ATS250 - Operator Manual
Operating Controls
ATS 250
© 2019. Advance Welding 1
Operating Controls ........................................................................................................................
Safety Notes .....................................................................................................................................
Product Specication ...................................................................................................................
Intended Use ....................................................................................................................................
Introduction ......................................................................................................................................
Delivered Items ................................................................................................................................
Electrical Safety ................................................................................................................................
Using the Equipment .....................................................................................................................
Data Log Memory ............................................................................................................................
Manual Welding .............................................................................................................................
Fusamatic Welding .......................................................................................................................
Bar Code Welding .........................................................................................................................
Fusion Operator Badge ..............................................................................................................
GPS Location .................................................................................................................................
Extreme Low Temperature Operation .................................................................................
Downloading the Weld Memory .............................................................................................
Upgrading the Operating Software .......................................................................................
Set Up Options ..............................................................................................................................
Information .....................................................................................................................................
Fault Finding ...................................................................................................................................
Maintenance ..................................................................................................................................
Disposal ............................................................................................................................................
Calibration and Warranty ...........................................................................................................
Declaration of Conformity ........................................................................................................
Service and Repair.........................................................................................................................
Quick Start Guide ..........................................................................................................................
ATS 250
Operating manual

ATS250 - Operator Manual
ATS 250
© 2019. Advance Welding 2
• Prepare the pipe and tting according to the manufacturer’s specication.
• Unwind all cables from the welding unit.
• Connect the supply cable to the correct voltage and switch it on.
• The unit will power up and show “Connect Fitting”.
• Connect the welding cable to the tting.
• Read the bar code on the tting or enter a time.
• Press the Start button.
• The time will count down to zero as the tting is being welded. Any faults will be
indicated on the display.
• At the end of the weld, disconnect the welding cable to reset the unit.
Quick Start Guide

ATS250 - Operator Manual
ATS 250
© 2019. Advance Welding 3
Quick Start Guide ........................................................................................................................
Index .................................................................................................................................................
Operating Controls ....................................................................................................................
Safety Notes ..................................................................................................................................
Product Specication ...............................................................................................................
Intended Use ................................................................................................................................
Introduction ...................................................................................................................................
Delivered Items .............................................................................................................................
Electrical Safety.............................................................................................................................
Using the Equipment ................................................................................................................
Data Entry .......................................................................................................................................
ATS 250 MANUAL Welding........................................................................................................
ATS 250 BASIC Welding .............................................................................................................
ATS 250 EXTRA Welding ............................................................................................................
Options Menu ...............................................................................................................................
Maintenance ..................................................................................................................................
Fault Finding ...................................................................................................................................
Disposal ...........................................................................................................................................
Calibration and Warranty ...........................................................................................................
Declaration of Conformity ........................................................................................................
Service and Repair .......................................................................................................................
Index
2
3
4
5
6
7
7
7
8
9
10
11
13
16
20
27
27
32
33
35
36

ATS250 - Operator Manual
ATS 250
© 2019. Advance Welding 4
1. Welding Cable
2. Ratings Plate
3. Supply Cable
4. Buttons
5. Temperature Sensor
6. Protective Frame
7. On/O switch (on right hand side of unit)
8. Display
9. Bar code pen reader
1. Welding Cable (can be provided with optional right angle plug)
2. USB Memory Drive
3. Bar Code Scanner (Optional)
4. Bar Code Pen (Standard)
5. USB Socket
6. Welding Cable Socket
7. Protective Lid
8. Display
9. Buttons
10. Protective Frame
11. Ratings Plate
12. Supply Cable
Operating Controls
2. Ratings Plate
9. Bar Code Pen Reader
8. Display
3. Supply Cable
5. Temperature Sensor
6. Protective Frame
4. Buttons
1. Welding Cable
7. On/O Switch

ATS250 - Operator Manual
ATS 250
© 2019. Advance Welding 5
• RISK OF EXPLOSION! This welding unit must not be used in a gaseous
atmosphere.
• RISK OF ELECTRIC SHOCK! Do not open. No user serviceable parts
inside.
• Before using, always visually inspect the unit to see that the cables and
connectors are not worn or damaged. Replace the damaged part before
welding.
• Switch o and remove the plug from the mains before adjusting, cleaning, or
if the cables are entangled and before leaving the equipment unattended for
any period.
• To avoid damaging the unit, do not interrupt the supply voltage or disconnect
the welding cable, while the unit is welding a tting.
• Do not lift or pull the equipment by its cables.
• Do not disconnect the welding cables by pulling on them, always pull o the
connectors from the tting.
• Do not start a weld without the pipe correctly inserted into the tting.
• Do not touch the tting while welding.
• Do not weld in the rain or leave the equipment outdoors whilst it is raining.
• Weld only in daylight or in good articial light.
• The operator is responsible for accidents or hazards occurring to other people
or their property while using this equipment. Keep the work area safe!
• Keep bystanders a safe distance away from the machine while welding.
• Never allow people unfamiliar with these instructions to use the welding unit.
Safety Notes

ATS250 - Operator Manual
ATS 250
© 2019. Advance Welding 6
Input Power Connections
for this model:
• 110V version
• 120V version
• 320V version
Input plug for your region or
country are available
Contact us for more information
Bespoke OEM
As a bespoke OEM Original Manufacturer we can
produce this product as an OEM to suit your business
Contact us to discuss your requirements
Specication details - ATS 250
Operating Modes Manual, Barcode
Welding Voltage 39.5V (8 to 48V)
Welding Current 1-60A
Welding Time 1-3000 seconds
Supply Voltage
115V ± 15% 110V
(40-60Hz)
230V ± 15% 230V
(40-60Hz)
Supply Current 1-28A (115V)
1-14A (230V)
Supply Power 3500 W
Weight 20 kg
Size 22 x 26 x 45cm
Operating Temp. -15ºC to +50ºC
Product Specication

ATS250 - Operator Manual
ATS 250
© 2019. Advance Welding 7
This equipment is intended to weld constant voltage electrofusion ttings suitable for low,
medium and high pressure pipe work systems.
This welding unit has been designed to comply with the International Organization for
Standardization standard ISO12176-2:2000 “Plastic pipes and ttings, equipment for fusion
jointing polyethylene systems , part 2, electrofusion”.
This manual gives instructions on the correct assembly and safe use of your welding unit. It
is important that you read these instructions carefully, and keep these instructions for the
life of the unit.
This manual does not detail the specic welding procedure for the ttings: scraping,
clamping and assembly of joints. For this information you must contact the manufacturer of
the ttings.
Carefully remove the welding unit from its packaging and check that you have the following
items:
• Welding unit.
• Bar code reading pen (not Manual unit)
When parts are missing or damaged, please contact your dealer.
Intended Use
Introduction
Delivered Items

ATS250 - Operator Manual
ATS 250
© 2019. Advance Welding 8
Electrical Safety
WARNING! Switch o and remove the plug from the mains before adjusting,
cleaning or if the cable is cut, damaged or entangled.
This welding unit is Class 1 and requires an earthed (grounded) connection. An earth
spike must be used with generators.
This unit is supplied in either 110 volt or 230 volt operation. Check the rating plate
on the side of the unit for the correct supply voltage.
The power source must be capable of providing 3500 Watts.
Extension cables should only be used if they comply with the H07RNF harmonized
standard. They must be tted with connectors to the BS EN 60309-2 standard. All
cables must be unwound from the reel to stop inductive heating eects. The cable
dimensions should be as follows:
It is recommended for increased electrical safety to use a Residual Current Device
(RCD) with a tripping current of not more than 30 mA. Always check your RCD every
time you use it.
The supply cable must be inspected for signs of damage before each use and the
equipment may only be used if in perfect condition. Damaged cables must be
replaced by an approved service agent.
This equipment is classied as “Portable for use on industrial applications”, and
must undergo a formal electrical safety check (Portable Appliance Test) as per local
regulations.
110V Volt operation
Up to 63mm diameter
2.5mm2 cable = 30m
Up to 180mm diameter
2.5mm2 cable = 20m
Over 180mm diameter
4.0mm2 cable = 10m
230 Volt operation
Up to 63mm diameter
1.5mm2 cable = 40m
Up to 180mm diameter
1.5mm2 cable = 25m
Over 180mm diameter
2.5mm2 cable = 20m

ATS250 - Operator Manual
ATS 250
© 2019. Advance Welding 9
Prepare and clamp the pipe and ttings inline with the manufacturers
recommendations. Connect the supply cable to the correct supply voltage and switch
the unit on.
The screen will show the model number and software version. It will also show the
current date and the calibration due date.
After a short pause the owner details will be shown.
The display will now show the “Connect Fitting” screen.
Connect the welding cable to the tting to begin the welding process.
Press the STOP button to enter the data logging menu (on the EXTRA unit only).
Press the OK button to enter the options menu.
The supply voltage and frequency are shown. This allows the operator to check the
quality of the power supply before welding starts.
Using the equipment
A D V A N C E W E L D I N G
A T S 2 5 0 E X T R A A . 1 . 0 2
C A L D U E : 0 9 / 1 0 / 2 0 1 0
1 0 : 3 1 1 9 / 1 0 / 2 0 0 9
P R O P E R T Y O F :
A D V A N C E W E L D I N G
TEL : [phone]
FAX : [phone]
C O N N E C T F I T T I N G
S T O P : D A T A L O G I N F O
O K : M E N U
S U P P L Y : 2 4 0 V 5 0 H Z

ATS250 - Operator Manual
ATS 250
© 2019. Advance Welding 10
Letters and numbers are entered using the arrow buttons. Using the up and down
arrows will scroll through the list of A to Z and 1 to 9. When the correct letter has been
chosen, pressing the right arrow button will move to the next position. If a mistake has
been made the left arrow button can be used to backspace.
For example, in the following screen:
To enter 40 seconds…
Press the up arrow button four times until the 4 is shown.
Press the right arrow button to move to the next position.
Press the down arrow button once until the 0 is shown.
Press the OK button to accept 40.
Data Entry
M A N U A L W E L D I N G
T I M E : _ _ _ _ S
V O L T S : 3 9 . 5 V
O K

ATS250 - Operator Manual
ATS 250
© 2019. Advance Welding 11
Welding modes:
Bar Code No
Manual Yes
Data Logging No
Connect the welding cable to the tting and the screen will show
Enter the welding time and press the OK button.
The welding voltage can now be entered. This will default to 39.5 volts. Use the up and
down arrows to select the required voltage and press the OK button to select.
The screen will display the following:
Conrm that the pipe and tting have been correctly prepared and start the welding by
pressing the START button.
C O N N E C T F I T T I N G
O K : M E N U
S U P P L Y : 2 4 0 V 5 0 H Z
M A N U A L W E L D I N G + 2 0 C
4 0 S 3 9 . 5 V
S C R A P E D & C L A M P E D ?
P R E S S S T A R T
M A N U A L W E L D I N G
T I M E : _ _ _ _ S
V O L T S : 3 9 . 5 V
O K

ATS250 - Operator Manual
ATS 250
© 2019. Advance Welding 12
During the welding, the following screen will be displayed:
The elapsed time will count up from zero to the set weld time.
The welding voltage and current will be displayed to allow the operator to conrm the
welding process is correct.
When the weld is complete, the following screen will be displayed:
The cooling time will now count up. This is to help the operator know when the weld
ended and will continue to count up until the lead is disconnected from the tting.
Disconnect the lead and the unit will reset back to the “Connect Fitting” message.
W E L D N U M B E R : 2 3 5
W E L D T I M E : 4 0 S
E L A P S E D : 1 2 S
3 9 . 5 3 V 5 . 1 4 A
C O O L I N G T I M E : 0 4 : 5 1
D I S C O N N E C T L E A D T O
C O M P L E T E W E L D 2 3 5

ATS250 - Operator Manual
ATS 250
© 2019. Advance Welding 13
Welding modes:
Bar Code Yes
Manual Yes
Data Logging No
Connect the welding cable to the tting and the screen will show
Read the bar code on the tting. If the code is read correctly then a message will be
displayed saying “Read OK”. Next, the resistance of the tting will be measured and
checked to the bar code data. If they match the message “Fitting Resistance Veried OK”
will be shown. This is to make sure the correct bar code for the correct tting is read.
The display will now show
Conrm that the pipe and tting have been correctly prepared and start the welding by
pressing the START button, or by reading the bar code for a second time.
C O N N E C T F I T T I N G
O K : M E N U
S U P P L Y : 2 4 0 V 5 0 H Z
G F S A D D L E + 2 2 C
1 2 5 M M 8 0 S 4 0 . 0 V
S C R A P E D & C L A M P E D ?
P R E S S S T A R T
F U S I O N B A R C O D E
R E A D C O D E
N U M B E R S M A N U A L V / T
ATS 250 BASIC Welding

ATS250 - Operator Manual
ATS 250
© 2019. Advance Welding 14
During the welding, the following screen will be displayed:
The elapsed time will count up from zero to the set weld time.
The welding voltage and current will be displayed to allow the operator to conrm the
welding process is correct.
When the weld is complete, the following screen will be displayed:
The cooling time will now count up. This is to help the operator know when the weld
ended and will continue to count up until the lead is disconnected from the tting.
Disconnect the lead and the unit will reset back to the “Connect Fitting” message.
NUMBER ENTRY
If the bar code pen does not work or the bar code label on the tting has been
damaged, then the barcode numbers can be manually entered. On the “Read Code”
screen, press the UP arrow button. The following screen will be displayed:
W E L D N U M B E R : 2 3 5
W E L D T I M E : 8 0 S
E L A P S E D : 2 2 S
4 0 . 0 1 V 5 . 1 4 A
C O O L I N G T I M E : 0 4 : 5 1
D I S C O N N E C T L E A D T O
C O M P L E T E W E L D 2 3 5
F U S I O N D I G I T S
____________________
____
O K

ATS250 - Operator Manual
ATS 250
© 2019. Advance Welding 15
Many bar code labels show the 24 numbers underneath the bar code stripes. Read
these from the label and enter them. When all numbers have been entered, press the
OK button.
The display will now show
Conrm that the pipe and tting have been correctly prepared and start the welding
by pressing the START button.
MANUAL ENTRY
If the bar code pen does not work or the bar code label on the tting has been
damaged and there are no numbers shown on the label, then the time and voltage
can be entered manually. On the “Read Code” screen, press the DOWN arrow button.
The following screen will be displayed:
Enter the welding time and press the OK button. The welding voltage can now be
entered. This will default to 39.5 volts. Use the up and down arrows to select the
required voltage and press the OK button to select.
The screen will display the following:
Conrm that the pipe and tting have been correctly prepared and start the welding
by pressing the START button.
G F S A D D L E + 2 2 C
1 2 5 M M 8 0 S 4 0 . 0 V
S C R A P E D & C L A M P E D ?
P R E S S S T A R T
M A N U A L W E L D I N G
T I M E : _ _ _ _ S
V O L T S : 3 9 . 5 V
O K
M A N U A L W E L D I N G + 2 0 C
8 0 S 3 9 . 5 V
S C R A P E D & C L A M P E D ?
P R E S S S T A R T

ATS250 - Operator Manual
ATS 250
© 2019. Advance Welding 16
Welding modes:
Bar Code Yes
Manual Yes
Data Logging Yes
Connect the welding cable to the tting and the screen will show
Read the bar code on the tting. If the code is read correctly then a message will be
displayed saying “Read OK”. Next, the resistance of the tting will be measured and
checked to the bar code data. If they match the message “Fitting Resistance Veried OK”
will be shown. This is to make sure the correct bar code for the correct tting is read.
The display will now show
Conrm that the pipe and tting have been correctly prepared and start the welding by
pressing the START button, or by reading the bar code for a second time.
C O N N E C T F I T T I N G
S T O P : D A T A L O G I N F O
O K : M E N U
S U P P L Y : 2 4 0 V 5 0 H Z
G F S A D D L E + 2 2 C
1 2 5 M M 8 0 S 4 0 . 0 V
S C R A P E D & C L A M P E D ?
P R E S S S T A R T
F U S I O N B A R C O D E
R E A D C O D E
N U M B E R S M A N U A L V / T
ATS 250 EXTRA Welding

ATS250 - Operator Manual
ATS 250
© 2019. Advance Welding 17
During the welding, the following screen will be displayed:
The elapsed time will count up from zero to the set weld time.
The welding voltage and current will be displayed to allow the operator to conrm the
welding process is correct.
When the weld is complete, the following screen will be displayed:
The cooling time will now count up. This is to help the operator know when the weld
ended and will continue to count up until the lead is disconnected from the tting.
Disconnect the lead and the unit will reset back to the “Connect Fitting” message.
NUMBER ENTRY
If the bar code pen does not work or the bar code label on the tting has been
damaged, then the barcode numbers can be manually entered. On the “Read Code”
screen, press the UP arrow button. The following screen will be displayed:
W E L D N U M B E R : 2 3 5
W E L D T I M E : 8 0 S
E L A P S E D : 2 2 S
4 0 . 0 1 V 5 . 1 4 A
C O O L I N G T I M E : 0 4 : 5 1
D I S C O N N E C T L E A D T O
C O M P L E T E W E L D 2 3 5
F U S I O N D I G I T S
____________________
____
O K

ATS250 - Operator Manual
ATS 250
© 2019. Advance Welding 18
Many bar code labels show the 24 numbers underneath the bar code stripes. Read
these from the label and enter them. When all numbers have been entered, press the
OK button.
The display will now show
Conrm that the pipe and tting have been correctly prepared and start the welding
by pressing the START button.
MANUAL ENTRY
If the bar code pen does not work or the bar code label on the tting has been
damaged and there are no numbers shown on the label, then the time and voltage
can be entered manually. On the “Read Code” screen, press the DOWN arrow button.
The following screen will be displayed:
Enter the welding time and press the OK button. The welding voltage can now be
entered. This will default to 39.5 volts. Use the up and down arrows to select the
required voltage and press the OK button to select.
The screen will display the following:
Conrm that the pipe and tting have been correctly prepared and start the welding
by pressing the START button.
G F S A D D L E + 2 2 C
1 2 5 M M 8 0 S 4 0 . 0 V
S C R A P E D & C L A M P E D ?
P R E S S S T A R T
M A N U A L W E L D I N G
T I M E : _ _ _ _ S
V O L T S : 3 9 . 5 V
O K
M A N U A L W E L D I N G + 2 0 C
8 0 S 3 9 . 5 V
S C R A P E D & C L A M P E D ?
P R E S S S T A R T

ATS250 - Operator Manual
ATS 250
© 2019. Advance Welding 19
DATA LOGGING
If data logging information is required, on the “Connect Fitting Screen” press the
STOP button. The screen will show:
Enter the Operator Name press the OK button. The screen will now show:
Enter the Location and press the OK button. The screen will now show:
Enter the Job Reference and press the OK button. The screen will now show:
Continue with the welding process by connecting the welding cable to the tting.
C H A N G E O P E R A T O R N A M E
__________________
O K
C H A N G E L O C A T I O N
__________________
O K
C H A N G E J O B R E F E R E N C E
__________________
O K
C O N N E C T F I T T I N G
S T O P : D A T A L O G I N F O
O K : M E N U
S U P P L Y : 2 4 0 V 5 0 H Z

ATS250 - Operator Manual
ATS 250
© 2019. Advance Welding 20
Options Menu
When the display shows the “Connect Fitting” message, pressing the OK button will
enter the options menu.
Press OK and the display will show:
Use the up and down arrows to scroll through the options. When the required option
is shown press the left or right arrow to select it.
For additional security, some options require a Supervisor or Workshop password to
access them. This stops the operator adjusting features without permission. When
asked for a password, the following screen will be shown:
Enter the Supervisor Password. Use the up and down arrows to scroll through A to Z
and then use the left and right arrows to move between positions. When the correct
password has been entered press the OK button.
The Supervisor and Workshop passwords are available on request.
Important! Not all options are available on all models of ATS250.
Welding. Operator
C O N N E C T F I T T I N G
S T O P : D A T A L O G I N F O
O K : M E N U
S U P P L Y : 2 4 0 V 5 0 H Z
W E L D I N G
D A T A D O W N L O A D
S Y S T E M O P T I O N S
S U P E R V I S O R P A S S W O R D
_ _ _ _ O K = C O N T I N U E
S T O P = C A N C E L
