Wyrestorm EXP-HDMI-H2-3M User manual

IMPORTANT! Installation Requirements
• Visit the product page to download the latest rmware, document version,
additional documentation, and conguration tools.
• Read through the Wiring and Connections section for important guidelines
before creating or choosing premade cables.
In The Box
1x WyreStorm EXP-HDMI-H2-xM
Basic Wiring Diagram
Copyright © 2019 WyreStorm Technologies | wyrestorm.com
EXP-HDMI-H2-xM Quickstart Guide | 191021
UK: [phone] | ROW: 844.280.WYRE (9973)
[email protected]
1 of 2
WyreStorm recommends reading through this document in its entirety to become familiar with the product’s features prior to starting the installation
process.
4K HDR 4:4:4 60Hz HDMI Cable with CL3 Rating
EXP-HDMI-H2-xM Quickstart Guide

Wiring and Connections
WyreStorm recommends that all wiring for the installation is run and terminated prior to making connections to the switcher. Read through this section in its
entirety before running or terminating the wires to ensure proper operation and to avoid damaging equipment.
IMPORTANT! HDMI Wiring Guidelines
• The use of patch panels, wall plates, cable extenders, kinks in cables, and electrical or environmental interference will have an adverse effect on HDMI
transmission limiting performance. Steps should be taken to minimize or remove these factors completely during installation for best results.
Installation and Operation
1. Connect an HDMI source to one end of the HDMI cable.
2. Connect an HDMI display device to the other end of the HDMI cable.
Troubleshooting
No or Poor Quality Picture (snow or noisy image)
• Verify that all HDMI connections are not loose and are functioning properly.
Troubleshooting Tips:
• WyreStorm recommends using a cable tester or connecting the cable to other devices to verify functionality.
Copyright © 2019 WyreStorm Technologies | wyrestorm.com
EXP-HDMI-H2-xM Quickstart Guide | 191021
UK: [phone] | ROW: 844.280.WYRE (9973)
[email protected]
2 of 2
Specications
Note: WyreStorm reserves the right to change product specication, appearance or dimensions of this product at any time without prior notice.
Audio and Video
Inputs 1x HDMI In: 19-pin type A
Outputs 1x HDMI Out: 19-pin type A
Output Video Encoding Uncompressed
Encoding Data Rate 18Gbps
End to End Latency Zero
Audio Formats 2ch PCM | Multichannel: LPCM and Up to DTS-X and Dolby Atmos
Video Resolutions (Max)
1920x1080p @240Hz 8bit RGB
2560x1440p @120Hz 8bit RGB
4096x2160p @60Hz 10bit HDR 4:2:0
4096x2160p @60Hz 12bit HDR 4:2:2
4096x2160p @60Hz 10bit HDR 4:4:4
4096x2160p @60Hz 10bit RGB
Supported Standards DCI | RGB | HDR | HDR10 | Dolby Vision up to 30Hz | HLG | BT.2020 | BT.2100
Maximum Pixel Clock 600MHz
Communication and Control
HDMI TMDS | HDCP 2.2 | EDID
Supported Features Ethernet | Audio Return Channel (ARC) | CEC Auto Low Latency Mode (ALLM) | Variable Refresh Rate (VRR)
Environmental
Operating Temperature 32°F ~ 113°F (0°C ~ 45°C) | 10% ~ 90%, non-condensing
Storage Temperature -4°F to ~ 158°F (-20°C ~ +70°C) | 10% ~ 90%, non-condensing
Maximum BTU N/A
Dimensions and Weight
Cable Length 0.5m/1.6ft | 1.0m/3.2ft | 2.0m/6.4ft | 3.0m/9.6ft | 5.0m/16ft
Weight 0.05kg/0.11lbs | 0.09kg/0.19lbs | 0.14kg/0.30lbs | 0.22kg/0.48lbs | 0.35kg/0.77lbs
Regulatory
Safety and Emission CE | FCC | RoHS
