Adata SU800 Instruction Manual

INSTALLING
AN 2.5" SATA SSD
ON A LAPTOP PC

1. GATHER THE THINGS YOU'LL
NEED
*Please use a standard Phillips screwdriver (3.5mm) for
disassembling the case.
PC, Phillips screwdriver, and ADATA 2.5" SATA
SSD
2. BACK UP YOUR DATA
Make sure to backup the important data on your
PC to an external device, such as an external
HDD, before starting installation.
3. POWER OFF YOUR PC
After backing up your data, power off your PC
to avoid data loss or damage to other
components during installation.
4. UNPLUG POWER CORD AND
BATTERY
*The battery removal step applies only to laptops when
it's possible to remove the battery. To see how to remove
the battery, refer to your user manual.
This action is necessary to discharge residual
power that can damage your PC and its
components.
BEFORE INSTALLATION

*If you are unsure how to do this, refer to your user
manual
*The bracket is used to secure the solid state drive,
because the slot is not exactly the same size as the
solid state drive.
*The slot has a foolproof design. Please insert the SSD
in the direction corresponding to the pins on the solid
state drive and the slot. Do not insert it forcibly to avoid
damage to the product.
INSTALLATION
Use your standard Phillips screwdriver to loosen
the screws and then remove the back plate.
2. REMOVE THE MOUNTING
BRACKET AND CABLES
3. CONNECT CABLES AND ATTACH
BRACKET TO THE NEW 2.5" SSD.
There is a row of pins on the cable as well as on
the SSD. Align to the correct orientation and
place the bracket back into the slot.
4. SECURE THE BACK PLATE INTO
PLACE
*Do not overtighten the screws as it may cause damage
1. REMOVE YOUR PC'S BACK
PLATE

5. PLUG IN THE POWER CORD AND
POWER ON THE PC TO COMPLETE
INSTALLATION
CUSTOMER SERVICE AND TECHNICAL SUPPORT
Contact Us: https://www.adata.com/en/support/online/
