ADC Megabit Modem 600F User manual

Megabit Modem
Megabit Modem
Catalog Number
MMD4090I1 Issue 1
Megabit Modem 400F, 500L, 600F, and
700F User Manual
Version 3.2.X

ii Megabit Modem 400F, 500L, 600F, and 700F User Manual
C
opyr
i
g
ht
March 2001
©Copyright 2001 ADC DSL Systems, Inc. All Rights Reserved.
Trademark Information
ADC is a registered trademark of ADC Telecommunications, Inc.
Avidia and Megabit Modem are registered trademarks of PairGain Technologies, Inc. No right, license, or interest to
such trademarks is granted hereunder, and you agree that no such right, license, or interest shall be asserted by you with
respect to such trademark.
Other product names mentioned in this practice are used for identification purposes only and may be trademarks or
registered trademarks of their respective companies.
Disclaimer of Liability
Information contained in this document is company private to ADC DSL Systems, Inc., and shall not be modified, used,
copied, reproduced or disclosed in whole or in part without the written consent of ADC.
Contents herein are current as of the date of publication. ADC reserves the right to change the contents without prior
notice. In no event shall ADC be liable for any damages resulting from loss of data, loss of use, or loss of profits, and
ADC further disclaims any and all liability for indirect, incidental, special, consequential or other similar damages. This
disclaimer of liability applies to all products, publications and services during and after the warranty period.

About This User Manual
Megabit Modem 400F, 500L, 600F, and 700F User Manual iii
ABOUT THIS USER MANUAL
Use this manual to install and configure the Megabit Modem®400F, 500L, 600F, and 700F.
This manual provides instruction on:
•information you will need to configure the modem
•unpacking and inspecting the modem for installation
•installing the modem
•setting up parameters for your applications that will be used to configure the modem
•configuring system parameters
•configuring sessions between the modem and a service provider
•monitoring and troubleshooting the modem
Chapter 10 provides a reference for the technology implemented in the Megabit Modem 400F,
500L, 600F, and 700F. This chapter covers information about ATM over ADSL transmission,
operating modes of PPP or bridging/routing, and SNMP management.
IP addresses used in this manual are for example only. You will acquire your own addresses
from the service provider and your information services coordinator to configure the Megabit
Modem 400F, 500L, 600F, and 700F. However, you will use the IP address specified in
“Accessing the Modem Web Pages” on page 27 to access the Megabit Modem 400F, 500L,
600F, and 700F from a Web browser.
DOCUMENT CONVENTIONS
Two types of messages, identified by icons, appear in the text.
Notes contain information about special circumstances.
Cautions indicate the possibility of equipment damage or the possibility of
personal injury.

Product Certifications
iv Megabit Modem 400F, 500L, 600F, and 700F User Manual
PRODUCT CERTIFICATIONS
FCC Class B Compliance
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant topart 15of theFCC Rules. Theselimits are designedto provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and,if not installed andused in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that to which the receiver
is connected.
•Consult the dealer or an experienced radio/TV technician for help.
UL
This product meets all safety requirements per UL-1950 standard.
CE
This product meets all EMC and safety requirements per EN 300 386-2 and IEC 950
(EN60950).
