-12
➤
Installing the TIRPC Communications Module on
NetWare Servers v4.11 and v.5.0
2-18
➤
Installing the Adaptec CI/O Management Software
on Novell NetWare Servers
2-19
➤
Installing Adaptec CI/O Management Software on
UnixWare 7.0.x Servers
2-21
Mount the CD-ROM for UnixWare v7.0.x
2-21
Install the Adaptec CI/O Management Software
on UnixWare v7.0.x
2-22
Uninstalling the Adaptec CI/O Management
Software on UnixWare v7.0.x
2-23

2-2
Adaptec CI/O Management Software User’s Guide
This chapter describes how to install Adaptec CI/O Management
Software on the following:
■Windows®95/98 or NT client
■Windows NT®server or workstation
■Novell NetWare server
■UnixWare server
It also describes how to install the TIRPC Communications Module
on NetWare.

2-3
Installing CI/O Software
Installing Adaptec CI/O Management Software
on Windows NT Server or Workstation
Follow these steps to install the Adaptec CI/O Management
Software on a Windows NT Server:
1
Start Windows NT.
2
Insert the Adaptec CI/O Management Software CD-ROM in
your CD-ROM drive.
3
Locate the Adaptec CI/O Management Software Setup Appli-
cation:
– Double-click on the My Computer icon.
– Double-click on the CD-ROM drive icon.
– Click on Cio400,then click on WINDOWS_95_NT.
– Click on disk 1.
4
Double-click the Setup Application icon. The Welcome screen
appears as shown in Figure Figure 2-1.
Figure 2-1. Welcome Screen

2-4
Adaptec CI/O Management Software User’s Guide
5
Click on Next. The Setup Type Selection screen appears.
6
If you are setting up a Windows NT server, select Networked
System and click on Next. If you are setting up a stand-alone
Windows NT Workstation, select Stand-alone system and click
on Next. The Information screen appears.
Figure 2-2. Setup Type Selection Screen
Figure 2-3. Information Screen

2-5
Installing CI/O Software
7
Click on Next. The Choose Destination Location screen
appears.
8
Use the Browse button to select the pathname for your installa-
tion folder or select the default path. Click on Next. The Select
Components screen appears
Note:
If you are using a Stand-alone system (choice B)
the Select Components Screen (Figure 2-5) will not
appear.
Figure 2-4. Choose Destination Location Screen

2-6
Adaptec CI/O Management Software User’s Guide
9
Select the components you want to install and clear the compo-
nents you do not want to install. Click on Next. The Select Pro-
gram Folder screen appears.
Figure 2-5. Select Components Screen
Figure 2-6. Select Program Folder Screen

2-7
Installing CI/O Software
10
Select the program folder from the existing folders list or type a
new folder name. Click on Next. The Start Copying Files
screen appears. If you previously selected Stand-alone system
(choice B) in the Steup Type Selection (2-2) screen, the Compo-
nents Selected will list only IO Manager Service and Console
User Interface.
11
Click on Next to begin copying files. When the files are copied,
the CI/O ReadMe file appears as shown in Figure 2-8.
Figure 2-7. Start Copying Files Screen
Figure 2-8. CI/O ReadMe file

2-8
Adaptec CI/O Management Software User’s Guide
12
Click Yes to view the ReadMe file or click No to view the Setup
Complete screen as shown in Figure 2-9.
13
The setup is now complete. Select Yes, I want to restart my
computer now. Click on Finish.
14
Wait while the system reboots.
Note:
The NT services for Adaptec CI/O Management
Software are configured to start automatically at boot
time. After installation you can start or stop these
services through the Services icon in the Windows NT
Control Panel.
Figure 2-9. Setup Complete Screen
