BZB Gear BG-DA-1X8C50M User manual

1/ 11
BG-DA-1X8C50M
HDMI Splitter 1x8
Over CAT5E/CAT6 50m

2/ 11
Thank you for purchasing this product
For optimum performance and safety, please read these instructions carefully
before connecting, operating or adjusting this product. Please keep this
manual for future reference.
Surge protection device recommended
This product contains sensitive electrical components that may be damaged
by electrical spikes, surges, electric shock, lightning strikes, etc. Use of surge
protection systems is highly recommended in order to protect and extend the
service life of your equipment.
Table of Contents
1. Introduction..................................................................................................................... 3
2. Features ...........................................................................................................................3
3. Package Contents ........................................................................................................3
4. Specifications .................................................................................................................4
5. Operation Controls and Functions.............................................................................4
5.1 Splitter ..........................................................................................................................4
5.2 Receiver ......................................................................................................................5
6. Connection Diagram....................................................................................................9
7. Warranty ........................................................................................................................ 10
8. Mission Statement........................................................................................................ 11

3/ 11
1. Introduction
The Splitter is a product for splitting and extending your HDMI signal over long
distances to a compatible display. It is designed to convert the HDMI signal
and transmit by Internet cable. The splitter supports resolutions up to
1080p@60Hz, and supports smart EDID management.
2. Features
Compliant with HDMI1.3, HDCP 1.2 and DVI 1.0.
Full HD support: 1080p@60Hz@24 bit/pixels.
Supports LPCM 7.1CH, Dolby True HD, and DTS-HD Master Audio.
Operates for TMDS clock frequencies up to 148.5MHz.
Support Power over cable function.
Use single UTP LAN cable (CAT5E/6) to substitute HDMI cable to achieve
long distances transmission.
UTP cable termination follows the standard of IEEE-568B.
Supports EDID control via EDID selector.
3. Package Contents
HDMI Splitter -------------------------------------------------------1PCS
Receiver -------------------------------------------------------------8PCS
12V2.5A DC Power Supply adapter --------------------------1PCS
Wideband IR Tx cable--------------------------------------------1PCS
Wideband IR Rx cable--------------------------------------------8PCS
Operation Manual -------------------------------------------------1PCS
Mounting ears--------------------------------------------------------2pcs

4/ 11
4. Specifications
Technical
Maximum Pixel Clock
165 MHz
Supports video resolutions
up to
1080p@60Hz
ESD Protection
Human body model —±8kV (air-gap discharge) &
±4kV (contact discharge)
Power Supply
DC 12V 2.5A
HDMI Splitter
Input Ports
1x HDMI, 1xMini USB
Output Ports
1xHDMI, 8xRJ45, 1xIR out
Receiver
Input Ports
1xRJ45, 1x IR in
Output Ports
1x HDMI
Mechanical
Dimensions (mm)
295(W) X 83 (D) X 17 (H)
Weight
HDMI Splitter: 720g
Receiver: 8 x 131g
Operating Temperature
0°C ~ 40°C / 32°F ~ 104°F
Storage Temperature
-20°C ~ 60°C / -4°F ~ 140°F
Relative Humidity
20~90% RH (Non-condensing)
Power Consumption (Max)
15W
5. Operation Controls and Functions
5.1 Splitter
POWER LED: This red LED will illuminate when the device is connected
with power supply.
CAT OUT1-OUT8: Eight RJ45 ports provide signal output.

5/ 11
HDMI OUT: Local HDMI loop output port.
HDMI IN: HDMI Input port. Connect source with HDMI cable.
IR OUT: Connect the IR Blaster cable included in the package for IR
signal transmission. Pace the IR blaster in direct line-of-sight of the
equipment to be controlled.
EDID: Select output signal format via EDID Selector.
※See the description 1
UPDATE: System software update.
DC12V: Plug the 12V2.5A DC power supply into the unit.
POWER OFF/ON: Power ON\OFF Switch.
5.2 Receiver
EQ switcher: HDMI Receiver equalizer switcher.
※See the description 2
HDMI out: This slot is to connect the HDMI input port of your display such
as an HDTV.
IR In: Connect to the IR Receiver for IR signal reception. Ensure that
remote being used is within the direct line-of-sight of the IR receiver.
Power LED: This LED will illuminate when the device is connected with
power supply.
CAT: Connect the CAT input of the receiver with the CAT output of the
transmitter with CAT5E/6 cable.
Lock LED: This LED will illuminate when the HDMI signal from the
transmitter is stable.

6/ 11
※See the description 1
EDID Control
Under normal circumstances, a source device (digital and analog) will require
information about a connected device/display to assess what resolutions and
features are available. The source can then cater its output to send only
resolutions and features that are compatible with the attached device/display.
This information is called EDID (Extended Display Information Data) and a
source device can only accept and read one EDID from a connected
device/display. Likewise, the source could only output one resolution to
connected device/display.
The EDID switch allows for EDID learning or to pre-set an EDID to encourage
a “handshake” between the display and source.
Manual EDID Learning Mode
When you switch to any number of“0-8”,the
Transmitter will set a fixed EDID to the source. The
detail EDID description, please refer to the EDID
table.
Auto EDID Learning Mode
When you switch to “9”, the Transmitter will copy the HDMI LOOP OUT port
display EDID to source.
Attention: Please confirm the extender is work normally, when you want to
modify the new EDID to source, toggle the EDID switcher to the corresponding
number first, then plug the Transmitter power again. The extender will send the
new EDID to source.

7/ 11
EDID TABLE:
Position
EDID Description
1080p, 2CH AUDIO
1080p, DOLBY/DTS 5.1
1080p, HD AUDIO
1080i, 2CH AUDIO
1080i, DOLBY/DTS 5.1
1080i, HD AUDIO
3D,1080p, 2CH AUDIO
3D, 1080p,DOLBY/DTS 5.1
3D,1080p, HD AUDIO
Copy EDID from the Transmitter HDMI loop out
1080p, 2CH AUDIO
1080p, 2CH AUDIO
1080i, 2CH AUDIO
1080i, 2CH AUDIO
1080i, 2CH AUDIO
1080i, 2CH AUDIO
※See the description 2
RX Equalizer distance adjust
If you find flickering or blinking image on the display, adjust the EQ switch to
improve the cable skew. MAX stands for the strongest HDMI signal level for
the longest possible transmission length while MIN stands for the weakest
HDMI signal level for short transmission length. Adjust the signal level from

8/ 11
MIN to MAX until ideal video quality displayed.
Wideband IR (30KHz---60KHz) introduction
IR Cable Pin Assignment
Control local device (Blu-ray player or DVD player, etc.) from remote: The IR
Receiver is connected to the receiver IR in port. The CAT output connector on
the HDMI Splitter is connected via CAT6 cable to an HDMI receiver. The IR
Transmitter is connected to the HDMI Splitter IR OUT port.
IR remote can be used to control local source device from remote.
Recommended EQ setting
Position
Cable Length
under 15m (49.5ft)
15-30m (49.5 ft - 99ft)
30-40m (99ft - 132ft)
40-50m( 132ft –164ft)

9/ 11
6. Connection Diagram
1.Connect a source such as a Blu-Ray Player, game console, A/V Receiver,
Cable or Satellite Receiver, etc. to the HDMI input on the Transmitting unit.
2. Connect a display such as an` HDTV or HD Projector to the HDMI output on
the Receiving unit.
3. Connect a single Cat5e/6 up to 164ft/50m to the output of the Transmitting
unit, and the other end to the input of the Receiving unit.
4. Connect the DC 12V Locking power supply to the power receptacle on the
splitter.
5. Connect the power supply to an available electrical outlet.

10 / 11
