Adaptive Micro Systems AlphaEclipse Excite User manual

Quick Start
March 16, 2007 © 2007 Adaptive Micro Systems LLC. All rights reserved PN 1199611201B
Before you start
You will need the following items:
• Ethernet cable or Ethernet crossover cable (for setting up a direct
connection)—included with the sign
• computer or laptop
• ooh!Media CD—included with the sign
• the sign’s network settings (at least the IP address, Subnet Mask,
and Default Gateway)
What is a direct connection?
A direct connection is primarily used to test the sign
communications. It requires a direct connection with a computer
or laptop via a crossover cable and is not ideal for a permanent
communication or networking solution.
Overview
These instructions apply to setting up an AlphaEclipse Excite™
23mm pitch sign on an Ethernet network or testing
communication via a direct connection.
Step Description Purpose
1Connect the sign to the
network
In order to communicate with the
sign, it must be on the network or
connected to the host computer
2Install ooh!Media
ooh!Media is the software that you
will use to send messages to the
sign. The computer it is installed on
is referred to as the “host” computer.
3Send a test message
You will verify communication
between the host computer and the
sign by sending a test message to
the sign.
1) Connect the sign to the network
WARNING! Hazardous voltage. Contact with high voltage may cause death or
serious injury. Always disconnect power to unit prior to servicing.
A. Disconnect all power from the sign at the power source.
B. At the sign, open the case door labeled Controller (bottom left-
most case)
• Using a 5/32-inch hex tool, turn screw counter-clockwise.
• Slowly pull the door toward you to open.
C. For a network connection:
Route the Ethernet cable from your network through the hole in
the back of the controller case and plug into the Ethernet
connection.
D. For a direct connection:
• If this is the permanent connection, route the crossover cable
through the back of the sign.
• Connect one end of the Ethernet crossover cable to the connection
labeled Ethernet in the sign’s controller case.
• Connect the other end to your computer’s Ethernet port.
E. Close the case door.
F. Apply power to the sign.
5/32-inch hex tool
Route the Ethernet cable from your network through this hole
Plug the Ethernet cable in here
Plug Ethernet crossover cable in here
Route the crossover cable from
your computer through this hole
Connecting
the Excite Sign
to an Ethernet
Network

March 16, 2007 © 2007 Adaptive Micro Systems LLC. All rights reserved PN 1199611201B
2) Install ooh!Media
A. Insert the ooh!Media CD into the CD-ROM drive.
If the installation does not start automatically, do the following:
• Select Start > Run.
• Type D:/amplayer (use the correct letter for your CD drive if not
D) and click OK.
B. On the first screen, click the Install ooh!Media button and follow
the instructions.
C. In the Network Setup window, select Use the Following IP
Address and enter the values you received from the network
administrator.
D. Click Set.
E. If the Login prompt appears, enter your password, click OK and
then click Close in the Network Setup window.
Fill in the following:
• IP Address
• Subnet Mask
• Default Gateway
Select Native.
3) Send a test message
A. Start ooh!Media.
Click Start > All Programs > ooh!Media > ooh!Media.
B. In the lower portion of the ooh!Media window under Run-time
Objects, click the insert new text button.
A new text message box appears in ooh!Media.
C. Highlight the text inside the message and type an appropriate test
message.
D. Extend the length of the message by stretching it in the Timeline
(see below).
Extend the message long enough for you to go to the sign and
look at it.
E. Click the disk icon to save the message.
F. Name the message and click Save.
G. Click the send message icon to send the message to the sign.
H. Verify the message appears on the sign.
Time in seconds
