AddMovement AddSeat 5:0 User manual

AddMovement
Getting started GuideGetting started Guide
Manual AddSeat 5.0 - 5.8 Ver 4.0
Segway i2, x2, i2 SE, x2 SE.

2 Model 5n Doc Ver 5.0 .
AddSeat
! !
V35-2D
WARNING
DEATH OR SERIOUS INJURY
Whenever you drive your Segway PT / AddSeat, you risk
death or serious injury from loss of control, collisions, and
falls. To reduce this risk, you must read and follow all
instructions in the user material.

3 Model 5n Doc Ver 5.0 .
AddSeat
Getting started
Guide
AddSeat 5:0-5.8
built on
Segway i2, x2, i2 SE och x2 SE.

4 Model 5n Doc Ver 5.0 .
AddSeat
Copyright, Trademarks and contact information
Copyright © 2006 Segway Inc. All rights reserved.
Brands (Trademarks)
Segway Inc. (”Segway”) owns a number of brands including the Segway and
the Segway ’Flyguy ”logo are registered in the U.S. and other countries.
Those trademarks followed by ® are registered trademarks of Segway.
All other marks used are trademarks of Segway. The fact that an
trademark is not used in this manual, does not mean that Segway doesn’t use
it, nor does it mean that the product is not actively marketed or is not impor-
tant in the current market. Segway has all the rights for all their brands. All
other trademarks are owned by their respective companies.
Such is AddSeat ® who is also a registered trademark and is owned by
AddMovement AB 556894-7336
Contact
For support, contact the dealer who sold you your Segway PT / AddSeat. For
a complete list of retailers, visit our website www.addmovement.com
Assembly plant
AddMovement AB
FritidsFokuz Factory
Industriområdet 109
843 95 Gällö
Sweden
Phone: [phone]
Technical [email protected]
Sales [email protected]

5 Model 5n Doc Ver 5.0 .
AddSeat
Contents
Getting started ........................................................................................................................... 3
Guide........................................................................................................................................... 3
AddSeat 5:n ............................................................................................................................ 3
built on Segway i2, x2, i2 SE och x2 SE. ................................................................................ 3
Preface ......................................................................................................................................... 7
About this guide ........................................................................................................................ 7
Introduction ................................................................................................................................ 8
Risk of injury ................................................................................................................................ 8
Learning to drive your AddSeat ............................................................................................... 9
Safety rst .....................................................................................................................................
10
AddSeats components............................................................................................................. 11
AddSeats parts from the front .............................................................................................. 12
AddSeats parts from behind................................................................................................. 13
Do’s and don’ts ......................................................................................................................... 14
Safety tips and guidelines ........................................................................................................ 15
The InfoKey Controller ................................................................................................................ 21
How to use the InfoKey Controller........................................................................................... 21
The InfoKey controller is NOT waterproof! .......................................................................... 21
InfoKey Contoller buttons and display ................................................................................ 22
Your AddSeats 5 different function modes......................................................................... 23
Prepare your AddSeat ............................................................................................................... 24
Unpack your AddSeat........................................................................................................... 24
Adjust the Steering rod ............................................................................................................. 25
Adjust the seat........................................................................................................................... 26
Adjust the backrest ................................................................................................................... 27
Changing tyres .......................................................................................................................... 29
Care and Maintenance ........................................................................................................... 30
Take care of the tyres............................................................................................................ 30
Cleaning Your AddSeat ........................................................................................................ 30
Lubricating the parking mechanism ................................................................................... 30
Charge the batteries .................................................................................................................. 31
To charge the batteries: ........................................................................................................... 32
Charging indicators .................................................................................................................. 33
Charge the seat battery .......................................................................................................... 34
Speed Limiter ............................................................................................................................. 35
Stick Shake warning .................................................................................................................. 35
Safety Shutdown ....................................................................................................................... 36
How the Gyro handle work........................................................................................................ 38
Instructions for folding up and down the parking stands. .................................................... 38
How the Balance mode work.................................................................................................. 39

6 Model 5n Doc Ver 5.0 .
AddSeat
A few rules to keep in mind ...................................................................................................... 40
Avoiding Hazards ...................................................................................................................... 41
Stopping.................................................................................................................................. 41
How to avoid slipping ............................................................................................................... 42
How to avoid tripping .............................................................................................................. 43
The steps before your rst drive ............................................................................................... 44
Step 1: Important things to know before you drive your AddSeat ................................. 44
Report all incidents ................................................................................................................ 48
Consult the Reference Manual and Website..................................................................... 48
Appendix.................................................................................................................................... 49
Specications for AddSeat ................................................................................................... 49

7 Model 5n Doc Ver 5.0 .
AddSeat
Preface
Congratulations on purchasing
your new AddSeat based on the Segway ® Personal Transporter (PT)
AddSeat is a standard term that refers to the rebuilt selfbalancing Segway
product described in this guide.
About this guide
In the remainder of this guide, we will use for your Segway PT/AddSeat ® only
the word AddSeat.
Getting Started guide will help you get started and use your AddSeat. If you
need to mount the AddSeat on a Segway see seperate tting instructions.
This Getting Started guide contains basic information that you need to learn
about the features and to let you understand your AddSeat in the best way.
It is important that you read and understand the warnings issued in all mate-
rials that come with your AddSeat. It is also very important that you use your
AddSeat with good judgment primarily for your own sake but also for others.

8 Model 5n Doc Ver 5.0 .
AddSeat
Introduction
This guide:
• Contains security information and warnings to help you drive safely and
have fun while using your AddSeat.
• Describes the parts to your AddSeat is built by.
• Describes the warnings meaning.
• Contains details on how to use your AddSeat (including how to prepare for
your rst drive).
• Describes driving techniques.
Risk of injury
.....................................................................................................................................................................
!! WARNING
Whenever you drive the your AddSeat, you risk death or serious injury from loss
of control, collisions, and falls.
It is your responsibility to learn how to drive safely in order to reduce this risk.
The Getting started Guide and Reference Manual for the Segway PT is
designed to help you learn this technique.
For a list of authorized Segway dealer, visit
http://www.segway.com

9 Model 5n Doc Ver 5.0 .
AddSeat
Learning to drive your AddSeat
We who are selling AddSeat want you to be safe and enjoy learning to drive
your AddSeat. Think about when you learned to drive a bike, drive a car, ski-
ing and anything else that involving transportation. You probably had some-
one who helped you. You started at a safe location. You started slowly and
carefully. This should you also apply when you learn to drive with your
AddSeat.
If you carefully follow the instructions in this guide, you will learn how to drive
your AddSeat, but you must be careful. If you try to teach yourself without
reading the guide it’s a great risk that you injure yourself. We recommend
that you have an assistant who also has read this guide to help you drive your
AddSeat for the rst time. Make sure tyres are ok and that there are no loose
parts.
Please do not take risks.
!! IMPORTANT!
In order to buy this vehicle it is required a thorough drive training to ensure
that you, the buyer can handle the vehicle. This vehicle is classed under the
rules of what applies to bicycles and used at your own risk.
!! WARNING
Incorrect performance of the AddSeat can lead to sever personal injuries or
damage to property. Always follow manual recommendations.

10 Model 5n Doc Ver 5.0 .
AddSeat
Safety first
This section covers safety information and warnings
that you must know
before you drive your AddSeat for the rst time.
...............
DEATH OR SERIOUS INJURY
When you drive your AddSeat there is some risk of injury from loss of control,
collisions, and falls. To reduce the risk of injury, you must read and follow all
instructions in the user material.
Always wear a helmet whenever you drive your AddSeat.
Use an approved bicycle or skatebo-
ard helmet that provides protection
for the back of your head. Make sure
the chin strap is in place.
Avoid obstacles and slippery
surfaces that can cause you
to lose traction, balance and
leads to falls.
Pay attention to all warnings and signals from your AddSeat.
They warn you that your AddSeat can not operate safely.
You must learn to recognize and understand them and act correctly.
This is described thoroughly in the user material.
!! WARNING

11 Model 5n Doc Ver 5.0 .
AddSeat
AddSeats components
Your AddSeat includes the following components:
• Infokey ™ controller
• handlerbar
• Steering rod
• Wheels with tyres and fenders
• Display with charge and balance indicators
• Decor
• Carpets
• Platform
• Batteries
• Seat
• load frames
!! WARNING
All parts of your AddSeat must be securely installed. Never attempt to drive
a AddSeat where the Steering rod and handlebar are not properly installed,
unlocked or not properly secured. If you use your AddSeat and parts are not
installed properly, you can injure yourself from loss of control, collisions, and
falls and this causes damage to you and your AddSeat.
Do not modify your AddSeat. Modifications that do not have written consent
from the Segway may interfere with the functionality and cause injury and
cause you to invalidates the warranty.
See Appendix ”Specifications for your AddSeat” on page 49 for more informa-
tion on measurements, weight and similar statistical information.

12 Model 5n Doc Ver 5.0 .
AddSeat
AddSeats parts from the front
Shock absorber
Load bar
Handlebar
Steering rod
Parking standParking stand
Seat
Wheel and tyre
Footrest
Right (unchecked)
Parking Handle
Starts the gyro opera-
tion - unless
left handed operation
Left
Parking
handle
Handle for
adjusting seat
forward or
backward
Button for
raising and
lowering seat
Infokey ™ controller

13 Model 5n Doc Ver 5.0 .
AddSeat
AddSeats parts from behind
Fender
Charging connector
(Segway)
charging and
balance indicators Parking stand
Parking stand
Batteries for
lifting seat
Platform and Segway batteries
AddSeat™ Logo
Levers for lowering
Seat back
Charging connector
for height adjustable
seat if tted
Carpet

14 Model 5n Doc Ver 5.0 .
AddSeat
Do’s and don’ts
• Behave with good manners when you drive your
addSeat.
• Be careful and considerate of others
• Just drive as fast as is safe to drive, both for you
and those around you. Always drive in turtle
mode, otherwise it is at your own risk!
• Always be prepared to stop, keep in mind that children could make
sudden and unexpected movements.
• Respect pedestrians by always yielding the right of way.
• Avoid startling pedestrians. When approaching from behind, announce
yourself and slow down to walking speed when passing. Pass on the left
whenever possible. When approaching a pedestrian from the front, stay
to the right and slow down to save the pedestrian from unnecessary
concern.
• In heavy pedestrian trafc, slow down and proceed at the pace of
pedestrian trafc. Pass only if there is plenty of room to do so safely.
Do not drive slalom (weave in and out)between pedestrians.
• When driving with other AddSeat / Segway- drivers, maintain a safe
distance, identify hazards and obstacles, and do not drive side-by-side
unless there is plenty of room left for pedestrians
• Do not park your AddSeat in a way that blocks pedestrian trafc.
• Cross streets and roads where it is supposed to be doing it. Do not drive
through a red light.
• Only travel on a road when a bike path is not available
or when sidewalk use is not allowed.
• Do not drive your AddSeat on private property unless
you have been given permission to do so.
• Learn about and obey the laws and regulations!

15 Model 5n Doc Ver 5.0 .
AddSeat
Safety tips and guidelines
Your AddSeat has a unique ability to balance and because it is so easy to use
you rapidly become very condent.
BUT please ”Do not drive over your ability!”
If you exceed the balance of your AddSeats such as driving over obstacles,
uneven ground, on slippery surfaces, on loose surfaces or steep hills, you can
quickly lose control causing you to collide, fall over and injure yourself. As with
all types of vehicles, the use of a AddSeat expose you to risk of injury. You can
reduce this risk by following the instructions in this guide, but you can not eli-
minate them completely.
• Read this guide.
• Do not let anyone else use your AddSeat without also having done so.
• Wear a helmet. When you drive your AddSeat you should use a helmet
with chin strap.Use an approved bicycle or skateboard helmet that provi-
des protection for the back of your head.
• Watch over novices carefully. All beginners should use Beginner Mode.
Always drive in turtle mode! You are responsible for Beginner’s safety. Do
not let anyone step on your AddSeat rst time without you or another as-
sistant holds the handlebar rmly. Watch carefully novice until they begin
to become comfortable with how a AddSeat works. Do not let a beginner
use your AddSeat without you having full control of them unless they have
read this guide.
• Avoid slippery surfaces, loose surfaces, steep slopes and obstacles of va-
rious kinds. If you can not avoid these, stop and park on a at surface and
call for help. An assistant can help you to lead you and your AddSeat past
the difcult passage or location. Be especially careful on loose ground or
high obstacles such as an edge.
• Be careful on slopes. Use caution when driving up, down or along one
slope. Do not attempt to drive in slopes if there is loose surface or if it’s slip-
pery. When you drive across a slope, you need to lean towards the top for
balance and make sure you have enough power to cope steer the vehic-
le in the direction of travel. The vehicle would strive to follow the slope of
the ground and will swing downward.

16 Model 5n Doc Ver 5.0 .
AddSeat
• Rocking back and forth is fun but dangerous. If it is a bit slippery, you will
probably fall in the end if you are not careful.
• Watch out in the turns! Always slow down before a turn. Quick turns can
lead to loss of control. Lean into turns.
• Don’t take any unnecessary risks. When you approach a steep slope,
uneven ground or anything that makes you uneasy, do not take the risk!
• Never wear loose clothing on you that can get caught in the wheels and
and prevent you from controlling the AddSeat properly.
• No passengers. Your AddSeat is only designed for one person. Do not carry
other passengers. Don’t carry a child in your lap or in any other way when
you drive!
• Have both hands on the handlebar and both feets resting safetly on the
footrests when you drive your AddSeat.
• Never drive in stairs or revolving doors. Driving in these are dangerous!
• Never drive your AddSeat in the dark or in poor visibility without lamp in the
front and rear. To drive safely you must be able to see what’s in front of you
and others must be able to see you!
• Be relaxed when driving. Keep your head up.
• Be prepared to stop. Be especially careful at crossing intersections, on
driveways, street corners, doorways and other places where you may
need to slow down or stop to avoid motorists, cyclists or pedestrians.
!! WARNING
Risk of head injury due to fall or collision. Helmet should be used at all time
when driving.

17 Model 5n Doc Ver 5.0 .
AddSeat
• Always be alert and as with any vehicle, you must be mentally capable
of driving a vehicle for driving a AddSeat safely. Do not drive if you do not
meet and understand the requirements stipulated in this guide. Do not dri-
ve if you are ill, or under the inuence of alcohol or drugs!
• Do not drive backwards with your AddSeat, you do probably not have
eyes in the back. Optionally, you may cautiously back a few feet to
maneuver but you have to know what’s behind you! Turn instead around
and drive forward. The difference between maneuvering backwards and
driving backwards is like taking a few steps back or walking backwards.
Maneuver backward only when you need to open a door or back away
from an obstacle.
• Do not restart and drive your AddSeat after it has indicated that the bat-
teries are dead or perfomed a automatic shutdown because the batteries
are dead. If you restart and continues to drive, you risk falling. In addition,
you risk damaging the batteries, which means that you reduce the lifetime
and capacity on them.
• It is dangerous to increase over a rock or something protruding xed
objects on the ground. If you get stuck on an object, the vehicle automati-
cally perform a safety shutdown and you can fall.
• In order to transport cargo, use a backpack that you can have on your
back or forward on the stomach. It can also be placed on the seat back
if it is not too heavy! If an emergency occurs, the parking (gyro) handles
has to be free! So thats why the load bars are not suitable for cargo on
your AddSeat. Do not place any load on the platform. The total weight
of the load on the handlebars is max 4.5 kg. If it is exceeded it disturbs the
balance ability. It could lead the AddSeat to accelerate on its own, which
could mean a risk of personal injury or damage to your AddSeat.
!! WARNING
Potential Injuries in case of loss of gyro function do to low or discharged bat-
tery level. Never defy warnings from the AddSeat.

18 Model 5n Doc Ver 5.0 .
AddSeat
• Do not exceed the maximum weight limit (for the driver and cargo), as
specied in the Reference Manual. If you exceed the maximum weight
limits the risk of falls and injures increases. The driver’s weight must not be
less than that specied in the Reference Manual. If you weigh less, it can
happen that you can not drive safely because you can not move the
body weight far enough back (behind the center line between the whe-
els) in order to slow down and stop, especially if you are driving in a down-
hill.
Drivers under the minimum weight limit can also be so light that they do
not activate AddSeats balancing system properly. Minimum weight of the
driver is 45 kg and max weight 120 kg of driver and cargo.
For more information on weight limits, see ”Weight Limits” in the Reference
Manual.
• Since the safe driving of AddSeat means understanding all instructions in
this guide, Segway Inc. recommend that you don’t let children drive your
AddSeat unless:
(a) You have learned to drive, so you understand what it takes to drive
safely. (b) The child has read this entire guide and (c) You are satised that
the child has the knowledge, maturity and physical ability to drive safely
and will not exposing herself or others at risk. Segway recommends that
must be at least 16 years old.
• Make sure tyre pressure is 1,5 - 2kg (bar). If you exceed the tyre pressure,
there is a risk of loss of control, collisions and falls. If you have a lower press-
ure it reduces the range and increases risk of damaging the tyres.
• Make sure your AddSeat is powered off before lifting it. Use good lifting
techniques. Segway recommends that two people lift it together. Both
should have a hand on the Steering rod and lift by the load bars. Lift with
your legs, not with your back. Never lift by the tyres or the fenders becau-
se your ngers can get caught between the tyre and fender. Secure the
machine properly when placed in a vehicle.
• Disconnect the charger cable before removing the batteries or do some
other form of service.
Improper lifting technique can damage your back. Your AddSeat is heavy (80-
90 kg depending on model, tiers and equipment)!
!! WARNING

19 Model 5n Doc Ver 5.0 .
AddSeat
For more instructions and warnings regarding service, see ”Maintaining your
Segway PT” in The Reference Manual.
• Inspect your AddSeat before each use. Do not use it if any parts are loose
or broken.
If you notice that any part is loose or broken, see ”Troubleshooting” in the Re-
ference Manual.
• Do not immerse the batteries or the platform in the water. Do not ush your
AddSeat with a pressure washer. Avoid getting water into the charger port.
Always reseal the charger port with the charger port cover after charging.
Avoid heavy rainfall and longer periods of heavy rain (including driving,
storage or transport).
If your AddSeat has been in heavy rain for some time, see the Reference Ma-
nual for further instructions. Clean and wash it with soap, water and a soft cloth.
Make sure the charger port is dry before you plug in the power cable.
• Do not open the platform. There are no parts that you need or can main-
tain. If you open the platform, you risk getting an electric shock. You also
risk invalidate the warranty, damage your AddSeat and making it unusable
and unsafe to use.
• Do not open the gearboxes. There are no parts that you need or can take

20 Model 5n Doc Ver 5.0 .
AddSeat
out maintain. You could damage your AddSeat and make it unsafe to use.
• Do not use your AddSeat in hazardous environments. The AddSeat is not
certied for use in hazardous environments. Hazardous environments, such
as places where explosion hazards exist due to ammable gases, vapors,
liquids, dusts and bers.
• Follow the instructions in the Reference Manual regarding servicing your
AddSeat.
