AdHoc DMX RX User manual
DMX RX
Art Nr: AH-DMX-RX
How to
Link
1. Power on the Transmitter and the Adhoc DMX RX.
2. On the Transmitter, press and release the button.
The transmitter will now search for any unlinked Receivers and Link them.
If successful, Link LED on the Adhoc DMX RX will turn Yellow.
Unlink One
On the Adhoc DMX RX, press and hold the UNLINK button for
3 seconds to unlink it from a Transmitter.
If successful, Link LED on the Adhoc DMX RX will turn Blue.
Unlink All
On the Transmitter, press and hold the button
for more than 3 seconds to unlink all of its receivers.
Adhoc Wireless DMX Receiver
Thanks for choosing Adhoc DMX RX!
Please read these instructions carefully and retain it for future reference.
Features
• 2.4Ghz Lumenradio CRMX receiver
• 1 DMX universe up to 512 channels
• Link range up to 1000 meters
Technical
Operating voltage 200–265V AC
Ambient temperature 10–35 °C
(operating)
Range 0–1000m line-of-sight
Latency Fixed 5 ms end-to-end
Antenna type Chip antenna
Operating frequency 2402–2480 MHz
Receiver sensitivity 0.1% BER: Typ. -93dBm
DMX frame size 0–512
DMX frame rate 0.8–830 fps
Dimension (LxWxH) 139.8 x 44.9 x 26 mm
Protection class IP20
DMX Output
Wired serial communication.
DMX+, DMX- and GND signal
will be connected to the
3-position screw terminal block.
Adhoc Wireless DMX Reciever
Art Nr: AH-DMX-RX
Unlink
Data +
Data
-
GND
N L
INPUT
230V~
Made in Sweden
DMX
OUT
DMX RX
Main Input
200–265V AC.
L and N signal will be
connected to the 2-position
screw terminal block.
Installing
Turn
DMX Present LED
ON DMX is present
OFF DMX is not present
Flashing Linked, but no active
radio link.
RF Link state
ON Signal between Adhoc DMX RX and transmitter
is active and in range
OFF No signal between Adhoc DMX RX and
transmitter. Or not in range.
Linked/unlinked
Blue Adhoc DMX RX is not linked.
Yellow Adhoc DMX RX is linked to a transmitter
Unlink
Data +
Data
-
GND
UNLINK button
Press and hold the red button for
3 seconds to unlink from a
DMX transmitter
DMX
OUT
LED indicators
LED indicators are placed to the left of the DMX output terminal block.
Terminal block for
0.13 to 1.3 mm² wire
Status LED
ON Active radio link, DMX data present
OFF Adhoc DMX RX is not linked to a transmitter
Fast Flashing Linked, but no active radio link
Slow Flashing Active radio link, no DMX present
Ljusdesign AB W Södra Skeppsbron 4 W 802 80 Gävle, Sweden
