ADS FLASHLOGIC FLRSCH4 User manual

REVISION DATE
20200320
DOCUMENT NUMBER
TERMS OF USE: Automotive Data Solutions Inc. (“ADS”) products are strictly intended for installation by
Certified Technicians who are employed by a registered business specialized in the installation of auto-
motive aftermarket electronics products. Prior to beginning installation of an ADS product in a vehicle,
it is the Certified Technician’s responsibility to review the most current Product Guide, Install Guide
and vehicle-specific notes available in Weblink®. ADS is not responsible for any damages whatsoever,
including but not limited to any consequential damages, incidental damages, damages for loss of time,
loss of earnings, loss of profit, commercial loss, loss of economic opportunity and the like that may or
may not have resulted from the use, misuse, improper installation or operation of its products. ADS
reserves itself the right to suspend any Weblink® account without notice and decline to offer technical
support to non-Certified Technicians, non-compliant Certified Technicians or end users.
BEFORE INSTALLATION
1- Connect module to computer
2- Login to Weblink account
3- Flash firmware to module (module is not preloaded with firmware)
4- Use accessories accordingly (accessories are sold separately)
Patent No. US 8,856,780 CA 2759622
INSTALL GUIDE
FLICHRSCH4FLRSCH4EN
HARDWARE
FLRSCH4
ACCESSORIES
FLPROG REQUIRED
FLRF1/2/4 OPTIONAL
CARLINK ASCL2 OPTIONAL
FIRMWARE
FLICHRSCH4FLRSCH4
www.flashlogic.comAutomotive Data Solutions Inc. © 2020
70095

Patent No. US 8,856,780 CA 2759622
VEHICLE LIST - 1 OF 1
MAKE MODEL YEAR INSTALL TYPE
FEATURES
DATA IMMOBILIZER BYPASS 3X LOCK START/STANDALONE MOD. PRIORITY UNLOCK DOOR LOCK DOOR UNLOCK ARM OEM ALARM DISARM OEM ALARM TRUNK/HATCH RELEASE POWER LIFTGATE POWER SLIDING DOOR (L) POWER SLIDING DOOR (R) DATA/MUX IGNITION CTRL RAP SHUTDOWN CTRL HOOD STATUS (W/OEM SW) DOOR STATUS BRAKE PEDAL STATUS TACHOMETER STATUS SECURE TAKEOVER PARKING LIGHT CTRL*
CHRYSLER
300 AT 08-10 1 • • • • • • • • • • • • • • • •
300 Limited AT 08-10 1 • • • • • • • • • • • • • • • •
300c AT 08-10 1 • • • • • • • • • • • • • • • •
300c SRT8 AT 08-10 1 • • • • • • • • • • • • • • • •
Town & Country AT 08-16 1 • • • • • • • • • • • • • • • • • •
DODGE
Caravan AT 08-10 1 • • • • • • • • • • • • • • • • • •
Challenger SXT AT 08-14 1 • • • • • • • • • • • • • • • •
Challenger R/T AT 08-14 1 • • • • • • • • • • • • • • • •
Challenger SRT8 AT 08-14 1 • • • • • • • • • • • • • • • •
Charger SE AT 08-10 1 • • • • • • • • • • • • • • • •
Charger R/T AT 08-10 1 • • • • • • • • • • • • • • • •
Charger SRT8 AT 08-10 1 • • • • • • • • • • • • • • • •
Durango AT 11-13 1 • • • • • • • • • • • • • • •
Grand Caravan AT 08-20 1 • • • • • • • • • • • • • • • • • •
Journey AT 09-10 1 • • • • • • • • • • • • • • • •
Magnum AT 08 1 • • • • • • • • • • • • • • • •
JEEP
Commander AT 08-10 1 • • • • • • • • • • • • • • • •
Grand Cherokee AT 08-13 1 • • • • • • • • • • • • • • • •
RAM
C/V AT 10-151••••••• •••••••••••
1500 AT 10-12 1 • •••••• ••••••••
2500 AT 10-12 1 • • • • • • • • • • • • • • •
3500 AT 10-12 1 • • • • • • • • • • • • • • •
4500 AT 11-12 1 • • • • • • • • • • • • • • •
5500 AT 11-12 1 • • • • • • • • • • • • • • •
VW
Routan AT 09-12 1 • • • • • • • • • • • • • • • • • •
* May require additional parts.
www.flashlogic.comAutomotive Data Solutions Inc. © 2020 FLICHRSCH4FLRSCH4EN
PAGE 2 OF 20
• 20200320
DOC.: #70095

Patent No. US 8,856,780 CA 2759622
BOX CONTENTS - 1 OF 1
VS1VS1
VS2VS2
MS1MS1
MS2MS2
3
6
4
1
2
5
C
B
A
F
G
E
D
7
9
3
10
8
11
13
14
12
15
17
18
19
20
16
6
4
1
2
5
7
9
3
10
8
11
12
6
4
1
2
5
2
1
3
7
9
3
10
8
6
4
12
5
2
1
3
4
2
1
3
4
BOX CONTENTS
T-HARNESS 1
AFTERMARKET HOOD SWITCH AND CABLE
WARNING STICKER
10 PIN CONNECTOR
12 PIN CONNECTOR
BLUE
PROGRAMMING
BUTTON
LED 2
LED 1
MODULE
BLACK
BLACK
BLACK
RF PORT/
WEBLINK PORT
BLACK
BLUE
TELEMATIC
PORT
WHITE
WEBLINK CABLE (required accessory sold separately)
WEBLINK CABLE
COMPUTER
USB PORT
4 PIN BLACK CABLE
MODULE
WEBLINK PORT
www.flashlogic.comAutomotive Data Solutions Inc. © 2020 FLICHRSCH4FLRSCH4EN
PAGE 3 OF 20
• 20200320
DOC.: #70095

Patent No. US 8,856,780 CA 2759622
www.flashlogic.comAutomotive Data Solutions Inc. © 2020 FLICHRSCH4FLRSCH4EN
PAGE 4 OF 20
• 20200320
COMPATIBLE ACCESSORIES - 1 OF 1
FLRF1/2/4 RF KIT
RF KIT (accessories sold separately)
(NC)
ANTENNA
MODULE
RF PORT
FLHRNTM
TELEMATIC KIT (accessories sold separately)
(NC)
CARLINK
MODULE
TELEMATIC PORT
10 11 12 13 14 15 16
12345678
9
FLHRNTM
TELEMATIC KIT (accessories sold separately)
MODULE
TELEMATIC PORT
CAR CONNECTIONPN 4120260 OBDII CONNECTOR
VEHICLE
OBDII PORT
(NC)
DOC.: #70095

Patent No. US 8,856,780 CA 2759622
TYPE 1 - WIRE CHART - 1 OF 2
MAKE MODEL YEAR WIRE DESCRIPTION CONNECTOR NAME CONNECTOR COLOR CONNECTOR TYPE POSITION WIRE COLOR POLARITY MODULE LOCATION COMPONENT LOCATOR
CHRYSLER
300 08-10 Parking Light D2242 Black 10 pin 1 White/Brown (MUX) Switch ~
Driver Door Pin ~ ~ ~ ~ Purple (-) Driver kick panel ~
300 Limited 08-10 Parking Light D2242 Black 10 pin 1 White/Brown (MUX) Switch ~
Driver Door Pin ~ ~ ~ ~ Purple (-) Driver kick panel ~
300C 08-10 Parking Light D2242 Black 10 pin 1 White/Brown (MUX) Switch ~
Driver Door Pin ~ ~ ~ ~ Purple (-) Driver kick panel ~
300 SRT8 08-10 Parking Light D2242 Black 10 pin 1 White/Brown (MUX) Switch ~
Driver Door Pin ~ ~ ~ ~ Purple (-) Driver kick panel ~
Town & Country 08-10 Parking Light D2242 Black 10 pin 1 White/Brown (MUX) Switch ~
Driver Door Pin ~ ~ ~ ~ Purple (-) Driver kick panel ~
Town & Country 11-16 Parking Light D2242 Black 6 pin 3 White/Green (MUX) Switch ~
Driver Door Pin ~ ~ ~ ~ Purple (-) Driver kick panel ~
DODGE
Caravan 08-10 Parking Light D2242 Black 10 pin 1 White/Brown (MUX) Switch ~
Driver Door Pin ~ ~ ~ ~ Purple (-) Driver kick panel ~
Challenger R/T 08-14 Parking Light D2242 Black 10 pin 1 White/Brown (MUX) Switch ~
Driver Door Pin ~ ~ ~ ~ Purple (-) Driver kick panel ~
Challenger SXT 08-14 Parking Light D2242 Black 10 pin 1 White/Brown (MUX) Switch ~
Driver Door Pin ~ ~ ~ ~ Purple (-) Driver kick panel ~
Challenger SRT8 08-14 Parking Light D2242 Black 10 pin 1 White/Brown (MUX) Switch ~
Driver Door Pin ~ ~ ~ ~ Purple (-) Driver kick panel ~
Charger SE 08-10 Parking Light D2242 Black 10 pin 1 White/Brown (MUX) Switch ~
Driver Door Pin ~ ~ ~ ~ Purple (-) Driver kick panel ~
Charger R/T 08-10 Parking Light D2242 Black 10 pin 1 White/Brown (MUX) Switch ~
Driver Door Pin ~ ~ ~ ~ Purple (-) Driver kick panel ~
Charger SRT8 08-10 Parking Light D2242 Black 10 pin 1 White/Brown (MUX) Switch ~
Driver Door Pin ~ ~ ~ ~ Purple (-) Driver kick panel ~
Durango 11-13 Parking Light D2242 Black 6 pin 1 White/Green (MUX) Switch ~
Driver Door Pin ~ ~ ~ ~ Purple (-) Driver kick panel ~
Grand Caravan 08-10 Parking Light D2242 Black 10 pin 1 White/Brown (MUX) Switch ~
Driver Door Pin ~ ~ ~ ~ Purple (-) Driver kick panel ~
Grand Caravan 11-20 Parking Light D2242 Black 6 pin 3 White/Green (MUX) Switch ~
Driver Door Pin ~ ~ ~ ~ Purple (-) Driver kick panel ~
Journey 09-10 Parking Light ~ ~ ~ ~ White/Violet (+) Driver kick panel ~
Driver Door Pin ~ ~ ~ ~ Purple (-) Driver kick panel ~
Magnum 08 Parking Light D2242 Black 10 pin 1 White/Brown (MUX) Switch ~
Driver Door Pin ~ ~ ~ ~ Purple (-) Driver kick panel ~
www.flashlogic.comAutomotive Data Solutions Inc. © 2020 FLICHRSCH4FLRSCH4EN
PAGE 5 OF 20
• 20200320
DOC.: #70095

Patent No. US 8,856,780 CA 2759622
TYPE 1 - WIRE CHART - 2 OF 2
MAKE MODEL YEAR WIRE DESCRIPTION CONNECTOR NAME CONNECTOR COLOR CONNECTOR TYPE POSITION WIRE COLOR POLARITY MODULE LOCATION COMPONENT LOCATOR
JEEP
Commander 08-10 Parking Light ~ ~ ~ ~ Pin #1 of relay #7 (-) Power module in engine compartment ~
Driver Door Pin ~ ~ ~ ~ Purple (-) Driver kick panel ~
Grand cherokee 08-10 Parking Light ~ ~ ~ ~ Pin #1 of relay #7 (-) Power module in engine compartment ~
Driver Door Pin ~ ~ 20 pin 05 Purple (-) Driver door module ~
Grand cherokee 11-13 Parking Light ~ Black 10 pin 01 White/LtGreen (MUX) Switch ~
Driver Door Pin ~ ~ ~ ~ Purple (-) Driver kick panel, door harness ~
RAM
C/V 10 Parking Light D2242 Black 10 pin 01 White/Brown (MUX) Switch ~
Driver Door Pin ~ ~ ~ ~ Purple (-) Driver kick panel ~
C/V 11-15 Parking Light D2242 Black 6 pin 01 White/Green (MUX) Switch ~
Driver Door Pin ~ ~ ~ ~ Purple (-) Driver kick panel ~
1500 10-12 Parking Light D2242 Black 10 pin 01 White (MUX) Switch ~
Driver Door Pin ~ ~ ~ ~ Purple (-) Driver kick panel ~
2500 10-12 Parking Light D2242 Black 10 pin 01 White (MUX) Switch ~
Driver Door Pin ~ ~ ~ ~ Purple (-) Driver kick panel ~
3500 10-12 Parking Light D2242 Black 10 pin 01 White (MUX) Switch ~
Driver Door Pin ~ ~ ~ ~ Purple (-) Driver kick panel ~
4500 11-12 Parking Light D2242 Black 10 pin 01 White (MUX) Switch ~
Driver Door Pin ~ ~ ~ ~ Purple (-) Driver kick panel ~
5500 11-12 Parking Light D2242 Black 10 pin 01 White (MUX) Switch ~
Driver Door Pin ~ ~ ~ ~ Purple (-) Driver kick panel ~
VW
Routan 09-12 Parking Light D2242 Black 10 pin 01 White/Brown (MUX) Switch ~
Driver Door Pin ~ ~ ~ ~ Purple (-) Driver kick panel ~
www.flashlogic.comAutomotive Data Solutions Inc. © 2020 FLICHRSCH4FLRSCH4EN
PAGE 6 OF 20
• 20200320
DOC.: #70095

Patent No. US 8,856,780 CA 2759622
87A
30
87
86
85
M6
M7
M1
M2
M3 M4
M5
5
5
M1
M2
M3
M4
1
1
2
2
4
4
3
3
3
MS1MS1
MS2MS2
WHITE/BROWN
WHITE/RED (NC)
WHITE/GREEN (NC)
IGNITION CONNECTOR
IGNITION HARNESS
TYPE 1 - WIRING DIAGRAM - 1 OF 1
INSTALL THE SUPPLIED HOOD SWITCH IF THE VEHICLE IS NOT EQUIPPED WITH ONE.
HOOD SWITCH
HORN (-)
IGNITION SWITCH
20
19
09
10
08
18
15
16
17
14
12
13
11
01
02
03
04
05
06
01
01 BROWN/BLACK - PARKING LIGHT (-) OUTPUT
01
02
03
05
06
07
04
09
10
08
12
11 GRAY/GREEN - HORN (-) OUTPUT
03
05
06
07
04
09
10
08
02
03
05
06
07
04 GRAY/WHITE - HOOD STATUS (-) INPUT
PARKING LIGHT (MUX)
PARKING LIGHT (-)
PARKING LIGHT (+)
12V (+)
OPTIONALOPTIONAL
IF VEHICLE IS EQUIPPED WITH PARKING LIGHT (+)
IF VEHICLE IS EQUIPPED WITH PARKING LIGHT (+)
IF VEHICLE IS EQUIPPED WITH PARKING LIGHT (-)IF VEHICLE IS EQUIPPED WITH PARKING LIGHT (-)
IF VEHICLE IS EQUIPPED WITH PARKING LIGHT ( )
IF VEHICLE IS EQUIPPED WITH PARKING LIGHT (MUX)
OR
OR
OR
OR
02 GRAY - RAP SHUTDOWN (-) OUTPUT
10A
TELEMATIC PORT
RF PORT/WEBLINK PORT
DRIVER DOOR PIN (-)
www.flashlogic.comAutomotive Data Solutions Inc. © 2020 FLICHRSCH4FLRSCH4EN
PAGE 7 OF 20
• 20200320
DOC.: #70095

Patent No. US 8,856,780 CA 2759622
01
02
03
OFF
ACC ON
START
04
OFF
ACC ON
START
05
06
07
OFF
ACC ON
START
08
OFF
ACC ON
START
09
10
11
MODULE PROGRAMMING PROCEDURE - STD KEY - 1 OF 1
Close driver door.
Re-open driver door to wake up data bus.
Insert key into ignition.
Turn key to ON position.
LED will turn solid RED.
Within 5 seconds, LED will flash GREEN
rapidly.
Turn key to OFF position.
Remove key.
Press UNLOCK on the OEM remote. If vehicle
is not equipped with OEM remote, press
module programming button.
Wait, LED will turn solid GREEN for 2 seconds.
Module Programming Procedure completed.
www.flashlogic.comAutomotive Data Solutions Inc. © 2020 FLICHRSCH4FLRSCH4EN
PAGE 8 OF 20
• 20200320
DOC.: #70095

Patent No. US 8,856,780 CA 2759622
01
02
03
ENGINE
START
STOP
STOP ACC ON START
ON
04
05
06
ENGINE
START
STOP
STOP ACC ON START
STOP
07
08
09
MODULE PROGRAMMING PROCEDURE - PTS - 1 OF 1
Close driver door.
Re-open driver door to wake up data bus.
DO NOT PRESS BRAKE PEDAL. Push start
button twice [2x] to ON position.
LED will turn solid RED.
Within 5 seconds, LED will flash GREEN
rapidly.
DO NOT PRESS BRAKE PEDAL. Push start
button once [1x] to OFF position.
Press UNLOCK on the OEM remote.
Wait, LED will turn solid GREEN for 2 seconds.
Module Programming Procedure completed.
www.flashlogic.comAutomotive Data Solutions Inc. © 2020 FLICHRSCH4FLRSCH4EN
PAGE 9 OF 20
• 20200320
DOC.: #70095

Patent No. US 8,856,780 CA 2759622
>>
01
02
ENGINE
START
STOP
OFF ACC ON START
ON
03
04
ENGINE
START
STOP
OFF ACC ON STARTOFF
05
>>
VALET MODE PROGRAMMING PROCEDURE - 1 OF 1
NOTE: In Valet Mode, the Remote starter is not
functional. Keyless entry, Lock and Unlock will
remain functional. See RF kit user manual for
alternate valet mode programming.
Time restriction. Complete next step within 7
seconds.
Cycle ignition ON five times [5x OFF/ON]
rapidly.
Wait, LED 1 will turn solid RED for 2 seconds.
Set ignition to OFF position.
Valet Mode Programming Procedure
completed.
To exit valet mode: repeat steps 1 to 5.
www.flashlogic.comAutomotive Data Solutions Inc. © 2020 FLICHRSCH4FLRSCH4EN
PAGE 10 OF 20
• 20200320
DOC.: #70095
