Adexa HBW-1P User manual

HBW-1P
HBW-2P
Food Warmer Manual
Durable and elegant design
All stainless steel construction
Automatic thermostat
High-efficient,easy operable&safe
Ⅰ..Safety and Warranty:

FOOD WARMER
•For your safety, do not store or use gasoline or other flammable vapors or liquids in the vicinity of this
or any other appliances. Keep the area free and clear of combustible.
•Improper installation, adjustment, alteration, service or maintenance can cause property damage,
injury, or death. Read the installation operating and maintenance instructions thoroughly before installing,
or servicing this equipment.
•Instructions must be posted in a prominent location. All safety precautions must be taken in the event
the user smells gas.
•These models are designed, built, and sold for commercial use only. If these models are positioned so
the general public can use the equipment, make sure that cautions, warnings, and operating instructions
are clearly posted near each unit so that anyone using the equipment will use it correctly and not injure
themselves or harm the equipment.
•A factory authorized agent should handle all maintenance and repair. Before doing any maintenance
or repair, contact your authorized service representative.
•This product is intended for commercial use only.
•Installation must comply with all local codes.
DANGER: This warns of imminent hazard, which could result in serious injury or death.
WARNING: This refers to a potential hazard or unsafe practice, which could result in serious
injury or death.
Ⅱ.Introduction:
1. Made by good quality stainless steel, beautiful and luxurious appearance.
2. The surface has been polished, easy for cleaning and good heating distributed.
3. Provide with a removable stainless steel tray, easy for cleaning the dregs.
Ⅲ. Technical Specifications:

Name
Model
Voltage
Power
Product
Size
Food warmer
HBW-1P
220-240V
525W
352x355x522MM
Food warmer
HBW-2P
220-240V
1050W
666 x 355 x 522MM
Ⅳ.Circuit diagram:
Ⅴ.Installation:
1. It must be place horizontal stably, provide a good ventilate environment, and make sure there is more
than 10cm from the wall.
2. Before use, check the power supply is corresponds to the required of this machine and the switch &
insurance fuse is suit with the machine’s requirement. The electric wire must be connected with the
leakage protection switch ( the leakage rated current is 5mA). Make sure the power switch can cut off
all electrodes. It should be put on the floor dependable.
3. If the wire is damage to avoid the danger, please ask the repairer to change the same model wire.
Ⅵ.Operating Instruction:
1. Before use please read the specification, and comprehends the feature of this item.

2. Place the item stably, then connect the power, just base on the requirement to adjust the temperature
to the fitting one, now yellow light is turn on, heating tube start to work.
3. When the temperature reach the setting one, then the item start to keep warm.
4. To avoid the metal tong damage the item, please use the wood or bamboo tong to take out the food.
5. When the temperature reaches the setting one, thermostat will shut down the power, yellow light will
turn off,heating tube will stop working. When the temperature comes down, the thermostat will start
working again automatically, yellow light turns o, and the heating tube also starts to work again. This
process is cycling repeatedly, guarantee the temperature is on the set up scope.
Ⅶ.Notes:
To avoid scald, please don’t touch the heating plate when it is working.
●Inject the water before turn on the switch
●When the item is stopped working please take out the plug or cut off the power.
●Forbidden to put the flammable material in the item.
Ⅷ.Maintenance and Maintain:
1. Please use a wet cloth to clean, or use neutral vinegar to clean if necessary, do not rinse the machine
with water directly to avoid the fire ware and electric control parts damage.
2. If the item appear trouble, do not dismount the machine, and send it to our company’s authorized
service department or distributor for repair.
3. Make sure the power is turned off when all the maintenance are in process.
4. Do not rinse the machine with water directly to avoid the fire ware and electric control parts damage.
5. If long time no use, it should be cleaned up and keep it in ventilate and non-fret environment.
Ⅸ.Explode View：

NO.
Name
Specification
QTY
NO.
Name
Specification
QTY
1
Inner door welded
#430/0.6
1
14
4T glass 1P
428*314*4
2
2
switch
1
15
Bottom Sealing board
#201/0.6
1
3
knob
A5/20B-21
1
16
Heating element
500W 230V
1
4
thermostat
WYE-085-A5/850
1
17
Water box
#201/0.8
1
5
Yellow instruction light
φ14
1
18
Terminal block
250V/30A/XL-805
1
6
Green instruction light
φ14
1
19
tray
#201/0.6
1
7
Light board
Zinc/0.6
1
20
Rubber feet
R-25
4
8
Upper plate
#201/0.6
1
21
1p box body welded
1
9
bull+light holder
220V/25W
1
22
Layer shelf
1P
1
10
Glass 1p
66*66*4
1
23
Left door welded plate
1
11
Glass pressing plate
#201/0.6
1
24
Cover handle
1
12
Probe pressing plate
#201/0.6
1
25
glass
341*249*4
1
13
4T glass 1P
428*314*4
1
26
Cable head
10mm
1
27
Power cord
3*1.0*1.8
1

NO.
Name
Specification
QTY
NO.
Name
Specification
QTY
1
switch
1
14
Bottom Sealing board
#201/0.6
1
2
Yellow instruction light
φ14
1
15
Rubber feet
R-25
4
3
Green instruction light
φ14
1
16
tray
#201/0.6
1
4
thermostat
WYE-085-A5/850
1
17
Water box
#201/0.8
2
5
knob
A5/20B-21
1
18
glass
341*249*4
2
6
Light board
Zinc/0.6
2
19
Cover handle
#201/0.6
2
7
Glass pressing plate
#201/0.6
2
20
Inner door welded
#430/0.6
2
8
bull+light holder
220V/25W
2
21
Left door welded plate
#430/0.6
2
9
Upper plate
#201/0.6
1
22
2p box body welded
1
10
Glass 1p
66*66*4
2
23
Cable head
10mm
1
11
4T glass 2P
624*428
1
24
Power cord
3*1.0*1.8
1
12
Glass 1p
428*314*4
2
25
Heating element
500W 230V
2
13
Layer shelf
1p
2
26
Probe pressing plate
#201/0.6
1
27
Terminal block
250V/30A/XL-805
1
