Applications
>Notebook systems
>External storage
>Multi-media
>Digital audio
The most complete 2.5-inch hard disk drive
Highlights
>Up to 100GB
>Power dissipation comparable to 4200 RPM
>Outstanding operating and non-operating
shock
>Doubling of industry standard load/unload
cycles to 600,000
>Enhancements to mechanical and
electrical design
>Supports both Parallel ATA and Serial ATA
interfaces
Advanced mobile systems
The Travelstar 5K100 design enhancements include a reduction in the chip set from 4 to 3
chips, and a redesigned actuator arm that will ensure it sets the new standard of ruggedness.
With outstanding shock characteristics, very efficient power consumption, whisper quiet
acoustics, and a range of speeds and capacities, Hitachi Travelstar drives deliver the best
combination of attributes for notebook systems and demanding mobile applications.
Hitachi Travelstar™ 5K100
HARD DISK DRIVES
www.hitachigst.com
Raising the bar of design
The Hitachi Travelstar 5K100 series delivers
a winning combination of characteristics.
With the industry’s lowest idle power and
enhancements to the mechanical and electrical
design, this 5400 RPM drive is the ideal choice
for notebook PCs. The Travelstar 5K100,
at100GB, offers the highest capacity in a 2.5"
5400 RPM drive. That, along with 300G of
operating shock and 1000G of non-operating
shock, makes Travelstar 5K100 the best all-
around 2.5” hard drive.
The Travelstar 5K100 is the centerpiece of a new
line-up of strong contenders.
Feature / Function Benefits
Capacity 100GB *25,000 4-minute MP3 songs, or
*40 hours professional audio, or
*100 hours standard TV, 11.5 hrs HDTV
Reliability 300G operating shock Exceptional ruggedness to withstand tougher
1000G non-operating shock handling and improve portability
600,000 load/unload cycles Double the industry standard specification
Reduces disk wear and protects user data
Fewer electrical components Additional design robustness
Enhanced Error Correction Code (ECC) Improved data integrity
Performance 493Mb/sec media transfer rate Best of breed 5400 RPM performance in Windows
Optimized caching applications
Acoustics Fluid Dynamic Bearing Motors (FDB) Quiet operation
Power 0.60W low power idle Leading low power for longer notebook battery life
Enhanced Adaptive Battery Life
Extender™ (ABLE)
Interface PATA / SATA Supports newest chip set technology
Features and Benefits
Hitachi quality and service
Hitachi Travelstar hard disk drives are designed to the highest quality standards and contain
field-proven components to provide superior quality hard drives backed by Hitachi warranty.
Hitachi provides worldwide technical support and services to enable global customers to
bring their products to market quickly.
100GB, 80GB, 60GB and 40GB |5400 RPM |ATA-6
*Actual storage may vary depending on the compression rate applied.

Hitachi Travelstar 5K100
Product Travelstar 5K100 Travelstar 5K100
Model names HTS541010G9AT00 HTS541010G9SA00
HTS541080G9AT00 HTS541080G9SA00
HTS541060G9AT00 HTS541060G9SA00
HTS541040G9AT00 HTS541040G9SA00
Specifications
Configuration Parallel ATA Serial ATA
Interface ATA-6 Serial ATA 1.5Gb/s
Capacity (GB) 1100 / 80 / 60 / 40 
Sector size (Bytes) 512 
Recording zones 24 
Data heads (physical) 4 / 4 / 3 / 2 
Data disks 2 / 2 / 2 / 1 
Max. areal density (Gbits/sq. inch) 86 / 70 / 70 / 70 
Performance
Data buffer (MB) 28 
Rotational speed (RPM) 5400 35400
Latency average (ms) 5.5 
Media transfer rate (Mbits/sec, max) 493 
Interface transfer rate (MB/sec, max) 100 Ultra DMA mode-5 150
16.6 PIO mode-4
Seek time (read, typical)
Average (ms) 12 
Reliability
Load/Unload cycle 600,000 
Power
Requirement +5VDC (+-5%) 
Dissipation (Typical)
Startup (peak, max.) 5.0W 
Read (avg.) 2.0W 
Write (avg.) 2.0W 
Active idle (avg.) 0.85W 1.2W
Low power idle (avg.) 0.60W 0.85W
Standby (avg.) 0.2W 0.4W
Sleep 0.1W 0.2W
Physical Size
Height (mm) 9.5 
Width (mm) 70 
Depth (mm) 100 
Weight - typical (g) 102 / 102 / 102 / 95 
Environmental characteristics
Operating
Ambient temperature 5° to 55° C 
Shock (half sine wave) 300 G / 2ms, 160G / 1ms 
Non-operating
Ambient temperature -40° to 65° C 
Shock (half sine wave) 1000 G / 1 ms 
Acoustics (A-Weighted Sound Power (Bels))
Idle (typ.) 2.5 / 2.5 / 2.5 / 2.2 
Op (typ.) 2.7 / 2.7 / 2.7 / 2.4 
RoHS compliant 4yes 
1GB equals one billion bytes when referring to hard drive capacity; accessible capacity may be less
2Upper 417KB reserved for firmware
3Part numbers 0A25825 and 0A25826 and others special bid parts are 5400 RPM drives with 4200 RPM emulation
mode enabled. These part numbers are designed for applications where 4200 RPM performance is desired.
4RoHS refers to the European Union Directive 2002/95/EC on the restriction of certain hazardous substances in
electrical and electronic equipment.
© 2007 Hitachi Global Storage Technologies
Hitachi Global Storage Technologies
3403 Yerba Buena Road
San Jose, CA 9515 USA
Produced in the United States 3/05, revised 4/06
All rights reserved.
Hitachi Global Storage Technologies (GST) trademarks
are intended and authorized for use only in countries and
jurisdictions in which Hitachi GST has obtained the rights to
use, market and advertise the brand. Contact Hitachi GST for
additional information. Hitachi GST shall not be liable to third
parties for unauthorized use of this document or unauthorized
use of its trademarks.
References in this publication to Hitachi Global Storage
Technologies products, programs, or services do not imply that
Hitachi Global Storage Technologies intends to make these
available in all countries in which it operates.
Product specifications provided are sample specifications and
do not constitute a warranty. Information is true as of the date of
publication and is subject to change. Actual specifications for
unique part numbers may vary. Please visit the Support section
of our website, www.hitachigst.com/support, for additional
information on product specifications. Photographs may show
design models.
For more information:
Internet:
>www.hitachigst.com (Main Web site)
>www.hitachigst.com/vpp (Reseller Web site)
Technical Support E-mail:
>[email protected] (N. America)
>[email protected] (Asia Pacific)
>[email protected] (EMEA and UK)
Technical Support Phone Numbers:
>1 888 426-5214 (N. America)
>65 6840 9595 (Asia Pacific)
>44 20 7133 0032 (EMEA and UK)
>49 6929 993601 (Germany)
How to Read the Travelstar Model Number
HTS541010G9AT00 = 100GB/8MB
H= Hitachi
T= Travelstar
S= Standard (E = Enhanced Availability)
54 = 5400 RPM3
10 = Full capacity - 100GB
10 = Capacity this model 10 =100GB (80 = 80GB,
60 = 60GB, 40 = 40GB)
G= Generation code
9= 9.5mm z - height
AT = ATA interface (SA = Serial ATA interface)
0= Reserved
0= Reserved
