Advance Tabco EC Series User manual

CHECK FOR CONCEALED DAMAGE
FILE CLAIM WITH DELIVERING FREIGHT CARRIER
Installation Instructions For
“EC” SERIES DROP-IN SINKS
DI-1-5SP-EC
DI-3-10-EC
DI-2-10-EC
DI-1-10SP-EC
Equipment that includes a faucet may expose you to chemicals, including lead,
that are known to the State of California to cause cancer or birth defects
or other reproductive harm. For more Info.,visit www.p65warnings.ca.gov.
WARNING:

2
STEP 1
• Remove all contents from carton. (NOTE: Check for concealed
damage - Notify Carrier of any damages immediately)
STEP 2
• Cut opening at desired location on countertop (See Chart on Back
Page). NOTE: Cut 1” radius at four intersecting corners.
• Place Drop-In Sink into opening. Mark
location of four threaded studs at each
corner (Figure 1). Remove Drop-In Sink
and drill four 3/8” diameter holes.
See Back Page For Cut-Out Chart
• NOTE: BEFORE CUTTING COUNTER
TOP, VERIFY CUTOUT DIMENSIONS!
REMEMBER: MEASURE TWICE,
CUT ONCE!
Figure 1
Contents:
(1) Drop-In Sink
(1) Gooseneck 4” O.C. Deck Mount Faucet
(1 OR 2) K-6 Basket Drain(s)
(4) Under-Counter Mounting Brackets
(4) Nuts
Material Required:
• Silicone Sealant
• Plumbing Putty
Recommended Safety
Materials:
• Safety Glasses
• Work Gloves
Tools Required:
• Ruler or Tape Measure
• Pencil
• Saber Saw or Jig Saw
• 1/4” and 3/8” Drill Bit
• Adjustable Wrench

3
STEP 3
• Install Drain(s) through Sink Body. Apply a bead of Plumber’s Putty on
the inside between the Drain Flange and Sink. Follow steps below...
Removable Aerator
Plastic Gasket
Rubber Washer
Metal Washer
Lock Nut
Supply Line
C
L
STEP 4
• Install Faucet (as shown).
1. Add Rubber Washer 2. Add Fiber Washer 3. Screw on Die Cast
Nut and Tighten

Edgewood, New York 11717-8380 ©ADVANCE TABCO SEPTEMBER 2018
STEP 5
• Apply a bead of Silicone Sealant
along edge of cut out (Figure 2).
• Insert Drop-In Sink into cut-out
while lining up the four holes with
the threaded studs and push
down into the bead of Silicone.
STEP 6
• From the underside, place each
bracket on an angle and tighten
each nut on all four threaded
studs. (Figure 3).
• DO NOT OVERTIGHTEN!
• Connect drain and faucet supply.
• Remove Aerator & flush line.
• Replace Aerator
Figure 3
Figure 2
For Further Assistance
Contact Customer Service at:
800-645-3166
or
[email protected]
MODEL Left To Right Front To Back
DI-5-SP-EC 10 1/2” 16 3/4”
DI-1-10SP-EC 10 1/2” 16 3/4”
DI-2-10-EC 23 1/2” 17 1/2”
DI-3-10-EC 35 1/2” 17 1/2”
CUT-OUT SIZES
