jbc TM20 User manual

TM20
ESD Spiral Earthing Cable
INSTRUCTION MANUAL

Packing List
The following items are included:
Manual ................................................. 1 unit
Ref. 0031821
This manual corresponds to the following reference:
TM20
Application
To equip an EPA (Electrostatic Protected Area) workplace, it can be used, among other items, an ESD
spiral earthing cable.
These components help to protect static-sensitive components from electrostatic discharge by
dissipating charge from objects placed on their surface. This prevents sensitive components from being
damaged by electrostatic discharges.
ESD
Spiral Earthing Cable .............................. 1 unit
Features
The spiral earthing cable has a length of
2.4m  /94.49 in and is made out of a highly
elastic material that allows the user great
freedom of movement when working.
It comes in black color and with 2 snap fasteners
- one with a ø10mm (female) connector and
the other with ø3mm (female) connector.
The electrical resistance is 106 Ω at each
connector.
ø10mm Snap Fastener
ø3mm Snap Fastener
2

* not included, sold separately
TMS or
TMB
Table Mat ESD
TM21
Earthing Cable
TM20
ESD Spiral
Earthing Cable
TM50
ESD Earthing Wristband
ø10mm
Snap Fastener
Connection
ø3mm
Snap Fastener
Connection
Eyelet
Connection
ø10mm
Snap Fastener
Connection
Earth Connection or
Grounded Common
Point
TM10
ESD
Earting Plug
Alternative
Connection
*
*
*
*
*
In order to function correctly, connect the ø3mm snap fastener to the ESD earthing wristband and
the ø10mm snap fastener to the ESD table mat connector (or directly to the grounded common
point).
The following matching accessories are sold separately: an ESD table mat, an ESD earthing
wristband, an ESD earthing cable and an ESD earthing plug.
Workplace Connection Example
3
40 mm
50 mm
60 mm
80 mm
100 mm
130 mm 130 mm
para manuales - color gris
200 mm
300 mm

This product should not be thrown in the garbage.
In accordance with the European directive 2012/19/EU, electronic equipment at the end of its life must
be collected and returned to an authorized recycling facility.
Warranty
JBC’s 2 year warranty covers this equipment against
all manufacturing defects, including the replacement
of defective parts and labour.
Warranty does not cover product wear or misuse.
In order for the warranty to be valid, equipment must
be returned, postage paid, to the dealer where it was
purchased.
40 mm
50 mm
60 mm
80 mm
100 mm
130 mm 130 mm
para manuales - color gris
200 mm
300 mm
00 31821-270 923
TM20
ESD Spiral Earthing Cable
Ref.: TM20
- Tested according to: BGI 818: 2001
- Connections: ø10mm snap fastener (1x) and ø3mm snap fastener (1x)
- Length: 2.5 m / 98.43in
- Color: Black
- Electrical resistance: 106Ω
- Total Net Weight: 29 g / 0.06 lb
- Package Dimensions/Weight: 81 x 43 x 114mm / 48 g
(L x W x H) 3.19 x 1.69 x 4.49in / 0.11 lb
Complies with CE standards.
ESD Safe.
Specifications
