ADC WFX-3100-M-1 User manual

WFX-3100 Remote DC Power System
Quick Installation Guide
Page 1 of 4
OVERVIEW
This Quick Installation Guide addresses the optional Remote DC
Power System (WFX-3100), and includes product specifications
and installation instructions.
The ADC family of products includes the following items:
•ADC Wireless LAN Array (WFX-3900/3700/3500) – ADC offers
multiple versions of the Wireless LAN Array to support a variety
of deployment types and client migration strategies. Each
Wireless LAN Array includes an embedded Array Controller and
comes in 16 (WFX-3900), 8 (WFX-3700), and 4 (WFX-3500)
Integrated Access Point configurations.
•ADC Centralized Management Platform (WFX-3300) – The
optional WFX-3300 can discover, authenticate and configure up
to 500 Wireless LAN Arrays from anywhere in the network.
•ADC Remote DC Power System (WFX-3100) – The optional
WFX-3100 provides a 48 volt DC power source for remotely
powering up to 12 DC-compatible Wireless LAN Arrays (for
example, WFX-3900-DC) in the event AC power is unavailable
or is cost prohibitive to deploy. The DC-compatible Wireless LAN
Array has a Buchanan socket located next to the ON/OFF
switch.
Features
• Distributes 48V DC power for up to 12 Wireless LAN Arrays.
• Uses standard CAT-5 data-grade cable.
• Needs only 2 cables (1 data and 1 power) per Wireless LAN
deployment.
• Supports up to 3 Power (Expansion) Modules, providing
maximum flexibility during Wi-Fi rollouts.
• When used with a UPS, the WFX-3100 grants all Wireless LAN
Arrays immunity to power outages.
• Fits into existing wiring closets and uses minimal rack space.
SPECIFICATIONS
Table 1 provides product specifications for the WFX-3100 Chassis
(WFX-3100-C) and the WFX-3100 Expansion (Power) Module
(WFX-3100-M).
Table 1. WFX-3100 Specifications PRE-INSTALLATION
Locate Required Equipment
To complete the following procedure, you will need the following:
• WFX-3100 unit
• Power module
• Rack mounting brackets (x2)
• 3/16 inch allen key (for installing the power module)
• Cross-head screwdriver (for attaching the mounting brackets to
the WFX-3100)
INSTALLATION
Attach the Mounting Brackets
Figure 1. Attach the Mounting Brackets
Element
Specifications for
WFX-3100-C
Specifications for
WFX-3100-M
Number of WLAN
Arrays supported
• Base configuration
supports up to 4
WLAN Arrays
• With one additional
Expansion Module
(WFX-3100-M),
supports up to 8
WLAN Arrays
• With two additional
Expansion Modules
(WFX-3100-M),
supports up to 12
WLAN Arrays
4 per Expansion Module
Physical • 19 inch rack-
mountable 1U chassis
• Height: 1.72 inches
(43.7 mm)
• Width: 17.19 inches
(437 mm)
• Depth: 13.25 inches
(336 mm)
• Weight: 10 lbs.
(4.53 kg)*
*12.75 lbs. [5.78 kg] with
one additional Expansion
Module, and 15.5 lbs.
(7.03 kg) with two
additional Expansion
Modules.
• Height: 1.6 inches
(41 mm)
• Width: 5 inches
(127 mm)
• Depth: 10.16 inches
(258 mm)
• Weight: 2.75 lbs
(1.25 kg)
Input voltage • Up to 3 at 85-264 VAC
(4.7 amp each)
• Input connector:
IEC60320 C14
• Up to 3 at 85-264 VAC
(4.7 amp each)
• Input connector:
IEC60320 C14
Output current • 48 VDC, 2 amp per
output connector
• Output connector:
TYCO AMP 796634-3
• 48 VDC, 2 amp per
output connector
• Output connector:
TYCO AMP 796634-3
LED indicators • AC power
•DCstatus
• AC power
• DC status
Operating
temperature range
• 0°C to 70°C ambient
• 0% to 90% humidity
(non-condensing)
• 0°C to 70°C ambient
• 0% to 90% humidity
(non-condensing)
Storage
temperature range
• -40°C to 85°C ambient
• 0% to 90% humidity
(non-condensing)
• -40°C to 85°C ambient
• 0% to 90% humidity
(non-condensing)
Step Action
1Using the countersunk screws provided, attach the
2 rack mounting brackets—one at each side of the unit
(see Figure 1). Tighten all four screws to 10–12 lbf-ft
(1.38–1.66 kg./m.)—do not overtighten!!
Page 2 of 4
Install the Power Module
Figure 2. Install the Power Module
Mount the WFX-3100
Step Action
2If necessary, remove the front bezel from the
WFX-3100.
3Insert the power module into a vacant slot in the
WFX-3100, and secure with a 3/16 inch allen key.
Step Action
1If necessary, reattach the front bezel.
2Mount the WFX-3100 in a 1U rack.
Page 3 of 4
This page intentionally left blank.
Page 4 of 4
HOW TO OBTAIN ADC DOCUMENTATION
Copies of this publication or the WFX-3100 Remote DC Power System User Manual (AIWS-UM-
4006) can be downloaded from the ADC website at www.adc.com. To order a hard copy, please
contact your sales representative.
FCC CLASS A COMPLIANCE
This equipment has been tested and found to comply with the limits for a Class A digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference when the equipment is operated in a commercial environment. This
equipment generates, uses, and can radiate radio frequency energy and, if not installed and used
in accordance with the instruction manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the interference at his own expense.
LIMITED WARRANTY
Product warranty is determined by your service agreement. Refer to the ADC Warranty/Software
Handbook for additional information, or contact your sales representative or Customer Service for
details.
MODIFICATIONS
Any changes or modifications made to this device that are not expressly approved by ADC
Telecommunications, Inc. voids the user's warranty. All wiring external to the products should
follow the provisions of the current edition of the National Electrical Code.
STANDARDS COMPLIANCE
This equipment has been tested and verified to comply with the applicable sections of the following
safety standards:
• GR 63-CORE - Network Equipment-Building System (NEBS) Requirements
• GR 1089-CORE - Electromagnetic Compatibility and Electrical Safety
• Binational standard, UL-60950/CSA C22.2 No. 60950-00: Safety of Information Technology
Equipment.
WORLD HEADQUARTERS
To contact ADC by mail:
ADC Telecommunications, Inc.
PO Box 1101
Minneapolis, MN 55440-1101
TECHNICAL SUPPORT
Technical assistance is available 24 hours a day, 7 days a week by contacting the ADC Technical
Assistance Center (TAC) at:
Telephone: 800.366.3891 (toll-free in the U.S. and Canada)
E-mail: [email protected]
Knowledge Base: www.adc.com/Knowledge_Base/index.jsp
Web: www.adc.com
WFX-3100 REMOTE DC POWER SYSTEM
QUICK INSTALLATION GUIDE
Product Catalog: WFX-3100-C-1, WFX-3100-M-1
Document: AIWS-QI-4004-01
Issued: December 22, 2005
´-TD¶8:¨
1352368
REVISION HISTORY
Copyright©2005 ADC Telecommunications, Inc. All rights reserved.
ADC is a registered trademark of ADC Telecommunications, Inc. No right, license, or interest to such trademarks is granted
hereunder, and you agree that no such right, license, or interest shall be asserted by you with respect to such trademark.
Other product names mentioned in this practice are used for identification purposes only and may be trademarks or
registered trademarks of their respective companies.
Information contained in this document is company private to ADC Telecommunications, Inc., and shall not be modified,
used, copied, reproduced or disclosed in whole or in part without the written consent of ADC.
Contents herein are current as of the date of publication. ADC reserves the right to change the contents without prior notice.
In no event shall ADC be liable for any damages resulting from loss of data, loss of use, or loss of profits, and ADC further
disclaims any and all liability for indirect, incidental, special, consequential, or other similar damages. This disclaimer of
liability applies to all products, publications and services during and after the warranty period.
Rev Date Revisions
01 12/22/05 Initial Release.
