Advanced micro peripherals DVICOMP-IS Quick user guide

HARDWARE
REFERENCE
MANUAL
DVICOMP-IS
DVI to Composite Scan Converter Board
Document version: A.01

Definitions
AMP and Advanced Micro Peripherals are the trading names for Advanced Micro Peripherals Inc. and Advanced Micro Peripherals Ltd.
Disclaimer
This document contains information on a new product. Specifications and information herein are subject to change without notice.
AMP reserves the right to make changes to any products herein to improve functioning and design. Although the information in this
document has been carefully reviewed and is believed to be reliable, AMP does not assume any liability arising out of the application
or use of any product or circuit described herein. Nothing in this document is to be taken as a license to operate under or a
recommendation to infringe any patents.
AMP does not recommend the use of any of its products in life support applications wherein a failure or malfunction of the product
may directly threaten life or injury. The user of AMP products in life support applications assumes all risk of such use and indemnifies
AMP against all damages. All information contained in this document is proprietary to AMP and may not be reproduced or disclosed
to any third parties without the written consent of AMP. The circuit design, EPLD programs and artworks are copyright AMP 2008.
The information contained in this document has been carefully checked and is believed to be reliable. However, Advanced Micro
Peripherals Ltd (AMP) makes no guarantee or warranty concerning the accuracy of said information and shall not be responsible for
any loss or damage of whatever nature resulting from the use of, or reliance upon, it. AMP does not guarantee that the use of any
information herein will not infringe upon the patent, trademark, copyright, or other rights of third parties, and no patent or other
license is implied hereby
AMP reserves the right to make changes in the products or specifications, or both, presented in this document at any time and
without notice.
Warranty
This product is supplied with a 1 year limited warranty. The product warranty covers failure of any AMP manufactured product
caused by manufacturing defects. AMP will make all reasonable effort to repair the product or replace it with an identical variant.
AMP reserves the right to replace the returned product with an alternative variant or an equivalent fit, form and functional product.
Trademarks
Tiny486, Tiny486, Tiny586DX, Tiny786LP, Mobile786EBX, Tiny886, Micro886, VAC104, VAC104plus , VAC2000, VAC2000, The
Embedded Video Experts are trademarks of Advanced Micro Peripherals.
All other trademarks recognized.
Revision History
Document version
Date
Comments
Approved
A.00
1st September 2017
Initial version derived from VGASTANAG
A.01
6th February 2018
Updated power figures

DVICOMP-IS Hardware Reference Manual
© 2018 Advanced Micro Peripherals
Document version A.01
3
Contents
1: Introduction ............................................................................................. 4
Features........................................................................................................................................................... 5
DVICOMP-IS ‘at a glance’ ............................................................................................................................... 6
Technical specification ..................................................................................................................................... 7
Functional summary......................................................................................................................................... 9
Ordering information ...................................................................................................................................... 10
Anti-static handling......................................................................................................................................... 10
RoHS compliance .......................................................................................................................................... 10
2: Installation............................................................................................. 11
System requirements......................................................................................................................................11
Jumpers and connectors................................................................................................................................ 12
Cable set........................................................................................................................................................ 16
A: Contacting AMP...................................................................................... 17

© 2018 Advanced Micro Peripherals
Document version A.01
4
1:
Introduction
The DVICOMP-IS is a scan converter module that accepts progressive scan DVI
signals at resolutions up to 1280 x 1024 from any standard graphics card for
conversion to NTSC or PAL composite. The module is a standard PCI-104 form
factor module.
The DVICOMP-IS is an intelligent stand-alone device with its own on-board CPU
and does not require device driver software. It can however be mounted on the
PCI-104 stack for mechanical convenience without consuming host CPU
resources.
The DVICOMP-IS also features a mini PCI socket that enables an AMP video
codec module to be hosted on a PC/104- Plus or PCI-104 stack.
AMP can provide custom configurations (subject to a minimum order quantity) for the
DVICOMP. Please contact our Sales team (see A: Contacting Advanced Micro
Peripherals, page 17) to discuss your requirements.

1: Introduction DVICOMP-IS Hardware Reference Manual
© 2018 Advanced Micro Peripherals
Document version A.01
1
5
Features
▪Converts computer DVI to composite output
▪Supports graphics display resolutions of 800 x 600, 1024 x 768 and 1280 x
1024
▪Operating modes:
PAL 625 lines @ 25 fps
NTSC/RS-170A 525 lines @ 30 fps
▪Standard PCI-104 form factor
▪Stand-alone operation and O/S-neutral
▪Single +5V power supply
▪Mini PCI expansion socket
▪Standard 3.8" x 4.5" PCI-104 stackable card.

1: Introduction DVICOMP-IS Hardware Reference Manual
© 2018 Advanced Micro Peripherals
Document version A.01
1
6
DVICOMP-IS ‘at a glance’
Optional mini PCI expansion
Composite output
Factory Use Only
Factory Use Only
LEVEL1 –PCI Stack Level
TMDS input
Power input
32 bit PCI connector

1: Introduction DVICOMP-IS Hardware Reference Manual
© 2018 Advanced Micro Peripherals
Document version A.01
1
7
Technical specification
DVI input: Standard progressive scan DVI input supporting
resolutions of 800x600, 1024x768 and 1280 x 1024.
Automatic detection of input resolution.
Composite output: 625 lines @ 25 fps (PAL option)
525 lines @ 30 fps (NTSC / RS-170A option)
(Note: fps means ‘frames per second’. Double this for
fields per second)
75Ω signal output
PCI-104: 133MB/sec bus bandwidth.
3.3v Add-in Module - compliant with 3.3V PCI-104 bus
signaling.
Jumper-selectable PCI-104 stack level.
mini PCI: Optional connector for mini PCI module
Power: Single +5V @ 1.1A (max).
Environmental: 0ºC to 60ºC.
-40ºC to +85ºC (-EXT option).
Physical size: Standard 3.8" x 4.5" PCI-104 stackable card form factor
(with I/O extension area).

1: Introduction DVICOMP-IS Hardware Reference Manual
© 2018 Advanced Micro Peripherals
Document version A.01
1
8

1: Introduction DVICOMP-IS Hardware Reference Manual
© 2018 Advanced Micro Peripherals
Document version A.01
1
9
Functional summary
Video Scaling
The DVICOMP-IS provides automatic vertical and horizontal up-scaling and
down-scaling of the input video, allowing resolutions of up to 1280x1024 to be
displayed on a 625 line (PAL) or 525 line (NTSC) video monitor.
Video Encoder
The video encoder features composite output with sync.
Host interface
The core functionality of the DVICOMP-IS is completely autonomous to the
host PCI bus. The DVICOMP-IS is factory configured for NTSC or PAL output
operation and will auto-detect the input resolution prior to performing the
rescaling.
The PCI host bus is connected directly only to the [optional] mini PCI socket
and enables a range of mini PCI modules to be fitted to the board. The
DVICOMP-IS is specifically designed to accommodate an AMP video codec
module such as the microMPEG4, microMPEG-D4 or microH264-D4. The PCI
connector is also used to provide the power supply to the board. Alternatively,
input power may be connected via the screw terminal block.
Please note: mini PCI is specified for 3.3v operation only and therefore the
DVICOMP-IS is a 3.3v add-in card when used with a mini PCI module.

1: Introduction DVICOMP-IS Hardware Reference Manual
© 2018 Advanced Micro Peripherals
Document version A.01
1
10
Ordering information
The following part number(s) can be used when ordering:
DVICOMP-IS-P PAL output
DVICOMP-IS-N NTSC/RS-170A output
DVICOMP-IS-P-EXT PAL output (-40°C to +85°C)
DVICOMP-IS-N-EXT NTSC output (-40°C to +85°C)
Cable-ST-MMCX-TO-BNC-S Composite output cable (MMCX to BNC)
Cable-STANAG/TMDS TMDS input cable (flat flex to DVI)
Anti-static handling
The board(s) supplied contain electrostatic components that are susceptible to
permanent damage from electrostatic discharge (static electricity). To prevent
electrostatic discharge, the boards are supplied in anti-static packaging.
When handling a board, observe the following anti-static precautions to alleviate
risk of damage:
▪Remove the board(s) from the packaging only when you are working on an
anti-static, earthed surface and wearing an anti-static wrist strap.
▪Retain the anti-static packaging that the board(s) were supplied in. If you
remove a board from a system, store it in this packaging.
RoHS compliance
The European RoHS Directive (Restriction on the use of certain Hazardous
Substances –Directive 2002/95/EC) limits the amount of six specific substances
within the composition of the product. The DVICOMP-IS is RoHS compliant.

© 2018 Advanced Micro Peripherals
Document version A.01
11
2:
Installation
System requirements
Computer form factor PC/104 -Plus / PCI-104 compliant 3.3v bus signaling.
Bus 32 bit PC/104 -Plus
Operating system The DVICOMP-IS is self configuring and does not
required any intervention from a host CPU.

2: Installation DVICOMP-IS Hardware Reference Manual
© 2018 Advanced Micro Peripherals
Document version A.01
2
12
Jumpers and connectors
The following diagram shows the location of the jumpers and connectors available
on the DVICOMP-IS:
MINI1
Factory Use Only
Factory Use Only
LEVEL1
TMDS
PWR
PCI1
COMP

2: Installation DVICOMP-IS Hardware Reference Manual
© 2018 Advanced Micro Peripherals
Document version A.01
2
13
Conventions
The following pages provide information about these jumpers and connectors. All
illustrations on these pages are shown in the same orientation as the photograph
above, unless otherwise stated.
The following table explains the conventions adopted when specifying jumper
settings:
Symbol
Explanation
Jumper is fitted.
Jumper is not fitted.
COMP –Composite output
The MMCX connector is used to provide the composite output.
Connector
Signal
COMP
Composite output
TMDS –DVI compatible (TMDS) input connected via 30-way flat flex cable
Pin
Signal
Pin
Signal
1
GND
2
Reserved
3
GND
4
Reserved
5
GND
6
GND
7
TX2-
8
TX2+
9
TX2/4 Shield
10
TX4-
11
TX4+
12
DDC CLK
13
DDC DATA
14
GND
15
TX1-
16
TX1+
17
TX1/3 Shield
18
TX3-
19
TC3+
20
Reserved
21
GND
22
GND

2: Installation DVICOMP-IS Hardware Reference Manual
© 2018 Advanced Micro Peripherals
Document version A.01
2
14
23
TX0-
24
TX0+
25
TX0/5 Shield
26
TX5-
27
TX5+
28
TXC Shield
29
TXC+
30
TXC-
Note: This connector is compatible with the TMDS output of the VAC2000 board.
PWR –Auxiliary power input (may also be used to supply power to the stack)
Pin
Signal
1
Not connected
2
GND
3
GND
4
+5v
PCI1 - PC/104 -Plus bus.
Standard 32-bit PCI-104 bus PCI Rev 2.1 compliant, 3.3V operation.
The standard PCI bus signals are only connected to the mini PCI socket. Since
mini PCI is defined as 3.3v only (not 5v compliant), the DVICOMP-IS may only
serve as a 3.3v Add-in card when fitted with a module.
MINI1- mini PCI Type III 32-bit PCI (3.3V operation)
Standard 3.3v mini PCI bus expansion connector.
LEVEL1 –links 1-2 and 3-4
Used for IDSEL card selection.
The setting of the first two links on the LEVEL header determine the logical stack
position of the DVICOMP-IS on the PCI-104 stack. This setting routes the
appropriate IDSEL, PCICLK, REQ and GNT signals to the mini PCI card hosted on
the DVICOMP-IS card.

2: Installation DVICOMP-IS Hardware Reference Manual
© 2018 Advanced Micro Peripherals
Document version A.01
2
15
The following configurations are valid.
Jumpers
IDSEL
PCICLK
REQ/GNT
IDSEL0
PCICLK0
0/0
IDSEL1
PCICLK1
1/1
IDSEL2
PCICLK2
2/2
IDSEL3
PCICLK3
2/2
NOTE:
WHEN USING MULTIPLE DVICOMP-IS DEVICES TO HOST MULTIPLE MINIPCI CARDS IN A SYSTEM,
EACH CARD MUST HAVE DIFFERENT REQ/GNT PAIR DEPENDING ON THE LEVEL OF THE DEVICE
ON THE PCI-104 STACK.
Default setting:

2: Installation DVICOMP-IS Hardware Reference Manual
© 2018 Advanced Micro Peripherals
Document version A.01
2
16
LEVEL1 –links 5-6 and 7-8
Used for PCI card interrupt selection.
The settings of the third and fourth links on the LEVEL header determine which of
the four PCI interrupts service the mini PCI module hosted on the DVICOMP-IS
card.
The following configurations are valid.
Jumpers
Interrupt
INTA
INTB
INTC
INTD
Cable set
The DVICOMP-IS may be supplied with a DVI breakout board that plugs into the
TMDS connector via a flat flex cable (part CABLE-STANAG/TMDS).
A composite output cable may also be included in the form of a BNC to MMCX co-
axial lead (part CABLE-ST-MMCX-TO-BNC-S). The MMCX connector interfaces
with the COMP header on the board.
Default setting:

© 2018 Advanced Micro Peripherals
Document version A.01
17
A:
Contacting AMP
Sales
AMP’s sales team is always available to assist you in choosing the board that best
meets your requirements. Contact your local sales office or hotline.
Sales office US
Sales office UK
Advanced Micro Peripherals Inc.
100 Church Street, Suite 808
New York
NY, 10007
USA
Tel: [phone]
Fax: [phone]
E-mail: [e-mail]
Web: www.amp-usa.com
Advanced Micro Peripherals Ltd.
1 Harrier House, Sedgeway Business Park
Witchford, Cambridge,
CB6 2HY
United Kingdom
Tel: [phone]
Fax: [phone]
E-mail: [e-mail]
Web: www.ampltd.com
Technical support
Comprehensive technical information is available on our websites (see above).
If you can’t find the information or solution you require, AMP has a team of
technical support engineers / embedded video experts available to provide a
quick and free response to your technical queries.
Please submit your technical support query to the appropriate email address:
Technical support US
Technical support UK
E-mail: [e-mail]
E-mail: [e-mail]
