Advantech CompactPCI MIC-3032/8 User manual

MIC-3032/8
6U 8-slot enclosure with CT bus and
rear I/O for CompactPCI TM

Preface and Table of Contents
PartNo.2008303200 1st Edition
PrintedinTaiwan January 2000
Copyright Notice
This document is copyrighted, 2000. All rights are reserved. The
original manufacturer reserves the right to make improvements to the
products described in this manual at any time without notice.
No part of this manual may be reproduced, copied, translated or
transmitted in any form or by any means without the prior written
permission of the original manufacturer. Information provided in this
manual is intended to be accurate and reliable. However, the original
manufacturer assumes no responsibility for its use, nor for any
infringements upon the rights of third parties which may result from its
use.
Acknowledgements
PICMG™,CompactPCI™ andthePICMG™, CompactPCI™logos are
trademarks of the PCI Industrial Computers Manufacturers Group
All other product names or trademarks are properties of their
respective owners.
CE Notification
The MIC-3032/8, developed by Advantech Co., Ltd., has passed the
CE test for environment specifications when shielded cables are used
for external wiring. We recommend the use of shielded cables.

MIC-3032/8 User's Manual

Preface and Table of Contents
Product warranty
Advantech warrants to you, the original purchaser, that each of its
products will be free from defects in materials and workmanship for
one year from the date of purchase.
This warranty does not apply to any products which have been
repaired or altered by persons other than repair personnel authorized
by Advantech, or which have been subject to misuse, abuse, accident
or improper installation. Advantech assumes no liability under the
terms of this warranty as a consequence of such events.
Because of Advantech’s high quality-control standards and rigorous
testing, most of our customers never need to use our repair service. If
an Advantech product is defective, it will be repaired or replaced at no
charge during the warranty period. For out-of-warranty repairs, you
will be billed according to the cost of replacement materials, service
time and freight. Please consult your dealer for more details.
If you think you have a defective product, follow these steps:
1. Collect all the information about the problem encountered. For
example, CPU speed, Advantech products used, other hardware
and software used, etc. Note anything abnormal and list any on-
screen messages you get when the problem occurs.
2. Call your dealer and describe the problem. Please have your
manual, product, and any helpful information readily available.
3. If your product is diagnosed as defective, obtain an RMA (return
merchandise authorization) number from your dealer. This allows us
to process your return more quickly.
4. Carefully pack the defective product, a fully-completed Repair and
Replacement Order Card and a photocopy proof of purchase date
(such as your sales receipt) in a shippable container. A product
returned without proof of the purchase date is not eligible for
warranty service.
5. Write the RMA number visibly on the outside of the package and
ship it prepaid to your dealer.

MIC-3032/8 User's Manual
Packing List
Before installation, ensure that the following materials have been
received:
• OneMIC-3032/8CompactPCIenclosure with backplane
• One box of accessories
• One warranty certificate
• MIC-3920/MIC-3921user’s manual
• PC Sentry user’s manual
• This user's manual
If any of these items are missing or damaged, contact your distributor
or sales representative immediately.
Technical Support and Sales Assistance
If you have any technical questions about the MIC-3032/8 or any
other Advantech products, please visit our support website at:
•http://www.advantech.com.tw/support
For more information about Advantech's products and sales informa-
tion, please visit:
•http://www.advantech.com

Preface and Table of Contents
Contents
1. General Information ............................................................ 1
1.1 Introduction ...................................................................................2
1.2 Features.........................................................................................3
1.3 Specifications ................................................................................4
1.3.1 General ..............................................................................................4
1.3.2 Hot-swap Fans .................................................................................4
1.3.3 Power Supply ...................................................................................5
1.4 Dimensions ...................................................................................6
2. Installation ........................................................................... 7
2.1 InitialInspection ...........................................................................8
2.2 TheMIC-3032/8Illustration ........................................................9
2.3 InstallationProcedures............................................................... 11
2.3.1 Card Installation and Removal ........................................................11
2.3.2 Before Operating the System .........................................................13
2.3.3 Installing Peripherals ......................................................................13
2.3.4 Installing a 5.25" Device .................................................................14
2.3.5 Installing a 3.5" Floppy Disk Drive ...............................................15
2.3.6 Replacing the Hot-swap Fan and Air Filter ...................................16

MIC-3032/8 User's Manual
Figures
Figure 1-1: MIC-3032/8 dimensions .............................................................. 6
Figure 2-1: Front view of MIC-3032/8 ............................................................. 9
Figure 2-2: Rear view of MIC-3032/8 ........................................................... 10
Figure 2-3: Installing a card into the chassis .............................................. 12
Figure 2-4: Attaching the mounting brackets to a 5.25" device ................... 14
Figure 2-5: Attaching the mounting brackets to a 3.5" floppy disk drive ...... 15
Figure 2-6: Recommended device bay configuration ................................. 16

Chapter 1 General Information 1
1
General Information
CHAPTER

2MIC-3032/8 User's Manual
1.1 Introduction
The MIC-3032/8 is an 8-slot CompactPCI enclosure for rack or panel
mounting. This 9U high enclosure provides eight 6U card slots, and
has a drive bay which can accommodate devices and peripherals such
as floppy disk drives and hard disk drives. The MIC-3032/8 has three
cooling fans to provide forced cooling air in the system. These three
fans are individually hot-swappable, and users can directly replace any
of the fans without interrupting the system's operation. The MIC-
3032/8 provides versatile power supply options and are available in
three versions:
• MIC-3032/8-9A:CompactPCI8-slot enclosure with ATX400 W AC
power supply
• MIC-3032/8-9D:CompactPCI 8-slot enclosurewithATX400 WDC
power supply
• MIC-3032/8-9R:CompactPCI8-slotenclosure with 300 W redundant
power supply
The MIC-3032/8 is integrated with a backplane and an alarm module.
Please refer to the backplane and alarm module manuals for more
detailedinformation.

Chapter 1 General Information 3
1.2 Features
• Eight 6U card slots
• Supports front and rear I/O
• Supports H.110 CT bus
• Drive bay accommodates up to 4 devices, secured by a lockable
door
• Versatile power supply options
• Hot-swap compliant backplane
• Hot-swap fans
• Integrated intelligent fault detection and alarm module

4MIC-3032/8 User's Manual
1.3 Specifications
1.3.1 General
•Construction:Aluminum frame and galvanized sheet steel
•Drivebay: Accommodates up to three 5.25"/3.5" drives and one 3.5"
floppy disk drive, front removable
• 12-slot space (48 TE), incl. 7 CompactPCI slots and one system slot
• "Hotswappable”platformcomplieswithPICMG2.1R1.0HotSwap
Specification
•Dimensions(W x H x D, mounting flanges not included):
9U:440x400x342mm(17.3"x16"x13.5")
•Weight:16kg
•Operatingtemperature:0~ 50° C(32~ 122° F)
•Storagetemperature:-20° C ~60°C(-4 ~ 158° F)
•Relativehumidity:10~95% @ 40° C, non-condensing
•Operatingaltitude: 0~ 3,048meters (0~ 10,000feet)
•Storage/transitaltitude: 0~ 12,190meters(40,000 feet)
•Shock: 10 G (operating); 30 G (storage/transit)
•Randomvibration:1.0Grms(operating)
1.3.2 Hot-swap Fans
•Airflow:Three86-CFMfans,providing 258 CFM in total
•Powerconsumption:0.45 A @12V per fan,1.3A total
•Ratedfanspeed:2170rpm
•Lifeexpectancy:50,000 hours @ 25°C

Chapter 1 General Information 5
1.3.3 Power Supply
MIC-3032/8-9A (ATX AC power supply)
•Input:90 ~135 or180 ~265 VAC @47~ 63Hz, switchable
•Output:+3.3 V@ 20A,+5V@42A,+12V@14A,-12 V@ 1.0A
•Minumumload:+3.3V@0.3A,+5V@2.5A
•Maxoutput:400W total,160 Wfor 5V and3.3V
•MTBF:100,000 hours@ 70%load
•Safety:UL/CUL/CE
MIC-3032/8-9D (ATX DC power supply)
•Input:-38~-72VDC
•Output:+3.3 V@ 20A,+5V@30A,+12V@14A,-12 V@ 1.0A
•Minumumload:+3.3V @0.1A,+5 V@ 2A,+12V@1A
•Maxoutput:250W total,170 Wfor 5V and3.3V
•MTBF:50,000hours @70% load
•Safety:UL/CUL/CE
MIC-3032/8-9R (redundant power supply)
•Input:90~264@47~63Hz,switchable
•Output:+3.3 V@ 22A,+5V@30A,+12V@13A,-12 V@ 1.0A
•Minumumload:+3.3V@0.3A,+5V@2A,+12V@0.5 A
•Maxoutput:300 W + 300Wredundant, 160 Wfor5 V and 3.3V
•MTBF:100,000 hours@ 70%load
•Safety:UL/CUL/CE

6MIC-3032/8 User's Manual
1.4 Dimensions
Figure 1-1: MIC-3032/8 dimensions

Chapter 2 Installation 7
2
Installation
CHAPTER

8MIC-3032/8 User's Manual
2.1 Initial Inspection
We have carefully inspected the MIC-3032/8 mechanically and
electrically before shipping. It should be free of marks and scratches
and in perfect working order upon receipt.
As you unpack the MIC-3032/8, check it for signs of shipping damage
(damaged box, scratches, dents, etc.). If it is damaged or fails to meet
specifications, notify our service department or your local representa-
tive immediately. Also notify the carrier. Retain the shipping carton and
packing material for inspection by the carrier. After inspection, we will
make arrangements to repair or replace the unit.
Warning! We strongly recommend that only qualified, experi-
enced personnel install or remove components. They
must exercise extreme caution when doing so.

Chapter 2 Installation 9
2.2 The MIC-3032/8 Illustration
The MIC-3032/8 is designed to be installed and maintained easily.
Figure 2-1 and Figure 2-2 illustrate important components on the front
and rear side of the enclosure.
Figure 2-1: Front view of MIC-3032/8
System slot
Device
protection
door
Power on/off switch
Intelligent system alarm module
Integrated
fan tray

10 MIC-3032/8 User's Manual
Figure 2-2: Rear view of MIC-3032/8
Power
supply
Intelligent system alarm module
Rear panel I/O

Chapter 2 Installation 11
2.3 Installation Procedures
2.3.1 Card Installation and Removal
The CompactPCI connectors are firm and rigid, and require careful
handling while plugging and unplugging. Improper installation of a
card can easily damage the backplane of the chassis.
The system card can be installed only in the system slot. The
CompactPCI specification allows the system slot to be in any position
in the backplane. Do not insert the system card into any other slot, or
insert a peripheral card into the system slot. The MIC-3021/8 accepts
different backplanes, so the location of the system slot may vary. The
system slot is marked by a triangle enclosing the slot number. Please
refer to the backplane user's manual.
The insert/eject handles on CompactPCI cards help users to install and
remove the cards easily and safely. Follow the procedures below to
install a card into a chassis:
To install a card:
1. Hold the card vertically. Be sure that the card is oriented correctly.
The components of the card should be pointing to the right-hand
side.
2. Be sure that the handles of the card are not latched. Release the
handles if they are latched. Handles from different vendors may
have different latch designs.
Caution: Keep your fingers away from the latch hinges to
prevent your fingers from getting pinched.
3. Insert the card into the chassis by sliding the upper and lower
edges of the card into the card guides.
4. Push the card into the slot gently by sliding the card along the card
guide until the handles meet the rectangular holes of the cross rails.

12 MIC-3032/8 User's Manual
Fig. 2-3: Installing a card into the chassis
Note: If the card is correctly positioned and has been slid
all the way into the chassis, the handles should
match the rectangular holes. If not, remove the card
from the card guide and repeat step 3 again. Do not
try to install a card by forcing it into the chassis.
5. Pull the upper handle down and lift the lower handle up to push the
card into place.
6. Secure the card by locking the handles into place.
To remove a card:
1. Unscrew the screws on the card front panel. Release the locking
latches on the handles.
2. Lift the upper handle up and press the lower handle down to release
the card from the backplane.
3. Slide the card out.
Kee
p
y
our fin
g
ers
awa
y
from this area.

Chapter 2 Installation 13
2.3.2 Before Operating the System
Before operating your system, first check your power supply source.
Adjust the switch on the power supply to the correct voltage.
Two mounting flanges are included for users who would like to install
the MIC-3032/8 on a 19" rack or on a panel. These flanges can be
installed on the front side for rack mounting or on the rear side for
panel mounting.
Four rubber stands can be attached to the bottom of the chassis for
desktop operation. They are not required for rack mounting.
2.3.3 Installing Peripherals
The device bay of the MIC-3032/8 accepts four devices, including
three 5.25"/3.5" devices and one 3.5" floppy disk drive. If the lower
two trays in the device bay are not occupied by power supplies, the
device bay may accommodate two more devices.
There are two types of mounting brackets shipped with the MIC-3032/
8. Three pairs of mounting brackets are designed for mounting 5.25"
devices such as hard disk drives or CD-ROM drives. Please refer to
Figure 2-4 for an illustration of mounting. However, if users would like
to use a 3.5" hard disk drive in the MIC-3032/8, extension brackets
(3.5" to 5.25") are required. These extension brackets are commonly
available in PC shops, or users can contact an Advantech distributor
to order them. For mounting a 3.5" floppy disk drive, a pair of mount-
ing brackets are provided. Users can mount the floppy disk drive on
the top tray in the device bay. Please refer to Figure 2-5 for an illustra-
tion of mounting. Figure 2-6 shows the recommended device bay
configuration.
