5/08 • 104974AE ProPatch®Programmable Series
ProPatch®Programmable Series
High-Density Patching Systems
2
www.adc.com • +1-952-938-8080 • 1-800-366-3891
Features
Industry’s only bantam and longframe audio•
panel fully qualified to meet demanding military
standards (MIL-STD 202F for ruggedness, and
MIL-J-641E for jack compliance)
Lightweight panels weigh only 6.2 pounds•
(2.8 kg)
High-density bantam 2x48 WECO-compliant•
bantam jacks on 0.312-inch centers
High-density 2x32 or 2x24 longframe jack on•
.500-inch centers
Gold plated DIP switch selectable circuit normals•
and grounds
Shallow depth chassis determined by•
connector style
Fully AES/EBU 110 W digital and analog•
compliant
Modular design allows individual jack access/•
configuration without affecting other circuits
Grounds can be configured on an individual•
circuit basis for lift, chassis, sleeve, and common
ground
Modules snap into place, tabs lock into chassis•
Circuit status icons allow users to identify circuit•
status with snap-in icons in eight colors
Designation strips cover tabs to prevent•
unauthorized access to circuit configuration
switches
Converts to a 1.5 rack unit panel with a patent-•
pending escutcheon kit
Largest designations on the market•
Bantam: .410" for 1 RU
Longframe: .313" for 1 RU
Bantam and Longframe: .680" for 1.5 RU
Individual Jack Access
Each ProPatch®Programmable panel features
individual jack cards. Cards contain an individual
circuit pair of jacks, front panel circuit status
snap-in icon, and seven-position gold plated
sealed DIP switch for normal and ground
configuration. The gold-plated header card
plugs and sockets contained in the chassis
ensure maximum reliability.
To remove a jack, remove the top and bottom
designation strips, push down the locking tab
on the jack module and slide the module out
from the front of the chassis. It is not necessary
to remove the entire panel from the rack, or
the cover from the chassis. Unauthorized circuit
changes are eliminated because switches are
hidden from front panel view.
The ProPatch Programmable system is the
only product in its class that passes demanding
MIL-202 environmental testing for thermal
shock, resistance from moisture contamination,
plating corrosion from salt fog, and vibration
to simulate long-term fixed installation and
over-the-road use.
ProPatch Programmable panel allows individual front-
panel jack access for normals and grounds without
having to take the entire panel off-line. Special 7-position
DIP switches allows configuration of the circuit normal
and grounds without cumbersome jumpers or pins to
lose. (See-through cover in photo is for demonstration
purposes only.)
Bantam
Longframe
