StarTech.com PEX4S553B User manual

Manual Revision: 06/10/2021
Forthemostup-to-dateinformation,pleasevisit:www.startech.com
DE: Bedienungsanleitung - de.startech.com
FR: Guide de l'utilisateur - fr.startech.com
ES: Guía del usuario - es.startech.com
IT: Guida per l'uso - it.startech.com
NL: Gebruiksaanwijzing - nl.startech.com
PT: Guia do usuário - pt.startech.com
PEX4S553B
4 Port RS232 PCI Express Serial Card w/
Breakout Cable
*actualproduct mayvary fromphotos

Instruction Manual
FCC Compliance Statement
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation.This equipment generates,
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there
is no guarantee that interference will not occur in a particular installation. If this equipment
does cause harmful interference to radio or television reception, which can be determined by
turning the equipment o and on, the user is encouraged to try to correct the interference by
one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent from that to which the receiver
is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Use of Trademarks, Registered Trademarks, and other Protected Names and
Symbols
This manual may make reference to trademarks, registered trademarks, and other
protected names and/or symbols of third-party companies not related in any way to
StarTech.com. Where they occur these references are for illustrative purposes only and do not
represent an endorsement of a product or service by StarTech.com, or an endorsement of the
product(s) to which this manual applies by the third-party company in question. Regardless
of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby
acknowledges that all trademarks, registered trademarks, service marks, and other protected
names and/or symbols contained in this manual and related documents are the property of
their respective holders.

Instruction Manual
i
Table of Contents
Introduction............................................................................................1
Packaging Contents ................................................................................................................................. 1
System Requirements.............................................................................................................................. 1
Installation ..............................................................................................1
Hardware Installation .............................................................................................................................. 1
Driver Installation...................................................................................................................................... 2
Verifying Installation................................................................................................................................ 2
Specications..........................................................................................3
Technical Support ..................................................................................4
Warranty Information............................................................................4

Instruction Manual
1
Introduction
Packaging Contents
• PCI Express serial card
• DB9 Breakout Cable
• Full Prole bracket
• Driver CD
• Instruction Manual
System Requirements
• PCI Express enabled computer with available PCIe slot
• Microsoft®Windows®98SE/2000/XP/Server 2003/Vista/Server 2008 R2/7 (32/64 bit),
Windows XP Embedded/CE5.0/CE6.0,
• macOS®10.4/10.5,
• Linux®kernel 2.6.11 and above
Installation
Hardware Installation
1. Turn your computer o and any peripherals connected to the computer (i.e. Printers,
external hard drives, etc.). Unplug the power cable from the rear of the power
supply on the back of the computer.
2. Remove the cover from the computer case.
3. Locate an open PCI Express slot and remove the metal cover plate on the rear of the
computer case. Note that this card will work in PCI Express slots of additional lanes
(i.e. x4, x8 or x16 slots)
4. Insert the card into the open PCI Express slot and screw the bracket to the rear of
the case.
5. Place the cover back onto the computer.
6. Insert the power cable into the socket on the power supply.

Instruction Manual
2
Driver Installation
Windows 2000/XP/Server 2003
1. When the Found New Hardware wizard appears on the screen, insert the Driver CD
into your CD-ROM drive. If you are prompted to connect to Windows Update, please
select the “No, not this time” option and click Next.
2. Select the option “Install Drivers Automatically (Recommended)”and then click the
Next button.
3. Windows should now start searching for the drivers. Once this has completed, click
the Finish button.
Windows Vista/7
1. When the Found New Hardware window appears on the screen, click on the“Locate
and install drivers software (Recommended)” option. If prompted to search online,
select the “Don’t search online” option.
2. When prompted to insert the disc, insert the Driver CD that came with the card, into
your CD-ROM drive and Windows will automatically proceed to search the CD.
3. If a Windows Security dialog window appears, click the “Install this driver software
anyway” option to proceed.
4. Once the driver is installed, click the Close button.
Verifying Installation
Windows 2000/XP/Server 2003/Vista/7
From the main desktop, right-click on “My Computer” (“Computer” in Vista/7), then
select Manage. In the new Computer Management window, select Device Manager
from the left window panel.
Double-click on the “Ports (COM & LPT)” option. The appropriate number of additional
COM ports should be visible. The port(s) are ready to connect to new devices.

Instruction Manual
3
Specications
Bus Interface PCI Express 1.0a
(x1 slot connector)
Form Factor Full/Low Prole
Chipset ID ASIX MosChip MCS9904CV-AA
External Connectors 4 x DB9 male
(via included breakout cable)
UART 16C550
Serial Protocol RS-232
Maximum Data Transfer Rate 250 Kbps (per port)
Operating Temperature 0°C ~ 70°C (32°F ~ 158°F)
Storage Temperature -40°C ~ 85°C (-40°F ~ 185°F)
Humidity 5% ~ 85% RH
Compatible Operating Systems
Windows 98SE/2000/XP/Server 2003/
Vista/Server 2008 R2/7 (32/64-bit),
Windows XP Embedded/
POS Ready 2009/
Embedded Search 2009/
CE 5.0/CE 6.0
Mac OS 10.4/10.5,
Linux Kernel 2.6.11 and above

Instruction Manual
4
Technical Support
StarTech.com’s lifetime technical support is an integral part of our commitment to
provide industry-leading solutions. If you ever need help with your product, visit
www.startech.com/support and access our comprehensive selection of online tools,
documentation, and downloads.
For the latest drivers/software, please visit www.startech.com/downloads
Warranty Information
This product is backed by a lifetime warranty.
In addition, StarTech.com warrants its products against defects in materials
and workmanship for the periods noted, following the initial date of purchase.
During this period, the products may be returned for repair, or replacement with
equivalent products at our discretion. The warranty covers parts and labor costs only.
StarTech.com does not warrant its products from defects or damages arising from
misuse, abuse, alteration, or normal wear and tear.
Limitation of Liability
In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their
ocers, directors, employees or agents) for any damages (whether direct or indirect,
special, punitive, incidental, consequential, or otherwise), loss of prots, loss of business,
or any pecuniary loss, arising out of or related to the use of the product exceed the
actual price paid for the product. Some states do not allow the exclusion or limitation
of incidental or consequential damages. If such laws apply, the limitations or exclusions
contained in this statement may not apply to you.
