LG FLATRON L1520BM-AL*R User manual












Model Description
MODEL BRAND
Printing Specification
1. Trim Size (Format) : 215mm x 280 mm
2. Printing Colors
•Cover : LG COLOR
•Inside : Black
3. Stock (Paper)
•Cover : Snow white paper 150 g/


•Inside : Snow white paper 100 g/


4. Printing Method :
5. Bindery : Saddle stitch
6. Language : English
7. Number of pages : 24(Including blank 1page)
Part No.
1.
2.
Service Guide Specification
Service Guide Specification
Changes
4.
REV.
NO. MM/DD/YY 

 CHANGE NO. CHANGE CONTENTS
1
2
3
4
5
7
6
SUFFIX
PARK
H. J
04.02.06
L1520BM
ALEUR
LG 3828TSL097G
KIM J. O
04.02.06
8
Special Instructions3.
Product Name FLATRON L1520B

Pagination sheet
Pagination sheet P/NO.3828TSL097G
Total pages : 24pages
Front
Cover
Front cover
Inside
(Blank)
English
2
English
3
English
4
English
…….
English
…..
English
19
Rear
Cover
English
20
English
21
Rear Cover
Inside
22

COLOR MONITOR
SERVICE MANUAL
Website:http://biz.LGservice.com
E-mail:http://www.LGEservice.com/techsup.html
CAUTION
BEFORE SERVICING THE UNIT,
READ THE SAFETY PRECAUTIONS IN THIS MANUAL.
CHASSIS NO. : CL-61
MODEL: L1520B (L1520BM-AL**R)
( ) **Same model for Service
*Same looking with new chassis.
Issue Date; 2004. 2

- 1 -

CONTENTS
SPECIFICATIONS
- 2 -
1. LCD CHARACTERISTICS
Type : TFT XGA LCD Module
Size : 352.0(H) x 263.5(V) x 14.0(T)
Pixel Pitch : 0.297mm x 0.297mm
Color Depth :
6bits(with FRC)/ 16M colors
Active Video Area : 15.0inch
(304.128 x 228.096)
Surface Treatment : Anti-Glare, Hard Coating (3H)
Backlight Unit : 2CCFL
Operating Mode : Transmissive mode, Normally white
Electrical Interface : LVDS interface
2. OPTICAL CHARACTERISTICS
2-1. Viewing Angle by Contrast Ratio
≥
10
Left : 55° min. 65° typ. Right: 55° min. 65° typ.
Top : 40° min. 45° typ. Bottom: 50° min. 55° typ.
2-2. Luminance
:
200(min.), 250(typ.) at Center point
2-3. Contrast Ratio : 300(min.), 400(typ.)
3. SIGNAL (Refer to the Timing Chart)
3-1. Sync Signal
1) Type : Separate Sync. (Horizontal & Vertical)
2) Input Voltage Level: Low=0~0.8V, High=2.1~5.5V
3) Sync Polarity : Positive or Negative
3-2. Video Input Signal
1) Type : R, G, B Analog
2) Voltage Level : 0~0.7 V
a) Color 0, 0 : 0 Vp-p
b) Color 7, 0 : 0.35 Vp-p
c) Color 15, 0 : 0.7 Vp-p
3) Input Impedance : 75 Ω
3-3. Operating Frequency
Horizontal : 30 ~ 63kHz
Vertical : 56 ~ 75Hz
4. POWER SUPPLY
4-1. Power
100-240V~, 50/60Hz 0.6A
4-2. Power Consumption
5. ENVIRONMENT
5-1. Operating Temperature: 10°C~35°C (50°F~95°F)
5-2. Operating Humidity : 10%~80%
5-3. MTBF : 50,000 Hours (Min.)
Lamp Life : 40,000 Hours (Min.)
6. DIMENSIONS (with TILT/SWIVEL)
FullUp Position
Width : 363.8mm (14.32'')
Depth : 220mm (8.66'')
Height : 330.7mm (13.02'')
Folded Position
Width : 363.8mm (14.32'')
Depth : 113.7mm (8.66'')
Height : 358mm (14.09'')
7. WEIGHT (with TILT/SWIVEL)
Net. Weight : 3.2kg (7.05 lbs)
Gross Weight : 5.5kg (12.13 lbs)
SPECIFICATIONS ................................................... 2
PRECAUTIONS ....................................................... 3
TIMING CHART ....................................................... 4
OPERATING INSTRUCTIONS ................................ 5
WIRING DIAGRAM ................................................. 6
BLOCK DIAGRAM ................................................... 7
DESCRIPTION OF BLOCK DIAGRAM ................... 8
ADJUSTMENT ........................................................ 9
TROUBLESHOOTING GUIDE .............................. 11
EXPLODED VIEW...................................................15
REPLACEMENT PARTS LIST ...............................17
SCHEMATIC DIAGRAM......................................... 19
MODE
POWER ON (NORMAL)
STAND-BY
SUSPEND
DPM OFF
POWER S/W OFF
H/V SYNC
ON/ON
OFF/ON
ON/OFF
OFF
-
POWER CONSUMPTION
less than 25 W
less than 1 W
less than 1 W
less than 1W
less than 1W
LED COLOR
BLUE
AMBER
AMBER
AMBER
OFF
VIDEO
ACTIVE
OFF
OFF
OFF
-

- 3 -
WARNING FOR THE SAFETY-RELATED COMPONENT.
• There are some special components used in LCD
monitor that are important for safety. These parts are
marked on the schematic diagram and the
replacement parts list. It is essential that these critical
parts should be replaced with the manufacturer’s
specified parts to prevent electric shock, fire or other
hazard.
• Do not modify original design without obtaining written
permission from manufacturer or you will void the
original parts and labor guarantee.
TAKE CARE DURING HANDLING THE LCD MODULE
WITH BACKLIGHT UNIT.
• Must mount the module using mounting holes arranged
in four corners.
• Do not press on the panel, edge of the frame strongly
or electric shock as this will result in damage to the
screen.
• Do not scratch or press on the panel with any sharp
objects, such as pencil or pen as this may result in
damage to the panel.
• Protect the module from the ESD as it may damage the
electronic circuit (C-MOS).
• Make certain that treatment person’s body are
grounded through wrist band.
• Do not leave the module in high temperature and in
areas of high humidity for a long time.
• The module not be exposed to the direct sunlight.
• Avoid contact with water as it may a short circuit within
the module.
• If the surface of panel become dirty, please wipe it off
with a softmaterial. (Cleaning with a dirty or rough cloth
may damage the panel.)
WARNING
BE CAREFUL ELECTRIC SHOCK !
• If you want to replace with the new backlight (CCFL) or
inverter circuit, must disconnect the AC adapter
because high voltage appears at inverter circuit about
650Vrms.
• Handle with care wires or connectors of the inverter
circuit. If the wires are pressed cause short and may
burn or take fire.
PRECAUTION
CAUTION
Please use only a plastic screwdriver to protect yourself
from shock hazard during service operation.

TIMING CHART
- 4 -
VIDEO
SYNC
B
D
CFE
A
H / V
H (Pixels)
V (Lines)
H (Pixels)
V (Lines)
H (Pixels)
V (Lines)
H (Pixels)
V (Lines)
H (Pixels)
V (Lines)
H (Pixels)
V (Lines)
H (Pixels)
V (Lines)
H (Pixels)
V (Lines)
H (Pixels)
V (Lines)
H (Pixels)
V (Lines)
H (Pixels)
V (Lines)
H (Pixels)
V (Lines)
H (Pixels)
V (Lines)
H (Pixels)
V (Lines)
Sync
Polarity
+
–
–
+
–
–
–
–
–
–
–
–
+
+
+
+
+
+
+
+
–
–
–
–
–
–
+
+
Dot
Clock
25.175
28.322
25.175
30.24
31.5
31.5
36.0
40.0
50.0
49.5
57.2832
65
75
78.75
Frequency
31.468 KHz
70.0 Hz
31.468 KHz
70.0 Hz
31.469 KHz
60.0 Hz
35.00 KHz
66.67 Hz
37.861 KHz
72.8 Hz
37.50 KHz
75.0 Hz
35.156KHz
56.25 Hz
37.879 KHz
60.3 Hz
48.077 KHz
72.188 Hz
46.875 KHz
75.0 Hz
49.725 KHz
74.55 Hz
48.363 KHz
60.0 Hz
56.476 KHz
70.0 Hz
60.023 KHz
75.0 Hz
Resolution
640 x 350
720 x 400
640 x 480
640 x 480
640 x 480
640 x 480
800 x 600
800 x 600
800 x 600
800 x 600
832 x 624
1024 x 768
1024 x 768
1024 x 768
Total
Period
( E )
800
449
900
449
800
525
864
525
832
520
840
500
1024
625
1056
628
1040
666
1056
625
1152
667
1344
806
1328
806
1312
800
Video
Active
Time ( A )
640
350
720
400
640
480
640
480
640
480
640
480
800
600
800
600
800
600
800
600
832
624
1024
768
1024
768
1024
768
Blanking
Time
( B )
160
99
180
49
160
45
224
45
192
40
200
20
224
25
256
28
240
66
256
25
320
43
320
38
304
38
288
32
Sync
Duration
( D )
96
2
108
2
96
2
64
3
40
3
64
3
72
2
128
4
120
6
80
3
64
3
136
6
136
6
96
3
Back
Porch
( F )
48
60
55
34
48
33
96
39
128
28
120
16
128
22
88
23
64
23
160
21
224
39
160
29
144
29
176
28
Front
Porch
( C )
16
37
17
13
16
10
64
3
24
9
16
1
24
1
40
1
56
37
16
1
32
1
24
3
24
3
16
1
MODE
1
2
3
4
5
6
7
8
9
10
11
12
13
14
(MAC)
(TEXT)

OPERATING INSTRUCTIONS
- 5 -
FRONT VIEW REAR VIEW
Front Control Panel
1. Power Button
Use this button to turn the display on or off.
<Power (DPMS) Indicator>
This Indicator lights up blue when the display
operates normally. If the display is in DPM (Energy
Saving) mode, this indicator color changes to
amber.
2. Button
Use these buttons to choose or adjust items in the
On Screen Display.
3. Menu Button
Use this button to enter or exit the On Screen
Display.
4.
AUTO/SELECT Button
Use this button to enter a selection in the On
Screen Display.
When adjusting your display settings, always
press the AUTO/SELECT button before entering
the On Screen Display(OSD). This will
automatically adjust your display image to the
ideal settings for the current screen resolution
size (display mode).
The best display mode is 1024x768/60Hz.
See front control panel
D-sub Connect
Power Connect
143 2
This feature lets you easily select the best desired image
condition optimized to the environment (ambient
illumination, image types etc.).
•DAY : Bright ambient illumination
•NIGHT : Dark ambient illumination
•TEXT : For text images (Word processing etc.)
•MOVIE : For animation images in videos or movies
•PHOTO : For pictures or drawings
•USER MODE : For use under user setup image
conditions (Brightness, contrast and color tint are
selected by the user in OSD Screen Setup Menu.)
100
100
Bring up Contrast and Brightness adjustment.
:

- 6 -
WIRING DIAGRAM
J704
J706
J707
CN3
CN2
AC IN-LET SOCKET:
P/N: 6620K00002C
Connector Ass’y :
P/N: 6631T11016C
Connector Ass’y :
P/N: 6631T20022G
Connector Ass’y :
P/N: 6631T20008G

- 7 -
BLOCK DIAGRAM
D-SUB
MST9111B
including
(ADC/LVDS/SCALER )
MTV312
Micom
LCD Module
R,G,B
differential
LL
LLVV
VVDD
DDSS
SS
((
((LL
LLoo
ooww
ww VV
VVoo
oollllttttaa
aagg
ggee
ee
DD
DDiiiiffffffffee
eerr
rree
eenn
nnttttiiiiaa
aallll SS
SSiiiigg
ggnn
nnaa
aalllliiiinn
nngg
gg))
))
LIPS
5V
5V
AC Input
3.3V
Reg. Diode
KDS184
5V 3.3V
12V
R,G,B, H/V Sync
3.3V 2.5V
3.3V 2.5V

DESCRIPTION OF BLOCK DIAGRAM
- 8 -
1. Video Controller Part.
This part amplifies the level of video signal for the digital conversion and converts from the analog video signal to the
digital video signal using a pixel clock.
The pixel clock for each mode is generated by the PLL.
The range of the pixel clock is from 25MHz to 135MHz.
This part consists of the Scaler, ADC, LVDS transmitter.
The Scaler gets the video signal converted analog to digital, interpolates input to 1280 X 1024 resolution signal and
outputs 8-bit R, G, B signal to transmitter.
2. Power Part.
This part consists of the one 3.3V regulator, and two 2.5V drop diodes to convert power which is provided 12V, 5V in
Power board.
5V is provided for LCD panel and Micom.
Also, 5V is converted 3.3V by regulator and 3.3V is converted 2.5V by drop diode.
Converted power is provided for IC in the main board.
3. MICOM Part.
This part consists of EEPROM IC which stores control data, Reset IC and the Micom.
The Micom distinguishes polarity and frequency of the H/V sync are supplied from signal cable.
The controlled data of each modes is stored in EEPROM.

- 9 -
ADJUSTMENT
Windows EDID V1.0 User Manual
Operating System: MS Windows 98, 2000, XP
Port Setup: Windows 98 => Don’t need setup
Windows 2000, XP => Need to Port Setup.
This program is available to LCD Monitor only.
1. Port Setup
a) Copy “UserPort.sys”file to
“c:\WINNT\system32\drivers”folder
b) Run Userport.exe
c) Remove all default number
d) Add 300-3FF
e) Click Start button.
f) Click Exit button.
2. EDID Read & Write
1) Run WinEDID.exe
2) Edit Week of Manufacture, Year of Manufacture,
Serial Number
a) Input User Info Data
b) Click “Update”button
c) Click “Write”button

- 10 -
Figure 1. Cable Connection
220
IBM
Compatible PC
PARALLEL PORT
Power inlet (required)
Power LED
ST Switch
Power Select Switch
(110V/220V)
Control Line
Not used
RS232C
PARALLEL
V-SYNC POWER
ST
VGS MONITOR
E
E
V-Sync On/Off Switch
(Switch must be ON.)
F
F
A
A
B
B
C
C
1510
5
569
1
1
1
14
13
25
6
5V
5V
5V
4.7K
4.7K
4.7K
74LS06
74LS06
OFF ON
OFF
ON
11
Video Signal
Generator
SERVICE OSD
1) Turn off the power switch at the front side of the display.
2) Wait for about 3 seconds and press MENU, POWER switch with 1 second interval.
3) The SVC OSD menu contains additional menus that the User OSD menu as described below.
a) MODULE : To select applied module.
b) NVRAM INIT : EEPROM initialize(24C08)
c) ADC OFFSET : The lowest value of input leves sets to digitally 0(zero).
d) ADC GAIN : The highest value of input levels sets to digitally 255.
e) ADC CAL : W/B balance sets the gain and offset value.
f) ELAPSED CLEAR : To initialize using time.

- 11 -
TROUBLESHOOTING GUIDE
1. NO POWER
NO POWER
(POWER INDICATOR OFF)
CHECK POWER
BOARD, AND FIND
OUT A SHORT POINT
AS OPENING
EACH POWER LINE
CHECK J705
VOLTAGE
PIN5, PIN6 (5V)?
NO
CHECK 5VS LINE
(OPEN CHECK)
CHECK
U501 PIN 8 Voltage
(5V) ?
NO
NO
NO
CHECK U201 PIN 122
PULSE
CHECK U201
CHECK 3.3V LINE
CHECK X-TAL
IS U201
PIN114 (3.3V)
VOLTAGE ?
YES
YES NO PROBLEM
YES
CHECK KEY CONTROL
CONNECTOR ROUTINE
YES

- 12 -
2. NO RASTER (OSD IS NOT DISPLAYED) –LIPS
CHECK MICOM INV
ON/OFF PORT.
J705 PIN9
5V? NO
NO RASTER
(OSD IS NOT DISPLAYED)
CHECK LIPS
J705
PIN5, PIN6
5V?
NO
1. CONFIRM BRIGHTNESS
OSD CONTRL STATE.
2. CHECK MICOM DIM-ADJ
PORT
J705 PIN10
5V? NO
LIPS
CHECK
PULSE AS
CONTACTING SCOPE
PROBE TO CAUTION LABEL.
(CONTACT PROBE TO
CAUTION LABEL.
CAN YOU SEE PULSE
AT YOUR
SCOPE?
NO
REPLACE CCFL LAMP
IN THE LCD MODULE
YES
YES
YES
YES

- 13 -
1. CHECK PIN122, 123
SOLDERING CONDITION
2. CHECK X501
3. TROUBLE IN U201
U201
POWER PIN8, 114
3.3V?
NO CHECK U801
U201
PIN122, 123
OSCILLATE AS
12MHZ?
CHECK CONNECTION LINE
FROM D-SUB TO U501
TROUBLE IN CABLE
OR LCD MODULE
YES
YES
YES
3. NO RASTER (OSD IS NOT DISPLAYED) –MST9011B
NO RASTER
(OSD IS NOT DISPLAYED)
U501
PIN43 IS 48KHz H-SYNC?
PIN44 IS 60Hz V-SYNC?
IS PULSE APPEARED
AT SIGNAL PINS?
AT MODE 12?
NO
NO

- 14 -
4. TROUBLE IN DPM
TROUBLE IN DPM
TROUBLE IN U501
CHECK PC
PC IS NOT GOING
INTO DPM OFF MODE
NO
CHECK H/V SYNC
LINE
NO
YES
YES
CHECK
R773, R775
(SYNC) ?
CHECK
U501 PIN 43.44
SYNC PULSE ?

- 15 -
EXPLODED VIEW
12
3
4
5
7 910 11
8
12
13
6
14

- 16 -
EXPLODED VIEW PARTS LIST
Ref. No.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
Part No.
3091TKL085A
6304FLP068A
or 6304FLP074A
3809TKL058A
3043TKK133E
3550TKK395A
6871TST436A
4951TKS112A
6631T11016C
6871TPT234G
3313TL5091A
4951TKK141C
3550TKK397A
3550TKK399A
6850TD9004H
Description
CABINET ASSEMBLY, L1520 BRAND
LCD(LIQUID CRYSTAL DISPLAY), LM150X06-A4C3 LG PHILPS TFT COLOR LPL
LCD(LIQUID CRYSTAL DISPLAY), LM150X06-A4K8 LG PHILPS TFT COLOR 5MASK
BACK COVER ASSEMBLY, L1520. SILVER SPRAY
TILT SWIVEL ASSEMBLYL1520. M/BASE-SPRAY-NEW SCREW/RUBBER
COVER, L1520 PIECE DECO
PWB(PCB) ASSEMBLY, SUB, L1520BL CONTROL TOTAL BRAND CL-32
METAL ASSEMBLY, FRAME L1520BL
CONNECTOR ASSEMBLY, 20P H-H 100MM UL20276 I/FACE CABLE LB500K
PWB(PCB) ASSEMBLY, POWER, L1520SL POWER TOTAL POWERNET MODIFIED LIPS ANALOG DIMMING FOR LPL
MAIN TOTL ASSEMBLY, L1520BM BRAND CL-61
METAL ASSEMBLY, REAR(L1520BL)
COVER, L1520. BACK CAP
COVER, L1520. HINGE CAP
CABLE, D-SUB, UL2990-9C(5.8MM) DT 1500MM GRAY 20 MODEL DM

- 17 -
DATE: 2004. 2. 4.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
C204 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C205 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C206 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C207 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C208 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C209 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C210 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C211 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C214 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C215 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C216 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C217 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C218 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C219 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C220 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C221 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C222 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C223 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C225 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C226 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C227 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C230 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C231 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C232 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C233 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C251 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C501 0CC101CK41A 100PF 1608 50V 5% R/TP NP0
C502 0CC101CK41A 100PF 1608 50V 5% R/TP NP0
C503 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C504 0CH8106F611 10UF 16V M 85STD(CYL) R/TP
C506 0CC030CK01A 3PF 1608 50V 0.25 PF R/TP NP0
C507 0CC180CK41A 18PF 1608 50V 5% R/TP NP0
C508 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C701 0CK105CD56A 1UF 1608 10V 10% R/TP X7R
C703 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C708 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y5P
C709 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y5P
C710 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y5P
C711 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y5P
C717 0CC101CK41A 100PF 1608 50V 5% R/TP NP0
C718 0CC101CK41A 100PF 1608 50V 5% R/TP NP0
C719 0CC680CK41A 68PF 1608 50V 5% R/TP NP0
C720 0CC101CK41A 100PF 1608 50V 5% R/TP NP0
C721 0CC680CK41A 68PF 1608 50V 5% R/TP NP0
C727 0CK105CD56A 1UF 1608 10V 10% R/TP X7R
C732 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y5P
C733 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C734 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C735 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C760 0CE107EF610 "100UF KMG,RD 16V 20% FL BULK"
C801 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y5P
C803 0CE107EF610 "100UF KMG,RD 16V 20% FL BULK"
DATE: 2004. 2. 4.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
C804 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C805 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C806 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y5P
C807 0CE107EF610 "100UF KMG,RD 16V 20% FL BULK"
C808 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C809 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y5P
C810 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C812 0CE107EF610 "100UF KMG,RD 16V 20% FL BULK"
C814 0CE107EF610 "100UF KMG,RD 16V 20% FL BULK"
C815 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C816 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y5P
D701 0DS226009AA KDS226 TP KEC SOT-23 80V 300M
D702 0DS226009AA KDS226 TP KEC SOT-23 80V 300M
D706 0DS226009AA KDS226 TP KEC SOT-23 80V 300M
D707 0DD184009AA KDS184 TP KEC - 85V - - - 300M
D804 0DD184009AA KDS184 TP KEC - 85V - - - 300M
D805 0DD184009AA KDS184 TP KEC - 85V - - - 300M
ZD701 0DZ560009GB BZT52C5V6S DIODES R/TP SOD323
ZD702 0DZ560009GB BZT52C5V6S DIODES R/TP SOD323
ZD703 0DZ560009GB BZT52C5V6S DIODES R/TP SOD323
ZD704 0DZ560009GB BZT52C5V6S DIODES R/TP SOD323
ZD705 0DZ560009GB BZT52C5V6S DIODES R/TP SOD323
ZD711 0DZ560009GB BZT52C5V6S DIODES R/TP SOD323
U201 0IPRPM3007B "MST9011B(ANALOG) MSTAR 128P,LQ"
U501 0IZZTSZ364A MYSON MTV312 L1520BM - E
U502 0ISG240860B M24C08W6 SGS-THOMSON 8SOP R/TP
U801 0IPMGKE011A KIA78D33F KEC DPAK R/TP 3.3V L
U803 0IPMGK2001B AIC1117A-33CYTR(BS33) AIC SOT2
Q502 0IKE704200H KIA7042AP TO-92 TP 4.2 VOLT.
Q503 0TR390409AE FAIRCHILD KST3904(LGEMTF) TP S
Q504 0TR390409AE FAIRCHILD KST3904(LGEMTF) TP S
Q505 0TR390409AE FAIRCHILD KST3904(LGEMTF) TP S
Q703 0TR390609FA KST3906-MTF TP SAMSUNG SOT23
Q704 0TR390609FA KST3906-MTF TP SAMSUNG SOT23
Q706 0TR390409AE FAIRCHILD KST3904(LGEMTF) TP S
Q707 0TR390409AE FAIRCHILD KST3904(LGEMTF) TP S
Q801 0TR127309AA KTA1273-Y(KTA966A) TP KEC TO92
Q802 0TR390409AE FAIRCHILD KST3904(LGEMTF) TP S
R201 0RJ1500D677 150 OHM 1/10 W 5% 1608 R/TP
R202 0RJ1500D677 150 OHM 1/10 W 5% 1608 R/TP
R203 0RJ1500D677 150 OHM 1/10 W 5% 1608 R/TP
R207 0RJ3900D677 390 OHM 1/10 W 5% 1608 R/TP
REPLACEMENT PARTS LIST
CAUTION: BEFORE REPLACING ANY OF THESE COMPONENTS,
READ CAREFULLY THE SAFETY PRECAUTIONS IN THIS MANUAL.
* NOTE : S SAFETY Mark
AL ALTERNATIVE PARTS
MAIN BOARD
CAPACITORS
ICs
DIODEs
TRANSISTOR
RESISTORs
