Advantech MIC-3351 Installation and operation manual

Modular Industrial Computer
MIC-3351
3U-sized Pentium®MMX CPU board for
CompactPCI

Preface and Table of Contents
Copyright Notice
This document is copyrighted, 1999. All rights are reserved. The
original manufacturer reserves the right to make improvements to the
products described in this manual at any time without notice.
No part of this manual may be reproduced, copied, translated or
transmitted in any form or by any means without the prior written
permission of the original manufacturer. Information provided in this
manual is intended to be accurate and reliable. However, the original
manufacturer assumes no responsibility for its use, nor for any
infringements upon the rights of third parties which may result from its
use.
Acknowledgements
Award is a trademark of Award Software International, Inc.
Fast EtherChannel (FEC) is a trademark of Cisco Systems, Inc.
IBM, PS/2, OS/2, and VGA are trademarks of International Business
Machines Corporation.
Intel,Pentium,andPRO/100+aretrademarksofIntelCorporation.
Windows is a registered trademark of Microsoft Corporation.
NetWare is a trademark of Novell, Inc.
Symbios is a trademark of Symbios Logic Corporation.
PICMG™,CompactPCI™andthePICMG™,and CompactPCI™ logos
are trademarks of the PCI Industrial Computers Manufacturers Group.
All other product names or trademarks are properties of their
respective owners.
CE Notification
The MIC-3351, developed by Advantech CO., LTD., has passed the CE
test for environment specification when shielded cables are used for
external wiring and sleeve core clamps are added to the USB cables.
We recommend the use of shielded cables and sleeve core clamps.
Part No. 2003335100 1st Edition
Printed in Taiwan September 1999

MIC-3351 User's Manual

Preface and Table of Contents
Product warranty
Advantech warrants to you, the original purchaser, that each of its
products will be free from defects in materials and workmanship for
one year from the date of purchase.
This warranty does not apply to any products which have been
repaired or altered by persons other than repair personnel authorized
by Advantech, or which have been subject to misuse, abuse, accident
or improper installation. Advantech assumes no liability under the
terms of this warranty as a consequence of such events.
Because of Advantech’s high quality-control standards and rigorous
testing, most of our customers never need to use our repair service. If
an Advantech product is defective, it will be repaired or replaced at no
charge during the warranty period. For out-of-warranty repairs, you
will be billed according to the cost of replacement materials, service
time and freight. Please consult your dealer for more details.
If you think you have a defective product, follow these steps:
1. Collect all the information about the problem encountered. (For
example, CPU speed, Advantech products used, other hardware
and software used, etc.) Note anything abnormal and list any on-
screen messages you get when the problem occurs.
2. Call your dealer and describe the problem. Please have your
manual, product, and any helpful information readily available.
3. If your product is diagnosed as defective, obtain an RMA (return
merchandize authorization) number from your dealer. This allows us
to process your return more quickly.
4. Carefully pack the defective product, a fully-completed Repair and
Replacement Order Card and a photocopy proof of purchase date
(such as your sales receipt) in a shippable container. A product
returned without proof of the purchase date is not eligible for
warranty service.
5. Write the RMA number visibly on the outside of the package and
ship it prepaid to your dealer.

MIC-3351 User's Manual
Packing List
Before installing your board, ensure that the following materials have
been received:
• OneMIC-3351all-in-onesingleboardcomputer
• OneutilityCD-ROMdisc
• Two serial port cables
• One 6-pin mini-DIN to PS/2 keyboard and PS/2 mouse cable
• One bracket for mounting floppy drive
• Oneharddiskdrive(IDE)interfacecable(44-pin)
• One26-pinFPCforfloppydrive
• One warranty certificate
• This user's manual
If any of these items are missing or damaged, contact your distributor
or sales representative immediately.
Technical Support and Sales Assistance
If you have any technical questions about the MIC-3351 or any other
Advantech products, please visit our support website at:
•http://support.advantech.com.tw
For more information about Advantech's products and sales informa-
tion, please visit:
•http://www.advantech.com

Preface and Table of Contents
Contents
1.Hardware Configuration ...................................................... 1
1.1 Introduction ......................................................................................2
1.2 Specifications ...................................................................................2
1.2.1 Standard SBC functions ........................................................................2
1.2.2 PCI SVGA interface ..............................................................................3
1.2.3 Ultra2 Wide SCSI Interface (MIC-3351S only) ...................................3
1.2.4 Mechanical and environmental specifications .......................................4
1.3 FunctionBlock Diagram ..................................................................5
1.4 BoardDimensions ............................................................................6
1.5 Jumpers ............................................................................................7
1.5.1 Jumper Locations .................................................................................. 7
1.5..2 Jumper Settings .....................................................................................8
1.5.3 Clear CMOS (JP1, pin 2,4,6) ...............................................................9
1.5.4 CompactFlash master/slave selection (JP1, pin 1,3,5) .........................9
1.6 Connectors .....................................................................................10
1.7 FrontPanelConnectorsandIndicators .........................................13
1.8 SafetyPrecautions .........................................................................14
1.9 InstallingSDRAM(SODIMMs).....................................................15
2.Connecting Peripherals .................................................... 17
2.1 IDEDevice(CN7) ............................................................................18
2.2 FloppyDrive(CN6) .........................................................................19
2.3 CompactFlashInterface(CN5) .......................................................19
2.4 VGADisplayConnector(CN1) ......................................................19
2.5 ParallelPort Connector(CN8) ......................................................19
2.6 PS/2KeyboardandMouseConnector(CN3) .................................20
2.7 SerialPorts (CN2) .........................................................................20
2.8 EthernetConfiguration(CN9) .......................................................21
2.9 USBConnector(CN4) ....................................................................21
2.10 Ultra2Wide SCSIInterface(CN10) ..............................................21
2.11 CardInstallation .............................................................................21

MIC-3351 User's Manual
3.Ethernet Software Configuration ..................................... 25
3.1 Introduction ....................................................................................26
3.2 UtilityandDrivers ..........................................................................26
4.SVGA Setup ........................................................................ 29
4.1 Introduction ....................................................................................30
4.2 InstallationofSVGADriver...........................................................30
4.2.1 Installation for Windows 3.1 ..............................................................31
4.2.2 Installation for Windows 95 ...............................................................33
4.2.3 Installation for Windows 98 ...............................................................33
4.2.4 Installation for Windows NT ..............................................................34
5.SCSI Software Configuration .......................................... 37
5.1 Introduction ....................................................................................38
5.2 UtilityUser's Guideand InstallationInstructions .........................38
5.3 BuildingDriver Diskettes .............................................................40
5.4 DriverandUtilityInstallation ........................................................41
6.Award BIOS Setup ............................................................. 43
6.1 AWARD BIOSSetup ......................................................................44
6.1.1 Entering setup .....................................................................................44
6.1.2 Standard CMOS setup ........................................................................45
6.1.3 BIOS features setup ............................................................................46
6.1.4 CHIPSET features setup ....................................................................50
6.1.5 Power management setup ...................................................................51
6.1.6 PCI configuration setup ......................................................................52
6.1.7 Load BIOS defaults .............................................................................52
6.1.8 Load setup defaults .............................................................................52
6.1.9 Integrated Peripherals .........................................................................53
6.1.10 Password setting .................................................................................53
6.1.11 IDE HDD auto detection ....................................................................53
6.1.12 Save & exit setup ................................................................................54
6.1.13 Exit without saving .............................................................................54
A.Programming the Watchdog Timer .................................. 55
A.1 ProgrammingtheWatchdogTimer ...............................................56

Preface and Table of Contents
B.Pin Assignments ................................................................ 59
B.1 VGADisplayConnector(CN1) ......................................................60
B.2 KeyboardandMouseConnnector(CN3) ........................................60
B.3 COM1andCOM2SerialPort(CN2).............................................61
B.4 USB Connector(CN4) ....................................................................62
B.5 EthernetRJ-45Connector(CN9) ..................................................62
B.6 ParallelPortConnector (CN8) ......................................................63
B.7 IDEConnector(CN7)......................................................................64
B.8 FloppyDriveConnnector(CN6) .....................................................65
B.9 Ultra2WideSCSIConnector(CN10)............................................66
B.10 CompactFlashSocket(CN5) ..........................................................68
B.11 SystemI/O Ports ............................................................................69
B.12 DMAChannel Assignments ..........................................................70
B.13 InterruptAssignments ...................................................................70
B.14 1stMBMemoryMap ......................................................................71
B.15 J1connector pin assignments .......................................................72
B.16 J2connector pin assignments .......................................................73

MIC-3351 User's Manual
Figures
Figure 1-1: MIC-3351 function block diagram ....................................... 5
Figure 1-2: MIC-3351 board dimensions .............................................. 6
Figure 1-3: MIC-3351 jumper locations ................................................ 7
Figure 1-4: MIC-3351 upper layer connector locations ....................... 11
Figure 1-5: MIC-3351 lower layer connector locations ........................ 12
Figure 1-6: MIC-3351 front panel connector and indicator locations ... 13
Figure 2-1: Installing hard disk drive and floppy disk drive .................. 18
Figure 2-2: Installing the card into the chassis .................................. 23
Figure 6-1: Setup program initial screen ............................................ 44
Figure 6-2: CMOS setup screen ........................................................ 45
Figure 6-3: BIOS features setup screen............................................. 46
Figure 6-4: CHIPSET features setup screen ...................................... 50
Figure 6-5: Power management setup screen ................................... 51
Figure 6-6: PCI configuration screen .................................................. 52
Figure 6-7: Integrated peripherals ...................................................... 53

Preface and Table of Contents
Tables
Table 1-1: MIC-3351 jumper descriptions .............................................. 7
Table 1-2: Clear CMOS ........................................................................ 9
Table 1-3: CompactFlash master/slave selection .................................. 9
Table 1-4: MIC-3351 connector descriptions ....................................... 10
Table 2-1: MIC-3351 serial port default settings .................................. 21
Table B-1: MIC-3351 CRT display connector ....................................... 60
Table B-2: MIC-3351 keyboard connector ............................................ 60
Table B-3: MIC-3351 COM1 and COM2 serial port .............................. 61
Table B-4: MIC-3351 USB1/USB2 connector ....................................... 62
Table B-5: MIC-3351 Ethernet RJ-45 connector ................................... 62
Table B-6: MIC-3351 parallel port connector ........................................ 63
Table B-7: MIC-3351 IDE connector .................................................... 64
Table B-8: MIC-3351 floppy drive connector ......................................... 65
Table B-9: MIC-3351 Ultra2 Wide SCSI connector .............................. 66
Table B-10: MIC-3351 CompactFlash socket ...................................... 68
Table B-11: System I/O ports ............................................................. 69
Table B-12: DMA channel assignments .............................................. 70
Table B-13: Interrupt assignments ...................................................... 70
Table B-14: 1st MB memory map ....................................................... 71
Table B-15: J1 connector pin assignments ......................................... 72
Table B-16: J2 connector pin assignments ......................................... 73

1
Hardware
Configuration
CHAPTER

2MIC-3351 User's Manual
1.1 Introduction
TheMIC-3351isa3U-sizedCompactPCITM all-in-one single board
computerwithPentium®MMX 266 CPUandcomplies with PICMG 2.0
R2.1CompactPCIspecifications. TheMIC-3351featuresapowerful
on-board Intel Pentium MMX 266 MHz CPU with low power dissipa-
tion. This CPU is designed for fan-less operation and has a wider
operating temperature range. The MIC-3351 offers very powerful
functions on a 3U-sized board for performance-demanding applica-
tions like real-time machine control and indstrial automation.
The MIC-3351 is available in two versions:
• MIC-3351:3UCompactPCI Pentium MMXCPUboard with a parallel
port.
• MIC-3351S:3UCompactPCI Pentium MMXCPUboard with an
Ultra2Wide SCSI interface
Please check which version of the MIC-3351 you have on hand. Some
of the functions in this manual may not be applicable to some version.
1.2 Specifications
1.2.1 Standard SBC functions
•CPU:On-boardIntel Pentium®MMX266 MHzCPU
•BIOS:Award 2 Mb flash BIOS
•Chipset:Intel 430TX
•Systembus frequency:66MHz
•L2cache:512KBonboard
•RAM:Two 144-pin SODIMM sockets. Supports up to 256 MB
SDRAM
•EIDEinterface:Handlesup to 2 IDE HDDs or other IDE devices.
Supports PIO mode 4 and Ultra DMA/33 mode
•CompactFlash interface: Providesone CompactFlash socket on IDE
channel, master/slave selectable by a jumper

Chapter 1 Hardware Configuration 3
•FDD interface: Supports up to two floppy disk drives
•Parallelport:Configured to LPT1, LPT2, LPT3ordisabled.
Supportsmulti-mode parallel port(SPP/ECP/EPP),MIC-3351 only
•Serialports:Two RS-232portswith16C550 UARTs
•Ethernet:Intel82559 Fast Ethernet Controller Chip 10/100Base-TX
with RJ-45 connector
•Keyboard/mouseconnector:One 6-pin mini-DINconnectoronthe
front panel
•USBinterface: Two USB connectors with fuse protection. Complies
withUSBspecification1.0
•PCI-to-PCIbridge:One Intel DEC 21150controllerchip, drives up to
seven bus master peripherals
•Watchdogtimer: Can generate a system reset or IRQ 15. Software
enabled/disabled. Time interval is from 1 to 63 seconds, jumperless
with run-time setup
1.2.2 PCI SVGA interface
•Controller:IntelC&T 69000
•Displaymemory:On-chip 2MBSDRAM
•DisplayResolution:
• 640x 480 with256/64 K/16 Mcolordisplay, 60/75/85Hz
• 800x 600 with256/64 K/16 Mcolordisplay, 60/75/85Hz
• 1024x 768with256/64 Kcolordisplay, 60/75/85Hz
• 1280x 1024with256 colordisplay,60 Hz
1.2.3 Ultra2 Wide SCSI Interface (MIC-3351S only)
•Controller:SymbiosSYM53C895
• Supports16-bitLowVoltage Differential(LVD)and Single Ended
(SE)signaling
• Performs Ultra2 Wide SCSI LVD synchronous. Transfers as fast as
80 MB/s

4MIC-3351 User's Manual
1.2.4 Mechanical and environmental specifications
•Boardsize:160 x 100mm(3U size), 2-slot(8TE)wide. Optional 1-slot
wide on-board FDD mounting bracket
•Max.powerrequirements:+5 V(4.75~5.25V)@2.30A(under
typical conditions)
•Operatingtemperature: 0~ 70°C (32 ~158° F)
•Storagetemperature: -20°C ~80°C(-4~176° F)
•Humidity(operatingand storage): 5~95% (non-condensing)
•Boardweight:0.8 kg(1.8 lb)
•Shock: 20 G (operating); 50 G (storage/transit)
•Randomvibration:1.5Grms

Chapter 1 Hardware Configuration 5
1.3 Function Block Diagram
Figure 1-1: MIC-3351 function block diagram

6MIC-3351 User's Manual
1.4 Board Dimensions
Figure 1-2: MIC-3351 board dimensions
160 mm
100 mm

Chapter 1 Hardware Configuration 7
1.5 Jumpers
1.5.1 Jumper Locations
The MIC-3351 provides jumpers for configuring your board for
specific applications other than the default settings.
Table 1-1 list the jumper functions. Figure 1-3 illustrates the jumper
locations.
Table 1-1: MIC-3351 jumper descriptions
Number Function
JP1 (1, 3, 5) CompactFlash master/slave selection
(2, 4, 6) Clear CMOS
Figure 1-3: MIC-3351 jumper locations
JP1
2 4 6
1 3 5

8MIC-3351 User's Manual
1.5..2 Jumper Settings
This section tells how to set the jumpers to configure your card. It
gives the card default configuration and your options for each jumper.
After you set the jumpers and install the card, you will also need to run
the BIOS Setup program (discussed in Chapter 6) to configure the
serial port addresses, floppy/hard disk drive types and system
operating parameters. Connections, such as hard disk cables, appear in
Chapter 2.
For the locations of each jumper, see the board layout diagram
depicted earlier in this chapter.
You configure your card to match the needs of your application by
setting jumpers. A jumper is the simplest kind of electric switch. It
consists of two metal pins and a small metal cap (often protected by a
plastic cover) that slides over the pins to connect them. To "close" a
jumper you connect the pins with the cap. To "open" a jumper you
remove the cap. Sometimes a jumper will have three pins, labeled 1, 2
and 3. In this case you connect either pins 1 and 2 or 2 and 3.
The jmper settings are schematically depicted in this manual as
follows:
Open Closed Closed 2-3
You may find a pair of needle-nose pliers useful for setting the
jumpers.
If you have any doubts about the best hardware configuration for
your application, contact your local distributor or sales representative
before you make any changes.
1
13
2
Open Closed Closed 2-3

Chapter 1 Hardware Configuration 9
1.5.3 Clear CMOS (JP1, pin 2,4,6)
This jumper is used to erase CMOS data and reset system BIOS
information. Follow the procedures below to clear the CMOS.
1. Turn off the system.
2.Close jumperJP1(4-6).
3. Turn on the system. The CMOS is now cleared.
4. Turn off the system. Close jumper JP1 (2-4).
5. Turn on the system. The BIOS is reset to its default setting.
Table 1-2: Clear CMOS
CMOS JP1
Clear
Normal
1.5.4 CompactFlash master/slave selection
(JP1, pin 1,3,5)
This jumper is used to set the CompactFlash card to be IDE master or
slave. The CompactFlash socket is connected to the primary IDE
channel. If a CompactFlash card and an IDE drive are connected to the
primary IDE channel at the same time, we recommend to set the
CompactFlash card as master and the other IDE drive as slave.
Otherwise, the MIC-3351 may not be able to detect the CompactFlash
correctly.
Table 1-3: CompactFlash master/slave selection
CMOS JP1
Master
Slave
135
246
246
135
246
135
246
135

10 MIC-3351 User's Manual
1.6 Connectors
On board connectors link to external devices such as hard disk drives,
keyboards, or floppy drives, etc. Table 1-4 lists the function of each
connector and Figure 1-4 and Figure 1-5 illustrate each connector
location. Chapter 2 gives instructions for connecting external devices
to your card.
Table 1-4: MIC-3351 connector descriptions
Number Function
SW1 Reset switch
CN1 VGA connector
CN2 COM1 and COM2 connector
CN3 PS/2 Keyboard and mouse connector
CN4 USB connector
CN5 CompactFlash socket
CN6 Floppy disk drive connector
CN7 IDE connector
CN8 Parallel port
CN9 Ethernet connector
CN10 Ultra2 Wide SCSI interface connector
DIMM1 SODIMM socket 1
DIMM2 SODIMM socket 2
LED1 HDD LED
LED2 Power LED
J1/J2 Primary CompactPCI bus
Please refer to Appendix B for pin assignments.
