Advantech PCA-6029 Installation and operation manual

PCA-6029 Startup Manual 1
Before you begin installing your card, please make sure the
following items have been shipped:
1. PCA-6029 PICMG 1.0 Single Board Computer
2. 1x PCA-6029 startup manual P/N: 2041602900
3. 2x Serial ATA HDD data cables P/N: 1700003194
4. 1x COM + printer ports cable kit P/N: 1701260305
5. 1x 4-port USB cable kit P/N: 1700008461-11
6. 1x Keyboard and mouse Y cable P/N: 1700060202
7. 1x Warranty card P/N: 2190000902
If any of these items are missing or damaged, please con-
tact your distributor or sales representative immediately.
Note 1:  AcrobatReaderisrequiredtoviewPDFles.Ac-
robat Reader can be downloaded at: get.adobe.
com/reader (Acrobat is a trademark of Adobe)
PCA-6029 LGA1151 6th and 7th Gen. Intel®Core™
i7/i5/i3/Pentium™/Celeron™ System Host Board with
VGA/DVI/DP and Dual GbE LAN
Startup Manual
General
• CPU: LGA1151 6th and 7th Gen. Intel®Core™ i7/i5/i3/
Pentium™/Celeron™
• BIOS: AMI 128Mbit SPI Flash
• Chipset: Intel®H110
• System memory: Dual-channel (non-ECC) U-DIMM
DDR4 2133/2400, up to 64 GB (32 GB per DIMM)
Note: 6th Gen. CPU up to 2133, 7th Gen. CPU up to 2400
• SATA ports: SATA 3.0 x 4 (600 MB/sec)
• Serial ports: 2x RS-232 with pin headers
• Parallel port: 1x parallel port, supports SPP/EPP/ECP
mode
• Keyboard/mouse connector: Supports 1x standard
PS/2 keyboard and mouse connector and 1x external
6-pin header
• Watchdog timer: 255 level timer intervals
• USB 2.0: Up to 7 (6x pin header, 1x vertical type A)
• USB 3.0: Up to 3 (2x pin header, 1x rear)
• GPIO: One programmable 8-bit GPIO pin-header
VGA Interface
• Chipset: Intel® HD graphics
• Shared system memory determined by OS
Ethernet Interface
• Chipset Supports:
- LAN1: Intel® I219-V
- LAN2: Intel® I211-AT
• Connection: 2x on-board RJ-45 connector with LED
indicators”
Mechanical and Enviromental
• Dimensions: (L x W): 338 x 122 mm (13.3 x 4.8 in)
• Power supply voltage: +12V, +5V, +5VSB
• Power requirements:
i7-6700 CPU, 32G 2Rx8 DDR4 3200U*2, SEAGATE
500GB*1
Voltage: +V12, +V5, +V5_SB, +V12_4P
Current: 0.13A, 0.94A, 0.08A, 1.33A
• Operating temperature: 0 ~ 60 °C (32 ~ 140 °F) (de-
pending on CPU)
• Weight: 0.5 kg/1.10 lb (weight of board)
Specications
Packing List
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com
http://www.advantech.com/eplatform
For technical support and service, please visit our
support website at:
https://advt.ch/PCA-6029
This manual is for the PCA-6029 Series Rev. A1.
Part No. 2041602900
Printed in China
1st Edition
November 2020

2 PCA-6029 Startup Manual
This board has a number of jumpers that allow users to con-
guretheirsystemtosuittheirapplications.Thetablebelow
lists the function of each of the jumpers and connectors.
Connectors
Label Function
LPT1 Parallel port, 1x parallel port, supports
SPP/EPP/ECP mode
LAN1 Intel® I219-V
LAN2 Intel® I211-AT
VGA1 VGA connector
KBMS1 PS/2 keyboard and mouse connector
KBMS2 External keyboard/mouse connector
COM1 Serial port: COM1; RS-232 (9-pin Box
Header)
COM2 Serial port: COM2; RS-232 (9-pin Box
Header)
JIR Infrared connector
JFP3
(Keyboard
Lock and
Power LED)
Power LED
Suspend:Fastash(ATX/AT)
SystemOn:ON(ATX/AT)
SystemO󰀨:OFF(ATX/AT)
JFP2 External speaker / SATA HDD LED
connector
JFP1 Power switch / Reset connector
JCASE1 Case open
CPUFAN1 CPU FAN connector (4-pin)
SYSFAN1 System FAN connector (4-pin)
LANLED1 LAN1/2 LED extension connector
HDAUD1 HD audio extension module connector
USB3C1 USB1 (USB3.0)
USB3H1 USB2, USB3 (USB3.0)
USB2H1 USB4, USB5
USB2H2 USB6, USB7
USB2H3 USB8, USB9
USB2A1 USB10
SATA0 Serial ATA 0
SATA1 Serial ATA 1
SATA2 Serial ATA 2
SATA3 Serial ATA 3
CPU1 CPU socket
DIMMA1 Memory connector channel A
DIMMB1 Memory connector channel B
GPIO1 GPIO pin header (SMD pitch-2.0 mm)
LPC1 COM port module expansion pin-header
DP1
DP/DVI connector
M.2
M.2 connector
SMBUS1
SMBus connector
ATX12V1
12V connector
ATXF1
ATXpowerconnector
Jumpers
Label Function
JCMOS1 CMOS clear
JME1 Clear ME data
JWDT Watchdog timer output selection
JOBS1 HW monitor alarm
1 2 3
JCMOS1/JME1: Clear CMOS/ME Data
Closed Pins Result
1-2 Keep CMOS/ME data (Default)
2-3 Clear CMOS/ME data
H/W Monitor Alarm (JOBS1)
Function Jumper Setting
Closed Enable OBS alarm (Default)
Open Disable OBS alarm
1 2 3
JWDT1: Watchdog Timer Output Option
Closed Pins Result
1-2 Reserved
2-3 System reset (Default)
Jumpers and Connectors
Closed Open

PCA-6029 Startup Manual 3
12 3
JERP1: Deep Sleep S5
Closed Pins Result
1-2 Enabled
2-3 Disabled (Default)
Software Installation
ThedriversforthePCA-6029arelocatedontheo󰀩cial
website: http://advt.ch/PCA-6029.
Caution! The computer is supplied with a battery-powered
realtime clock circuit. There is a danger of
explosion if battery is incorrectly replaced.
Replace only with the same or equivalent type
recommended by the manufacturer. Discard
used batteries acording to the manufacturer’s
instructions.
Declaration of Conformity
Board Layout
Software Installation
This device complies with the requirements in Part 15 of
the FCC rules. Operation is subject to the following two
conditons:
1. This device may not cause harmful interference
2. This device must accept any interference received,
including interference that may cause undesired opera-
tion
PCH
Parallel Port
CPU
SATA 0~3
USB3C1
VGA1
KBMS1
USB2H3
USB2H1
USB2H2
LAN12
KBMS2
COM2
COM1
DIMMB1
DIMMA1
DP1
M.2
USB3H1
CPUFAN1
USB2A1
Figure 1: Board Layout: Jumper and Connector Locations
