ADTRAN NetVanta 1544F User manual

NetVanta® 1544F is a managed, 28-port, Layer 3,
Gigabit Ethernet switch designed as an access
layer or network backbone switch for small to
medium-sized businesses. With the combination
of the advanced multi-layer switching fabric, high-
bandwidth capabilities, and enhanced Quality of
Service (QoS) features, the NetVanta 1544F is ideal as
an aggregation switch for high-bandwidth Voice over
IP (VoIP), and converged voice and data networks.
Hardware
e NetVanta 1544F rackmount switch provides
28 Gigabit Ethernet ports, consisting of 24 standard
1 Gbps Small Form-factor Pluggable (SFP) Ethernet
ports and four enhanced 2.5 Gbps SFP ports.
e enhanced SFP ports support standard 1 Gbps
up to 2.5 Gbps data rates. Together the four
enhanced SFP ports can provide up to 20 Gbps of
bi-directional bandwidth between interconnected
NetVanta 1544 switches.
Multi-layer Switching
e NetVanta 1544F supports advanced multi-layer
(Layer 2 and Layer 3) switching. It supports
static routes, RIP V1/V2, OSPF, Border Gateway
Protocol (BGP) and Virtual Router Redundancy
Protocol (VRRP), allowing it to easily scale
from small and medium-sized businesses to
enterprise-sized customers.
Standards Protocols
Based on the ADTRAN® Operating System (AOS),
this device oers support for Link Aggregation
(802.3ad); Port Mirroring; port-based switching
features including Broadcast Storm Control,
Spanning Tree (802.1D) and Rapid Spanning Tree
(802.1w) for faster network convergence, link
redundancy, and recovery from topology changes.
Link Layer Discovery Protocol (LLDP) auto-
discovers neighboring Ethernet devices, simplifying
integration into multi-vendor environments.
Virtual LANs (VLANs)
All NetVanta switches support 802.1Q trunking
and up to 255 VLANs to allow network managers
to separate broadcast domains for ecient network
performance and trac control. NetVanta 1544F also
supports dynamic VLANs assigned via 802.1x. is
is an ideal way to make sure users are automatically
assigned to the correct VLAN, based on the login.
Private VLANs are also available to provide extra
security by isolating upstream trac from user ports.
VoIP Ready
NetVanta 1544F has been designed specically
for VoIP. e ability to automatically congure
IP phones using LLDP-MED, and the ability to
separate voice trac onto voice VLANs, helps
ease the deployment of VoIP.
Quality of Service
NetVanta switches also support QoS to prioritize
mission-critical trac like VoIP and control network
congestion. NetVanta 1544F oers 802.1p and
DiServ Class of Service (CoS). It also supports
frame tagging, as well as enforcement of tagged
trac received from trusted sources. Four egress
queues (per port) are available for assigning trac
priorities using Weighted Round Robin (WRR) and
Strict Priority Scheduling.
Security
Rest assured, with NetVanta 1544F your network
is protected. is product oers a variety of data
security features including MAC-based port security,
multilevel user passwords, Secure Shell (SSH) and
Secure Socket Layer (SSL) for encrypted user login,
and Access Authentication and Authorization (AAA)
for authentication with RADIUS, RSA SecurID and
TACACS+. With features such as 802.1x and
port security, administrators can assure that only
authorized users are allowed access to the network.
Port Scheduler
NetVanta 1544F allows ports to be scheduled, or
turned on or o based on time of day. is ability to
schedule available ports allows for added security.
Administration
AOS oers both a CLI that mimics the widely
deployed, industry de facto standard and an intuitive
Web-based GUI with step-by-step conguration
wizards. For automating setup and conguration,
NetVanta 1544F also supports features like
Auto-Provisioning which allows automatic
conguration scripts to be run from the integrated
CompactFlash slot and Auto-Cong which
provides the ability to automatically obtain the
switch conguration via DHCP.
Product Features
n28-port multi-layer Gigabit
Ethernet aggregation switch
n24-standard Gigabit SFP ports
and four enhanced SFP ports
nEnhanced SFP ports support
standard 1 Gbps or 2.5 Gbps
data rates
nNon-blocking, up to 68 Gbps
switching capacity
nLine rate Layer 2 and
Layer 3 switching
nStatic routes, RIP V1/V2,
OSPF and BGP
nVRRP
nHardware ACLs
n802.1Q VLANs, Private VLANs
and VLAN assignment via 802.1x
nAdvanced QoS with support for
802.1p and DiffServ prioritization
with four queues per egress port
nAutomate actions with Port
Scheduler and TCL scripting
nVoIP Ready with LLDP/LLDP-MED
and Voice VLANS
nBusiness-class security with
RADIUS, TACACS+, 802.1x
and port security
nCompactFlash®slot for
auto provisioning
nWi-Fi®access controller
for centralized management
of NetVanta Wireless
Access Points (WAPs)
nFamiliar Command Line Interface
(CLI) and Web-based Graphical
User Interface (GUI)
nLimited Lifetime Warranty
nNext Business Day
Advance Replacement
NetVanta 1544F
Fiber, Layer 3 Gigabit
Ethernet Switch

NetVanta 1544F
Fiber, Layer 3 Gigabit Ethernet Switch
Physical Interfaces
Ethernet Ports
n24 -10/100/1000 Mbps SFP Ports
n4-1 Gbps/2.5 Gbps SFP Ports
Console Port
nDB-9, RS-232
Switching Performance
nNon-blocking Layer 2/3 Switching
nJumbo Frames: Supports Rrames up to 13k Bytes
Maximum Forwarding Bandwidth
n68 Gbps
Layer 2 Support
n802.1D Spanning Tree n802.1w Rapid STP
n802.3ad Link Aggregation n 16,000 MAC Addresses
Layer 3 Support
nStatic Routes n RIP V1/V2
nOSPF n BGP
nVRRP nUDP Relay
n128 Layer 3 Interfaces n 1k ARP Entries
n1k Unicast Routes
Diagnostics
nPort Mirroring n LLDP (802.1AB)
nLLDP-MED nPing
nTroubleshooting Page
Front Panel Status LEDs
nPower Status
nLAN: Link, Activity
Port Statistics
nNumber of TX/RX Frames
nNumber of Collisions
nNumber of Errors
Quality of Service
n802.1p and DiffServ
nFour Output Queues per Egress Port
nWeighted Round Robin (WRR)
nStrict Priority Scheduling
VLAN
nPort-based VLANs
n802.1Q tagged trunked VLANs
nVoice VLANs
nPrivate VLAN Edge
nDynamic 802.1x Assigned VLANs
nSupport for up to 255 Active VLANs
Storm Control
nBroadcast, Unicast, and Multicast
Administration
nCLI (Console/Telnet/SSH) n SNMP v3
nWeb-based GUI (HTTP/SSL) n SYSLOG
nn-Command®Support nEmail Alerts
nRADIUS nTACACS+
nFLASH Provisioning n Auto Cong
nTCL Scripting nPort Scheduler
Network Access Control
nPort authentication (802.1x) nPort Security
Wi-Fi Controller
nControls up to 24 NetVanta WAPS
Environment
nOperating Temperature: 32° to 122° F (0° to 50° C)
nStorage Temperature: -4° to 158° F (-20° to 70° C)
nRelative Humidity: Up to 95%, Non-condensing
Physical
nChassis: 1U, 19 in. Rackmountable Metal Enclosure
nDimensions: 1.7 in. x 17.2 in. x 9.2 in.
(4.3 cm x 43.7 cm x 23.4 cm) (H x W x D)
nWeight: 6.0 lbs. (2.7 kg.)
nAC Power: 100–130V, 50/60 Hz
nPower: 80 Watts
Agency Approvals
nFCC Part 15 Class A, UL 1950/CSA, CE Mark,
C-tick, RoHS
Product Specications
ADTRAN, Inc.
Attn: Enterprise Networks
901 Explorer Boulevard
Huntsville, AL 35806
P.O. Box 140000
Huntsville, AL 35814-4000
256 963-8000
256 963-8699 fax
General Information
800 9ADTRAN
[email protected]
www.adtran.com
Pre-Sales Technical Support
888 423-8726
[email protected]
www.adtran.com/presales
Post-Sales Technical Support
888 423-8726
[email protected]
www.adtran.com/support
Where to Buy
888 423-8726
[email protected]
www.adtran.com/where2buy
ProServicesSM
888 874-2237
[email protected]
www.adtran.com/proservices
Global Inquiries
256 963-8000
256 963-6300 fax
[email protected]
ADTRAN believes the information in this
publication to be accurate as of publica-
tion date, and is not responsible for
error. Specifications subject to change
without notice. ADTRAN, n-Command
and NetVanta are registered trademarks of
ADTRAN, Inc. and its affiliates in various
countries. All other trademarks mentioned
in this document are the property of their
respective owners.
ADTRAN warranty duration and entitle-
ments vary by product and geography.
For specific warranty information, visit
www.adtran.com/warranty
ADTRAN products may be subject to U.S.
export controls and other trade restric-
tions. Any export, re-export, or transfer of
the products contrary to law is prohibited.
For more information regarding
ADTRAN’s export license, please
visit www.adtran.com/exportlicense
ADTRAN is an ISO 9001, ISO 14001,
and a TL 9000 certified supplier.
61700546G1#120 November
Copyright © 2013 ADTRAN, Inc.
All rights reserved.
Ordering Information
Equipment Part No.
NetVanta 1544F 1700546G1#120
SFP Transceivers
NetVanta 1000BaseSX 1200480E1
NetVanta 1000BaseLX 1200481E1
NetVanta 10/100/1000Base-T 1200485G1
NetVanta 2.5Gbps Multimode 1200482G1
NetVanta 2.5Gbps Singlemode 1200483G1
Interconnect Cables
NetVanta 1 Meter SFP 1200484G1
NetVanta 3 Meter SFP 1200484G3
