ADLINK Technology PCIe-PXIe-8638 Series User manual

Leading EDGE COMPUTING
Manual Rev.: 2.1
Revision Date: Dec. 19, 2020
Part No: 50-17050-1010
PCIe-PXIe-8638 Series
ADLINK PXIe Extension Kit
User’s Manual

ii
Leading EDGE COMPUTING
Revision History
Revision Release Date Description of Change(s)
2.0 2014-12-29 Initial release
2.1 2020-12-19 Added PXIe-8638D/P models.

Preface iii
PCIe-PXIe-8638 Series
Preface
Copyright © 2020 ADLINK Technology Inc.
This document contains proprietary information protected by copy-
right. All rights are reserved. No part of this manual may be repro-
duced by any mechanical, electronic, or other means in any form
without prior written permission of the manufacturer.
Disclaimer
The information in this document is subject to change without prior
notice in order to improve reliability, design, and function and does
not represent a commitment on the part of the manufacturer.
In no event will the manufacturer be liable for direct, indirect,
special, incidental, or consequential damages arising out of the
use or inability to use the product or documentation, even if
advised of the possibility of such damages.
ADLINK is committed to fulfill its social responsi-
bility to global environmental preservation
through compliance with the European Union's
Restriction of Hazardous Substances (RoHS)
directive and Waste Electrical and Electronic
Equipment (WEEE) directive. Environmental
protection is a top priority for ADLINK. We have
enforced measures to ensure that our products,
manufacturing processes, components, and raw
materials have as little impact on the environment as possible.
When products are at their end of life, our customers are encour-
aged to dispose of them in accordance with the product disposal
and/or recovery programs prescribed by their nation or company.
Battery Labels (for products with battery)
ᘄ㟁ụㄳᅇᨲ

iv Preface
Leading EDGE COMPUTING
California Proposition 65 Warning
WARNING: This product can expose you to chemicals
including acrylamide, arsenic, benzene, cadmium,
Tris(1,3-dichloro-2-propyl)phosphate (TDCPP), 1,4-Diox-
ane, formaldehyde, lead, DEHP, styrene, DINP, BBP, PVC, and
vinyl materials, which are known to the State of California to cause
cancer, and acrylamide, benzene, cadmium, lead, mercury,
phthalates, toluene, DEHP, DIDP, DnHP, DBP, BBP, PVC, and
vinyl materials, which are known to the State of California to cause
birth defects or other reproductive harm. For more information go
to www.P65Warnings.ca.gov.
Trademarks
Product names mentioned herein are used for identification pur-
poses only and may be trademarks and/or registered trademarks
of their respective companies.
Conventions
Take note of the following conventions used throughout this
manual to make sure that users perform certain tasks and
instructions properly.
NOTE:
NOTE:
Additional information, aids, and tips that help users perform
tasks.
CAUTION:
Information to prevent minor physical injury, component dam-
age, data loss, and/or program corruption when trying to com-
plete a task.
WARNING:
Information to prevent serious physical injury, component
damage, data loss, and/or program corruption when trying to
complete a specific task.

v
PCIe-PXIe-8638 Series
Table of Contents
Preface.................................................................................... iii
List of Figures....................................................................... vii
List of Tables.......................................................................... ix
1 Introduction ........................................................................ 1
1.1 Controlling a PXI Express System via PCI Express............ 1
1.2 Specifications....................................................................... 2
1.3 Features............................................................................... 3
1.4 Ordering Options ................................................................. 4
1.5 Applications ......................................................................... 4
1.6 PXI Platform Services Installation........................................ 5
2 Getting Started ................................................................... 7
2.1 PCIe-PXIe-8638 Kit Package Contents............................... 7
2.2 Installation Environment ...................................................... 7
2.3 Installing the PCIe-8638 on a Host Computer..................... 8
2.4 PXIe-8638 Series to PXIe Chassis Installation.................. 10
2.4.1 PXIe-8638/D to PXIe Chassis Installation................10
2.4.2 PXIe-8638P to PXIe Chassis Installation .................11
2.5 Cabling the Host Computer to a PXI Chassis.................... 12
2.6 Configuration Block Diagrams........................................... 14
2.6.1 PC to PXIe Chassis..................................................14
2.6.2 PC to PXIe Chassis (Star Topology)........................15
2.6.3 PC to PXIe Chassis (Daisy Chain Topology) ...........16
2.6.4 PXIe to PXIe Chassis Connection............................17
2.7 Power On/Off Sequence.................................................... 18

vi
Leading EDGE COMPUTING
3 Hardware Information...................................................... 19
3.1 PCIe-8638 Layout, Connectors and Jumpers.................... 19
3.2 PXIe-8638(D/P) Layout, Connectors and Jumpers............ 20
A Appendix: Troubleshooting (FAQ).................................. 23
Important Safety Instructions.............................................. 27
Getting Service..................................................................... 29

List of Figures vii
PCIe-PXIe-8638 Series
List of Figures
Figure 2-1: PCIe-8638 to Host PC Installation...................................9
Figure 2-2: PXIe-8638(D) to PXI™ Chassis Installation Diagram....10
Figure 2-3: PXIe-8638D/P to PXI Chassis Installation Diagram ......11
Figure 2-4: PCIe x8 Cable Assembly...............................................12
Figure 2-5: PC to PXIe Chassis.......................................................14
Figure 2-6: PC to PXIe Chassis Block Diagram...............................14
Figure 2-7: PC to PXIe Chassis (Star Topology) .............................15
Figure 2-8: PC to PXIe Block Diagram (Star Topology)...................15
Figure 2-9: PC to PXIe Chassis (Daisy Chain Topology).................16
Figure 2-10: PC to PXIe Block Diagram (Daisy Chain Topology)......16
Figure 2-11: PXIe to PXIe Chassis Connection.................................17
Figure 2-12: PXIe to PXIe Chassis Connection Block Diagram.........17
Figure 3-1: PCIe-8638 Mechanical Layout.......................................19
Figure 3-2: PXIe-8638 Mechanical Layout.......................................20
Figure 3-3: PXIe-8638D Mechanical Layout....................................20
Figure 3-4: PXIe-8638P Mechanical Layout ....................................21
Figure A-1: Bus Number Information Result.....................................24

viii List of Figures
Leading EDGE COMPUTING
This page intentionally left blank.

List of Tables ix
PCIe-PXIe-8638 Series
List of Tables
Table 1-1: Model Specifications........................................................3
Table 1-2: PXIe-8638 Series Power Consumption...........................3
Table 1-3: Ordering Options .............................................................4
Table 2-1: PCIe-8638 to Host PC Installation Legend......................9
Table 3-1: PCIe-8638 Mechanical Layout Legend..........................19
Table 3-2: PCIe-8638 Connectors, Switches, and LEDs................19
Table 3-3: PXIe-8638 Series Connectors and LEDs ......................21
Table A-1: PCI Bus Number Requirements ....................................24

x List of Tables
Leading EDGE COMPUTING
This page intentionally left blank.

Introduction 1
PCIe-PXIe-8638 Series
1 Introduction
The PCIe-PXIe-8638 PCI Express to PXI Express extension kit pro-
vides control of PXI Express modules installed in a PXIe chassis
using high bandwidth PCI Express technology. The extension kit
provides up to 4GB/s bandwidth using PCIe x8 Gen2 signaling. With
comprehensive hardware and software transparency, the extension
kit enables fast and convenient detection of any PXI modules
installed in the system, requiring no additional drivers or software.
The host PC may be separated from the PXI Express chassis by
up to five meters using high-quality shielded twisted copper
cables. The robust and reliable PCIe to PXIe Extension Kit is
suited for test and measurement applications with high-density I/O
requirements and can be used in hazardous industrial control and
automation environments.
The dual port PXIe-8638D provides the capability of multi-chassis
control in a daisy chain configuration with the upper port connected
to a PCIe-8638 installed in a host PC, or PXIe-8638D/PXIe-8638P
in a PXI Express chassis, and the lower port connected to another
PXIe-8638 or PXIe-8638D in subsequent chassis.
The PXIe-8638P supports multi-chassis expansion in a daisy or
star chain configuration. A PXIe-8638P in a peripheral slot can
connect to another chassis with a PXIe-8638 or PXIe-8638D to
establish multi-chassis control.
1.1 Controlling a PXI Express System via PCI
Express
Based on PCI Express technology, the PCIe to PXIe Extension Kit
provides bus extension capability through a high-speed differential
signal interface.
The PCIe-PXIe-8638 PCI Express-to-PXI Express expansion kit
provides additional PXI instrument slots to the host computer by
implementing PCI Express-based control of PXI modules. The
technology consists of a PCIe-8638 host adapter installed in the
host computer, a PCIe x8 cable, and a PXIe-8638 remote controller
with the 3U (Eurocard) expansion module. The PCIe-8638 comes
with a PCI Express x8 interface and a PCIe x8 cable connector.

2 Introduction
Leading EDGE COMPUTING
1.2 Specifications
PCIe-8638 PXIe-8638 PXIe-8638D PXIe-8638P
Format Low Profile Standard Profile
Compliance
PCI Express
Base
Specifications
Rev. 2.0
PXI-5 PXI Express Hardware Specification
Rev. 2.0
Dimensions
Low-profile
PCI Express
module
142(W) x
69(H) mm
PXI Express system module:
175 mm (W) x 107 mm (H)
PXIe
Peripheral
Module
175 mm (W) x
107 mm (H)
Up-Link Port To Host PC PCIe: PCIe
Gen2 x8 External Port: PCIe Gen2 x8
To PXIe
chassis
backplane:
PCIe Gen2 x8
Down-Link
Port External Port: PCIe Gen2 x8
To PXIe
chassis
backplane:
PCIe Gen2
Four-link
configuration:
x4 x4 x4 x4
Two-link
configuration:
x8 x16
To PXIe
chassis
backplane:
PCIe Gen2
Four-link
configuration:
x4 x4 x4 x4
Two-link
configuration:
x8 x16
External Port:
PCIe Gen2 x8
External Port:
PCIe Gen2 x8
PXI Express
Link Capability N/A Four-link configuration: x4 x4 x4 x4 Two-link configuration: x16 x8
Data
Bandwidth
(max) 4GB/s (PCIe x8 Gen2)
Power
Consumption 4W (typical) 8W (max.) Refer to Table 1.2

Introduction 3
PCIe-PXIe-8638 Series
Table 1-1: Model Specifications
Table 1-2: PXIe-8638 Series Power Consumption
1.3 Features
XPXI-5 PXI Express hardware specification Rev. 2.0
XPCI Express® Base Specifications Rev. 2.0
XMaximum system throughput 4 GB/s
XPXI Express system slot link capability:
ZFour-link configuration: x4 x4 x4 x4
ZTwo-link configuration: x16 x8
XExpansion up to 5m (expansion cables at 2 or 5m)
XComprehensive hardware and software transparency
Cable Length Up to 5 meters for Gen2
Operating
Temperature 0°C to 55°C
Storage
Temperature -20°C to 70°C
Relative
Humidity 10% to 90%, non-condensing
Power Rail 12 V 3.3 V
Typical Current 0.85 A 1.3 A
Maximum Current 1.7 A 2.6 A
CAUTION:
Insertion loss in sockets and accessory cable connectors may
increase after frequent multiple insertions/removals, degrading
signal integrity of high speed PCI Express transmission. For
each PCIe-PXIe-8638 socket or accessory cable connector,
more than 200 connections/disconnections can impede func-
tionality and performance.
PCIe-8638 PXIe-8638 PXIe-8638D PXIe-8638P

4 Introduction
Leading EDGE COMPUTING
1.4 Ordering Options
Table 1-3: Ordering Options
1.5 Applications
These extension kits are suitable for:
XElectronics manufacturing testing
XHigh-density I/O systems
XIndustrial automation and control
XMilitary and aerospace
XTesting systems for remote and/or harsh environments
XVideo capture
Product Description
PCIe-PXIe-8638/2M PXIe remote controller kit. PCIe-8638,
PXIe-8638, and 2m cable.
PCIe-PXIe-8638/5M PXIe remote controller kit. PCIe-8638,
PXIe-8638, and 5m cable.
PCIe-PXIe-8638D/2M PXIe remote controller kit. PCIe-8638,
PXIe-8638D, and 2m cable.
PCIe-PXIe-8638D/5M PXIe remote controller kit. PCIe-8638,
PXIe-8638D, and 5m cable.
PCIe-8638 PCIe x8 host adapter for PCIe-to-PXIe
cable extension.
PXIe-8638 PXIe remote controller for PCIe-to-PXIe
cable extension.
PXIe-8638D PXIe remote controller for PCIe-to-PXIe
cable extension, dual ports.
PXIe-8638P PXIe peripheral module for PCIe-to-PXIe
cable extension.
2m Cable for PCIe/PXIe-8638
SAS 2*4 Cable Assembly 2m PCIe x8 cable
5m PCIe x8 Cable for
PCIe/PXIe-8638 5m PCIe x8 cable

Introduction 5
PCIe-PXIe-8638 Series
1.6 PXI Platform Services Installation
It is recommended that ADLINK PXI Platform Services be down-
loaded and installed prior to operation. See the ADLINK PXI Plat-
form Services User’s Manual for more details.

6 Introduction
Leading EDGE COMPUTING
This page intentionally left blank.

Getting Started 7
PCIe-PXIe-8638 Series
2 Getting Started
2.1 PCIe-PXIe-8638 Kit Package Contents
XPCI-8638 (PCI Express x8 host adapter for extension kit)
XPXIe-8638 Series (PXI Express remote controller)
XPCI Express x8 cable assembly (2 or 5m)
XQuick Start Guide
2.2 Installation Environment
Whenever unpacking and preparing to install any equipment
described in this manual, refer to the Appendix B, Important
Safety Instructions:.
Install equipment in well lit areas on flat, sturdy surfaces with
access to basic tools such as flat and cross-head screwdrivers.
The PCIe to PXIe Extension Kit contains several electrostatic sensi-
tive components that can be easily damaged by static electricity.
For this reason, the modules and chassis should be handled on a
grounded anti-static mat and the operator should wear an anti-static
wristband during the unpacking and installation procedure.
Inspect the components for any damage. Improper shipping and
handling may cause damage to the components. Be sure there is no
damage to the components before continuing with the installation.
NOTE:
NOTE:
Diagrams and images of equipment are for reference only. The
actual system appearance may vary.
NOTE:
NOTE:
If any of the items in the contents list are missing or damaged,
contact your ADLINK dealer.

8 Getting Started
Leading EDGE COMPUTING
2.3 Installing the PCIe-8638 on a Host Computer
1. Power-off the host computer.
2. Unscrew the housing of the host computer using a
(cross-head or flat-head) screwdriver. Open the housing.
3. Locate the PCI Express®extension module (PCIe-8638)
and remove it from its packaging. (Wear anti-static
gloves and use an anti-static surface when handling the
module).
4. Install the PCIe-8638 in an available x8 or x16 PCI
Express slot in the host computer. Be sure to firmly
attach the PCIe-8638’s bracket to the backplane of the
host PC.
5. Close the chassis and re-install the housing screws.
CAUTION:
Do not apply power to damaged equipment.

Getting Started 9
PCIe-PXIe-8638 Series
Figure 2-1: PCIe-8638 to Host PC Installation
Table 2-1: PCIe-8638 to Host PC Installation Legend
Item Description
A Industrial or desktop PC with PCI Express x8 slot
B PCIe-8638 (PCI Express host module)
C PCI Express x8 slot
A
B
C

10 Getting Started
Leading EDGE COMPUTING
2.4 PXIe-8638 Series to PXIe Chassis Installation
2.4.1 PXIe-8638/D to PXIe Chassis Installation
1. Remove the cover panel of the system slot.
2. Locate the PXIe-8638/PXIe-8638D and remove it from
its packaging. (Wear anti-static gloves and use an
anti-static surface when handling the module).
3. Insert the PXIe-8638/PXIe-8638D into the system slot
and tighten the bracket-retaining screws on the top and
bottom of the panel to fasten the PXIe-8638/PXIe-8638D
to the chassis.
Figure 2-2: PXIe-8638(D) to PXI™ Chassis Installation Diagram
WARNING:
The PXIe-8638/PXIe-8638D must be installed into the PXI™
system slot. Peripheral slots must not be used.
