Advent ADVDLX9 User manual

ADVDLX9
9" OVERHEAD LED BACKLIT
LCD MONITOR WITH
DVD PLAYER
R
INSTALLATION
GUIDE

TABLE OF CONTENTS
IMPORTANT NOTICES ...................................................................................................................................................................................................................2
GENERAL SYSTEM CONFIGURATIONS IR TRANSMIT AND RECEIVE MODES M1 OR M2 .............................................................................................3
MATERIALS INCLUDED IN THIS PACKAGE................................................................................................................................................................................4
INSTALLING THE UNIT IN A VEHICLE.........................................................................................................................................................................................5
INSTALLING THE SNAPON SHROUD AND SCREEN COVER .................................................................................................................................................6
INSTALLING THE TRIM RING........................................................................................................................................................................................................7
GENERAL VEHICLE INSTALLATION APPROACH ......................................................................................................................................................................9
VEHICLE PREPARATION............................................................................................................................................................................................................. 10
CONNECTING THE DOME LIGHTS ........................................................................................................................................................................................... 11
INSTALLING THE MOUNTING BRACKET................................................................................................................................................................................. 13
INSTALLING THE ADVDLX9 VIDEO SYSTEM.......................................................................................................................................................................... 14
INSTALLING THE SCREW CAPS AND USB COVER ................................................................................................................................................................ 16
TROUBLESHOOTING .................................................................................................................................................................................................................. 17
APPENDIX A REMOVING THE TRIM RING, SNAPON SHROUD AND SCREEN COVER ............................................................................................... 18
APPENDIX B INSTALLING THE OPTIONAL THICK TRIM RING ........................................................................................................................................ 19
NOTES............................................................................................................................................................................................................................................ 20
1

IMPORTANT NOTICES
2
Installation of overhead products requires careful planning and
preparation. Be extremely careful when working on a vehicle with
side curtain air bags. Do not route wires near any portion of the side
curtain air bag assemblies. This includes anchor points in A, B, C or D
pillars of the vehicle. Routing wires in these areas or running wires by
the side curtain air bags can prevent the side curtain air bag from fully
deploying which can result in personal injury to vehicle occupants. If
you have any question regarding routing in a vehicle, please contact
Audiovox Technical support at 1-800-225-6074.
An LCD panel and/or video monitor may be installed in a motor vehicle
and visible to the driver only if the LCD panel or video monitor is used
for vehicle information, system control, rear or side observation or
navigation. If the LCD panel or video monitor is used for television
reception, video or DVD play, the LCD panel or video monitor must be
installed so that these features will only function when the vehicle is in
“park” or when the vehicle’s parking brake is applied.
An LCD panel and/or video monitor used for television reception,
video or DVD play that operates when the vehicle is in gear or when
the parking brake is not applied must be installed to the rear of the
driver seat where it will not be visible, directly or indirectly, to the
operator of the motor vehicle.
WARNINGS
• Do not use any solvents or cleaning materials when cleaning the
video monitor.
• Do not use any abrasive cleaners, they may scratch the screen.
• Use only lightly dampened lint free cloth to wipe the screen if it is
dirty.
• Lock the LCD screen in fully closed position when not in use.
• Before putting on headphones, always adjust the volume setting to
OFF or lowest position.
• Remember to leave the dome light switch in the o or auto position
when the vehicle is unattended, as the dome lights, if left on, can
drain the vehicle battery.
• Do not put pressure on the screen.
• Caution children to avoid touching or scratching the screen, as it
may become dirty or damaged.
Safety Precautions
For safety reasons, when changing video media, it is recommended
that the vehicle is not in motion, and that you do not allow children to
unfasten seat-belts to change video media or make any adjustments
to the system. System adjustments can be accomplished using the
remote control, while seat-belts remain fastened. Enjoy your ADVENT
entertainment system but remember that the safety of all passengers
remains the number one priority.
The ADVDLX9 incorporates three new features:
1)A wireless FM Modulator
2)Snap on Covers with matching Trim Rings (Black, Shale and
Pewter). Select the color that matches the interior trim.
3)Switchable M1/M2 modes (See page 3)
Please be advised that the wireless FM modulator will perform well in
most applications. However, in certain applications the quality of the
wireless signal may be less than optimal, resulting in static or strong
local station bleed through.
Licensed under one or more of the following patents, Patent Numbers
5,775,762, 5,927,784, and 6,678,892.
When connecting power and ground in a mobile video installation,
insure that the ACC wire is fused at the point where it is connected
to the vehicle’s ACC wiring. Failure to do so can result in damage
to the vehicle if a short circuit develops between the vehicle
connection point and the mobile video product.
*** Important Notices***
When installing this overhead monitor there should be no
obstructions such as extra cabling, power chokes or any other
objects placed between this overhead and supplied mounting
bracket. Failure to comply may cause damage to the overhead
monitor and will void the warranty.

3
The following is intended to provide some of the system congurations that are possible with the ADVDLX9 Overhead LED Backlit LCD Monitor
with DVD Player:
The ADVDLX9 has an option that allows the user to select from two IR transmit and receive codes (M1 or M2). This feature can be used when using
two ADVDLX9s in the same installation or if the vehicle has an RSA (Rear Seat Audio) that uses an“A”channel headset. The ADVDLX9 comes factory
set to M1. When in the M1 mode the unit will respond to remote commands when M1 is selected on the remote and will transmit audio on the A
channel. When in the M2 mode the unit will respond to remote commands when M2 is selected on the remote and will transmit audio on the B
channel.
NOTE: M1 will appear on the screen for 4~5 seconds.
Selecting a Monitor Code (M1 or M2)
1. Power ON the unit and wait until M1 on the OSD appears. M1 will appear on the screen for 4~5 seconds.
2. To change the monitor code, press the System Menu button.
3. Use the por qcursor buttons to select the Monitor Mode menu option. Press OK to conrm the setting.
4. Use the por qcursor buttons to select the desired monitor mode (M1 or M2), then press OK to conrm the setting.
5. Press the System Menu button on the remote to exit the System Menu mode.
The two overheads can be connected together using the RCA cables.
• Plug the AV OUT of the M1 unit into the AV IN of the M2.
• Plug the AV IN of the M1 unit into the AV OUT of the M2.
GENERAL SYSTEM CONFIGURATIONS
FMM OFF
M2
DVD
IRT OFF
FMM 88.3MHz
M1
AUX/GAME
IRT ON
SYSTEM MENU
OSD LANGUAGE
DEFAULT DVD ON/OFF
SCREEN MODE
FM MODULATOR
MONITOR MODE
WARNING
SETTING THE MONITOR TO THE M2 MODE WILL
REQUIRE USING 2-CHANNEL HEADPHONES.
USE THE DOWN KEY ON THE REMOTE CONTROL
TO SELECT M2 AND PRESS OK TO SET THE
MONITOR TO M2 MODE
TO REMAIN IN THE M1 MODE PRESS OK
M1
M2

4
MATERIALS INCLUDED IN THIS PACKAGE
1. 9” TFT LCD Overhead Monitor With DVD Player - (1 pc)
2. Hardware Package (P/N 150-1661) - (1 pkg)
M3 x 8mm Phillips Screws (P/N 100-2427) - (5 pcs)
#4 x 5/16” Phillips Self Tapping Screw (P/N 100-2316) - (1 pc)
#4 x 7/16” Phillips Self Tapping Screws (P/N 100-2426) - (3 pcs)
#8 x 3/8” Self Drilling Screws (P/N 100-2397) - (4 pcs)
M5 x 10mm Phillips Screws (P/N 100-2394) - (4 pcs)
M5 x 20mm Phillips Screws (P/N 100-2581) - (4 pcs)
M5 x 40mm Phillips Screws (P/N 100-2582) - (4 pcs)
CAUTION: The 10mm, 20mm and 40mm screws in the hardware kit are
provided to facilitate installation. Use extreme caution when using these
screws to avoid damage to vehicle roof or other components, wiring, etc.
3. Remote Control w/ Battery (P/N 136-5326) - (1 pc)
4. Universal Mounting Bracket (P/N 108-3921) - (1 pc)
5. 6 Pin Power/Dome Light Harness (P/N 112-4270) - (1 pc)
6. AUX Pigtail (P/N 112B3227) - (1 pc)
7. 5 Pin AV input Harness (Blue Connector - P/N 112-4259) - (1 pc)
8. 5 Pin AV output Harness (White Connector - P/N 112-4260) - (1 pc)
9. Pry Tool (P/N 100-2424) - (1 pc)
10. USB Cover (P/N 102-4599) - (1pc)
11. Screw Cap - Shale (P/N 102-4253) - (2 pcs)
- Pewter (P/N 102-4254) - (2 pcs)
- Black (P/N 172-0197) - (2 pcs)
12. Trim Ring - Shale (P/N 102-4231) - (1 pc)
- Pewter (P/N 102-4232) - (1 pc)
- Black (P/N 172-0180) - (1 pc)
13. Snap On Cover (Screen Back) - Shale (P/N 102-4233) - (1 pc)
- Pewter (P/N 102-4234) - (1 pc)
- Black (P/N 102-4617) - (1 pc)
14. Snap On Cover (Shroud) - Shale (P/N 172-0183) - (1 pc)
- Pewter (P/N 172-0184) - (1 pc)
- Black (P/N 172-0196) - (1 pc)
15. Wireless Headphones w/ Batteries (P/N 136-5301) - (2 pcs)
16. Installation Guide & Owner’s Manual (Not Shown) - (1 of each)
123
4
6
7 &
5
9
10
8
11
13
14
12
15

3.2. 4.1. 5. 6.
INSTALLING THE UNIT IN A VEHICLE
Tools Required
Installing the Snap On Covers
The ADVDLX9 is supplied with black, shale and pewter plastics to allow a custom installation. Choose the desired cover and install as follows.
1. #2 Phillips Screwdriver
2. #1 Phillips Screwdriver
3. Utility or Razor Knife
4. Wire Strippers
5. Upholstery hook tool (for removal of panels as necessary)
6. Electrical Tape
7. Masking Tape
8. Multimeter to verify 12 volt DC and continuity (Do not use a test
light or logic probe)
9. Marker pen – to mark headliner, to mark trim ring if used
10. Misc. Electrical Connectors (to connect to vehicle power source,
requirements will vary from vehicle to vehicle)
11. DVD Movie (to verify system operation after installation)
Preparation
Place the unit on a soft surface to avoid damaging the plastic.
5
Housing Snap On Cover
(Shroud)
1 Black, 1 Pewter, and
1 Shale
Snap On Cover
(Screen Back Cabinet)
1 Black, 1 Pewter, and
1 Shale
Pry Tool Screw Cap
(L & R)
2 Black, 2 Pewter,
and 2 Shale
USB Cover

6
Installing the Shroud
1. Remove the tape backing from the front and rear areas at the
bottom of the shroud.
2. Hook the shroud over the dome light (areas “A” as shown).
3. Carefully align the two catches (1) with the openings on the DVD
player (2) and slide the Shroud down until the Shroud snaps into
the catches on either side.
4. Apply pressure to the front and rear of the shroud in the area of
the double sided tape to ensure that the tape adheres.
Installing the Screen Cover
(B) (B)
1. Open the LCD screen.
2. Hook the two tabs “B” (as shown) on the bottom edge of the
screen.
3. Carefully snap the opposite side over the hinge.
NOTE: If the wrong color Shroud and Screen Cover is installed, refer to
Appendix A of this manual for instructions to change the Shroud and
Screen Cover color.
INSTALLING THE SNAPON SHROUD AND SCREEN COVER
NOTE: Work on a soft surface to avoid damaging the plastic.
(A)
Tape Backing
(Front and Rear)
(A)
1
2
1
2

7
Installing the Trim Ring
1. Turn the DVD Player over on a surface with protective covering to prevent scratches.
2. Using a screwdriver, remove the three screws located in the “A” locations shown in the gure above. These screws can be discarded as new
screws are supplied in the hardware kit.
3. Place the trim ring onto the DVD Player.
The trim ring is attached to the video monitor using the perimeter screw bosses. It is important that the screws used in this installation are not over
tightened, and that the video monitor and trim ring are mounted in such a way that the assembly does not distort (or bend) when the mounting
screws are tightened.
There are two Trim Ring options for mounting the ADVDLX9, one is to use the supplied Trim Ring for all vehicles with at headliner mounting areas
(no contour) or a thick Trim Ring (not supplied) that can be cut to t the contour of a headliner that is not at (see Appendix B of this manual)
NOTE: The trim rings supplied with this unit are not designed to be trimmed.
INSTALLING THE TRIM RING
(A)
(A)
(A)
9

9
4. Locate the #4 x 5/16”self-tapping screw in the hardware kit.
5. Using a screwdriver, install the #4 x 5/16” self-tapping screw into the location marked “B” shown in the gure below.
6. Locate the three (3) #4 x 7/16” self-tapping screws in the hardware kit.
7. Using a screwdriver, install the three (3) #4 x 7/16”self-tapping screws into the locations marked“C” shown in the gure below.
8. Locate the ve (5) M3 x 8mm screws in the hardware kit.
9. Using a screwdriver, install the ve (5) M3 x 8mm screws into the locations marked “D” shown in the gure above.
NOTE: Use caution tightening screws as the threads may strip in the DVD Player.
8
INSTALLING THE TRIM RING
Trim Ring DVD
PLAYER
TRIM
RING
ON DVD
PLAYER
(B)
(C)
(C)
(C)
(D)
(D)
(D)
(D) (D)
TRIM RING SCREW SET
(B) #4 X 5/16” SELF TAPPING SCREW
(QTY 1)
(C) #4 X 7/16” SELF TAPPING SCREW
(QTY 3)
(D) M3 X 8mm SCREW
(QTY 5)
(B) (C) (D)
9
9

9
GENERAL VEHICLE INSTALLATION APPROACH
1. Decide upon system conguration and options that will be installed (i.e.: what components, Video Game, external amp, VCP, etc.).
2. Review all manuals to become familiar with electrical requirements and connections.
3. Decide upon mounting locations of all components and method of mounting.
4. Prep the vehicle by removing any interior trim necessary to gain access to vehicle’s wiring as well as all areas where interconnecting wire
harnesses will need to be located. If any access holes need to be cut into the vehicle (headliner, other trim components etc.), this should
be done now as well.
5. Route the wiring harnesses throughout the vehicle as necessary. (Refer to the Wiring Diagrams on page 14 of this manual, as well as the
wiring instructions for the individual components and accessory options being installed). Be sure that all wiring is protected from sharp
edges and is routed in such a manner that wiring is not pinched when all components and interior trim are fully installed. Be sure to leave
enough slack in the wiring at each component to allow working room. Avoid routing wiring near or over airbag wiring or airbags.
6. Remove all A/V system components from their packaging and place them loosely in the vehicle at their respective locations.
7. Connect all components together (electrically) and verify proper operation of all system functions. Note: This is best done BEFORE,
components have been permanently mounted.
8. After verifying proper operation of the system proceed to mount each component.
9. When all components are mounted recheck the function of the entire system again to ensure that no wiring was pinched or connected
improperly during nal installation.

10
VEHICLE PREPARATION
1. Locate an accessory +12v power source with a good ground. These wires can be found at the ignition switch or fuse-box.
Power Source
• +12v when the key is in the ACC. and run positions.
• 0v when the key is OFF.
NOTE: Always fuse the ACC +12V at the source where it is connected to the vehicle.
2. The mounting method and location will vary from vehicle to vehicle, the only focus of this manual is the installation of the ADVDLX9.
3. Generally, the best location for the video monitor is where the vehicle’s factory dome light is installed. The monitor should be located in
such a manner that it can be comfortably viewed by rear seat passengers.
NOTE: Never install the monitor in a place within the driver’s view. This is not only dangerous, but it is also illegal in many states.
4. Once the mounting location of the monitor has been determined, additional preparation work may be necessary, depending on the vehicle
structure and installation method. Some of the steps that may be required are:
a. Removal of the vehicle’s dome light.
b. Cutting an opening in the headliner to install the mounting bracket.
c. If the optional Thick Trim Ring will be used, it may have to be trimmed to t the contour of the vehicle’s headliner. Refer to Appendix B
Installing the Optional Thick Trim Ring.

11
CONNECTING THE DOME LIGHTS
The dome lights in the video monitor require three connections to the vehicle’s wiring. There are two common types of dome light circuits used,
positive switched systems or negative switched systems. Positive switched systems supply voltage to the interior lights to turn ON; negative
switched systems apply ground to illuminate the bulbs.
To determine which system you have to locate the wires at the dome light:
• On a positive switched system, with all the doors closed and the lights out, both wires at the dome light will rest at ground. When the light is
activated, one of these wires will switch to +12 VDC. This is the vehicle’s switching wire.
• On a negative switched system, with all the doors closed and the lights out, both wires at the dome light will rest at +12 VDC. When the light
is activated, one of these wires will switch to ground. This is the vehicle’s switching wire.
For positive switched systems, connect the Purple / Brown (Lamp Auto) wire to the vehicle’s switched wire. Then connect the Red / Black (Lamp
ON) wire to a fused constant 12 volt source and the Black / Red (Lamp Common) wire to a good ground. Positive switched systems are commonly
found on Ford vehicles.
For negative switched systems, connect the Purple / Brown (Lamp Auto) wire to the vehicle’s switched wire. Then connect the Red / Black (Lamp
On) wire to a good ground and the Black / Red (Lamp Common) wire to a fused constant 12 volt source. Negative switched systems are commonly
found on General Motors and import vehicles.
NOTE: Some vehicles which incorporate transistorized control of the dome light circuit, such as the 1999 Dodge Caravan, may require that the
Purple / brown (Lamp Auto) wire be connected to the door pin switch wire, as the additional current draw of the monitor’s lights may not be
supported by the output of the vehicle’s body control computer.
After wiring the dome lights make sure the dome lights operate properly with doors opening and closing and that they are not always
on. Do not leave the dome lamp switch on the DVD overhead in ON position as this will drain the battery over time.

12
To 3 pin
connector
on Monitor
To
constant
+12 VDC
To
constant
+12 VDC
Factory Door Ajar
Switch or Body
Control Computer
Red-Lamp ON
Black-Lamp Common
Purple-Lamp Auto
Positive Switched Dome Lighting
Fused
Factory Dome Light Circuit
To 3 pin
connector
To
constant
Factory Door Ajar
Switch or Body
Control Computer
Red-Lamp on
Black-Lamp common
Purple-Lamp Auto
To
constant
+12 VDC
+12 VDC
Negative Switched Dome Lighting
Fused
CONNECTING THE DOME LIGHTS

13
INSTALLING THE MOUNTING BRACKET
*
Self-drilling Screws
Mounting Bracket
Headliner
Roof Cross-Member
Roof
(4 x Self Drilling
Screws - #8 x 3/8”)
Mounting Bracket
*CAUTION: Use extreme caution when using the
Self-drilling Screws to avoid damage to vehicle
roof or other components, wiring, etc.
Front
of
Vehicle
Direction Arrow
Bracket
Mounting
Holes
Installing the Mounting Bracket
1. Once all the pre-wiring is complete, locate:
• Mounting Bracket
• (4) #8 x 3/8” Self-drilling Screws
2. Carefully align the Mounting Bracket in the location it is to be
installed with direction arrow facing the front of the vehicle (make
sure there is nothing between the Mounting Bracket and Roof
Cross-Member)
NOTE: The headliner may need to be cut to install the bracket. When
cutting the headliner make sure no wires above the headliner are cut.
3. While holding the Mounting Bracket in place, install the
4- #8 x 3/8” Self-drilling Screws.
CAUTION: Be sure that the Self-drilling Screws do not pierce the
outer roof skin when fully fastened to the Roof Cross-Member

14
INSTALLING THE ADVDLX9 VIDEO SYSTEM
1. Connect the 6 pin harness to the unit and make the connections to
the vehicle.
2. Connect the red and black power wires of the Power Harness to
vehicle’s electrical system by tapping into an accessory hot line and
a good ground.
3. If connecting to an external source, connect the 5 Pin AV Input
Harness (112-4259 Blue Connector) to provide the AV signals input.
4. If connecting to an external source, connect the if used 5 Pin AV
Output Harness (112-4260 White Connector) to provide the AV
signals output.
5. Verify all system functions before nal mounting of the nished
assembly.
A/V Source Denitions:
• DVD - Built in DVD/USB
• AV - Signal Harness (P/N 112-4259 Blue Connector) to the 3 RCA
Jack Pigtail is used for AV input.
• AUX - AUX input (P/N 112B3227) 3.5mm jack to RCA Cable
NOTE: The antenna has been designed for optimal performance.
When installing the unit, position the antenna for best reception.
WIRING DIAGRAM
5 Pin AV input Harness
(P/N 112-4259 Blue Connector)
5 Pin AV output Harness
(P/N 112-4260 White Connector)
6 Pin Power/Dome Light
Harness (P/N 112-4270)
Antenna for
Wireless FM Mod.
See Antenna Note
Optional Relay Box

15
INSTALLING ADVDLX9 VIDEO SYSTEM
Mounting
Bracket
Headliner
Roof
4 x M5
Screws
Video Unit
Front
of
Vehicle
Mounting Bracket
Mounting Holes
Installing the ADVDLX9 System
1. Make all electrical connections.
2. Attach the ADVDLX9 unit to the mounting bracket using four M5 screws.
CAUTION: The M5 screws are supplied in three dierent lengths (10mm, 20mm and 40mm) to facilitate proper installation. Use extreme caution
when using these screws to avoid damage to vehicle roof or other components, wiring, etc.
CAUTION: Do not trap any wiring between the bracket and the unit.
ADVDLX9
NOTE: Do Not over
torque/tighten M5
screws.

16
Snap-in
Installing the Screw Caps
1. After the unit is mounted to the headliner, install the two snap in Screw Caps. The snap in Screw Caps are marked“L”and “R” on the
inside.
a. Facing the front of the vehicle, press the snap in Screw Cap marked“L” into the left screw hole.
b. Facing the front of the vehicle, press the snap in Screw Cap marked “R” into the right screw hole.
1. Install the USB Cover by feeding the Cover tether into the opening located below the USB connector.
Two
Screw
Caps
INSTALLING THE SCREW CAPS AND USB COVER
Snap-in
USB
Cover
Installing the USB Cover

TROUBLESHOOTING
SYMPTOM: REMEDY:
No power at Video Monitor Verify +12 VDC on the Red wire at 6 Pin Power Harness behind the
video monitor. Verify a ground connection with a continuity test
from a known good ground to the black wire at the 6 Pin Power
Harness.
Power but no video or sound Verify that the correct source is selected (DVD/USB, AV, AUX). Verify
that the source is on and playing a known good media (such as a
video tape).
17

Removing the Shroud
1. Insert the supplied pry tool between the Housing and Shroud
and disengage the tape in the front and back.
2. Press the pry tool to release the Shroud.
3. Continue disengaging the attaching areas around the unit
removing the Shroud and discard.
Removing the Screen Back Cover
1. Starting from the back of the unit, carefully insert the supplied
pry tool between the Housing and Screen Back Cover
2. Press the pry tool to release the Screen Back Cover.
3. While lifting Screen Back Cover slide the pry tool around to the
attaching areas and press to release the Screen Back Cover
4. Remove the Screen Back Cover and discard.
Removing the Snap-in Screw Caps and Snap-in USB Cover
1. Using the supplied pry tool remove the two snap-in Screw Caps
and discard.
2. Using the supplied pry tool remove the snap-in USB Cover.
NOTE: Do not Discard USB Cover, it will be reused.
APPENDIX A REMOVING THE TRIM RING, SNAPON SHROUD AND SCREEN COVER
This section is intended for situations where the color of the Shroud,
Screen Cover and Trim Ring need to be changed after the unit is setup for
installation. NOTE: Work on a soft surface to avoid damaging the plastic.
Removing the Trim Ring
1. Remove the Trim Ring screws ((1)-#4 x 5/16” self-tapping screw,
(3)-#4 x 7/16” self-tapping screws and (5) M3 x 8mm screws).
Refer to page 8 for screw locations.
NOTE: Do not Discard Screws! These screws are used to attach the
new Trim Ring.
2. Remove the Trim Ring and discard.
Snap-in
Snap-in
Two
Screw
Caps
USB
Cover
18
