Exor GigaSOM gS01 User manual

gigaSOM gS01Carrier
HW Manual
September 2019

THW-EKGS01 - REV. 0.2
©2019 EXOR Embedded S.r.l. - Subject to change without notice
exorint.com 2
gigaSOM gS01 Carrier
History
Rev
Date
Description
By
0.0
29/Mar/2019
Created (Draft)
T. Smrtić
0.2
03/Sep/2019
Removed “preliminary”, minor changes
DJ
Reference
Cross
Reference
Filename
Description
[1]
Document contains
Author(s)
Functional Specs
Usability Specs
Techical Specs
Test Procedures
Technical Documentation
ѵ
User Documentation
The reproduction, transmission or use of this document or its contents is not permitted without express written authority. Offenders will be
liable for damages. All rights, including rights created by patent grant or registration of a utility model or design, are reserved. Technical data
subject to change. Copyright © 2019 EXOR International S.p.A. - All Rights Reserved.

THW-EKGS01 - REV. 0.2
©2019 EXOR Embedded S.r.l. - Subject to change without notice
exorint.com 3
TABLE OF CONTENTS
1Introduction.................................................................................................................................5
2Features.......................................................................................................................................6
2.1 Layout and Communication Interfaces ........................................................................6
2.2 Block Diagram ...................................................................................................................8
2.3 gigaSOM Edge Pads.........................................................................................................9
2.4 Temperature Range....................................................................................................... 21
2.5 Power Supply.................................................................................................................. 21
2.6 RTC Battery..................................................................................................................... 21
2.7 FAN Connector............................................................................................................... 22
2.8 Mechanical Dimensions ............................................................................................... 22
3Interfaces.................................................................................................................................. 23
3.1 USB ................................................................................................................................... 23
3.1.1 Micro USB 3.0 Type B ...................................................................................... 23
3.1.2 USB 3.0 Type A.................................................................................................. 23
3.1.3 USB 2.0 Type A.................................................................................................. 23
3.1.4 USB 2.0 Header................................................................................................. 23
3.1.5 USB 2.0 Debug Port.......................................................................................... 24
3.2 HDMI................................................................................................................................. 24
3.3 DisplayPort...................................................................................................................... 24
3.4 LVDS Interface................................................................................................................ 24
3.5 Gigabit Ethernet.............................................................................................................. 25
3.6 Micro SD Card................................................................................................................. 25
3.7 Audio Interfaces ............................................................................................................. 25
3.8 CSI Interface ................................................................................................................... 26
3.9 Serial Port ........................................................................................................................ 27
3.10LPC Bus............................................................................................................................ 28
3.11SPI Interfaces ................................................................................................................. 28
3.12PCIe .................................................................................................................................. 29
3.12.1 M.2 key B (J17) ................................................................................................. 29
3.12.2 M.2 key E............................................................................................................ 29
3.13SATA................................................................................................................................. 30
3.14CAN................................................................................................................................... 30
3.15SFP+ ................................................................................................................................. 30
3.16FMC .................................................................................................................................. 30
3.16.1 FMC JTAG.......................................................................................................... 32
3.17SSW Connector .............................................................................................................. 32
4Additional Features................................................................................................................. 34
4.1 Buttons............................................................................................................................. 34
4.1.1 Power.................................................................................................................. 34
4.1.2 Reset ................................................................................................................... 34
4.2 GPIO, SMB, I2C, PWM Header ..................................................................................... 34
4.3 LEDs, DIP Switches........................................................................................................ 35
4.4 JTAG................................................................................................................................. 37

THW-EKGS01 - REV. 0.2
©2019 EXOR Embedded S.r.l. - Subject to change without notice
exorint.com 4
List of Figures
Figure 1. gigaSOM Carrier ....................................................................................................................................5
Figure 2. The gigaSOM Carrier and Component Diagram.............................................................................. 6
Figure 3. Block Diagram........................................................................................................................................8
Figure 4. Mechanical Dimensions.....................................................................................................................22
List of Tables
Table 1. gigaSOM Edge Pads.............................................................................................................................21
Table 2. Power Connector Description ............................................................................................................21
Table 3. FAN Connector Description................................................................................................................22
Table 4. USB 2.0 Header Description ...............................................................................................................23
Table 5. Slide Switch S1 Description................................................................................................................23
Table 6. LVDS QSH Connector Description.....................................................................................................25
Table 7. CSI QSH Connector Description ........................................................................................................27
Table 8. DIP Switch S2 Description ..................................................................................................................27
Table 9. LPC Bus Description ............................................................................................................................28
Table 10. SPI Header Description .....................................................................................................................28
Table 11. Fast SPI Interface Description .........................................................................................................29
Table 12. Slide Switch S2 Description..............................................................................................................29
Table 13. SFP Interface LED Status Description............................................................................................30
Table 14. FMC Connector Pinout......................................................................................................................32
Table 15. FMC JTAG Pinout...............................................................................................................................32
Table 16. SSW Connector Description.............................................................................................................33
Table 17. GPIO, SMB, I2C, PWM Header Description....................................................................................35
Table 18. LED Status (0-4) Description............................................................................................................35
Table 19. DIP Switch (S6) Configuration .........................................................................................................35
Table 20. LED Status (0-7) Description............................................................................................................36
Table 21. DIP Switch (S5) Configuration .........................................................................................................36
Table 22. JTAG Pinout ........................................................................................................................................37

THW-EKGS01 - REV. 0.2
©2019 EXOR Embedded S.r.l. - Subject to change without notice
exorint.com 5
1Introduction
Figure 1. gigaSOM Carrier
The gigaSOM carrier is a flexible development environment with which you can explore and
evaluate the functionality and performance of the gigaSOM module which is soldered directly into
the gigaSOM Carrier board.
This HW manual describes the gigaSOM carrier board. This document provides information about
the features and communication interfaces available on gigaSOM Carrier.

THW-EKGS01 - REV. 0.2
©2019 EXOR Embedded S.r.l. - Subject to change without notice
exorint.com 6
2Features
This chapter will show technical and mechanical details of gigaSOM carrier.
2.1 Layout and Communication Interfaces
The photo of the gigaSOM carrier is shown in Figure 2. They depict
the layout of the board and indicates the location of the communication interfaces.
Figure 2. The gigaSOM Carrier and Component Diagram
SD Card
Serial
port
RJ45
USB 2.0
LVDS
interfaces
Power
input
USB
debug
CSI
interface
USB 3.0
HDMI
DP
SSW
connector
JTAG
Audio
interfaces
CAN
interfaces
SIM card
FMC
connector
RTC
battery
M.2 key B
slots
JTAG
DIP switches,
LEDs
SPI
heders
M.2 key E slot
GPIO,SMB
FAN connector
SFP+
Interfaces
LPC
Interface
gigaSOM
Edge Pads

THW-EKGS01 - REV. 0.2
©2019 EXOR Embedded S.r.l. - Subject to change without notice
exorint.com 7
The following features and communication interfaces are provided on the gigaSOM carrier:
-2x USB 2.0 port
-2x USB 3.0 port
-HDMI Port
-DisplayPort
-RJ45 Ethernet
-Micro SD Card
-2x Audio Interfaces
-Dual Channel LVDS Interface
-CSI Interface
-Serial Port
-FAN Connector
-2x M.2 Key B slots
-M.2 Key E slot
-SIM Card
-LPC Interface
-USB Debug Port
-2x SPI Headers
-GPIO, SMB Header
-EEPROM
-Temperature Sensor
-RTC Battery
-2x CAN Interfaces
-FMC Connector
-2x JTAG
-2x SFP+ Interfaces
-2x GPIO, DIP Switches Controlled LEDs
-SSW Connector
-3x Buttons

THW-EKGS01 - REV. 0.2
©2019 EXOR Embedded S.r.l. - Subject to change without notice
exorint.com 8
2.2 Block Diagram
This section shows the block diagram of gigaSOM carrier. Figure 3.
Figure 3. Block Diagram

THW-EKGS01 - REV. 0.2
©2019 EXOR Embedded S.r.l. - Subject to change without notice
exorint.com 9
2.3 gigaSOM Edge Pads
This section shows the gigaSOM edge pads pinout of gigaSOM module. Table 1.
Pin name
Pin
Connector
Pin name
Pin
Connector
GND
TL1
External left
SDCARD_D0
TL2
External left
SDCARD_D1
TL3
External left
SDCARD_D2
TL4
External left
SDCARD_D3
TL5
External left
GND
TL6
External left
LPC_AD0
BL1
Internal left
SDCARD_CMD
TL7
External left
LPC_AD1
BL2
Internal left
SDCARD_CD
TL8
External left
LPC_AD2
BL3
Internal left
SDCARD_WP
TL9
External left
LPC_AD3
BL4
Internal left
SDCARD_CLK
TL10
External left
GND
BL5
Internal left
SDCARD_PWR_EN
TL11
External left
LPC_FRAME
BL6
Internal left
GND
TL12
External left
LPC_SERIRQ
BL7
Internal left
LAN_MDI3N
TL13
External left
LPC_CLKRUN
BL8
Internal left
LAN_MDI3P
TL14
External left
LPC_CLK0
BL9
Internal left
LAN_LINK100#
TL15
External left
GND
BL10
Internal left
LAN_LINK1G#
TL16
External left
USB2_N5
BL11
Internal left
LAN_MDI2N
TL17
External left
USB2_P5
BL12
Internal left
LAN_MDI2P
TL18
External left
GND
BL13
Internal left
LAN_LED_ACT#
TL19
External left
USB2_N4
BL14
Internal left
LAN_MDI1N
TL20
External left
USB2_P4
BL15
Internal left
LAN_MDI1P
TL21
External left
GND
BL16
Internal left

THW-EKGS01 - REV. 0.2
©2019 EXOR Embedded S.r.l. - Subject to change without notice
exorint.com 10
LAN_GTREF
TL22
External left
USB2_N3
BL17
Internal left
LAN_MDI0N
TL23
External left
USB2_P3
BL18
Internal left
LAN_MDI0P
TL24
External left
GND
BL19
Internal left
GND
TL25
External left
USB2_N2
BL20
Internal left
EDP_HDP
TL26
External left
USB2_P2
BL21
Internal left
EDP_AUXN
TL27
External left
GND
BL22
Internal left
EDP_AUXP
TL28
External left
USB2_N1
BL23
Internal left
GND
TL29
External left
USB2_P1
BL24
Internal left
EDP_TXN0
TL30
External left
GND
BL25
Internal left
EDP_TXP0
TL31
External left
USB2_N0
BL26
Internal left
EDP_TXN1
TL32
External left
USB2_P0
BL27
Internal left
EDP_TXP1
TL33
External left
GND
BL28
Internal left
GND
TL34
External left
USB2_OTG_ID
BL29
Internal left
EDP_TXN2
TL35
External left
USB2_VBUS_SNS
BL30
Internal left
EDP_TXP2
TL36
External left
USB_OC1
BL31
Internal left
EDP_TXN3
TL37
External left
USB_OC0
BL32
Internal left
EDP_TXP3
TL38
External left
GND
BL33
Internal left
GND
TL39
External left
GPIO15
BL34
Internal left
UART2_RTS
TL40
External left
GPIO14
BL35
Internal left
UART2_CTS
TL41
External left
GPIO13
BL36
Internal left
UART2_RXD
TL42
External left
GPIO12
BL37
Internal left
UART2_TXD
TL43
External left
GPIO11
BL38
Internal left
UART1_RTS
TL44
External left
GPIO10
BL39
Internal left
UART1_CTS
TL45
External left
GPIO9
BL40
Internal left

THW-EKGS01 - REV. 0.2
©2019 EXOR Embedded S.r.l. - Subject to change without notice
exorint.com 11
UART1_RXD
TL46
External left
GPIO7
BL41
Internal left
UART1_TXD
TL47
External left
GPIO6
BL42
Internal left
UART0_RTS
TL48
External left
GPIO5
BL43
Internal left
UART0_CTS
TL49
External left
UART0_RXD
TL50
External left
UART0_TXD
TL51
External left
GND
TL52
External left
PMU_SUSCLK
TL53
External left
CB_POK
TL54
External left
GPIO4
TL55
External left
GPIO3
TL56
External left
GPIO2
TL57
External left
GPIO1
TL58
External left
F_FMC_LA_TXN10
TR1
External right
F_FMC_LA_TXP10
TR2
External right
F_FMC_LA_TXN12
TR3
External right
F_FMC_LA_TXP12
TR4
External right
GND
TR5
External right
F_FMC_LA_TXN9
TR6
External right
F_FMC_LA_RXN13
BR1
Internal right
F_FMC_LA_TXP9
TR7
External right
F_FMC_LA_RXP13
BR2
Internal right
F_FMC_LA_TXN11
TR8
External right
GND
BR3
Internal right
F_FMC_LA_TXP11
TR9
External right
F_FMC_LA_RXN11
BR4
Internal right
GND
TR10
External right
F_FMC_LA_RXP11
BR5
Internal right
F_SPI_CLK_1V5
TR11
External right
F_FMC_LA_RXN15
BR6
Internal right

THW-EKGS01 - REV. 0.2
©2019 EXOR Embedded S.r.l. - Subject to change without notice
exorint.com 12
F_SPI_CS0_1V5
TR12
External right
F_FMC_LA_RXP15
BR7
Internal right
F_SPI_MISO_1V5
TR13
External right
GND
BR8
Internal right
F_SPI_CS1_1V5
TR14
External right
F_FMC_LA_RXN8
BR9
Internal right
F_SPI_MOSI_1V5
TR15
External right
F_FMC_LA_RXP8
BR10
Internal right
GND
TR16
External right
F_FMC_LA_RXN10
BR11
Internal right
F_CAN_RX2_1V5
TR17
External right
F_FMC_LA_RXP10
BR12
Internal right
F_CAN_TX2_1V5
TR18
External right
GND
BR13
Internal right
F_CAN_RX1_1V5
TR19
External right
F_FMC_DP_C2M_RE
S_N
BR14
Internal right
F_CAN_TX1_1V5
TR20
External right
F_FMC_DP_C2M_RE
S_P
BR15
Internal right
F_FMC_SCL
TR21
External right
F_SPF_REFCLK_N
BR16
Internal right
F_FMC_SDA
TR22
External right
F_SPF_REFCLK_P
BR17
Internal right
GND
TR23
External right
GND
BR18
Internal right
F_FMC_DP_M2C_N
TR24
External right
F_SPF_RX1_N
BR19
Internal right
F_FMC_DP_M2C_P
TR25
External right
F_SPF_RX1_P
BR20
Internal right
F_FMC_DP_C2M_N
TR26
External right
F_SPF_TX1_N
BR21
Internal right
F_FMC_DP_C2M_P
TR27
External right
F_SPF_TX1_P
BR22
Internal right
GND
TR28
External right
GND
BR23
Internal right
F_FMC_GBTCLK_M2
C_N0
TR29
External right
F_SPF_RX0_N
BR24
Internal right
F_FMC_GBTCLK_M2
C_P0
TR30
External right
F_SPF_RX0_P
BR25
Internal right
GND
TR31
External right
F_SPF_TX0_N
BR26
Internal right
F_FMC_LA_TXN8
TR32
External right
F_SPF_TX0_P
BR27
Internal right
F_FMC_LA_TXP8
TR33
External right
GND
BR28
Internal right
F_FMC_LA_TXN15
TR34
External right
F_FMC_LA_RXN12
BR29
Internal right
F_FMC_LA_TXP15
TR35
External right
F_FMC_LA_RXP12
BR30
Internal right

THW-EKGS01 - REV. 0.2
©2019 EXOR Embedded S.r.l. - Subject to change without notice
exorint.com 13
GND
TR36
External right
F_FMC_LA_RXN9
BR31
Internal right
F_FMC_LA_TXN13
TR37
External right
F_FMC_LA_RXP9
BR32
Internal right
F_FMC_LA_TXP13
TR38
External right
GND
BR33
Internal right
F_FMC_LA_TXN14
TR39
External right
F_FMC_LA_CC_N1
BR34
Internal right
F_FMC_LA_TXP14
TR40
External right
F_FMC_LA_CC_P1
BR35
Internal right
GND
TR41
External right
F_FMC_CLK_M2C_N
1
BR36
Internal right
F_FMC_LA_TXN2
TR42
External right
F_FMC_CLK_M2C_P
1
BR37
Internal right
F_FMC_LA_TXP2
TR43
External right
GND
BR38
Internal right
F_FMC_LA_TXN1
TR44
External right
F_FMC_CLK_M2C_N
0
BR39
Internal right
F_FMC_LA_TXP1
TR45
External right
F_FMC_CLK_M2C_P
0
BR40
Internal right
GND
TR46
External right
F_FMC_LA_CC_N0
BR41
Internal right
F_FMC_LA_TXN0
TR47
External right
F_FMC_LA_CC_P0
BR42
Internal right
F_FMC_LA_TXP0
TR48
External right
GND
BR43
Internal right
GND
TR49
External right
F_FMC_LA_TXN6
TR50
External right
F_FMC_LA_TXP6
TR51
External right
F_FMC_LA_TXN5
TR52
External right
F_FMC_LA_TXP5
TR53
External right
GND
TR54
External right
F_FMC_LA_TXN4
TR55
External right
F_FMC_LA_TXP4
TR56
External right
F_FMC_LA_TXN3
TR57
External right
F_FMC_LA_TXP3
TR58
External right
5VSB
TT1
External top

THW-EKGS01 - REV. 0.2
©2019 EXOR Embedded S.r.l. - Subject to change without notice
exorint.com 14
5VSB
TT2
External top
5VSB
TT3
External top
5VSB
TT4
External top
5VSB
TT5
External top
5VSB
TT6
External top
5VSB
TT7
External top
5VSB
TT8
External top
5VSB
TT9
External top
5VSB
TT10
External top
GND
TT11
External top
GND
TT12
External top
GND
TT13
External top
GND
TT14
External top
GND
TT15
External top
GND
TT16
External top
GND
TT17
External top
GND
TT18
External top
SDIO_D0
TT19
External top
SDIO_D1
TT20
External top
SDIO_D2
TT21
External top
SDIO_D3
TT22
External top
SDIO_CMD
TT23
External top
SDIO_CLK
TT24
External top
GND
TT25
External top

THW-EKGS01 - REV. 0.2
©2019 EXOR Embedded S.r.l. - Subject to change without notice
exorint.com 15
HDA_SPKR
TT26
External top
HDA_WS_SYNC
TT27
External top
HDA_SDO
TT28
External top
HDA_SDI
TT29
External top
HDA_BCLK
TT30
External top
HDA_RST_N
TT31
External top
GND
TT32
External top
CAM_MCK
TT33
External top
CAM_I2C2_SCL
TT34
External top
CAM_I2C2_SDA
TT35
External top
CAM1_PWR
TT36
External top
CAM1_RST
TT37
External top
GND
TT38
External top
SMB_CLK_3P3
TT39
External top
SMB_DATA_3P3
TT40
External top
SMB_ALERT
TT41
External top
VCCRTC_3P3
TT42
External top
GND
TT43
External top
SATA_LED_N
TT44
External top
LPSS_I2C0_SDA
TT45
External top
LPSS_I2C0_SCL
TT46
External top
LPSS_I2C1_SDA
TT47
External top
LPSS_I2C1_SCL
TT48
External top
LPSS_I2C2_SDA
TT49
External top

THW-EKGS01 - REV. 0.2
©2019 EXOR Embedded S.r.l. - Subject to change without notice
exorint.com 16
LPSS_I2C2_SCL
TT50
External top
LPSS_I2C3_SDA
TT51
External top
LPSS_I2C3_SCL
TT52
External top
GND
TT53
External top
POWERBTNIN_N
TT54
External top
PMU_RSTBTN#
TT55
External top
PLTRST_N
TT56
External top
SOC_SLP_S3_N
TT57
External top
1V8A
TT58
External top
GND
TT59
External top
AVS_I2S2_SYNC
TT60
External top
AVS_I2S2_SDO
TT61
External top
AVS_I2S2_SDI
TT62
External top
AVS_I2S2_BCLK
TT63
External top
GND
TT64
External top
AVS_I2S1_SDI
TT65
External top
AVS_I2S1_SYNC
TT66
External top
AVS_I2S1_MCLK
TT67
External top
AVS_I2S1_SDO
TT68
External top
AVS_I2S1_BCLK
TT69
External top
VCC_ADJ_F
TT70
External top
VCC_ADJ_F
TT71
External top
VCC_ADJ_F
TT72
External top
VCC_ADJ_F
TT73
External top

THW-EKGS01 - REV. 0.2
©2019 EXOR Embedded S.r.l. - Subject to change without notice
exorint.com 17
F_GPIO_0
TT74
External top
F_GPIO_1
TT75
External top
F_GPIO_2
TT76
External top
F_GPIO_3
TT77
External top
F_GPIO_4
TT78
External top
F_EN_GROUP4
TT79
External top
IO_INT*
TT80
External top
F_FPGA_TMS
TT81
External top
F_FPGA_TDI
TT82
External top
F_FPGA_TDO
TT83
External top
F_FPGA_TCK
TT84
External top
GND
TT85
External top
F_SPF0_SDA
TT86
External top
F_SPF0_SCL
TT87
External top
F_FMC_LA_TXN7
TT88
External top
F_FMC_LA_TXP7
TT89
External top
SOC_PWM3
TB1
External
bottom
SOC_PWM2
TB2
External
bottom
SOC_PWM1
TB3
External
bottom
SOC_PWM0
TB4
External
bottom
GND
TB5
External
bottom
SATA_RXN1
TB6
External
bottom
GPIO8
BB1
Internal
bottom
SATA_RXP1
TB7
External
bottom
GND
BB2
Internal
bottom
SATA_TXN1
TB8
External
bottom
SIO_SPI1_FS0
BB3
Internal
bottom

THW-EKGS01 - REV. 0.2
©2019 EXOR Embedded S.r.l. - Subject to change without notice
exorint.com 18
SATA_TXP1
TB9
External
bottom
SIO_SPI1_RXD
BB4
Internal
bottom
GND
TB10
External
bottom
SIO_SPI1_TXD
BB5
Internal
bottom
SATA_RXN0
TB11
External
bottom
SIO_SPI1_CLK
BB6
Internal
bottom
SATA_RXP0
TB12
External
bottom
SIO_SPI1_FS1
BB7
Internal
bottom
SATA_TXN0
TB13
External
bottom
GND
BB8
Internal
bottom
SATA_TXP0
TB14
External
bottom
FST_SPI_HOLD#
BB9
Internal
bottom
GND
TB15
External
bottom
FST_SPI_WP#
BB10
Internal
bottom
PANEL1_BKLTCTL
TB16
External
bottom
FST_SPI_MOSI
BB11
Internal
bottom
DDI1_CLK
TB17
External
bottom
FST_SPI_MISO
BB12
Internal
bottom
DDI1_DATA
TB18
External
bottom
FST_SPI_CS2#
BB13
Internal
bottom
PANEL1_BKLTEN
TB19
External
bottom
FST_SPI_CS1#
BB14
Internal
bottom
PANEL1_VDDEN
TB20
External
bottom
FST_SPI_CLK
BB15
Internal
bottom
DDI1_HPD
TB21
External
bottom
GND
BB16
Internal
bottom
DDI1_AUXN_R
TB22
External
bottom
MCSI_RX_DATA3_N
BB17
Internal
bottom
DDI1_AUXP_R
TB23
External
bottom
MCSI_RX_DATA3_P
BB18
Internal
bottom
GND
TB24
External
bottom
MCSI_RX_DATA2_N
BB19
Internal
bottom
DDI1_TXN3
TB25
External
bottom
MCSI_RX_DATA2_P
BB20
Internal
bottom
DDI1_TXP3
TB26
External
bottom
GND
BB21
Internal
bottom
DDI1_TXN2
TB27
External
bottom
MCSI_RX_CLK1_N
BB22
Internal
bottom
DDI1_TXP2
TB28
External
bottom
MCSI_RX_CLK1_P
BB23
Internal
bottom
GND
TB29
External
bottom
GND
BB24
Internal
bottom
DDI1_TXN1
TB30
External
bottom
MCSI_RX_CLK0_N
BB25
Internal
bottom
DDI1_TXP1
TB31
External
bottom
MCSI_RX_CLK0_P
BB26
Internal
bottom
DDI1_TXN0
TB32
External
bottom
GND
BB27
Internal
bottom

THW-EKGS01 - REV. 0.2
©2019 EXOR Embedded S.r.l. - Subject to change without notice
exorint.com 19
DDI1_TXP0
TB33
External
bottom
MCSI_RX_DATA1_N
BB28
Internal
bottom
GND
TB34
External
bottom
MCSI_RX_DATA1_P
BB29
Internal
bottom
DDI0_TXN3
TB35
External
bottom
MCSI_RX_DATA0_N
BB30
Internal
bottom
DDI0_TXP3
TB36
External
bottom
MCSI_RX_DATA0_P
BB31
Internal
bottom
DDI0_TXN2
TB37
External
bottom
GND
BB32
Internal
bottom
DDI0_TXP2
TB38
External
bottom
USB3_RX0N
BB33
Internal
bottom
GND
TB39
External
bottom
USB3_RX0P
BB34
Internal
bottom
DDI0_TXN1
TB40
External
bottom
USB3_TX0N
BB35
Internal
bottom
DDI0_TXP1
TB41
External
bottom
USB3_TX0P
BB36
Internal
bottom
DDI0_TXN0
TB42
External
bottom
GND
BB37
Internal
bottom
DDI0_TXP0
TB43
External
bottom
USB3_RX1N
BB38
Internal
bottom
GND
TB44
External
bottom
USB3_RX1P
BB39
Internal
bottom
DDI0_AUXN_R
TB45
External
bottom
USB3_TX1N
BB40
Internal
bottom
DDI0_AUXP_R
TB46
External
bottom
USB3_TX1P
BB41
Internal
bottom
DDI0_HPD
TB47
External
bottom
GND
BB42
Internal
bottom
DDI0_DATA
TB48
External
bottom
PCIE2_RESET
BB43
Internal
bottom
DDI0_CLK
TB49
External
bottom
PCIE_WAKE1#
BB44
Internal
bottom
PANEL0_VDDEN
TB50
External
bottom
PCIE_CLKREQ2#
BB45
Internal
bottom
PANEL0_BKLTEN
TB51
External
bottom
GND
BB46
Internal
bottom
PANEL0_BKLTCTL
TB52
External
bottom
PCIE_CLKOUT2N
BB47
Internal
bottom
GND
TB53
External
bottom
PCIE_CLKOUT2P
BB48
Internal
bottom
PCIE_CLKREQ3#
TB54
External
bottom
GND
BB49
Internal
bottom
PCIE1_RESET
TB55
External
bottom
PCIE_P2_RXN
BB50
Internal
bottom
PCIE_WAKE2#
TB56
External
bottom
PCIE_P2_RXP
BB51
Internal
bottom

THW-EKGS01 - REV. 0.2
©2019 EXOR Embedded S.r.l. - Subject to change without notice
exorint.com 20
GND
TB57
External
bottom
PCIE_P2_TXN
BB52
Internal
bottom
PCIE_P0_RXN
TB58
External
bottom
PCIE_P2_TXP
BB53
Internal
bottom
PCIE_P0_RXP
TB59
External
bottom
GND
BB54
Internal
bottom
PCIE_P0_TXN
TB60
External
bottom
F_FMC_LA_RXN4
BB55
Internal
bottom
PCIE_P0_TXP
TB61
External
bottom
F_FMC_LA_RXP4
BB56
Internal
bottom
GND
TB62
External
bottom
GND
BB57
Internal
bottom
PCIE_CLKOUT3N
TB63
External
bottom
F_FMC_LA_RXN3
BB58
Internal
bottom
PCIE_CLKOUT3P
TB64
External
bottom
F_FMC_LA_RXP3
BB59
Internal
bottom
GND
TB65
External
bottom
F_FMC_LA_RXN5
BB60
Internal
bottom
PCIE_P1_RXN
TB66
External
bottom
F_FMC_LA_RXP5
BB61
Internal
bottom
PCIE_P1_RXN
TB67
External
bottom
GND
BB62
Internal
bottom
PCIE_P1_TXN
TB68
External
bottom
F_FMC_LA_RXN6
BB63
Internal
bottom
PCIE_P1_TXP
TB69
External
bottom
F_FMC_LA_RXP6
BB64
Internal
bottom
GND
TB70
External
bottom
F_FMC_LA_RXN2
BB65
Internal
bottom
F_CTS1_1V5
TB71
External
bottom
F_FMC_LA_RXP2
BB66
Internal
bottom
F_RTS1_1V5
TB72
External
bottom
GND
BB67
Internal
bottom
F_RX1_1V5
TB73
External
bottom
F_FMC_LA_RXN0
BB68
Internal
bottom
F_TX1_1V5
TB74
External
bottom
F_FMC_LA_RXP0
BB69
Internal
bottom
F_SFP_INT1
TB75
External
bottom
F_FMC_LA_RXN1
BB70
Internal
bottom
F_SFP_INT0
TB76
External
bottom
F_FMC_LA_RXP1
BB71
Internal
bottom
F_VREF_FMC
TB77
External
bottom
FMC_PRENT
TB78
External
bottom
GND
TB79
External
bottom
1V5_MEM_F
TB80
External
bottom
