Advantech CPC-2420 Installation and operation manual

CPC-2420 Startup Manual 1
CPC-2420
2.5" Carrier Board for Mini-Biscuit PC
Startup Manual
CPC-2420 2.5" Carrier Board for Mini-Biscuit PC
Packing List
Before you begin installing your card, please make sure
that the following materials have been shipped:
• 1 CPC-2420 carrier board for CPC-2245 mini-biscuit PC
• 1 warranty certificate
• 1 CD ROM including user's full manual
• This startup manual
• 1 40-pin FPC cable (part no.1701400301)
• 1 50-pin FPC cable (part no.1701500700)
• Y cable (part no.1700060201)
• HDD cable (part no.1701440500)
• FDD cable (part no.1701340600)
• LPT cable (part no.1703340300)
• COM cable (part no.1700100250)
• Phoenix power connector (part no.1652002101)
• Power cable (part no.1703050050)
If any of these items are missing or damaged, contact your
distributor or sales representative immediately.
Note 1: For detailed contents of the CPC-2420, please
refer to the enclosed CD-ROM (in PDF format).
Note 2: Acrobat Reader is required to view any PDF
file.Acrobat Reader can be downloaded at:
www.adobe.com/Prodindex/acrobat/
readstep.html
(Acrobat is a trademark of Adobe.)
Specifications
• Two FPC connectors for ISA-bus expansion
• DB-15 VGA connector
• RJ-45 Ethernet connector
• DB-9 COM1 serial port connector
• 10-pin COM2 serial port box header
• LCD connector
• One FDD/LPT connector
• 44-pin HDD connector
• 6-pin PS/2 KB/mouse connector
• Size:120 x 82 mm
• Weight: 80 g
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com
http://www.advantech.com/epc
For technical support and service, please visit our support
website at:
http://www.advantech.com/support
This manual is for the CPC-2420.
Part No.2006242010 1st Edition
Printed in Taiwan Jan.2000

2CPC-2420 Startup Manual
Jumpers and Connectors
The board has a number of jumpers that allow you to
configure your system to suit your application.
Jumper Settings
J3: Reset switch
Connect a wire from the reset button to J3.When J3 is
"closed", the reset signal will be activated.
J6: LCD 3.3/5 V select
Function Pins 1-2 Pins 2-3
5 V Closed Open
3.3 V Open Closed
The following table lists the connectors on the CPC-2420.
Table 1-1: Connectors
Number Function
CN1 SODIMM socket
CN2 FDD/LPT connector
CN3 VGA connector
CN4 Ethernet connector
CN5 IDE connector
CN6 Power connector
CN7 Keyboard and PS/2
mouse connector
CN8 LCD 24-bit connector
CN9 LCD inverter connector
CN10 COM1 RS-232 connector
CN11 LCD 36-bit connector
CN12 COM2 RS-232 connector
CN15 Phoenix power connector
J1 ISA slot connector
J2 ISA slot connector
J4 LCD FPC connector
J5 VGA/COM/KB/MS FPC
connector
Figure 1-1: Board layout:connector locations (component
side)
Figure 1-2: Board layout:connector locations (solder side)
Locating Connectors
