AEBOS Technology ALS-368L Quick guide

A
AL LS S- -3 36 68 8L L
Operating and safety instructions
3.6V Li-ion cordless screwdriver

Attention!
Always follow the safety rules and instructions in
this manual. The manufacturer will not accept any responsibility
for damage or injury caused by improper use or not in keeping
with
the requirements of the operating instructions of this tool.
Diagram
No.
Descriptions
01
Bit insertion
02
Direction swtich
03
Led light
04
Trigger
05
Charging receptacle
06
Plug protector
07
Charging adapter
08
10pcs bit set
09
Bit holder
10
Drill bit

Foreword
This brand new 3.6V Li-ion cordless screwdriver is designed for
driving tighten and loosen screws. Its built-in new battery tech-
nology and more efficient motor make cordless screwdriver to in-
crease working time, greater power, lighter weight, long cycle life,

no
memory effect or self discharge when not in use, less pollution.
This handy tool withegregious soft grip handle and LED light for
poorly lit areas ensure to enjoy works as well as enjoy your life.
Technical data
Model
ALS-368L
Dimension
158mm x 120mm x 43mm
Rated voltage
DC 3.6V
No-load speed.
max. 180 rpm
Max. torque
6.0 Nm
Screw diameter
max. 5 mm
Weight
320g
Battery
Capacity
1.3 Ah
Charging time approx.
3 Hr.
Battery charger
Input
AC 230V, 50Hz
Output
DC 4.5V, 400mAH

General Safety Rules
WARNING!
Read all instructions. Failure to follow all
instructions listed below may result in electric shock, fire and/or
serious injury. The term “power tool”in all of the warnings listed
below refers to your mains operated (corded) power tool or
battery operated (cordless) power tool.
FOLLOW THESE INSTRUCTIONS
1) Work area
a)
Keep work area clean and well lit. Cluttered and dark
areas invited accidents.
b)
Do not operate power tools in explosive
atmospheres,
such as in the presence of flammable liquids, gases
or dust. Power tools create sparks which may ignite the
dust or fumes.
c)
Keep children and bystanders away while operating
a power tool. Distractions can cause you to lose control.
2) Electrical safety
a)
Charging adapter plug must match the outlet. Never
modify
the plug in any way. Do not use any adapter plugs
with earthed (grounded) power tools. Unmodified
plugs
and matching outlets will reduce risk of electric shock.

b)
Avoid body contact with earthed or grounded
surfaces
such as pipes, radiators, ranges and refrigerators.
There is an increased risk of electric shock if your body is
earthed or grounded.
c)
Do not expose power tools to rain or wet conditions.
Water entering a power tool will increase the risk of
electric shock.
d)
Do not abuse the cord. Never use the cord for
carrying,
pulling or unplugging the power tool. Keep cord
away
from heat, oil, sharp edges or moving parts.
Damaged or entangled cords increase the
risk of electric shock.
3) Personal safety
a)
Stay alert, watch what you are doing and use
common
sense when operating a power tool. Do not use a
power tool while you are tired or under the influence
of
drugs, alcohol or medication. A moment of inattention
while operating power tools may result in serious
personal
injury.
b)
Use safety equipment. Always wear eye protection.

Safety equipment such as dust mask, non-skid safety
shoes, hard hat, or hearing protection used for
appropriate
conditions will reduce personal injuries.
c)
Avoid accidental starting. Ensure the switch is in the
off position before plugging in the charger.Carrying
power tools
with your finger on the switch or plugging in power tools
that have the switch on invites accidents.
d)
Do not overreach. Keep proper footing and balance
at
all times. This enables better control of the power tool
in unexpected situations.
e)
Dress properly. Do not wear loose clothing or
jewellery. Keep your hair, clothing and gloves away
from moving parts. Loose clothes, jewellery or long hair
can be caught in moving parts.
4) Power tool use and care
a)
Do not force the power tool. Use the correct power
tool
for your application. The correct power tool will do the
job
better and safer at the rate for which it was designed.
b)
Do not use the power tool if the switch does not turn

it
on and off. Any power tool that cannot be controlled with
the switch is dangerous and must be repaired.
c)
Disconnect the charger plug from the power source
before
making any adjustments, changing accessories, or
storing power tools. Such preventive safety measures
reduce the risk of starting the power tool accidentally.
d)
Store idle power tools out of the reach of children
and
do not allow persons unfamiliar with the power tool
or
these instructions to operate the power tool. Power
tools are dangerous in the hands of untrained users.
e)
If damaged, have the power tool repaired before
use. Many accidents are caused by poorly maintained
power tools.
g)
Use the power tool, accessories and tool bits etc., in
accordance with these instructions and in the
manner
intended for the particular type of power tool, taking
into account the working conditions and the work to
be performed. Use of the power tool for operations
different from those intended could result in a hazardous
situation.

h)
Release trigger switch immediately when a screw is
Fastened withy no rotating.Stop pushing trigger when
Loosening a screw with no turing within 5 seconds.
Improper stress on a cordless screwdriver will cause
dmage to motor.
5) Battery tool use and care
a)
This is a built-in type battery screwdriver,if
something damaged,do not attempt to open the
housing of this screwdriver,take it to a skilled service
center.
b)
Recharge only with the charger specified by the
manu-
facturer. A charger suitable for one type of
screwdriver may create a risk of fire when used with ano-
ther screwdriver.
c)
Use power tools only with specifically designated
battery packs. Use of any other battery packs may
create
a risk of injury and fire.
e)
Under abusive conditions, liquid may be ejected
from
the battery; avoid contact. If contact accidentally
occurs, flush with water. If liquid contacts eyes, addi-
tionally seek medical help. Liquid ejected from the
battery may cause irritation or burns.
6) Service
a)
Have your power tool repaired only by qualified per-
sonnel using original spare parts. This will ensure that

the safety of the power tool is maintained.
Additional safety instructions
WARNING!
Read all instructions. Failure to follow all
instructions listed below may result in electric shock, fire and/or
serious injury.
■
This Li-ion cordless screwdriver is designed built-in battery.
Do not attempt to open or disassemble the battery or remove
any component projecting from the battery terminal. There is
danger of a short circuit, fire or injury may result. Prior to re-
cycling, protect exposed terminals with heavy insulating tape
to prevent shorting.
■
Store idle tool in a cool, dry place where they are protected
from frost. Do not store this tool where temperatures may
exceed 120°F (49°C) such as in a vehicle, domestic heaters,
direct sunlight or metal building during the summer.
Temperatures of >50°C < -5°C and high moisture levels
will damage the battery pack. There is risk of explosion.
■
Hold the tool with a firm grip. High reaction torque can briefly
occur while driving in and loosening screws. Also use clamps
or other practical way to secure and support the workpiece
to a stable platform. Holding the work piece by hand or
against
your body is unstable and may lead to loss of control.
■
Do not exceed the maximum driving torque. You are recom-
mended to leave it to cool down, if the tool overheats or
driving times stipulated.

Safety rules for battery charger
■
Do not expose battery charger to rain, moisture or snow.
The penetration of water in a battery charger increases the
risk of electric shock.
■
Keep the battery charger terminal clean. Contamination
may cause the danger of electric shock
■
Do not operate battery charger with damaged cord or
plug. Do not open the battery charger yourself and have
it
repaired only by qualified personnel using original spare
parts. Damaged battery chargers, cables and plugs increase
the risk of electric shock.
■
Do not operate the battery charger on easily inflammable
surfaces (e.g. paper, textiles, etc.) or combustible
environ-
ments. There is danger of fire due to the heating of the
battery
charger during charging.
Battery charging instructions
■
The battery charger supplied is matched to the Li-ion battery
built-in the tool. Any other battery charger is forbidden.
■
The battery for this tool is shipped partially charged and must
be completely charged prior to first time using and follow the
charging instructions. The Li-ion battery can be charged at
any time without reducing its service life. Interrupting the
charging procedure does not damage the battery.

■
The Li-ion battery is protected against deep discharging.
When
the battery is hungry, the LED on the switch flash twice by
means of protective circuit. The tool holder no longer rotates
Note! If the On/Off
switch is subject to continued use, the Li-ion battery can be
damaged.
■
The charging procedure starts as soon as the mains plug the
charger into the AC socket and plug the battery charger ter-
minal into the connector. The LED on switch lights up to
indicate the charging procedure. The LED blinks by means of
the battery is fully charged.
■
It is normal for the handle of the machine to warm up during
the charging procedure.
■
If the battery is warm (after being used or if exposed to the
sun etc.) let it cool down prior to charge.
■
Do not charge the battery when the temperature is below
0°C or above 35°C.
■
Never connect the battery charger to a three-phase supply,
motor-powered generator or DC power source.
■
Disconnect the battery charger from the socket when not
using it for extended periods.
Operation instructions
■
Installing bits: The required screwdriver bit is pushed into

holder. Note! Use attached bit holder to hold 25 mm
bits,do not use double-end crewdriver bits which
are long than 25mm.
■
Caution! Apply the power tool to the screw/nut only when it is
switched off.
■
On/Off switch: To switch on the screwdriver by pressing
On/Off switch and keep it depressed. The head LED lights up
when
“switch on”enable to illuminate poorly area. Release the
switch ,the screwdriver will stop and head LED extinguish
within 30 seconds.
Also the trigger lights up when switch on,and it
extinguish at the itme of releasing switch.
■
Direction of rotation: Push the rotation direction switch
onward for clockwise rotation, and backward for left
anti-clockwise rotation.
■
Spindle locking: When the On/Off switch is released or set
up
rotation direction switch to “0”, the is locked. This enables
screws to be screwed in, even when the battery is empty and
allows for the using as a manually screwdriver.
■
Attention! Use only screwdriver bits that fit properly in the
head of the screw. And, when driving in larger and/or longer
screws in hard workpieces, it is advisable to drill a pilot hole
first.

Maintenance
■
This Li-ion cordless screwdriver is maintenance-free.
■
Store idle tool in a cool, dry place where they are protected
from frost. Do not store this tool where temperatures may
exceed 120°F (49°C) such as in a vehicle, domestic heaters,
direct sunlight or metal building during the summer.
Temperatures of >50°C < -5°C and high moisture levels
will damage the battery pack. There is risk of explosion.
Environmental protection
Recycle raw materials instead of disposing as
waste
The machine, accessories and packaging should be
sorted for environmental-friendly recycling.
Waste of the power tool or battery should not be disposed into
household waste, fire or water. Please recycle where facilities
exist.
Check with your local authority or retailer for recycling advice.
Defective or worn out batteries must be recycled according to
the guidelines 91/157/EEC.
To remove the battery from the machine, actuate the On/Off
switch
until the battery is fully discharged. Disconnect the connections at
the battery and remove the battery. Prior to recycling, protect
exposed terminals with heavy insulating tape to prevent shorting.
EC-Declaration of Conformity

We :
AEBOS Technology Co. Ltd.
60851 No. 67, Chung Cheng Rd, Shuishang Hsiang
Chia Yi County, Taiwan, R.O.C.
here with declare that the following machine complies with the
appropriate basic safety and health requirements of the EC
Directive based on its design and type, as brought into circu-
lation by us.
In case of alteration of the machine, not agreed upon by us, this
declaration will lose its validity.
Machine Description:
3.6V Li-ion cordless screwdriver
Machine type:
ALS-368L
Applicable EC Directives:
98/37/EC
73/23/EEC
89/336/EEC
Applicable harmonized
EN 60745 (Battery powered product)
standards:
EN 55014-1; EN 55014-2
EN 60335 (Battery charger)
Date/Authorized
signature:
30/08/09
General Manager
