1 USING THIS DOCUMENT
This document provides detailed user guidelines for Wireless LAN USBAdapter
operation and setting-up. Though every effort has been made to ensure that this
document is up-todate and accurate, more information may have become available
subsequent to the production of this guide.
2 INTRODUCTION
Thank you for purchasing Wireless LAN USBAdapter.Wireless LAN USB Adapter is a
perfect combination of both performance and cost-effective product introduced. It is
sincerely hoped that you can enjoy the wireless world through this solidly profiled
wireless adapter.
It provides a full solution of all the IEEE 802.11 b/g/n protocols, that pass the WiFi
tests and are compatible with all the wireless products with WiFi logo. If you have a
Wireless LAN USB Adapter on hand, it means you can connect to the wireless world
without any difficulty.
It also provides all the data rates in the IEEE 802.11 b/g/n standards, with both short
and long preambles to ensure the compatibility of legacy wireless products and new
ones, saving the panic works for end users to find compatible products.
Since the security issue has become one of the most important one in the wireless
society, it provides you with the full security coverage from the 64/128bits WEP
encryptions, second generation WPA-PSK encryption, to the most advanced
WPA2-AES encryption. WPA2 is the latest security standard currently approved by
WiFi standards.
Saving mode, Ad hoc wireless LAN, Wake on LAN (WOL) and other exciting features
are also included in this Wireless LAN USB Adapter. This user manual will guide you
through these exciting features in the following chapters and we is believed that you
will be greatly satisfied with its performance and ease of use.
3 SYSTEM REQUIREMENTS
Windows System : Windows 98SE, Me, 2000, XP 32/64 bit, Vista 32/64 bit, WIN7
32/64 bit. PCs must have a device driver installed. It allows you to communicate with
WLAN USB Adapter.

4 Driver Installation and Uninstallation
Warning! Do not cover or block the airflow to the adapter. The adapter will reach a
high temperature during use.
4.1 Driver Installation
Before you proceed with the installation, please notice the following descriptions.
Notes1:
The following installation was operated under Windows 7.
(Procedures are similar for Windows 98SE/Me/XP/2000/vista.)
Notes2:
If you have installed the WLAN USB driver & utility before, please uninstall the old
version first.
Do not plug the wireless LAN USB adapter into your computer USB port before
installing the software program
Insert the software program CD , then auto installation window pops up on
following:
Step1: While the following screen pops out, click Driver Installation or browser the CD,
click setup.exe
Step 2: Choose a setup language. Click Next to process the installation.

Step 3: Click Next
Step 4: Click Install

The system starts software installation of the WLAN USB adapter.
Step 5: Click Finish to complete the installation.

After click Finish to complete the installation , under Windows7 <ALL Programs>
menu , REALTEK 11n USB wireless LAN Utility program installed.
Realtek Utility shortcut on the desktop.
Insert the wireless LAN USB adapter into your computer USB port , the computer
detected and active the wireless LAN USB adapter automatically.

4.2 Driver Uninstallation
Step 1:
Uninstall the WLAN USBAdapter Driver from "Start">"All Programs" >"REALTEK 11n
USB Wireless LAN Utility">Click "Uninstall" to remove Wireless LAN USB Adapter
driver.

Open Control Panel and click Programs.
Click Uninstall a program

Select REALTEK Wireless LAN Driver and Utility Click Uninstall
Step2: Click Yes.

Step 3: Click Finish to complete the uninstallation.And restart computer.

5 Wireless LAN Manaement GUI
Introduction of Main Window
A. Main Menu
1. Refresh(R)
When clicking the refresh menu, you can update and re-enumerate the contents
of adapter list area.
2. Mode(M)
Wireless configuration is quickly switched to be either [Station] or [Access Point].

3. About (A)
Click the "About" to show the about dialog. The application version and license
information are shown in the about dialog.
B. Adapter List Area
All connected adapters on this system with multiple adapter installations are
displayed in this area. It is easy for users to change the selected adapter by one click.
The contents of properties area are dependant on wireless configuration that the
selected adapter is set up. If only single adapter is installed on the system, only one
adapter is always selected.

C. Properties Area
The contents of this area are dependent on current wireless configuration. The
current configuration is determined on previous explanation of submenu "Mode". The
more detailed contents are described in the following wireless configuration sections
for both Station andAP mode.
D. Global Control Bar
Each control item on this bar affects the adapter or management GUI directly.
Show Tray Icon
Checking "Show Tray Icon" and clicking “Close” button, the management GUI will
be minimized and stay on the tray icon located at the right bottom corner of Windows.
If not, management GUI will shut down while clicking "Close" button with unchecked
condition.
Client mode utility running but no WLAN Adapter plugged.

Client mode utility running and WLAN Adapter scan available network.
Client mode utility running and WLAN Adapter can not scan any AP.
Radio Off
Turn off the radio to save power.While the radio is off, the links with other wireless
network nodes are disconnected. User should be aware that while the wireless
configuration is in AP mode. The radio off will cause the sub network belonging to the
AP to be disconnected with internet/intranet.
Disable Adapter
Stop wireless USB device.
Close
Whether to check or uncheck "Show Tray Icon" is to shutdown or hide the
management GUI.
5.1 Station Mode
The following explanations focus on the properties area.

Infrastructure and Ad-Hoc
With both Infrastructure and Ad-Hoc types, the properties should look like the
picture above. Six property pages present different information of current wireless
network status.Please read the following explanations before you reviewing these
pages, it could help you to well understand the wireless environment around the
system. It is easy to use to switch property pages just by clicking left button of mouse
on the title of each page. The following six sections describe detailed information of
each page.
5.2 General Page
This page represents the general information of this adapter.
1. Status : The status of station connection toAP.
2. Speed : Current transition speed in Mbps (Mega-Bits-Per-Second).
3. Type : Current wireless LAN configuration type.
4. Encryption : Current encryption mode used.
5. SSID : Name of wireless network.
6. Signal Strength :
The average signal quality of packets received from wireless network.
We recommend connectingAP with over 70% signal strength.
7. Throughput Diagram :
Current throughput, including transmission (Tx) and total traffic (Total).

8. Network Address
zMac Address: six two-digital number of this Wireless LAN USB adapter
zIPAddress: assigned network address by DHCP server or self-definition in four
three-digital number format.
zSubnet Mask: the only valid value is 2555.255.255.0
zGateway: It comes from connected AP. Your system can not connect internet
with this field empty.
5.3 Profile Page
This page provides profiles management such as add, remove, edit and duplicate
just by pressing the respected button.
Available Profile(s)
The list box shows all the created profiles.
1. Add : Add a new profile for AP or IBSS (Ad-Hoc mode).
2. Remove : Remove the selected profile.
3. Edit : Edit contents of selected profile.
4. Duplicate : Make copy of selected profile.
5. Set Default : Set the selected profile as default selection.

5.4 Available Network
This page presents all BSS, including AP and IBSS, around this system. You can
pick any one of these network connections.
1. Refresh : Rescan network connection around this system.
2. Add to Profile :
Create profile for selected network connection and add it to to profile list.

5.5 Status Page
zNDIS Driver Version: Driver version
zShort Radio Header: No
zEncryption: Current encryption mode.
zAuthenticate: Authentication state
zChannel Set: Selected channel plan currently.
zMAC Address: MAC address of this adapter.
zData Rate: Wireless LAN transition speed
zChannel(Frequency): Current channel number
zStatus: Wireless network status
zSSID: name of connecting AP
zNetwork Type: Indicate current network configuration type
zPower Save Mode: Current setting power save mode
zAssociated AP MAC: MAC address of connecting AP
zAssociated AP IP: IP address of connecting AP
zUp Time: Total connection time

5.6 Statistics Page
You could watch the Tx/Rx status of current wireless connection. This page
shows a statistic analysis of packet transition.
