ADO MTB Series User manual

Attention!
Please keep the instruction manual properly!
To ensure your safety, please read the
instruction manual carefully before using
the electric bicycle to better understand the
performance of the electric bicycle.
ADO EBIKE
MTB Series User Manual

Applicable Document
Before using the bicycle, please read and follow this manual and all other applicable documents.
The manufacturer’s documents contain additional information and illustrations about bicycle components,
which are also a part of this User Manual. Please keep them properly together with this User Manual and
present them while selling or distributing the bicycle.
The risk of injury may be caused by violation of regulations of relevant documents.
Unpacking and Open-box Inspection
Open the box.
Take the bicycle out of the box.
Take the battery charger out of the box.
Take two keys used to dismount the batteries out of the box.
Inspect assembly list and follow the "Quick Installation Guide " to install
Prevent children from playing with packing film in order to avoid suffocation.
Dispose of packing materials according to local instructions and regulations.
A26 Bicycle and Components
01
1
2
3
4
5
6
78910 11
12
13
14
15
16
English

Brake crank
Instrument
bell switch
Front light
Front disc brake
Battery cartridge
Controller
Folding pedal
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
Kickstand
Rear disc brake
Motor
Rear gearbox
Saddle tube quick release
Saddle
Lighting switch
Shift Lever set
A26 Display Specification
D30 Display Specification
1.In shutdown state, long press Power key for 3 second to start the ebike;
2.In the power on state, Long press Power key for 3 second to off the ebike;
3.In the power-on state, press POWER KEY, the multi-function area will display ODO, VOL, TRIP, TIME.
ODO: The total mileage of this bicycle when it is turned on
VOL: Current battery voltage value display
TRIP: Mileage traveled after this start
TIME: The time since the start of this ride
4. Press the “+” button to increase the gear. The higher the gear, the faster the speed.
5. Press the “-” button to lower the gear. The lower the gear, the slower the speed.
Power key
Battery power display
Speed display
Assist gear display
Assist gear
adjustment
Multifunctional display area
SPEED
km/h
km
Power key
Battery power display
Long press to turn
on the front light
Speed display
Assist gear display
Assist gear
adjustment
Multifunctional display area
USB charging port
02
CUR
Km/h
PAS
%
SPEED
S830
Km

D30 Bicycle and Components
03
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
Rear disc brake
Motor
Rear gearbox
Saddle tube quick release
Saddle
Damping switch
Shift Lever set
bell
Brake crank
Instrument
Switch
Front light
Front disc brake
Battery cartridge
Pedal
Kickstand
1
2
3
4
5
6
7
8910 11
12
13
14
15
16

The power-assisted system should be furnished with batteries, which are installed in the
frame.
The batteries can be removed using the key and charged. Only the charger attached can be
used to charge the batteries.
Like most large batteries, lithium ion battery is a hazardous substance according to
transportation regulations. The bicycle cannot be transported before the battery pack is
installed. For air transportation, regulations on hazardous substances should prevail.
(Please comply with local transportation regulations)
The packing box of battery pack must be marked with Danger during transportation.
Battery pack
Controller
The bicycle is furnished with a controller to adjust the power, which is controlled using the
handlebar. The power of the controller is calculated according to preset speed, actual speed
and pedal stress. The maximum speed is 25km/h. Power is not supplied above the
maximum speed.
The bicycle is furnished with gearbox.
Meaning of the following terms is as follows:
1.Down shift means to shift to a lower gear so that it is easier to step on the pedal.
2.Up shift means to shift to a higher gear so that it is hard to step on the pedal.
The gearbox consists of the following parts:
1.The gear box or threaded chain wheel on the rear wheel
2.Rear gearbox
3.Tray/chain ring
4.Drive/driven chain
5.Shift level/gear lever
The gearbox shifts gears on the condition that the drive chain moves forward and is at least at tense state.
The user can select a suitable gear as appropriate.
The brake is used not only to stop the bicycle but also to control the speed. The maximum braking force of
the tires refers to the stress when the tires are “locked” (do not rotate) and slide. In case of tire slip, most
braking force will be lost and the bicycle will be out of control. Please brake gently and stop the bicycle
slowly, namely progressive braking skill, to prevent the tires from being locked.
1.Push the brake to the handlebar to increase the braking force gradually.
2.If the wheels are stuck, please release the brake so that the wheels can rotate and are not stuck.
Brake
Power-on or Power-off
Please turn on the display as follows:
Press and hold “ ” for about 3s.
Please turn off the display as follows:
Press and hold “ ” again for about 3s.
Motor
The motor of the bicycle directly acts on the rear wheel and helps the user step on the pedal. The user can
adjust the power of the motor using existing control system and select different grades of riding. The motor
enables the maximum speed of 25km/h.
Gearbox
The pedal is installed at the end of the two cranks. Step on the pedal and the chain rotates to drive the
chain wheel.
The folding bicycle is furnished with two folding pedals easy to fold and transport.
Pedal
04 8

DescriptionNo. DescriptionNo.
Brake cable
Adjust screw of brake
Brake arm
Locking screw of brake
Brake lining
Brake disc
Brake System
The brake is installed on the front wheel and the rear wheel. The disc brake block acts on the disc to slow down.
The brake disc will be worn and is controlled by the handlebar. The disc brake is a mechanical drive.
05
I.Adjustment of front and rear brake system: (the adjustment method of front and rear brakes is the same)
1.The rear integrated disc brake(see figure 1); Adjust the upper and lower nuts of the disc brake to make the
spacing between disc brake and brake caliper 1.5-3mm, adjust the height of disc brake, and then tighten the
nuts.
2.Front integrated disc brake (see figure 2): Adjust the A and B nuts of the disc brake and adjust the height of the
disc brake so that the distance between the disc brake and the caliper is 1.5-3mm. If the distance is deviated,
use the C screw to adjust, and then tighten the nut.
Rotate the Adjusting nut to rotate the Adjusting nut forward, the brake becomes tight, otherwise it becomes loose.
When adjusting, hold the brake handle at the same time, so that when the position of the brake handle is 1/3 of
the total stroke, the brake rubber block can be tightly attached to the brake drum.
3.Disc brake: (see Figure 3 and 4)
Key points of disc brake adjustment: there is enough clearance between disc brake and brake pad (there is no
interference between the brake disc and the brake skin when rotating, and the best braking effect is appropriate)
adjust the nut, lengthen about brake cable, check whether the brake handle has been adjusted to the appropriate
tightness; Then test ride to ensure effective and normal braking.
Note: To ensure driving safety, brake rubber the working face is worn to 1/2 of brake rubber, a new brake
rubber should be replaced.
ABC
1 2 3 4

The batteries may explode if a wrong charger is used and consequently severe injury or death may be caused.
Only the charger attached can be used.
Read and comply with the instructions in the charger specification.
The batteries should be charged at a temperature of 10-45℃.
Please charge the batteries as follows:
1.Take out the battery or charge it directly in the bicycle.
2.Ensure no damage of battery case and other visible damages.
3.Please charge the batteries on the surface of non-flammable objects,
4.Comply with the instructions in the charger specification (if contained).
5.Insert the charger plug into the socket on the batteries.
6.Insert the charger plug into a 110V-230V and 50Hz power socket and the light on the charger will be red. It
takes 5-6 hours to charge the batteries. When the light turns green, it means that the batteries have been fully
charged.
7.Remove the plug from the socket.
8.Remove the plug from the battery socket.
9.Reinstall the batteries.
Please be sure to inspect fixation of bicycle, brake, tire and screw/nut before riding.
Ensure all brake cables are connected well and the torque should be 8-10N.m.
After the wheel is loosened, please adjust it according to the recommended torque. The locking torque of the
rear wheel should be no less than 30N.m and that of the front wheel should be no less than 25N.m.
1.The user can identify the permissible inflation pressure range on the side wall of the tires. Test inflation
pressure of the tires.
2.Foot pump with pressure gage/pressure meter is recommended to inspect and correct tire pressure.
Tire Pressure Inspection
1.The batteries have been fully charged
2.The brake, chain guard and fender work normally
3.The handlebar is connected securely and adjusted properly
4.The saddle is connected securely and adjusted properly
5.The pedals are connected securely
6.The wheels are connected securely
7.The tires are connected securely
8.Tire pressure is correct
9.The lights are normal and are adjusted properly
10.The circuits are normal and are adjusted properly
11.The quick release screw, nut and operating lever are secure
Before Initial Riding
Battery Charging
Before riding, make sure that:
06

Saddle Adjustment
It is of great importance for safety to adjust the saddle correctly. The user can adjust height of the saddle freely.
Please inspect whether height of the saddle is adjusted correctly as follows:
1.Sit on the saddle
2.Keep being seated
3.Place a pedal downward
4.Put feet on the pedals
If your legs do not extend completely when your feet are put on the pedals, height of the saddle is adjusted
correctly.
Please adjust height of the saddle as follows:
Release and open the quick release seat post clamp.
Then, move the saddle up and down and adjust the height.
Adjust the saddle as needed.
Power Level Selection
During Riding
According to the selected power level, power exercise can help you step on the pedal.
Three power levels are optional:
gear1 gear2 gear3
Turn on the controller
Press “+” again to select a higher power level.
Press “-” again to select a lower power level.
Please be sure to wear a helmet consistent with the latest certification standard during riding. For adjustment,
use and maintenance of helmet, please refer to the manufacturer’s specification. Most severe injuries are
caused to the head during riding, which can be prevented through wearing a helmet.
According to regulations on release of road traffic permit, the following equipment is needed for riding a bicycle
safely on public roads:
1.A bell
2.Two independent brake systems
3.White front light
4.Front white reflector
5.red rear light
6.rear red reflector
7.Two yellow reflectors are installed on the spoke of every wheel with a deviation angle
8.of 180° or a white reflector is installed on the tire.
9.A yellow reflector is installed on the front and rear pedals.
The rider may fall down if the seat post is damaged and consequently severe injury may be caused.
Ensure the minimum insertion mark (minimum insertion amount) on the seat post is in the seat
tube and invisible.
Personal Protective Equipment
Severe injury or death may be caused during riding.
Please be sure to wear a certified helmet in riding, and adjust, use and maintain the helmet according to the
manufacturer’s manual.
1.Please be sure to wear secure shoes with non-slip soles (such as special-shaped rubber soles).
2.Please be sure to wear gloves.
3.Please be sure to wear tights to avoid being caught by the bicycle or objects on the road.
4.Please be sure to wear (transparent) dirtproof, dustproof and mothproof glasses.
5.Please be sure to wear sun glasses in sunny days.
07

1
2
3
4
5
6
7
Unpowered Riding
You can also use an unpowered bicycle. Turn off the power-assisted system and the bicycle is an unpowered
bicycle.
e.g.: When the batteries are exhausted.
If you have never ride a power-assisted bicycle, please get familiar with it in an open space. The
power device will be activated only after it is powered on and the rider is stepping on the pedal. It
may be a little uncomfortable in the beginning, but the rider will get used to it soon. The rider should
set on the saddle before stepping on the pedal.
Do daily exercise from the minimum level of riding, e.g.:
Stop stepping on the pedal and the power-assisted system will still provide power within a short time.
The power-assisted endurance mileage is determined by the following factors:
1.Starting
2.Accelerating
3.Braking
4.Turning a corner
1.Total weight of bicycle, rider and luggage
2.Speed control
3.Tire pressure
Power-assisted Riding
Troubleshooting
The display does not work
The green light of the
charger lights up, but the
batteries cannot be charged
Please be sure to connect
the charger to the batteries
and then insert it into the
socket in the wall
The batteries have been exhausted or
the bicycle is not connected to the
batteries
The batteries are not connected to
the charger correctly
It may be caused by adverse wind,
mountain road, rider’s weight, speed
adjustment and tire pressure
Please be sure to connect the charger to
the batteries and then insert it into the
socket in the wall
Ensure the batteries have been charged
and installed correctly. Ensure the batteries
have been locked in order to avoid
disconnection between the batteries and
the bicycle during riding
Problem Possible cause Solution
Know the gear level:
1.The gear has the same working principle as ordinary bicycle, which is unrelated to the motor.
2.The DIP shifter is installed on the right of the handlebar. Pull the “+”/ “-” handle to raise/lower the gear.
3.The lower the gear level is the more energy will be saved. Vice versa.
4.The gear level has been preset upon delivery and needs not be adjusted.
5.After used for a period of time (3 months), the shift cable will be extended and may need to be adjusted.
6.A local bicycle store or the exclusive shop of the electric bicycle can provide this service.
Gear Adjustment
08

The bicycle may fall off or slip off during transportation and consequently severe injury may be caused. The bicycle
should be protected from turning over, slipping off and falling off when transported by vehicles or public transportation
facilities.
Please transport the bicycle using certified luggage carrier.
If there is no luggage carrier, the bicycle must be placed in the trunk (it cannot be placed on the gearbox).
The design charging cycle of battery is about 500 times. After the batteries are charged for 500
times, the battery level will no longer reach 100% but about 60%. A charging cycle refers to that
the battery level increases from 0% to 100%. If the battery level increases from 99% to 100%, it is
not a complete charging cycle but only 1% of a complete charging cycle. Generally, a charging
cycle can last for more than two years.
When the battery level is 75%, the batteries can be stored for about three months. When the
battery level is 50%, the batteries can be stored for about two months.
In order not to reduce the service life of battery, please follow the steps below:
1.Charge the batteries when the battery level is 30%-50% after riding.
2.Ensure the batteries are not fully discharged.
It takes 5-8 hours (from 1%-100%) to charge the batteries after fully discharged.
To store the batteries for more than two months, please follow the steps below:
Take out the batteries.
Ensure no damage of battery case and other visible damages.
Charge the batteries before stored for a long time.
Store the batteries in a safe and dry place.
Store the batteries at a temperature of 5-20℃.
Prevent great temperature variation of battery.
Please do not store the batteries under sunlight or high temperature.
Please charge the batteries at least every two months.
Moisture, pollution or mechanical damage may cause short circuit and consequently a fire or battery explosion may be
caused.
Clean the motor and the controller using wet sponge from outside.
If the motor and the controller are immersed in water accidently, please pull out the plug immediately and disconnect
the motor and the battery. Consult the manufacturer before powering on the motor again.
Bicycle Maintenance and Repair
Battery Maintenance
Maintenance of Motor and Controller
Bicycle Transportation
Lubrication
Use light machine oil (20W)
Please remove dust before lubrication and remove lubricant after lubrication.
Part
Pedal
Chain
Underframe
Motor
Lubrication plan Recommend lubrication method
Every 6 months
Every 6 months
Every 6 months
Every 6 months
Contact professionals
Contact professionals
Apply 4 drops of machine oil to the joint between the pedal and the pedal spindle
Apply 1 drop of machine oil to every roller of the chain
While inflating the tires, please be sure to check the tire pressure.
Inflation Pressure
09

Please charge the batteries for 6-8 hours when the battery level decreases to 30%-50% in order to extend the
service life. If stored at a low battery level, the batteries will be exhausted and cannot be reused. Please
charge the battery pack fully after long-distance riding. Please do not charge the batteries for a long time
(namely “more than 10 hours”) in summer in order to avoid damage.
The batteries should be charged monthly during storage.
The charging temperature should be 10-45℃.
The battery pack may not be fully charged if the temperature is too high or too low.
The temperature may rise slightly when the batteries are charged, but it should be limited to 50℃. If the
indicator light of the charger remains unchanged or the batteries are very hot (the temperature is above 50℃)
after the batteries are fully charged, please consult the seller about maintenance immediately.
After the batteries are removed from the bicycle, try to reduce vibration and disturbance in order to avoid
damage. Keep the charger far away from water.
Every battery pack is designed with a charger. Please do not charge the battery pack using other types of
charger in order to avoid burn-out of batteries and danger thus incurred.
The batteries should be stored at a temperature of 0-45℃in a clean, cool, dry and well-ventilated place. The
batteries should be protected from sunlight, fire, flood and corrosive substance during transportation and
storage.
Please keep the button at the head of the battery holder at “ON” during charging.
Please ensure no short circuit of the socket in the wall in order to avoid burn-out of batteries and danger thus
incurred.
Please do not pull out the power key while riding at high speed.
Description of Battery Maintenance and Charging
Chain Tension
1.Please thoroughly read the chain tension adjustment manual attached for a detailed understanding of chain
tension adjustment.
2.Ensure to lubricate and clean the chain so that it functions well.
3.Chain tension should be adjusted correctly by qualified technical personnel.
4.Maintenance should be conducted especially in a humid or dusty environment.
5.Chain tension should be about 15mm.
6.While adjusting the chain, loosen the nut of the rear spindle, adjust the fastening screw of the chain and
tighten the screw of the rear spindle.
1.Ensure the inflating volume of the tires is limited to the recommended value indicated on the side wall of the
tires.
2.Ensure the tires have patterns and are free from bulge or excess wear.
3.Ensure the rims run normally and do not waggle or bend obviously.
4.Ensure all wheel spokes are secure and not broken.
5.Inspect whether the nut of the spindle is tightened. If the bicycle has a quick release spindle, please ensure
the locking lever is fastened and at OFF position.
Wheel Set Damage and Wear
10

Endurance Test
Wipe for 15s using a piece of cloth with water and then wise for 15s using a piece of cloth with benzoline.
1.Warning 1-Like all mechanical parts, the power-assisted bicycle will be affected by wear and high stress.
Different materials and parts may respond to wear or stress fatigue differently. If the design life of a part
expires, the part may break down suddenly and consequently the rider may be injured. Any form of crack,
scratch or change in color of the highly stressed area indicates that the service life of the part expires and the
component should be replaced.
2.Warning 2-The user may not see impact damage of parts made from composite materials and the
manufacturer should explain the impact damage and its consequences. The parts made from composite
materials should be returned to them manufacturer for inspection or destruction and replacement.
3.The weighted A noise at ears of the rider should be less than 70dB (A).
4.The bicycle must not be tampered deliberately or refitted without authorization.
5.The manufacturer/seller does not assume any responsibility for damage arising from the user’s tampering
and the user should ask for help from professionals.
6.The child seat cannot be installed below the bicycle.
7.Be sure not to clean the bicycle using high pressure cleaner.
8.For minimum height and dimension of the saddle, please refer to the minimum insertion mark on the seat
post.
9.The total permissible load of the bicycle (including rider) is 120kg.
10.The bare weight of the bicycle is about 21.5kg.
11.The bicycle cannot be designed with a trailer.
Maintenance Plan
Interval Component Operation
After riding for a
long time or for at
least 150km
After riding for a
long time or for
10-20 hours
(high-intensity)
Bicycle chain
Finished bicycle
Clean the bicycle and lubricate the chain gently.
Remove excess oil using cloth.
Dispose of duster cloth in an environmental way.
Use commercially available detergent and lubricant.
Comply with safety instructions for similar products and
environmental regulations on relevant substances.
Inspect whether the bicycle is damaged.
Dismount the bicycle. When necessary, it should be
repaired by a qualified distributor.
After riding for
25km (high-inten-
sity) to 50km
(highway)
Finished bicycle
Inspect whether the bicycle is damaged.
Dismount the bicycle. When necessary, it should be
repaired by a qualified distributor.
When necessary Frame, rim and
pedal
Remove dirt using suitable brush.
Clean components using wet cloth
and neutral soap solution.
11

Warranty Clause and Condition
The bicycle is manufactured by Shenzhen Aodishi Technology Co., Ltd. at Rm#1005, Henglu E Era, Pinghu
Street, Longgang District, Shenzhen, China.
Shenzhen Audis Technology Co., Ltd. Shenzhen Audis Technology Co., Ltd. provides a 5-year warranty for
the frame from the date of purchase. And 1 year warranty, any manufacturing problems or material defects,
including damage caused by normal riding (except improper use) or tearing provide warranty service.
any manufacturing problems or material defects, including damage caused by normal riding (except improper
use) Or tear to provide warranty service.
All vulnerable parts should be excluded from the warranty scope, e.g.: chain, pedal, synchronous belt, tire,
rim, hose, bearing, gearbox hanger, brake block, chain wheel, pinion, underframe, outer tube of shifter and
brake cable, oil paint and paster.
All damages arising from non-compliance of assembly instructions or improper use (jump, special effect,
single-wheel riding and alpine drop). The bicycle can be used for private purpose only. Damages arising from
rent, lease or participation in competition should be excluded from the warranty scope. Unauthorized
maintenance or refitting should be excluded from the warranty scope. Regular maintenance not accordance
with this User Manual or careful inspection conducted at least once or twice per year should be excluded from
the warranty scope. To apply for warranty service, please keep the original proof of purchase and the service
manual. Contents in the warranty scope should be validated as of the purchase date.
Full name
Address
Postcode
Telephone/mobile number
Fax
Purchase date
Bicycle name
Frame number
Wheel size
Color
Special function/accessories
Service Record
Motor number
Bicycle Card
Bicycle Recycling
Please the recycle the abandoned bicycle according to the following procedure:
Abandon bicycle and parts thereof such as batteries and electrical components in a recycle bin according to
local laws and regulations.
Recycle the bicycle according to the manufacturer’s instructions for batteries and electrical components.
12

13
Maintenance record
Warranty description:
1.All parts of the vehicle will be guaranteed strictly according to the warranty period.
2.The warranty period starts from the factory date.
3.If you unpack the controller, charger, battery and motor privately, no warranty will be given.
4.Other parts of the whole vehicle will not be guaranteed except for three months due to quality
problems.
5.When the vehicle fails, the maintenance must be carried out at the designated maintenance
point, and the accessories must not be disassembled and assembled privately. Controller, battery
and charger must ensure that all labeling is complete, and no one is damaged.
6.When the vehicle is repaired, relevant certificates such as warranty card, invoice, certificate of
conformity and so on must be presented.
7.Battery warranty adopts one-to-one warranty. In case of battery problems, the battery must be
returned to the manufacturer first. After the battery is tested by the manufacturer, judge whether
the battery is broken according to the battery testing standard, and determine whether the battery
damage is within the scope of warranty, and then carryout warranty.
8.The controller will be maintained for warranty. The replacement of the controller must ensure
that the plug-in is complete for testing. If it cannot be repaired, a new controller will be replaced. If
the controller is damaged manually, it will not be guaranteed.
9.Pay attention to the maintenance of the whole vehicle and avoid riding in the water as much as
possible. The damage of electrical devices caused by water inflow will not be guaranteed.
Date Maintenance content Remarks

Unauthorized Refitting Prohibited
Refitting or refitting the bicycle improperly, especially improper operation and refitting of the motor and the
controller, may result in serious damage beyond the warranty scope.
Be sure not to refit the controller or the motor by any means.
It is more dangerous to ride a bicycle in the dark at night than in the day and it is harder for the rider to identify
other road users, and consequently severe injury or death may be caused.
Do not ride a bicycle in the dark at night.
1.Please be sure to ride a bicycle carefully.
2.Please be sure to use light and reflector while riding a bicycle.
3.Please be sure not to ride a bicycle in the dark and in rush hour.
4.Please be sure to keep off obstacles on the road.
5.If possible, please be sure to ride a bicycle on a familiar road.
Avoid severe injury or death in the dusk or in the night
Brand new materials (such as oil paint) and high-temperature motor will produce volatile gases. Volatile gases
will gather when the bicycle is stored indoors and consequently difficult breathing and suffocation may be
caused.
The legs may be injured (relating to Q value) if the space between the pedals is too small. The rider may feel
uncomfortable with the pedals.
In this case, please inspect the bicycle at the distributor immediately.
The bicycle may be out of control and overturned due to sudden power.
1.Please be sure to test power function before initial riding.
2.Please be sure to wear personal protective equipment.
3.Please be sure to inspect default speed settings of the bicycle.
4.Please be sure to thoroughly inspect braking force, speed and function before riding.
Avoid injury in the legs
Avoid difficult breathing and ffocation
Avoid falling down due to sudden power
Intended Use
The bicycle shall be used by one person and can be used in auxiliary roads and public roads. The tires must
always be in touch with the ground during riding. The bicycle shall be used for private purpose only and cannot
be used for other purposes. Necessary safety equipment must be adopted in use, which shall be included in the
assembly list.
The bicycle is not applicable to:
1.Jump
2.Stair riding
3.Deepwater riding
4.Sports event
The intended use also includes maintenance conducted as per the recommend time interval and reading and
comprehension of this User Manual.
Safety Precautions
Avoid severe injury or fatal injury caused by mechanical failure and improper use of the bicycle.
Severe injury and even death may be caused by mechanical failure or improper use during riding.
1.Please be sure to carry out safety test before riding.
2.Please get familiar with the brake, pedal and gear before riding.
3.Please be sure to adjust the riding speed as appropriate.
14

Rainy and humid weather will the rider’s and other road users’ traction, braking force and visibility. In this case,
your (and other road users’) braking force will decrease exponentially, tread pattern has work efficiency inferior
to dry pavement’s, it is more complex to control speed and the rider will lose control of their bicycle, and
consequently severe injury may be caused.
1.Please be sure to ride a bicycle slowly in rainy and humid weather.
2.Please be sure to brake carefully in rainy and humid weather.
3.Turn off the motor or try to reduce the motor power and ride a bicycle carefully.
Qualification of User and Rider
This User Manual is applicable to educated rider.
The rider should have the following knowledge and experience:
1.Use the bicycle descried in the distributor’s User Manual effectively;
2.Realize that improper use of the bicycle may cause an accident
3.Able to use the bicycle as requested by this User Manual.
Avoid severe injury or death in rainy days
The bicycle and parts thereof will be worn (scratch, crack, wear and color change). The damaged parts may
break down suddenly and consequently injury and death may be caused.
1.Inspect wear of all parts (such as brake block and tire) regularly.
2.Qualified distributor/specialist shall replace (if possible) or repair the damaged parts.
3.Please be sure to store the bicycle in a well-ventilated room.
The motor may work abnormally in case of improper assembly, wear and overload (e.g.: The motor is
powered in the bumpy pavement and on the curb) or loose parts.
1.The bicycle can be used on the approved road only.
2.In case of crack or obvious damage, please consult the distributor/specialist about maintenance.
3.Inspect whether the parts makes a correct response (e.g.: Shift the gear on a flat surface) and whether
they function well before riding.
4.The rider is allowed to ride a bicycle on the approved road only.
Men may have prostatic diseases after sitting on the saddle long and frequently.
1.If necessary, install an ergonomic saddle suitable for women/men.
2.When necessary, adopt preventive measures.
The damaged parts (such as battery and electrical or electronic components) of the bicycle may produce toxic
substances or gases and consequently environmental poisoning may be caused.
1.Abandon waste batteries and electrical/electronic components of the bicycle according to laws and regulations.
2.Please comply with the manufacturer’s instructions during operation.
Property losses may be caused by improper use of battery.
1.Ensure batteries are not fully discharged.
2.The batteries can be stored in a dry place only.
3.Please charge the batteries at least once every half year.
Avoid severe injury or death caused by damaged parts
Avoid injury or uncomfortable experience
Environmental issues
Avoid material damage
Avoid vibration
15

The damaged parts (such as battery and electrical or electronic components) of the bicycle may produce toxic
substances or gases and consequently environmental poisoning may be caused.
1.Abandon waste batteries and electrical/electronic components of the bicycle according to laws and regulations.
2.Please comply with the manufacturer’s instructions during operation.
Avoid electric shock or explosion caused by improper operation of battery and charger.
1.Only the batteries attached can be used.
2.Be sure not to connect positive and negative poles of the batteries.
3.Protect the batteries from direct sunlight.
4.Please do not dismount or clean the batteries.
5.Only the charger attached can be used to charge the batteries.
6.The charger plug is used to cut off the power. Please ensure the power socket is close to the charger for
user-friendliness.
7.The charger can be used for 110-230V grounding receptacle only. Please be sure to prevent the charger from
water or any type of liquids.
8.Keep metal contacts clean and clean them using soft dry cloth when necessary.
9.Please do not charge batteries with damaged case and other obvious damages.
10.Please prevent the batteries from falling off.
11.Charge the batteries at a temperature of 10-45℃.
12.Use batteries to power the bicycle at a temperature of 0-45°C.
13.Ensure the charger is used by people without physical, sensory or mental disabilities only.
In case of obstacles, please carry the bicycle.
In case of damage, please inspect the bicycle at the distributor.
Avoidance of Damage to Bicycle
Avoid severe injury caused by damaged parts
looseness of reflector and light
The reflector can capture and reflect light of street light, car headlight and other light sources so that the rider is
easy to identify. The rider may be hard to identify if the reflector is damaged, bent or loose and consequently
severe injury or death will be caused.
To avoid such accidents, you should:
1.Request the distributor to replace the damaged, bent or loose reflector and the light.
2.Inspect the reflector and the light regularly.
Improper maintenance, repair and cleaning may result in severe injury or death.
1.Only activities set forth in the maintenance plan can be carried out.
2.Only commercially available lubricant and detergent can be used.
3.Only qualified distributor can carry out maintenance and repair.
Parts of the bicycle (brake and tire) may heat up during riding and burn injury may be caused by touching
these parts.
Cool hot parts down before use or wear thermal protection device.
Riding is a strenuous physical activity.
Please be sure to supply sufficient liquids. Please inspect the bicycle at the distributor.
Cold injury may be easily caused while riding in cold weather.
Please be sure to wear suitable clothes in cold weather, including face shield, mask and gloves.
Avoid severe injury caused by improper and cleaning
Avoid burn injury
Avoid dehydration while riding
Avoid cold injury
16

Fully comply with regional traffic laws and regulations on bicycle. Comply with regulations on
bicycle registration and riding on sidewalk and laws on the use of bikeway. The user is obliged
to get familiar with and comply with laws and regulations.
Respect the rights of motorway users, pedestrians and other riders on the same road/bikeway.
Keep the lights on.
Ride a bicycle foreseeingly. Please be sure to suppose that others cannot see you.
Observe before crossing the road.
The car ahead brakes or reverses and the car behind approaches
The door of a parked vehicle is opened
Pedestrians in the street
Children or pets playing on the roadside
Pit, trench, railway and expansion joint
Construction of road or sideway, rubbles or other obstacles which may force you to use the opposite lane
An accident is caused by evading or being caught by the bicycle or losing control
Ride in the designated bikeway or ride as close to the roadside as possible according to regional regulations or
along the traffic direction
Park in front of parking sign and traffic light. Observe around while braking at the intersection. Remember that a rider
is always the weakest road user
Please use common gestures while turning a corner or parking
Be sure not to wear a headset while riding since it can shield the whistle easily
Traffic noise and whistle may distract the rider and make the rider out of control
Be sure not to carry anyone while riding. Eligible helmet and correctly installed child seat or baby cart must be used
to carry infants. For weight restrictions, please follow the manufacturer’s suggestions for child seat or baby cart
Be sure not to carry any objects which will obstruct the rider’s view, will affect the rider’s control over the bicycle or
will be stuck by moving parts of the bicycle
Please avoid being dragged by other vehicles while riding
Please do not perform special effects, ride on a single wheel or jump; otherwise, the bicycle may be damaged
Be sure not to cross the road, ride around and behave in the ways that other road users cannot predict
Ride a bicycle foreseeingly and pay attention to order of importance and emergency
Be sure not to ride after drinking wine or taking drugs
Try not to ride in severe weather, at poor visibility, in the dusk, in the night or under fatigue; otherwise, accident risk
will increase.
The user also should make the following preparations:
Safety Precautions about Riding
If the speed is not controlled properly while riding in the countryside or in the sidewalk, the rider may fall down
and consequently severe injury or death may be caused.
1.Please be sure to adjust the riding speed as appropriate.
2.Replace parts or add accessories appropriately in order to avoid severe injury or death.
Many components and accessories can improve comfortableness, performance and appearance of bicycle.
The risk of adding components or accessories shall be borne by the user, since such components or
accessories may not pass the test on compatibility, reliability or safety conducted by the manufacturer.
Uncertified compatibility, reliability or safety and improper installation, use and maintenance of components or
accessories of bicycle may result in severe injury or death.
1.Please be sure to consult the distributor before installation, use and maintenance of components.
2.Please be sure to read and comply with the instructions attached.
While riding in the countryside or on the curb
Body parts or other objects may touch chain wheel, mobile chain, rotating pedal, crank and wheel of the bicycle
during riding and consequently severe injury will be caused. Please be sure to avoid contact between body
parts and the aforesaid parts.
Please avoid contact between body parts and the aforesaid parts of the bicycle during riding.
Avoidance of Damage to Rider and Bicycle
17

19
D30 Product Description
Manufacturer’s Contact Information
Shenzhen Aodishi Technology Co., Ltd
Rm#1005, Henglu E Era, Pinghu Street, Longgang District, Shenzhen, China
E-mail: [email protected]
Website: www.adoebike.com
Hardware Configuration
Bicycle type
Tires Size:
Max Speed:
Electric Range:
Assisting Rang:
Load Capacity:
Product Net Weight:
Product Gross Weight:
Overall Unit:(L*W*H)
Packing size:(L*W*H)
Body Material:
Motor Type:
Transmission:
Shock Absorber:
Brake System:
Battery Type:
Battery Capacity:
Battery Charger Power:
Mountain Electric Bicycle
27.5*1.95 inches
25km/h
<60KM
<90KM
120kg
22kg
29.5kg
1800*640*1070mm
1480*260*780mm
Aluminum alloy 6061
Hall Brushless DC Motor
Shimano 11 speeds (D30C 9 speeds)
Wire-controlled shock absorber front fork
Front and rear hydraulic disc brakes
Built-in lithium battery
36V/10AH
42V/2A(CE/ Safety)
