Advantech-DLoG TREK-303 User manual

User Manual
TREK-570/TREK-303
In-Vehicle Computing Box / 7"
Smart Display

TREK-570/303 User Manual ii
Copyright
The documentation and the software included with this product are copyrighted 2015
by Advantech Co., Ltd. All rights are reserved. Advantech Co., Ltd. reserves the right
to make improvements in the products described in this manual at any time without
notice. No part of this manual may be reproduced, copied, translated or transmitted
in any form or by any means without the prior written permission of Advantech Co.,
Ltd. Information provided in this manual is intended to be accurate and reliable. How-
ever, Advantech Co., Ltd. assumes no responsibility for its use, nor for any infringe-
ments of the rights of third parties, which may result from its use.
Acknowledgements
Intel and Atom are trademarks of Intel Corporation.
Microsoft Windows and MS-DOS is registered trademarks of Microsoft Corp.
All other product names or trademarks are properties of their respective owners.
Product Warranty (2 years)
Advantech warrants to you, the original purchaser, that each of its products will be
free from defects in materials and workmanship for two years from the date of pur-
chase.
This warranty does not apply to any products which have been repaired or altered by
persons other than repair personnel authorized by Advantech, or which have been
subject to misuse, abuse, accident or improper installation. Advantech assumes no
liability under the terms of this warranty as a consequence of such events.
Because of Advantech’s high quality-control standards and rigorous testing, most of
our customers never need to use our repair service. If an Advantech product is defec-
tive, it will be repaired or replaced at no charge during the warranty period. For out-
of-warranty repairs, you will be billed according to the cost of replacement materials,
service time and freight. Please consult your dealer for more details.
If you think you have a defective product, follow these steps:
1. Collect all the information about the problem encountered. (For example, CPU
speed, Advantech products used, other hardware and software used, etc.) Note
anything abnormal and list any onscreen messages you get when the problem
occurs.
2. Call your dealer and describe the problem. Please have your manual, product,
and any helpful information readily available.
3. If your product is diagnosed as defective, obtain an RMA (return merchandize
authorization) number from your dealer. This allows us to process your return
more quickly.
4. Carefully pack the defective product, a fully-completed Repair and Replacement
Order Card and a photocopy proof of purchase date (such as your sales receipt)
in a shippable container. A product returned without proof of the purchase date
is not eligible for warranty service.
5. Write the RMA number visibly on the outside of the package and ship it prepaid
to your dealer.
Part No. Edition 1
Printed in Taiwan January 2015

iii TREK-570/303 User Manual
Declaration of Conformity
CE
This product has passed the CE test for environmental specifications. Test conditions
for passing included the equipment being operated within an industrial enclosure. In
order to protect the product from being damaged by ESD (Electrostatic Discharge)
and EMI leakage, we strongly recommend the use of CE-compliant industrial enclo-
sure products.
FCC Class B
Note: This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installa-
tion. This equipment generates, uses and can radiate radio frequency energy and, if
not installed and used in accordance with the instructions, may cause harmful inter-
ference to radio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause harmful interfer-
ence to radio or television reception, which can be determined by turning the equip-
ment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
Technical Support and Assistance
1. Visit the Advantech web siteat http://support.advantech.com where you can find
the latest information about the product.
2. Contact your distributor, sales representative, or Advantech's customer service
center for technical support if you need additional assistance. Please have the
following information ready before you call:
–Product name and serial number
–Description of your peripheral attachments
–Description of your software (operating system, version, application software,
etc.)
–A complete description of the problem
–The exact wording of any error messages

TREK-570/303 User Manual iv
Warnings, Cautions and Notes
Document Feedback
To assist us in making improvements to this manual, we would welcome comments
and constructive criticism. Please send all such - in writing to: support@advan-
tech.com
Packing List
Before setting up the system, check that the items listed below are included and in
good condition. If any item does not accord with the table, please contact your dealer
immediately.
TREK-570 In-Vehicle Computing Box
USB/HDMI cable clip
Power cable
Vehicle I/O cable (Dual CAN/J1708, RS-485) in/CAN cable
Generic I/O Cable
Antenna (base on order configuration request)
Warning! Warnings indicate conditions, which if not observed, can cause personal
injury!
Caution! Cautions are included to help you avoid damaging hardware or losing
data. e.g.
There is a danger of a new battery exploding if it is incorrectly installed.
Do not attempt to recharge, force open, or heat the battery. Replace the
battery only with the same or equivalent type recommended by the man-
ufacturer. Discard used batteries according to the manufacturer's
instructions.
Note! Notes provide optional additional information.

v TREK-570/303 User Manual
Ordering Information
Safety Instructions
1. Read these safety instructions carefully.
2. Keep this User Manual for later reference.
3. Disconnect this equipment from any AC outlet before cleaning. Use a damp
cloth. Do not use liquid or spray detergents for cleaning.
4. For plug-in equipment, the power outlet socket must be located near the equip-
ment and must be easily accessible.
5. Keep this equipment away from humidity.
6. Put this equipment on a reliable surface during installation. Dropping it or letting
it fall may cause damage.
7. Do not leave this equipment in an environment unconditioned where the storage
temperature under -40° C or above 80° C, it may damage the equipment.
Operating temperature -30° C ~70° C
8. The openings on the enclosure are for air convection. Protect the equipment
from overheating. DO NOT COVER THE OPENINGS.
9. Make sure the voltage of the power source is correct before connecting the
equipment to the power outlet.
10. Position the power cord so that people cannot step on it. Do not place anything
over the power cord.The voltage and current rating of the cord should be greater
than the voltage and current rating marked on the product.
11. All cautions and warnings on the equipment should be noted.
12. If the equipment is not used for a long time, disconnect it from the power source
to avoid damage by transient overvoltage.
13. Never pour any liquid into an opening. This may cause fire or electrical shock.
14. Never open the equipment. For safety reasons, the equipment should be
opened only by qualified service personnel.
15. If one of the following situations arises, get the equipment checked by service
personnel:
The power cord or plug is damaged.
Liquid has penetrated into the equipment.
The equipment has been exposed to moisture.
The equipment does not work well, or you cannot get it to work according to
the user's manual.
The equipment has been dropped and damaged.
The equipment has obvious signs of breakage.
16. CAUTION: The computer is provided with a battery-powered real-time clock cir-
cuit. There is a danger of explosion if battery is incorrectly replaced. Replace
only with same or equivalent type recommended by the manufacture. Discard
P/N Description
TREK-570-00A0E TREK-570 Intel BYT E3826(2C,1.46GHz)Barebone
TREK-570-LWB7A0E TREK-570 w/LTE(EU)/GPS/WLAN/BT/WES7
TREK-570-LWB7B0E TREK-570 w/LTE(USA)/GPS/WLAN/BT/WES7

TREK-570/303 User Manual vi
used batteries according to the manufacturers instructions.
17. THE COMPUTER IS PROVIDED WITH CD DRIVES COMPLY WITH APPRO-
PRIATE SAFETY STANDARDS INCLUDING IEC 60825.
18. This device complies with Part 15 of the FCC rules. Operation is subject to the
following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.
19. CAUTION: Always completely disconnect the power cord from your chassis
whenever you work with the hardware. Do not make connections while the
power is on. Sensitive electronic components can be damaged by sudden
power surges.
20. CAUTION: Always ground yourself to remove any static charge before touching
the motherboard, backplane, or add-on cards. Modern electronic devices are
very sensitive to static electric charges. As a safety precaution, use a grounding
wrist strap at all times. Place all electronic components on a static-dissipative
surface or in a static-shielded bag when they are not in the chassis.
21. CAUTION: Any unverified component could cause unexpected damage. To
ensure the correct installation, please always use the components (ex. screws)
provided with the accessory box.
22. Caution text concerning lithium batteries:
23. "Rack Mount Instructions - The following or similar rack-mount instructions are
included with the installation instructions:
A) Elevated Operating Ambient - If installed in a closed or multi-unit rack
assembly, the operating ambient temperature of the rack environment may be
greater than room ambient. Therefore, consideration should be given to install-
ing the equipment in an environment compatible with the maximum ambient
temperature (Tma) specified by the manufacturer.
B) Reduced Air Flow - Installation of the equipment in a rack should be such that
the amount of air flow required for safe operation of the equipment is not com-
promised.
C) Mechanical Loading - Mounting of the equipment in the rack should be such
that a hazardous condition is not achieved due to uneven mechanical loading.
D) Circuit Overloading - Consideration should be given to the connection of the
equipment to the supply circuit and the effect that overloading of the circuits
might have on over current protection and supply wiring. Appropriate consider-
ation of equipment nameplate ratings should be used when addressing this con-
cern.

vii TREK-570/303 User Manual
E) Reliable Earthing - Reliable earthing of rack-mounted equipment should be
maintained. Particular attention should be given to supply connections other
than direct connections to the branch circuit (e.g. use of power strips)."
Safety Precaution - Static Electricity
Follow these simple precautions to protect yourself from harm and the products from
damage.
To avoid electrical shock, always disconnect the power from your system chas-
sis before you work on it. Don't touch any components on the main board or
other cards while the system is on.
Disconnect power before making any configuration changes. The sudden rush
of power as you connect a jumper or install a card may damage sensitive elec-
tronic components.
European Contact Information:
Advantech Europe GmbH Kolberger Straße 7
D-40599 Düsseldorf, Germany
Tel: [phone]
Fax: [phone]
Warning! 1. Input voltage rated: 6 ~32 Vdc.
2. Transport: carry the unit with both hands and handle with care.
3. Maintenance: to properly maintain and clean the surfaces, use only
approved products or clean with a dry applicator.
4. Turn off the power before inserting or removing mSATA and Mini-
PCIe card.

TREK-570/303 User Manual viii

ix TREK-570/303 User Manual
Contents
Chapter 1 General Information ............................1
1.1 Introduction ...............................................................................................2
1.2 General Specifications..............................................................................3
1.3 Dimensions ...............................................................................................5
Figure 1.1 TREK-570 dimensions................................................5
Chapter 2 System Setup.......................................7
2.1 A Quick Tour of the TREK-570 Computing Box........................................8
Figure 2.1 Front view of TREK-570.............................................8
Figure 2.2 Rear view of TREK-570..............................................8
2.2 Installation Procedures..............................................................................8
2.2.1 Connecting the Power Cord..........................................................8
Table 2.1: Pin Definition of Power Cord ......................................8
2.2.2 Power Connector (12/24V; 9 ~ 32V).............................................9
Figure 2.3 Power connector outlook............................................9
Table 2.2: Power Connector........................................................9
2.3 Running the BIOS Setup Program............................................................9
Chapter 3 Hardware & Peripheral Installation..11
3.1 Overview of Hardware Installation & Upgrading .....................................12
3.2 Installing the Storage Device and Memory .............................................12
3.3 Installing Optional Accessories...............................................................12
3.3.1 Installing TREK-570 Peripheral Modules....................................12
Figure 3.1 Install peripheral in the system.................................12
3.3.2 Installing the MiniPCIe Type WWAN, SIM Card and Coin Battery .
12
3.3.3 GPS Module................................................................................12
3.4 Paired with TREK-303 Specifications .....................................................13
Chapter 4 Jumper Settings and Connectors....15
4.1 Setting Jumpers and Switches................................................................16
Chapter 5 Pin Assignments ...............................19
5.1 Front Side Connectors............................................................................20
5.2 Rear Side Connectors.............................................................................20
5.3 Power Connector (12/24V; 9 ~ 32V).......................................................20
Table 5.1: Power Connector......................................................20
5.4 Smart Display Connector........................................................................21
Table 5.2: Smart Display Connector..........................................21
5.5 RS-232 Connector (COM3).....................................................................22
Table 5.3: RS232 Connector(COM3)........................................22
5.6 Vehicle I/O...............................................................................................22
Table 5.4: Vehicle I/O................................................................22
5.7 Generic I/O Connector ............................................................................23
Table 5.5: Generic I/O Connector..............................................23

TREK-570/303 User Manual x
Chapter 6 Software Demo Utility Setup............25
6.1 Introduction............................................................................................. 26
6.2 Execute VCIL Sample Code................................................................... 26
6.2.1 System Menu.............................................................................. 26
6.2.2 Testing VCIL............................................................................... 31
6.2.3 Testing CAN ............................................................................... 34
6.2.4 Testing J1939............................................................................. 37
6.2.5 Testing ODB2............................................................................. 39
6.2.6 Testing J1708............................................................................. 42
6.2.7 Testing J1587............................................................................. 44
6.3 Vehicle Power Management................................................................... 46
6.3.1 Power Management Mechanism................................................ 46
6.3.2 Power Management demo program........................................... 47
6.4 WatchDog Sample Code ........................................................................ 51
6.5 Peripheral Control Demo Program.......................................................... 52
Appendix A TREK-303........................................... 55
A.1 Paired with TREK-303 Specifications ..................................................... 56
Table A.1: TREK-303 Specification........................................... 56
Figure A.1 Hotkey utility............................................................. 59

Chapter 1
1General Information
This chapter gives background
information on the TREK-570 In-
Vehicle Computing Box.
Sections include:
Introduction
General Specifications
Dimensions

TREK-570/303 User Manual 2
1.1 Introduction
TREK-570 is a compact and economical vehicle-grade, Intel Atom E3826 SOC
empowered computing box mainly designed for fleet management market. It can
work in extreme environments with features like the wide working temperature range
(-30-70°C) and anti-shock/vibration to pass MIL-STD-810G and 5M3 standard. Its
special power protection surges from impacting the system. guarding against dam-
age from transient card power.
TREK-570 combined with variety of I/O connectors can be connected to devices like
TPMS (Tire Pressure Monitoring System), Rear view Camera (for parking monitoring)
and CAN Bus devices. It has dual CAN BUS ports and support several kind of vehicle
protocols (e.g. J1939,OBD-II/ISO 15765) for vehicle diagnostics and driver behavior
management. Build-in wireless communication (WWAN, WLAN,BT) enable TREK-
570 to send import ant driver/vehicle/location/cargo information back to the control
center. Furthermore, TREK-570 also reserved dual display/dual audio interfaces sup-
porting different resolutions can deliver different applications to different displays; eg:
one application to a fleet driver and another to passenger to IVI and digital signage
application.
I/O Connectors

3 TREK-570/303 User Manual
Chapter 1 General Information
1.2 General Specifications
Key features
Automotive grade working temperature range (-30° C to 70° C)
Rich I/O including CAN, LAN, RS-232, RS-485, J1708, isolation 4DI/4DO, Line
out, Mic in, USB, and Video-in
Built-in GSM/GPRS/LTE (support dual SIM Cards)/GNSS/BT and WLAN
Certifications: CE/FCC/e-mark, MIL-SD810F, ISO 7637-2, SAE J1455, SAE
J1113 regulations
Dual independent display/audio output for both driver and passenger
Ignition on/off delay; SW controllable for car power management
Specifications
Dimensions: (W x H x D): 229.6 x 71 x 117.9 mm
Weight: 2 kg
Vehicle power feature:
–Input voltage: 6 ~ 32 Vdc, support ignition cold crank
–Supports Ignition on/off
–Supports low battery shut-down protection threshold (optional)
–Supports power off event delay
–Supports power on delay
–Supports power low delay
–Supports power low hard delay
–Supports hard off delay
CPU: Intel Atom E3826(Dual Core, 1.46GHz)
Chipset: Integrated in LE82US15EE
BIOS: 4MB Flash BIOS, ACPI Compliant.
System memory: One SODIMM sockets, accepts up to 4GB DDR3L1066
SDRAM
Storage: One mSATA slot, support system boot up
Serial ports: Two CAN Bus
Two 4-wire RS232,1 x RS485, 1 x J1708 ports
Universal serial bus (USB) port: one USB3.0 Type A, one USB 2.0 Type A
LAN port: 1 x 10/100/1000 Ethernet by RJ45
Note! For more detail of function please refer to Chapter 6, Section 6.3 of this
manual.
Note! This product is covered by one or more of the following patents:
US5,307,459, US5,434,872, US5,732,094, US6,570,884, US6,115,776
and US6,327,625.

TREK-570/303 User Manual 4
Storage: 1x Mini PCI express bus expansion slot for m-SATA: SATA rev2.0 bus
Video output:
–1 X LVDS output by Smart Display port
–1 x VGA output by DB-15
–1 x HDMI output by HDMI 19pin Receptacle
*note: 2 of 3 video output can be displayed simultaneously in BIOS or OS.
Video in: 1 x composite video input (for rear view monitor) by BNC connector
on Generic IO cable
Mini PCI express bus expansion slot: Accepts full size mini PCIe bus card.
Mini PCI express bus expansion slot for WWAN: support dual SIM card
switch
Watchdog timer: Supports 0-255 sec. time intervals, SW programmable and
SW enable/disabled.
RTC Battery: 3.0 V @ 200 mAH lithium battery.
Power management: Supports power saving modes including Normal/ sus-
pend-to-disk modes.
Digital I/O: Isolated 4 digital input and 4 digital output
CAN/J1939 bus: Support CAN V2.0B up to 1 Mb/s, by DB-9 connector on Vehi-
cle I/O cable
ODBII bus: up to 500kbps, by DB-9 connector on Vehicle I/O cable J1708 bus:
9600 bps, by DB-9 connector on Vehicle I/O cable
GNSS (Ublox MAX-M8Q/W): GPS, GLONASS, BEIDOU
Audio: 2 audio codecs, one is for smart display, one is for TREK-570 line out
and mic in phone jack by Generic I/O cable.
RS-485: up to 115200 bps by Generic I/O cable.
Optional modules:
RF:
–WLAN+BT (Sparklan WEPA-251N(BT)): IEEE802.11a/b/g/n MIMO +Blue-
tooth V4.0
–WWAN (Sierra Wireless MC7304/54): Quad-band GSM/GPRS, HSDPA+,
CDMA2000, LTE
–PCI Express Bus Ethernet Interface: Ethernet: support 1000/100/10Base-T
auto-sensing capability.
Operating temperature: -30 ~ 70° C
Relative humidity: 10 ~ 95% @ 40° C (non-condensing)
Shock: 30 G peak acceleration (11 msec duration)
Certifications: CE, FCC, CCC, Emark
Vibration: 5 ~ 500 Hz SAE J1455 4.9.4.2, MIL-STD-810F 514.5

5 TREK-570/303 User Manual
Chapter 1 General Information
1.3 Dimensions
Figure 1.1 TREK-570 dimensions

TREK-570/303 User Manual 6

Chapter 2
2System Setup
This chapter details system setup
on TREK-570.
Sections include:
A Quick Tour of the Computer
Box
Installation Procedures
Running the BIOS Setup Pro-
gram

TREK-570/303 User Manual 8
2.1 A Quick Tour of the TREK-570 Computing Box
Before starting to set up the In-Vehicle Computing Box, take a moment to become
familiar with the locations and functions of the controls, drives, connectors and ports,
which are illustrated in the figures below. When the Computer box is placed inside
truck glove cabinet or under the passenger's seat next to the driver, its front appears
as shown in Figure 2.1.
Figure 2.1 Front view of TREK-570
Figure 2.2 Rear view of TREK-570
2.2 Installation Procedures
2.2.1 Connecting the Power Cord
Connect the three pin waterproof power cord to the DC inlet of the In-Vehicle Com-
puting Box. On the open-wire end, one pin is reserved for positive voltage and is
marked, "+"; one pin is reserved for ground and is marked, "-"; and, one pin is
reserved for the ignition signal with an "ignition" mark.
Note! Ignition on/off setting: The TREK-570 supports an ignition on/off function
sothat youcanpower on/offtheTREK-570via theignitionsignal/volt-
age and connect the TREK- vehicle ignition switch.
Table 2.1: Pin Definition of Power Cord
Pin Definition Color
1+Red
2- Black
3 Ignition Orange

9 TREK-570/303 User Manual
Chapter 2 System Setup
2.2.2 Power Connector (12/24V; 9 ~ 32V)
Figure 2.3 Power connector outlook
2.3 Running the BIOS Setup Program
In most cases, the computer will have been properly set up and configured by the
dealer or SI prior to delivery. However, it may still be necessary to adjust some of the
computer's BIOS (Basic Input-Output System) setup programs to change the system
configuration data, like the current date and time, or the specific type of hard drive
currently installed.
The setup program is stored in read-only memory (ROM). It can be accessed either
when turning on or resetting the computer, by pressing the "Del" key on the keyboard
immediately after powering up the computer.
The settings that are specified with the setup program are recorded in a special area
of the memory called CMOS RAM. This memory is backed up by a battery so that it
will not be erased when turning off or resetting the system. Whenever the power is
turned on, the system reads the settings stored in CMOS RAM and compares them
to the equipment check conducted during the power on self-test (POST). If an error
occurs, an error message is displayed on screen, and the user is prompted to run the
setup program.
Table 2.2: Power Connector
Pin Signal Depiction
1Ground
2 Power Input (6 ~ 36 VDC; 18 ~ 58 VDC)
3 Acc Ignition Input
