ADJ PINSPOT LED QUAD DMX User manual

User Instructions
7/14
©2013 ADJ Products, LLC all rights reserved. Information,
specications, diagrams, images, and instructions herein are
subject to change without notice. ADJ Products, LLC logo and
identifying product names and numbers herein are trademarks
of ADJ Products, LLC. Copyright protection claimed includes all
forms and matters of copyrightable materials and information
now allowed by statutory or judicial law or hereinafter granted.
Product names used in this document may be trademarks or
registered trademarks of their respective companies and are
hereby acknowledged. All non-ADJ Products, LLC brands and
product names are trademarks or registered trademarks of their
respective companies.
ADJ Products, LLC and all aliated companies hereby dis-
claim any and all liabilities for property, equipment, building, and
electrical damages, injuries to any persons, and direct or indi-
rect economic loss associated with the use or reliance of any
information contained within this document, and/or as a result
of the improper, unsafe, unsucient and negligent assembly,
installation, rigging, and operation of this product.
Europe Energy Saving Notice
Energy Saving Matters (EuP 2009/125/EC)
Saving electric energy is a key to help protecting the enviroment.
Please turn o all electrical products when they are not in use. To
avoid power consumption in idle mode, disconnect all electrical
equipment from power when not in use. Thank you!
PINSPOT LED QUAD DMX

ADJ Products, LLC - www.adj.com - Pinspot LED Quad DMX User Manual Page 3
• Multi-Colors
• 3 Operating Modes
• Electronic Dimming 0-100%
• Built in Microphone
• DMX-512 protocol
• 3-Pin DMX Connection
• 6 DMX Channels
Pinspot LED Quad DMX Warranty Registration
Pinspot LED Quad DMX Features
To optimize the performance of this product, please read these operat-
ing instructions carefully to familiarize yourself with the basic operations
of this unit. These instructions contain important safety information
regarding the use and maintenance of this unit. Please keep this manual
with the unit, for future reference.
Pinspot LED Quad DMX General Instructions
The Pinspot LED Quad DMX carries a two year limited warranty.
Please fill out the enclosed warranty card to validate your purchase.
All returned service items whether under warranty or not, must be
freight pre-paid and accompany a return authorization (R.A.) number.
The R.A. number must be clearly written on the outside of the return
package. A brief description of the problem as well as the R.A. number
must also be written down on a piece of paper included in the ship-
ping carton. If the unit is under warranty, you must provide a copy of
your proof of purchase invoice. You may obtain a R.A. number by con-
tacting our customer support team on our customer support number.
All packages returned to the service department not displaying a R.A.
number on the outside of the package will be returned to the shipper.
Pinspot LED Quad DMX Introduction
ADJ Products, LLC - www.adj.com - Pinspot LED Quad DMX User Manual Page 2
Unpacking: Thank you for purchasing the Pinspot LED Quad DMX by
ADJ Products, LLC. Every Pinspot LED Quad DMX has been thoroughly
tested and has been shipped in perfect operating condition. Carefully
check the shipping carton for damage that may have occurred during
shipping. If the carton appears to be damaged, carefully inspect your
xture for any damage and be sure all accessories necessary to oper-
ate the unit has arrived intact. In the case damage has been found
or parts are missing, please contact our toll free customer support
number for further instructions. Do not return this unit to your dealer
without rst contacting customer support.
Introduction: The ADJ Pinspot LED Quad DMX is part of a continu-
ing pursuit to create high quality intelligent lighting. The Pinspot LED
Quad DMX is a DMX intelligent, high powered LED par can. This xture
can be used in a stand alone mode or connected in a Master/Slave
conguration. The unit can also be controlled via DMX controller. This
unit has 3 operating modes: Sound Active mode, Auto mode, and DMX
control mode.
Customer Support: ADJ provides a customer support line, to pro-
vide set up help and to answer any question should you encounter
problems during your set up or initial operation. You may also visit us
on the web at www.adj.com for any comments or suggestions. Service
Hours are Monday through Friday 8:00 a.m. to 4:30 p.m. Pacic Stan-
dard Time.
Voice: [phone]
Fax: [phone]
E-mail: [e-mail]
Warning! To prevent or reduce the risk of electrical shock or re, do
not expose this unit to rain or moisture.
Caution! There are no user serviceable parts inside this unit. Do not
attempt any repairs yourself, doing so will void your manufactures war-
ranty. In the unlikely event your unit may require service please contact
ADJ Products, LLC.
PLEASE recycle the shipping carton when ever possible.

Pinspot LED Quad DMX Safety Precautions
ADJ Products, LLC - www.adj.com - Pinspot LED Quad DMX User Manual Page 4
Power Supply: The ADJ Pinspot LED Quad DMX contains a auto-
matic voltage switch, which will auto sense the voltage when it is
plugged into the power source. With this switch there is no need to
worry about the correct power voltage, this unit can be plugged in
anywhere.
DMX-512: DMX is short for Digital Multiplex. This is a universal pro-
tocol used as a form of communication between intelligent fixtures
and controllers. A DMX controller sends DMX data instructions from
the controller to the fixture. DMX data is sent as serial data that trav-
els from fixture to fixture via the DATA “IN” and DATA “OUT” XLR ter-
minals located on all DMX fixtures (most controllers only have a DATA
“OUT” terminal).
DMX Linking: DMX is a language allowing all makes and models of
dierent manufactures to be linked together and operate from a single
controller, as long as all xtures and the controller are DMX compli-
ant. To ensure proper DMX data transmission, when using several
DMX fixtures try to use the shortest cable path possible. The order
in which fixtures are connected in a DMX line does not influence the
DMX addressing. For example; a fixture assigned a DMX address of 1
may be placed anywhere in a DMX line, at the beginning, at the end,
or anywhere in the middle. When a fixture is assigned a DMX address
of 1, the DMX controller knows to send DATA assigned to address 1
to that unit, no matter where it is located in the DMX chain.
Data Cable (DMX Cable) Requirements (For DMX Operation):
The Pinspot LED Quad DMX can be controlled via DMX-512 protocol.
The Pinspot LED Quad DMX has 6 DMX channels, please see page 7 for
the DMX values and traits. The DMX address is set
using the dipswitches located on the rear of the
Pinspot LED Quad DMX. Your unit and your DMX
controller require a standard 3-pin XLR connec-
tor for data input and data output (Figure 1). We
recommend Accu-Cable DMX cables. If you are
making your own cables, be sure to use standard
110-120 Ohm shielded cable (This cable may be
purchased at almost all pro lighting stores). Your
cables should be made with a male and female
XLR connector on either end of the cable. Also remember that DMX
ADJ Products, LLC - www.adj.com - Pinspot LED Quad DMX User Manual Page 5
Pinspot LED Quad DMX Set Up
• To reduce the risk of electrical shock or re, do not expose this unit
rain or moisture
• Do not spill water or other liquids into or on to your unit.
• Be sure that the local power outlet match that of the required volt-
age for your unit.
• Do not attempt to operate this unit if the power cord has been
frayed or broken. Do not attempt to remove or break o the ground
prong from the electrical cord. This prong is used to reduce the risk
of electrical shock and re in case of an internal short.
• Disconnect from main power before making any type of connection.
• Do not remove the cover under any conditions. There are no user
serviceable parts inside.
• Never operate this unit when it’s cover is removed.
• Never plug this unit in to a dimmer pack
• Always be sure to mount this unit in an area that will allow proper
ventilation. Allow about 6” (15cm) between this device and a wall.
• Do not attempt to operate this unit, if it becomes damaged.
• This unit is intended for indoor use only, use of this product out`
doors voids all warranties.
• During long periods of non-use, disconnect the unit’s main power.
• Always mount this unit in safe and stable matter.
• Power-supply cords should be routed so that they are not likely to
be walked on or pinched by items placed upon or against them,
paying particular attention to the point they exit from the unit.
• Cleaning -The fixture should be cleaned only as recommended by
t he manufacturer. See page 9 for cleaning details.
• Heat -The appliance should be situated away from heat sources
such as radiators, heat registers, stoves, or other appliances (inclu-
d ing amplifiers) that produce heat.
• The fixture should be serviced by qualified service personnel when:
A. The power-supply cord or the plug has been damaged.
B. Objects have fallen, or liquid has been spilled into the appliance.
C. The appliance has been exposed to rain or water.
D. The appliance does not appear to operate normally or exhibits a
marked change in performance.
Figure 1

Pinspot LED Quad DMX Operating Instructions
ADJ Products, LLC - www.adj.com - Pinspot LED Quad DMX User Manual Page 7
Operating Modes:
Sound Active Mode:
1. Plug the fixture in and put all dipswitches in the OFF position.
Show Mode:
1. Plug the fixture in and put dipswitches #1in the ON position.
Dipswitches 4, 5, 6, will control the show speed.
DMX Mode:
Operating through a DMX controller gives the user the freedom to
create their own programs tailored to their own individual needs.
This function also allows you to use your fixtures as spot lights. The
Pinspot LED Quad DMX has 6 DMX channels.
1. This function will allow you to control each individual fixture’s
traits with a standard DMX 512 controller.
2. To run your fixture in DMX mode, plug in the fixture via the XLR
connections to any standard DMX controller. Use dipswitches
1-9 to set your desired DMX address. See below for example
addressing.
3. Please see the next page for the DMX values and traits.
ADJ Products, LLC - www.adj.com - Pinspot LED Quad DMX User Manual Page 6
cable must be daisy chained and cannot be split.
Notice: Be sure to follow gures two and three when making your own
cables. Do not use the ground lug on the XLR connector. Do not con-
nect the cable’s shield conductor to the ground lug or allow the shield
conductor to come in contact with the XLR’s outer casing. Grounding
the shield could cause a short circuit and erratic behavior.
Pinspot LED Quad DMX Set Up
DMX512 IN
3-PIN XLR
SOUND
REMOTE
CONTROL
INPUT
POWER
INPUT OUTPUT
SOUND
REMOTE
CONTROL
INPUT
POWER
INPUT OUTPUT
SOUND
REMOTE
CONTROL
INPUT
POWER
INPUT OUTPUT
DMX512
DMX+,DMX-,COMMON
1
2
3
Termination reduces signal errors and
avoids signal transmission problems
and interference. It is always advisable
to connect a DMX terminal, (Resistance
120 Ohm 1/4 W) between PIN 2 (DMX-)
and PIN 3 (DMX +) of the last fixture.
1
2
3
1
2
3
DMX +
DMX -
COMMON
DMX512 OUT
3-PIN XLR
Figure 2
Figure 3
1 Ground 1 Ground
XLR Male Socket
XLR Pin Conguration
3 Hot
2 Cold 2 Cold
3 Hot
XLR Female Socket
Pin 3 = Data True (positive)
Pin 2 = Data Compliment (negative)
Pin 1 = Ground
Special Note: Line Termination. When longer runs of cable are
used, you may need to use a terminator on the last unit to avoid erratic
behavior. A terminator is a 110-120 ohm 1/4 watt resistor which is con-
nected between pins 2 and 3 of a male XLR connector (DATA + and
DATA -). This unit is inserted in the female XLR connector of the last
unit in your daisy chain to terminate the line. Using a cable terminator
(ADJ part number Z-DMX/T) will decrease the possibilities of erratic
behavior.
DMX512 IN
3-PIN XLR
SOUND
REMOTE
CONTROL
INPUT
POWER
INPUT OUTPUT
SOUND
REMOTE
CONTROL
INPUT
POWER
INPUT OUTPUT
SOUND
REMOTE
CONTROL
INPUT
POWER
INPUT OUTPUT
DMX512
DMX+,DMX-,COMMON
1
2
3
Termination reduces signal errors and
avoids signal transmission problems
and interference. It is always advisable
to connect a DMX terminal, (Resistance
120 Ohm 1/4 W) between PIN 2 (DMX-)
and PIN 3 (DMX +) of the last fixture.
1
2
3
1
2
3
DMX +
DMX -
COMMON
DMX512 OUT
3-PIN XLR
Figure 4
5-Pin XLR DMX Connectors. Some manufactures use 5-pin DMX-
512 data cables for DATA transmission in place of 3-pin. 5-pin DMX
xtures may be implemented in a 3-pin DMX line. When inserting stan-
dard 5-pin data cables in to a 3-pin line a cable adaptor must be used,
these adaptors are readily available at most electric stores. The chart
below details a proper cable conversion.
Conductor 5-Pin XLR Male (In)3-Pin XLR Female (Out)
Pin 1
Do Not Use
Do Not Use
Pin 3
Pin 2
Pin 1
Pin 3
Pin 2
Not Used
Not Used
Data True (+ signal)
Data Compliment (- signal)
Ground/Shield
3-Pin XLR to 5-Pin XLR Conversion
UniversalDMXcontroller
WhenusingauniversalDMXcontrollertocontrolthechainofunits,youhavetosetDMXaddress
withDipswitchesfrom1to9tomakesurealltheunitswillreceiveaDMXsignal.Pleasereferto
thefollowingdiagramforhowtoaddressyourDMX512systemusingthebinarycode.
DMX512AddressChart：

Dipswitches
#1
#2
#3
#4
#5
#6
#7
#8
#9
#10
Value
1
2
4
8
16
32
64
128
256
2Lightshow

•Examples: 
6ChannelsMode:
Channel
mode
Unit1
Address
Unit2
Address
Unit3
Address
Unit4
Address
6Channels 1 7 19 4


Unit1：dip/on:#1(=1)
Unit2：dip/on:#1,#2,#3(=1+2+4=7)
Unit3：dip/on:#1,#3,#4(=1+4+8=13)
Unit4：dip/on:#1,#2,#5(=1+2+16=19)


ADJ Products, LLC - www.adj.com - Pinspot LED Quad DMX User Manual Page 8 ADJ Products, LLC - www.adj.com - Pinspot LED Quad DMX User Manual Page 9
Pinspot LED Quad DMX UC-IR Remote
The UC-IR infrared remote has many differnet functions and gives
you complete control of your Pinspot LED Quad DMX. To control the
your desired fixture you must aim the controller at the front of the fix-
ture and be no more the 30 feet away.
STAND BY - Pressing this button will blackout the fixture.
FULL ON -Hold this button down to fully light up the unit. When you
let the button go, the unit will return to its previous state.
FADE/GOBO - Invalid for this fixture.
COLOR - Press buttons 1-9 to choose a desired color. Adjust
the output intensity using either the number buttons, or using the
“DIMMER +” and “DIMMER -” buttons.
STROBE - Press and hold this button the to strobe. This function is
only valid under color mode.
SOUND ON & OFF - These buttons activate and deactivate the
sound active mode.
SHOW - This button will activate the random show (default). Press the
buttons 1-9 to select a different show.
“DIMMER +” and “DIMMER -” - Use these buttons to adjust the out-
put intensity in Color mode.
Master-Slave Setup:
This function will allows you to link units together to run in a Master-
Slave mode. In a Master-Slave set up one unit will act as the control-
ling unit and the others will react to the controlling units built-in pro-
grams. Any unit can act as a Master or as a Slave however, only one
unit can be programmed to act as the “Master.”
1. Daisy chain your units via the XLR connector on the rear of the
unit. Use standard XLR microphone cables to link your units
together. Remember that the Male XLR connector is the input and
the Female XLR connector is the ouput. The first unit in the chain
(master) will use the female XLR connector only. The last unit in
the chain will use the male XLR connector only.
2. Set the dipswitch #1 to the ON position, all other dipswitches o
for the “Master” unit.
3. For the “Slave” unit(s), any dipswitch in the On position except
#1.
4. Connect the “Slave” unit or units and they will automatically start
to follow the “Master.”
Pinspot LED Quad DMX Operating Instructions
Pinspot LED Quad DMX 6 Channel Mode
Channel Value Function
1 RED
0 - 255 0% - 100%
2 GREEN
0 - 255 0% - 100%
3 BLUE
0 - 255 0% - 100%
4 WHITE
0 - 255 0% - 100%
5 MASTER DIMMER
0 - 255 0% - 100%
6 STROBING
0 - 7 NO STROBING
8 - 247 STROBING SLOW - FAST
248 - 255 SOUND ACTIVE STROBING
Pinspot LED Quad DMX Cleaning
Due to fog residue, smoke, and dust cleaning the internal and exter-
nal optical lenses must be carried out periodically to optimize light
output.
1. Use normal glass cleaner and a soft cloth to wipe down the
outside casing.
2. Clean the external optics with glass cleaner and a soft cloth
every 20 days.
3. Always be sure to dry all parts completely before plugging
the unit back in.
Cleaning frequency depends on the environment in which the fixture
operates (i.e. smoke, fog residue, dust, dew).
