Advent AWLMSL20 User manual

Silent Mouse
Instruction Manual / Εγχειρίδιο Οδηγιών
AWLMSL20

GB Contents
Unpacking....................................................................................... 4
Product Overview........................................................................... 5
System Requirements .................................................................... 6
Installing the Batteries................................................................... 6
Connecting the Nano Dongle ........................................................ 7
Activating the Wireless Mouse ...................................................... 7
Changing DPI Resolutions ............................................................. 8
Hints and Tips.................................................................................. 8
Specications.................................................................................. 9
GR Περιεχόμενα
Αφαίρεση συσκευασίας ............................................................... 11
Επισκόπηση προϊόντος ................................................................ 12
Απαιτήσεις συστήματος............................................................... 13
Εγκατάσταση των μπαταριών...................................................... 13
Ενεργοποίηση του ποντικιού ...................................................... 14
Ενεργοποίηση του ασύρματου ποντικιού .................................. 14
Αλλαγή ανάλυσης DPI .................................................................. 15
Υποδείξεις και Συμβουλές ........................................................... 15
Προδιαγραφές .............................................................................. 16

4
GB
Thank you for purchasing your new
product.
We recommend that you spend some time
reading this instruction manual in order that you
fully understand all the operational features it
oers. You will also nd some hints and tips to
help you resolve any issues.
Read all the safety instructions carefully before
use and keep this instruction manual for future
reference.
Unpacking
Remove all items from the packaging. Retain the
packaging. If you dispose of it please do so according
to local regulations.
The following items are included:
• Main Unit (with nano dongle)
• AAA Size Battery x 2
• Instruction Manual

5
GB
Product Overview
Top View
Right Button
Left Button
Scroll Wheel
Bottom View
ON/OFF Switch Nano Dongle
LED Indicator
Battery Compartment
Forward / Backward Buttons

6
GB
System Requirements
Operating Systems: Microsoft® Windows® 7 / 8 / 10
MAC® OS X or later
Installing the Batteries
When battery is low, the LED
indicator will ash.
1. Remove the battery cover.
2. Insert 2 x AAA batteries.
3. Close the battery cover.
Please ensure the batteries’ polarities (+/–)
match the battery compartment’s polarities.

7
GB
Connecting the Nano Dongle
Remove the Nano Dongle from the mouse and then
plug the Nano Dongle directly into your computer’s
USB port.
If the mouse does not use
for a long period, switch
the ON/OFF switch into
the OFF position to
conserve energy.
Activating the Wireless Mouse
Switch the ON/OFF button to
power on the mouse and then the
mouse will automatically connect
to the Nano Dongle plugged into
your computer.
Nano Dongle

8
GB
Changing DPI Resolutions
Press and hold the left button and the scroll wheel
until the LED indicator ashes.
800 dpi – LED indicator ashes once.
1200 dpi (default) – LED indicator ashes twice.
1600 dpi – LED indicator ashes three times.
Hints and Tips
Mouse not working:
1. Check that the power switch is in the ON position.
2. Check battery installation. Replace battery if needed.
3. Repeat the connection procedure. You can also try
moving the mouse closer to the Nano Dongle.
4. If the mouse is moving erratically, change the
working surface which the mouse is operating on.
5. Make sure the Nano Dongle is plugged into a USB
port and the computer is on or try the Nano Dongle
in a dierent USB port.
6. If mouse performance is slow or intermittent around
a wireless network, unplug the Nano Dongle from
the USB port and then reinsert it. To reactivate the
mouse, switch it on, o and on again using the
ON/OFF switch on the bottom of the mouse.

9
GB
Specications
Model AWLMSL20
Operating Range 8m (10m in open space)
Resolution 800 / 1200 / 1600 dpi
Frequency Band(s) 2406 – 2476 MHz
Max. Radio Frequency
Power Transmitted
Mouse: -10 dBm
Dongle: -12 dBm
Dimension (L x W x H) 111.2 x 62.3 x 41.2 mm
Net Weight 70 g
Features and specications are subject to change
without prior notice.

10
GB The wireless LAN hardware in your product conforms to the requirements and
provisions set out in European Directive 1999/5/EC (R&TTE). Limitations may
apply for details go to www.currys.co.uk/compliance.
Windows is a registered trademark of Microsoft Corporation in the United
States and other countries.
All trademarks are the property of their respective owners and all rights are
acknowledged.
Declaration of Conformity (RED)
Hereby, DSG Retail Ltd. declares that the radio
equipment type [AWLMSL20] is in compliance
with Directive 2014/53/EU.
The full text of the EU declaration of conformity is
available at the following internet address:
https://www.teamknowhow.com/
Click on SEARCH and enter the model number.
