Advantech ROM-3420CD-MDA1E User manual

The information contained in this document has been carefully researched and is, to the best
of our knowledge, accurate. However, we assume no liability for any product failures or
damages, immediate or consequential, resulting from the use of the information provided
herein. Our products are not intended for use in systems in which failures of product could
result in personal injury. All trademarks mentioned herein are property of their respective
owners. All specifications are subject to change without notice.
Manual
ROM-3420
Advantech
Our company network supports you worldwide with offices in Germany, Austria,
Switzerland, Great Britain and the USA. For more information please contact:
FORTEC Elektronik AG
Hauptniederlassung
Lechwiesenstr. 9
86899 Landsberg am Lech
Telefon: [phone]
Telefax: [phone]
E-Mail: [email protected]
Internet: www.fortecag.de
FORTEC Elektronik AG
Büro West
Hohenstaufenring 55
50674 Köln
Telefon: [phone]
Telefax: [phone]
E-Mail: [email protected]
Internet: www.fortecag.de
FORTEC Elektronik AG
Büro Wien
Nuschinggasse 12
A-1230 Wien
Telefon: [phone]
Telefax: [phone]
E-Mail: [email protected]
Internet: www.fortec.at
ALTRAC AG
(Tochter der FORTEC):
Bahnhofstraße 3
CH-5436 Würenlos
Telefon: [phone]
Telefax: [phone]
E-Mail: [email protected]
Internet: www.altrac.ch

User Manual
ROM-3420
RISC-based RTX Module with
Freescale i.MX6 ARM® Cortex™
A9 Processor

ROM-3420 User Manual ii
Copyright
The documentation and the software included with this product are copyrighted 2014
by Advantech Co., Ltd. All rights are reserved. Advantech Co., Ltd. reserves the right
to make improvements in the products described in this manual at any time without
notice. No part of this manual may be reproduced, copied, translated or transmitted
in any form or by any means without the prior written permission of Advantech Co.,
Ltd. Information provided in this manual is intended to be accurate and reliable. How-
ever, Advantech Co., Ltd. assumes no responsibility for its use, nor for any infringe-
ments of the rights of third parties, which may result from its use.
Acknowledgements
ARM is trademarks of ARM Corporation.
Freescale is trademarks of Freescale Corporation.
Microsoft Windows are registered trademarks of Microsoft Corp.
All other product names or trademarks are properties of their respective owners.
Product Warranty (2 years)
Advantech warrants to you, the original purchaser, that each of its products will be
free from defects in materials and workmanship for two years from the date of pur-
chase.
This warranty does not apply to any products which have been repaired or altered by
persons other than repair personnel authorized by Advantech, or which have been
subject to misuse, abuse, accident or improper installation. Advantech assumes no
liability under the terms of this warranty as a consequence of such events.
Because of Advantech’s high quality-control standards and rigorous testing, most of
our customers never need to use our repair service. If an Advantech product is defec-
tive, it will be repaired or replaced at no charge during the warranty period. For out-
of-warranty repairs, you will be billed according to the cost of replacement materials,
service time and freight. Please consult your dealer for more details.
If you think you have a defective product, follow these steps:
1. Collect all the information about the problem encountered. (For example, CPU
speed, Advantech products used, other hardware and software used, etc.) Note
anything abnormal and list any onscreen messages you get when the problem
occurs.
2. Call your dealer and describe the problem. Please have your manual, product,
and any helpful information readily available.
3. If your product is diagnosed as defective, obtain an RMA (return merchandize
authorization) number from your dealer. This allows us to process your return
more quickly.
4. Carefully pack the defective product, a fully-completed Repair and Replacement
Order Card and a photocopy proof of purchase date (such as your sales receipt)
in a shippable container. A product returned without proof of the purchase date
is not eligible for warranty service.
5. Write the RMA number visibly on the outside of the package and ship it prepaid
to your dealer.
Part No. 2006M34201 Edition 2
Printed in Taiwan June 2015

iii ROM-3420 User Manual
Declaration of Conformity
FCC Class B
Note: This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installa-
tion. This equipment generates, uses and can radiate radio frequency energy and, if
not installed and used in accordance with the instructions, may cause harmful inter-
ference to radio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause harmful interfer-
ence to radio or television reception, which can be determined by turning the equip-
ment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
Packing List
Before setting up the system, check that the items listed below are included and in
good condition. If any item does not accord with the table, please contact your dealer
immediately.
1 ROM-3420
4 Screws for ROM-3420
1 China RoHs Notice
Optional Accessories
Part No. Description
1960065189N001 Heatsink for ROM-3420
1935020402 Screw for ROM-3420+Heatsink
9696ED2000E Debug adapter board
1700022373-01 Debug port cable for ROM-3420

ROM-3420 User Manual iv
Development Board
For more information please refer to "Advantech Baseboard Check List" and "Evalu-
ation Board Reference Schematic".
You can download "Advantech Baseboard Check List" and "Evaluation Board Refer-
ence Schematic" from http://com.advantech.com/
OrderingInformation
Model Number Description
Commercial grade
Part No. Description
ROM-3420CD-MDA1E Freescale i.mx6 Dual 1GHz w/1GB DDR3 RTX module(0~60C)
ROM-3420WD-MDA1E Freescale i.mx6 Dual 1GHz w/1GB DDR3 RTX module(-40~85C)
ROM-3420CQ-MDA1E Freescale i.mx6 Quad 1GHz w/2GB DDR3 RTX module(0~60C)
ROM-3420WQ-MDA1E Freescale i.mx6 Quad 1GHz w/2GB DDR3 RTX module(-40~85C)
Part No. Description
ROM-3420CD-MDA1E Freescale i.mx6 Dual 1GHz w/1GB DDR3 RTX module(0~60C)
ROM-3420WD-MDA1E Freescale i.mx6 Dual 1GHz w/1GB DDR3 RTX module(-40~85C)
ROM-3420CQ-MDA1E Freescale i.mx6 Quad 1GHz w/2GB DDR3 RTX module(0~60C)
ROM-3420WQ-MDA1E Freescale i.mx6 Quad 1GHz w/2GB DDR3 RTX module(-40~85C)

v ROM-3420 User Manual
Safety Instructions
1. Read these safety instructions carefully.
2. Keep this User Manual for later reference.
3. Disconnect this equipment from any AC outlet before cleaning. Use a damp
cloth. Do not use liquid or spray detergents for cleaning.
4. For plug-in equipment, the power outlet socket must be located near the equip-
ment and must be easily accessible.
5. Keep this equipment away from humidity.
6. Put this equipment on a reliable surface during installation. Dropping it or letting
it fall may cause damage.
7. The openings on the enclosure are for air convection. Protect the equipment
from overheating. DO NOT COVER THE OPENINGS.
8. Make sure the voltage of the power source is correct before connecting the
equipment to the power outlet.
9. Position the power cord so that people cannot step on it. Do not place anything
over the power cord.
10. All cautions and warnings on the equipment should be noted.
11. If the equipment is not used for a long time, disconnect it from the power source
to avoid damage by transient overvoltage.
12. Never pour any liquid into an opening. This may cause fire or electrical shock.
13. Never open the equipment. For safety reasons, the equipment should be
opened only by qualified service personnel.
14. If one of the following situations arises, get the equipment checked by service
personnel:
The power cord or plug is damaged.
Liquid has penetrated into the equipment.
The equipment has been exposed to moisture.
The equipment does not work well, or you cannot get it to work according to
the user's manual.
The equipment has been dropped and damaged.
The equipment has obvious signs of breakage.
DISCLAIMER: This set of instructions is given according to IEC 704-1. Advantech
disclaims all responsibility for the accuracy of any statements contained herein.

ROM-3420 User Manual vi
Safety Precaution - Static Electricity
Follow these simple precautions to protect yourself from harm and the products from
damage.
To avoid electrical shock, always disconnect the power from your PC chassis
before you work on it. Don't touch any components on the CPU card or other
cards while the PC is on.
Disconnect power before making any configuration changes. The sudden rush
of power as you connect a jumper or install a card may damage sensitive elec-
tronic components.

vii ROM-3420 User Manual
Contents
Chapter 1 Product Overview ................................1
1.1 Introduction ............................................................................................... 2
1.2 Product Features....................................................................................... 3
1.3 Mechanical Specifications......................................................................... 4
1.4 Electrical Specifications ............................................................................ 4
1.5 Environmental Specifications .................................................................... 4
Chapter 2 H/W Installation....................................5
2.1 ROM-3420 Board Looks ........................................................................... 6
2.2 Board Connectors ..................................................................................... 6
2.2.1 Connector List............................................................................... 6
2.3 ROM-3420 Board Block Diagram.............................................................. 8
Figure 2.1 ROM-3420 Block Diagram.......................................... 8
Chapter 3 Software Functionality ........................9
3.1 Test Tools ............................................................................................... 10
3.1.1 eMMC Test ................................................................................. 10
3.1.2 SATA Test................................................................................... 10
3.1.3 USB Test..................................................................................... 10
3.1.4 SD Test ....................................................................................... 11
3.1.5 GPIO Test ................................................................................... 12
3.1.6 LVDS/HDMI/VGA Test................................................................ 13
3.1.7 I2C Test ...................................................................................... 14
3.1.8 Mini PCIe (WiFi) Test.................................................................. 15
3.1.9 CAN Test .................................................................................... 15
3.1.10 Audio Out and MIC In Test ......................................................... 16
3.1.11 OpenGL Test .............................................................................. 16
3.1.12 LAN Test ..................................................................................... 17
3.1.13 RS232 Test ................................................................................. 18
3.1.14 Watchdog Timer Test.................................................................. 19
3.1.15 Audio Test................................................................................... 19
3.1.16 Photo Demo Test ........................................................................ 19
3.1.17 Camera Input Test ...................................................................... 20
3.1.18 System Bus Test......................................................................... 20
3.1.19 Keypad Test................................................................................ 21
3.2 Package Content..................................................................................... 22
3.2.1 Source Code Package ................................................................ 22
3.3 Set up Build Environment........................................................................ 24
3.3.1 Installing required packages ....................................................... 25
3.3.2 setenv.sh..................................................................................... 25
3.4 Build Instructions..................................................................................... 26
3.4.1 Build u-boot Image...................................................................... 26
3.4.2 Build Linux Kernel Image ............................................................ 26
3.4.3 Build Log ..................................................................................... 26
3.5 Source Code Modification ....................................................................... 27
3.5.1 Add a Driver to Kernel by menuconfig ........................................ 27
Figure 3.1 Linux Kernel Configuration ....................................... 27
Figure 3.2 Selecting Seiko Instruments S-35390A .................... 28
3.5.2 Change ROM-3420 Boot Logo ................................................... 29
3.6 Debug Console ...................................................................................... 29
3.7 Boot up from the SD card, onboard eMMC or SATA DOM..................... 29

ROM-3420 User Manual viii
3.7.1 Boot up from the SD card ........................................................... 29
3.7.2 Boot up from the onboard eMMC ............................................... 30
3.7.3 Boot up from SATA DOM ........................................................... 30
3.8 Linux Software AP and Testing on ROM-3420 ....................................... 30
3.8.1 “Hello World!” Application and Execution ................................... 30
3.8.2 Watchdog Timer Sample Code................................................... 31
3.8.3 GPIO Setting............................................................................... 32
3.8.4 RS232 Initial Code...................................................................... 33
3.8.5 Display Output Setting ................................................................ 33
3.8.6 Network Setup ............................................................................ 35
3.8.7 Storage (SATA /eMMC/SD Card) ............................................... 35
3.8.8 3G Sample Code ........................................................................ 35
Chapter 4 System Recovery .............................. 37
4.1 Boot up from the SD card, onboard eMMC or SATA DOM..................... 38
4.1.1 Boot up from the SD card ........................................................... 38
4.1.2 Boot up from the onboard eMMC ............................................... 38
4.1.3 Boot up from SATA DOM ........................................................... 38
Chapter 5 Advantech Services.......................... 39
5.1 RISC Design-in Services ........................................................................ 40
5.2 Contact Information................................................................................. 43
5.3 Technical Support and Assistance.......................................................... 44

Chapter 1
1Product Overview
This chapter briefly introduces
ROM-3420 platform.
Sections include:
Introduction
Specification

ROM-3420 User Manual 2
1.1 Introduction
ROM-3420 uses the Freescale i.MX6 Dual Core Processor - ARM® Cortex™ A9
architecture as its SoC solution. Main features include: RTX 2.0 Standard, heatsink-
less, compact size, total reliability and excellent power management. ROM-3420
platform is suitable for the following applications:
HMI (Human Machine Interface)
Ruggedized applications
Fleet management / Navigation
Industrial data collection
The main features of Freescale i.MX6 processors are:
ARM Cortex™-A9 high performance processor, dual core 1 GHz
Supports OpenGL ES 2.0 and OpenVG™ 1.1 hardware accelerators, full HD
1080p video codec
Freescale Smart Speed™ technology supports low power consumption
Capabilities of I/O expansion: UART(3), Single LVDS, Audio, USB Host, USB
OTG, Gigabit Ethernet, SD, SATA, GPIO(10), I2C(4), SPI(2), System bus (Data
16-bits, Address 26-bits), CAN bus(2), PCIe signal inside and parallel RGB/
HDMI, MIPI camera support
Supports SATA storage interface and CAN bus for vehicle applications
Supports Linux 3.0.35
Supports working temperature ranges of 0 ~ 60 °C
Specialized heatsink design for ROM-3420

3 ROM-3420 User Manual
Chapter 1 Product Overview
1.2 Product Features
Compatible Module RTX 2.0
Processor System CPU Freescale i.MX6 Dual Core 1.0 GHz
Memory
Technology DDR3 1066 MHz
Capacity On-board DDR3 1 GB
Flash 4 GB eMMC for O.S. and 4 MB NOR
Flash for Advantech boot loader
Graphic
Graphics Engine 2 GPUs. OpenGL ES 2.0 for 3D, BitBlt
for 2D and OpenVG 1.1
H/W Video Codec
Decoder: MPEG-4 ASP, H.264 HP,
H.263, MPEG-2 MP, MJPEG BP
Encoder: MPEG-4 SP, H.264 BP,
H.263, MJPEG BP
HDMI 1 HDMI
LVDS 1 single 24-bit LVDS
TTL LCD 24-bit TTL LCD
Ethernet Chipset Freescale i.MX6 Dual integrated
RGMII
Speed 1 10/100/1000 Mbps, Max. 400Mbps
Watch Dog Timer 256 Level timer interval, from 0 ~ 128
sec, multi-option S/W watchdog timer
I/O
PCIe 1 PCIe
SATA 1 SATA II
USB 1 USB 2.0, 1 USB2.0 OTG
Audio HD Audio with I2S
Serial Port 3 UART (3 x 4 wires w/ 3.3 V)
SPI 1 SPI
CAN 2 CAN bus 2.0B
GPIO 10 GPIO
I2C 4 I2C
System bus Address: 26-bits, Data: 16-bits, 2 chip
select pins
O.S Linux 3.0.35
Power Supply Voltage 5 ~ 24 V
Environment
Operation 0 ~ 60° C
Operating Humidity 0% ~ 90% relative humidity, non-con-
densing
Physical
Characteristics Dimensions (WxD) 68 x 68 mm

ROM-3420 User Manual 4
1.3 Mechanical Specifications
Dimensions: RTX form factor size, 68 mm (W) x 68 mm(D)
Height on Top: Under 5.5 mm base on SPEC definition (without heatsink)
Height on Bottom: Under 2.5 mm base on SPEC definition
Heatsink Dimensions: 68 mm x 68 mm x 10.5 mm (L x W x H)
1.4 Electrical Specifications
Power supply Voltage:
–Voltage requirements: 5 ~ 24 V
Power Consumption:
1.5 Environmental Specifications
Operating temperature: 0 ~ 60° C (32~140° F)
The operating temperature refers to the environmental temperature for the
model.
Operating Humidity: 0% ~ 90% relative humidity, non-condensing
Storage temperature: -40~85° C
Storage Humidity:
–Relative humidity: 95% @ 60° C
+5 V Kernel idle Maximum mode
ROM-3420CD-MDA1E on Linux 2.85 W 6.25 W

Chapter 2
2H/W Installation
This chapter gives mechanical
and connector information on the
ROM-3420 CPU Computer on
Module.
Sections include:
Connector Information
Mechanical Drawing

ROM-3420 User Manual 6
2.1 ROM-3420 Board Looks
2.2 Board Connectors
The board has four connectors that allow you to configure your system to your appli-
cation.
2.2.1 Connector List
External IO Connector
Position Description
U1101 Flash ROM A
SW1001 Boot selection B
CN1201 JTAG connector C
CN1101 MCU programming port D
CN1202 Debug port E

7 ROM-3420 User Manual
Chapter 2 H/W Installation
SW1001 (Boot selection)
CN1101 (MCU programming port)
CN1201 (JTAG connector)
CN1202 (Debug connector)
Jumper Mode Jumper Mode
1-ON
2-OFF SPI-ROM (Default) 1-OFF 2-ON SD (Reserved for recovery)
Pin Signal Pin Signal
1+3.3V 2 MCU_TXD
3 MCU_RXD 4 MCU_PROGRAM#
5GND
Pin Signal Pin Signal
1 +3.3 V 2 JTAG_TRST#
3JTAG_TMS 4 JTAG_TDO
5JTAG_TDI 6 JTAG_TCK
7- 8 GND
9- 10GND
Pin Signal Pin Signal
1 +3.3 V 2 UART1_TX
3UART1_RX 4 GND

ROM-3420 User Manual 8
2.3 ROM-3420 Board Block Diagram
Figure 2.1 ROM-3420 Block Diagram
Freescale
i.MX6
1GHz
DDR3 256MB x 4pcs SPI NOR 4MB eMMC 4GB
RTX CONN A
SYSTEM BUS
RTX CONN B
BOOT SELECT
TTL LCD
I2C3
4 bit SD
SPI
GPIO x 10
RTX CONN C
CSI1 MIPI
PCIE0
USB2.0 OTG
RTX CONN D
SATA
UART x3
GIGA LAN
USB2.0 HOST
LVDS
HDMI
HDMI DDC
CAN BUS x2
I2C2
ATHERO
AR8033-AL1B x642 chip select/address 26 bit/data 16 bitx24SPI1(CS0/1)/SPI5(CS1/2)IIMGRIDM4 lanes1 laneConsole
UART2-wires
JTAG
I2S
MISC
POWER
MANAGMENT
WDT
RTC POWER
RTX POWER
I2C1SPI5 CS0I2C SWITCH
PCA9545APW 2C2I2WSI2C SWITCH
PCA9545APW 2C2I0WSMCU
I2C SWITCH
PCA9545APW
I2C2SW3UART1UART2/4/5SD2 4bitSD4 8bitI2C0 I2C3I2C1
I2C SWITCH
PCA9545APW 2C2I1WS

Chapter 3
3Software Functionality
This chapter details the software
programs on the ROM-3420 plat-
form.

ROM-3420 User Manual 10
3.1 Test Tools
All test tools must be verified on the ROM-3420 Evaluation kit, please prepare
required test fixtures before verifying each specified I/O. If you have any problems
getting the test fixtures, please contact your Advantech contact window for help.
3.1.1 eMMC Test
Step1: Erase and check
#ddif=/dev/zeroof=/dev/mmcblk0bs=1024count=1seek=25118
1+0recordsin
1+0recordsout
#hexdump‐C/dev/mmcblk0‐s25720832‐n16
0188780000000000000000000000000000000000|................|
Step2: Write and check
#echo‐n"0123456789ABCDEF"|ddof=/dev/mmcbllk0bs=1024count=1seek=25118
0+1recordsin
0+1recordsout
#hexdump‐C/dev/mmcblk0‐s25720832‐n16
0188780030313233343536373839414243444546|0123456789ABCDEF|
3.1.2 SATA Test
Step1: Erase and check
#ddif=/dev/zeroof=/dev/sdabs=1024count=1seek=25118
1+0recordsin
1+0recordsout
#hexdump‐C/dev/sda‐s25720832‐n16
0188780000000000000000000000000000000000|................|
Step2: Write and check
#echo‐n"0123456789ABCDEF"|ddof=/dev/sdabs=1024count=1seek=25118
0+1recordsin
0+1recordsout
#hexdump‐C/dev/sda‐s25720832‐n16
0188780030313233343536373839414243444546|0123456789ABCDEF|
3.1.3 USB Test
Step 1: Insert USB flash disk then assure it is in ROM-3420 device list
Step 2: Erase and check
#ddif=/dev/zeroof=/dev/sdbbs=1024count=1seek=25118

11 ROM-3420 User Manual
Chapter 3 Software Functionality
1+0recordsin
1+0recordsout
#hexdump‐C/dev/sdb‐s25720832‐n16
0188780000000000000000000000000000000000|................|
Step 3: Write and check
#echo‐n"0123456789ABCDEF"|ddof=/dev/sdbbs=1024count=1seek=25118
0+1recordsin
0+1recordsout
#hexdump‐C/dev/sdb‐s25720832‐n16
0188780030313233343536373839414243444546|0123456789ABCDEF|
3.1.4 SD Test
Step 1: When booting from eMMC, you would see only below directories:
#ls/dev/mmcblk*
/dev/mmcblk0/dev/mmcblk0boot0/dev/mmcblk0boot1/dev/mmcblk0p1
Step 2: Insert SD card to SD card slot and check your device again. You should be
able to see more devices. /dev/mmcblk1 is the SD card storage.
#ls/dev/mmcblk*
/dev/mmcblk0/dev/mmcblk0boot1/dev/mmcblk1/dev/mmcblk1p2
/dev/mmcblk0boot0/dev/mmcblk0p1/dev/mmcblk1p1
Step 3: Erase and check
#ddif=/dev/zeroof=/dev/mmcblk1bs=1024count=1seek=25118
1+0recordsin
1+0recordsout
#hexdump‐C/dev/mmcblk1‐s25720832‐n16
0188780000000000000000000000000000000000|................|
Step 4: Write and check
#echo‐n"0123456789ABCDEF"|ddof=/dev/mmcblk1bs=1024count=1seek=25118
0+1recordsin
0+1recordsout
Note! This operation may damage the data stored in USB flash disk. Please
make sure there is no critical data in the USB flash disk being used for
this test.
