ADX FIRECAST C01 User manual

FIRECAST
C01
MICROPHONE & MOUNT
INSTRUCTION MANUAL
ADXFC0220

Contents
Safety Warnings................................................................................. 3
Unpacking.......................................................................................... 4
Product Overview.............................................................................. 5
Installation ......................................................................................... 6
Connections ....................................................................................... 7
Hints and Tips..................................................................................... 7
System Requirements ....................................................................... 8
Specications..................................................................................... 8

3
Safety Warnings
Damage
• Please inspect the unit for damage after unpacking.
• Do not continue to operate the unit if you are in any doubt about it
working normally, or if it is damaged in any way.
Temperature
• Avoid extreme degrees of temperature, either hot or cold. Place the
unit well away from heat sources such as radiators or gas / electric
res.
• Avoid exposure to direct sunlight and other sources of heat.
Naked Flames
• Never place any type of candle or naked ame on the top of or near
the unit.
Interference
• Do not place the unit on or near appliances which may cause
electromagnetic interference. If you do, it may adversely aect the
working performance of the unit, and cause a distorted sound.

4
Unpacking
Remove all items from the packaging. Retain the packaging. If you
dispose of it please do so according to local regulations.
The following items are included:
• Microphone
• Shockproof stand
• Adjustable suspension boom scissor arm stand
• Foam cover
• Mount clamp
• USB Cable
Thank you for purchasing your new product.
We recommend that you spend some time reading this
instruction manual in order that you fully understand all
the operational features it oers. You will also nd some
hints and tips to help you resolve any issues.
Read all the safety instructions carefully before use and
keep this instruction manual for future reference.

5
1
2
3
4
5
Product Overview
1. Foam Cover
2. Microphone
3. Shockproof Stand
4. Adjustable suspension boom scissor arm stand
5. Mount clamp

6
Installation
1. Fix the table clamp mount on the edge of
the table.
2. Insert the adjustable arm into the table
clamp mount and then tighten it.
3. Secure the shock mount into
the other end of the adjustable
arm.
4. Press the clip of the shock mount
and then place the microphone
onto it.
1
2
1
2
1
1
2

7
Connections
Connect the microphone
to your computer with the
provided USB cable.
Hints and Tips
• Make sure the USB plug is fully plugged into a USB port and
the computer is on or try to use a dierent USB port.
• If the unit is not working properly, re-insert the USB plug into
the USB port.
• While using the microphone, make sure that:
1) you are facing to the front of the unit;
2) The microphone is in a stand-straight position.
Before using the microphone, make sure that you have
selected "USB PnP Audio Device" for sound input.

8
System Requirements
Operating Systems: Microsoft® Windows® 8 / 10
Hardware: PC with available USB 2.0 port
Specications
Model ADXFC0220
Frequency Reposnse 50 Hz - 20 KHz
Sensitivty –45±3dB
Load Impedance ≥680 Ω
Mic Sample Rate 8K / 11.025K / 16K / 22.05K /
32K / 44.1K / 48 KHZ at 16bit
Polar Pattern Cardioid
Operating System Microsoft® Windows® 8 / 10 ?
Dimension (Microphone) 180.4 (L) × 44.7 (W) × 45.6 (H)
(± 2 mm) mm
Weight (Microphone) 228 g
Features and specications are subject to change without prior
notice.
