Advantech Zlinx BB-ZP9D115RMLR-A User manual
Zlinx™ Radio Modem
Model BB-ZP9D115RMLR-A
USER MANUAL
BB-ZP9D115RMLR-A Radio Modem
ii
ABOUT THIS MANUAL
2019 Advantech. All rights reserved. Information in this manual is subject to
change without notice, and does not represent a commitment on the part of
Advantech. Advantech assumes no responsibility for errors that may appear in
this document. Advantech shall not be liable for incidental or consequential
damages resulting from the furnishing, performance or use of this manual.
No part of this publication may be reproduced or transmitted in any form or by
any means, electronic or mechanical, including photography, recording or any
information storage and retrieval system without written consent.
Other brands or product names used in this manual may be registered
trademarks and the property of their respective owners. The use of trademarks or
other designations in this publication is for reference purposes only and does not
constitute an endorsement by the trademark holder.
FCC RADIO FREQUENCY INTERFERENCE STATEMENT
This equipment has been tested and found to comply with the limits for a Class B
computing device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference when the
equipment is operated in a commercial environment This equipment generates,
uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instruction manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential area is likely to
cause harmful interference in which the user will be required to correct the
interference at his own expense.
Any changes or modifications not expressly approved by the manufacturer could
void the user’s authority to operate the equipment.
The use of non-shielded I/O cables may not guarantee compliance with FCC RFI
limits. This digital apparatus does not exceed the Class B limits for radio noise
emission from digital apparatus set out in the Radio Interference Regulation of
the Canadian Department of Communications.
Le présent appareil numérique n’émet pas de bruits radioélectriques dépassant
les limites applicables aux appareils numériques de classe B prescrites dans le
Règlement sur le brouillage radioélectrique publié par le ministère des
Communications du Canada.
BB-ZP9D115RMLR-A Radio Modem
iii
CONTENTS
About This Manual ................................................................................. ii
FCC Radio Frequency Interference Statement...................................... ii
Introduction.............................................................................................1
Contents of Package..............................................................................1
Hardware Installation .............................................................................2
DIP Switch Settings ............................................................................2
Mounting and Power...........................................................................2
Serial Connections .................................................................................3
RS-232................................................................................................3
RS-422/485.........................................................................................4
Wireless Link Failure Output ..............................................................5
Radio Frequency Information .............................................................6
Zlinx Manager Software .........................................................................7
Installation...........................................................................................7
Set Up.................................................................................................7
On-Line Configuration ........................................................................8
Test / Troubleshoot...........................................................................12
Firmware Update ..............................................................................13
Specifications .......................................................................................14
Special Precautions for UL Class 1/Division 2.....................................16
Advanced Programming.......................................................................17
AT Commands..................................................................................17
Binary Commands ............................................................................18
Command Reference Table.................................................................19
Zlinx Commands...............................................................................19
Command Descriptions ....................................................................23
API Operation ...................................................................................48
API Frame Specifications..................................................................48
Technical Support ................................................................................52
BB-ZP9D115RMLR-A Radio Modem
1
INTRODUCTION
Easy to install, up to 22.5 km (14 mi) range. No wires, no
cables. Zlinx™ radio modems get your data moving
farther, easier and at less cost than running cable. Plug-
and-play, Modbus compatible, signal strength indicator,
space saving DIN rail mounting. Heavy-duty, wide
temperature design handles most industrial power
configurations and tough indoor/outdoor environments.
Model Number
Frequency
Radio Power
RF Data Rate
BB-ZP9D115RMLR-A 900 MHz
Configurable
1 mW to 1W
Configurable
9600bps to 115kbps
CONTENTS OF PACKAGE
The package includes:
•Radio Modem
•Antenna
•Software CD
•Manual on CD
•Quick Start Guide on CD
Requires 18-30VAC or 10-48VDC Power Supply (sold separately).
Model BB-ZP9D115RMLR-A = 5.0W, maximum
BB-ZP9D115RMLR-A Radio Modem
2
HARDWARE INSTALLATION
DIP SWITCH SETTINGS
Dip Switch
OFF
ON
1 4-wire 2-wire
2 4-wire 2-wire
3 No termination Termination
4 RS-422 RS-485
MOUNTING AND POWER
•Install on properly grounded DIN rail.
oOperating Temperature: -40 to +85 °C
oOperating Humidity: 10-90%, non-condensing
•Connect Power Supply
oPower supply is 10-48 VDC or 18-30 VAC
10-48 VDC
or
18-30 VAC
BB-ZP9D115RMLR-A Radio Modem
3
SERIAL CONNECTIONS
RS-232
RS-232 is always present on DB9.
* Pins 1 & 6 are not used. They are tied together.
Wiring Terminal Identification
DB9F Pin Signal Name Direction
1
Data Carrier Detect*
---
2
Receive Data
Out
3
Transmit Data
In
4
Data Terminal Ready
In
5
Signal Ground
---
6
Data Set Ready*
---
7
Request To Send
In
8
Clear To Send
Out
9
Not used
---
Note: The DTR input is used to put the
radio into sleep mode. The radio sleep
option must be enabled first using the
configuration software. Once enabled,
lowering the DTR signal will put the
radio in sleep mode and raising the
DTR signal will put the radio in idle
mode, ready to receive or transmit data.
BB-ZP9D115RMLR-A Radio Modem
4
RS-422/485 (4-wire)
RS-422/485
BB-ZP9D115RMLR-A Radio Modem
5
WIRELESS LINK FAILURE OUTPUT
•The Zlinx Radio Modem offers a source (PNP) transistor output
when the wireless signal strength drops below a critical level (link
failure or miss packets).
•40 mA maximum current
Note: In order for the RSSI LED to continuously indicate the signal strength, set the RP
command (RSSI PWM timer) to FF.
BB-ZP9D115RMLR-A Radio Modem
6
RADIO FREQUENCY INFORMATION
•Model BB-ZP9D115RMLR-A has an indoor range of up to 914 m
(3000 ft) and an outdoor range of up to 22.5 km (14 mi).
•These ranges are for line-of-sight installations using the supplied
antenna. Performance may vary depending on your particular
installation.
•The antenna connection on the radio modem is an RPSMA
female plug.
Model #
Frequency
Radio Power
RF Data Rate
BB-ZP9D115RMLR-A
900 MHz
1mW to 1W
(selectable)
9600 bps to
115 kbps
BB-ZP9D115RMLR-A Radio Modem
7
ZLINX MANAGER SOFTWARE
INSTALLATION
•The Zlinx Manager Software is contained on included CD.
•Insert the CD into the drive.
•The installation program should auto-start.
•Follow the on-screen prompts.
SET UP
1. Connect your PC to the modem using a straight through serial cable.
2. Start the Zlinx Manager Software and click on the Radio Modem
button.
3. The radio modem launcher screen will appear.
BB-ZP9D115RMLR-A Radio Modem
8
3. Click on the Radio Modem Configuration button to configure the
modem on-line or the Radio Modem Configuration Button (Offline) to
configure the modem offline. Follow the on-screen directions.
Note: using the off-line configuration button skips the auto-modem discovery process.
ON-LINE CONFIGURATION
1. Click the Radio Modem Configuration button. The following screen
appears.
2. Use the pull down menu items to set up the communication
parameters.
BB-ZP9D115RMLR-A Radio Modem
9
3. Click the Auto Modem Search button. The Zlinx Manager
software will find the radio modem. If the modem is not found, the
following screen will appear.
4. When the modem is found, the following screen will appear.
BB-ZP9D115RMLR-A Radio Modem
10
5. Click OK. The following screen will appear.
BB-ZP9D115RMLR-A Radio Modem
11
5. On the Basic Modem Setting tab, configure a unique channel
number, network identifier, and destination address. This will prevent
interference from other modems. Click the Update button to save the
parameters. Click the Restore Defaults button to revert to the
default configuration.
6. Use the Advanced Modem Setting tab to configure additional
parameters. When each option is highlighted, the text box will display
an explanation of the command and the associated hex range. Click
the Update button to save the parameters. Click the Restore
Defaults button to revert to the default configuration.
BB-ZP9D115RMLR-A Radio Modem
12
TEST / TROUBLESHOOT
1. The RSSI Range Test allows you test your installation. Cross connect
TD and RD on the remote modem before running the test.
2. The basic screen shows test results and signal strength. Check the
Show Advanced Optionsbox to customize the test.
BB-ZP9D115RMLR-A Radio Modem
13
FIRMWARE UPDATE
1. Connect your PC to the radio modem using a straight-through serial
cable and the auto-connect function. The new firmware must be stored
on the PC’s local drive.
2. From the Zlinx Manager Radio Modem launch screen, click the
Firmware Update button.
3. Once connected, the software will determine which firmware versions
are available on the PC and what version is loaded in the modem. The
following screen allows you to choose which firmware version to load.
4. Select the firmware version to load from the pull down menu and click
the Update button.
BB-ZP9D115RMLR-A Radio Modem
14
SPECIFICATIONS
RF Properties
Physical Standard
Proprietary radio
Range
Up to 91m (3000 ft) indoor or 22.5km (14 mi) outdoor
Frequency
900 MHz
Transmit Power
1W (selectable)
Software
Zlinx Radio Modem
Windows OS Support
2000, 2003 Server, XP, Vista, 10, 7, 8, 8.1
Features
AT command
Terminal emulation
RSSI signal range test
Modem emulation
Antenna Options
External Reverse Polarity SMA male jack connector,
Omni-directional (included with product)
Radio Address
Defaulted at factory, set by software otherwise
Serial settings
Baud
1200, 2400, 4800, 9600, 19200, 38400, 57600, 115200,
230400
Data Bit
7, 8
Parity
None, even, odd, mark, space
Stop Bit
1, 2
RS-232
Connector
DB9F DCE
Lines
TX, RX, RTS, CTS, DTR, RI, GND
Connector
Removable terminal block
Lines
TX, RX, GND
RS-422
Connector
Removable terminal block
Lines
2 or 4 wire –
TX+, TX-, RX+, RX-, GND (2 or 4-wire dipswitch selectable)
Termination
120 Ohm dipswitch selectable
RS-485
Connector
Removable terminal block
Lines
2 or 4-wire with SD control
TX+, TX-, RX+, RX-, GND (2 or 4-wire dipswitch selectable)
SD Control
Bit wise
Termination
120 Ohm dipswitch selectable
Transistor ink failure
No wireless signal or RSSI LED off
Connector
Removable terminal block with RS-422/485
Output Type
Open collector, dry contact, 40mA
Power Supply
Connector
Removable terminal block
BB-ZP9D115RMLR-A Radio Modem
15
Input Voltage
10–48 VDC, 18-30 VAC
Power Consumption
5.0W, maximum
Dimensions
(3.1W x 8.4D x 11.9H cm) (1.2W x 3.3D x 4.7H in)
Environmental
Intended for indoor use only
Operating
Temperature
-40 to +85 ºC (-40 to +185 ºF)
Storage Temperature
-40 to +85 ºC (-40 to +185 ºF)
Operating Humidity
10 to 90%, non-condensing
Enclosure Rating
Rating
IP30
Mounting
DIN rail mount, 35mm
LED Status
Front Panel LED
Status
Power
Red = On
OFF = No Power
RSSI (Signal Strength)
Green = Strong
Yellow = OK
Red = Weak
OFF = No Signal
Wireless Data
Green = Blink on with data
Note: In order for the RSSI LED to continuously indicate signal
strength, set the RP command (RSSI PWM Timer) to FF.
Wiring
(Copper Wire Only)
Size / Type
28 to 16 AWG / solid copper
Temperature Rating
105 °C (221 °F) minimum
Terminal Torque
0.2 Nm (Newton-meters)
Regulatory
FCC
Part 15, CFR Title 47 – Digital Apparatus
IC
ICES-003, Class B – Digital Apparatus
UL
UL, cUL, Class 1/Division 2; Groups A, B, C, D
CE – Standards
- EMC
ETSI EN 301 489-1 V1.9.2 – Applied in accordance with
specific requirements of:
ETSI EN 301 489-17 V2.2.1 – EMC & Radio Spectrum
Matters: Broadband Data Systems
EN 55032 Class B – Electromagnetic compatibility of
multimedia equipment – emission requirements
EN 61000-6-3 + A1 – Generic emission standard for
residential, commercial and light-industrial environments
EN 61000-6-2 - Generic immunity standard for (heavy)
industrial environments
CE – Standards
- Safety
EN 60950-1 +A11 + A1 + A12 +A2 – Information technology
equipment – Safety – Part 1: general requirements
EN 62479 – RF exposure limits
RoHS Directive
- lead free
Yes
BB-ZP9D115RMLR-A Radio Modem
16
Special Instructions for Installation and Operation
in a UL and UL Class 1 Division 2 Environments
THIS APPARATUS IS SUITABLE FOR USE IN CLASS I, DIVISION 2, GROUPS A, B, C
AND D HAZARDOUS LOCATIONS, OR NONHAZARDOUS LOCATIONS ONLY.
CET APPAREIL EST CONÇU POUR ÊTRE UTILISÉ DANS DES ENDROITS
DANGEREUX DE CLASSE I, DE DIVISION 2, DE GROUPES A, B, C ET D OU DANS
DES ENDROITS NON HASARDEUX.
WARNING – EXPLOSION HAZARD – WHEN IN HAZARDOUS LOCATIONS, TURN
OFF POWER BEFORE REPLACING ANTENNA.
AVERTISSEMENT - RISQUE D’EXPLOSION - LORSQU’IL EST DANS DES ENDROITS
DANGEREUX, COUPER L’ALIMENTATION AVANT DE REMPLACER L’ANTENNE.
WARNING – EXPLOSION HAZARD – DO NOT DISCONNECT EQUIPMENT UNLESS
POWER HAS BEEN SWITCHED OFF OR THE AREA IS KNOWN TO BE
NONHAZARDOUS.
AVERTISSEMENT - RISQUE D’EXPLOSION - NE DÉBRANCHEZ PAS
L’ÉQUIPEMENT À MOINS D’ÉTEINDRE L’ALIMENTATION OU SI LA ZONE EST NON
HASARDE.
SPECIAL PRECAUTIONS FOR UL CLASS 1/DIVISION 2
Table of contents
Other Advantech Radio Modem manuals
