AEC ITALO2 Manual

ITALO 2_IM_ENG - Rev.03 of 27/10/14 Page 1 of 4
MOUNTING AND MAINTENANCE
INSTRUCTION
0°
10°
ATTACHMENT
Pic. 2
M8 screws + split washer and plain washer
Set screw wrench: 6mm
Twisting moment: 10Nm
20°
5°
15°
M8 / 5/16" Set screws
Set screw wrench: 4mm
Twisting moment: 8Nm
--------------------------------
M8 / 5/16" nuts
Adjustable wrench:13mm
Twisting moment: 8Nm
Pic. 4
Pic. 5A – Post-top mounting
Pic. 5B – Arm mounting
Pic. 3A – Post-top mounting Pic. 3B – Bracket mounting
Sign reference
0°
-10°
-20°
-5°
Sign reference
-15°
Pic. 1
MOUNTING AND MAINTENANCE INSTRUCTION
Post-top or bracket mounting
ITALO 2 is equipped with an universal attachment (post-top or bracket mounting)
according to the ordered version:
- Attachment Ø33-60mm. Ø1-3/8" - 2-3/8"
- Attachment Ø60-76mm. Ø2-3/8" - 3"
Place correctly the attachment as indicated in Pic. 5A (Post-top) or in Pic. 5B
(Bracket).
Fix the attachment to the luminaire with the two M8 screws as indicated in Pic. 2.
Possible to tilt:
- Post-top mounting: 0°, +5°, +10°, +15°, +20°
- Bracket mounting: 0°, -5°, -10°, -15°, -20°
Use the proper sign as indicated in Pic. 3A and 3B.
The regulation of the luminaire can be done loosing the two screws (Pic. 2).
Fix the attachment to the post-top or to the bracket as indicated in Pic. 4.
To avoid any possible unscrewing of set screws, two M8 (5/16") nuts have
to be tightened on the set screws as indicate in Pic. 4.

ITALO 2_IM_ENG - Rev.03 of 27/10/14 Page 2 of 4
MOUNTING AND MAINTENANCE
INSTRUCTION
Pic. 6
A
Electrical line connection
To gain access to the electrical line, unlock the closing hook (A – Pic. 6) and lift the upper frame untill the hinge locks (Pic. 7)
- Luminaire with cable gland: follow the directions in Pic. 8. You must secure the external cable by tightening
plastic holder on the "on-load switch".
- Luminaire with membrane: follow the directions in Pic. 9. You must secure the external cable by tightening
plastic holder onthe "on-load switch".
In case the luminaire is equipped with PLM device, before closing the luminaire, annotate the serial number of the device.
Pic. 8 Pic. 9
Tighten the screws up to the complete
closure of the cable holder
M20 plastic cable gland
Adjustable wrench: 24mm
Twisting moment: 4.5Nm
--------------------------------
M25 plastic cable gland
Adjustable wrench: 30mm
Twisting moment: 6Nm
CABLE GLAND MEMBRANE
Pic. 7
Hinge
Cable gland Membrane
A 6 ÷7 mm / 1/4" 6 ÷7 mm / 1/4"
B < 25mm / 1" < 25mm / 1"
C M20: 8 ÷ 12mm / .31"÷.47"
M25: 10 ÷ 17mm / .39"÷.67" 8÷ 12mm / .31"÷.47"
D ≤2.5mmq / 12AWG ≤2.5mmq / 12AWG
CLASS I
CLASS II
C
A
B
A
B
C D
D

ITALO 2_IM_ENG - Rev.03 of 27/10/14 Page 3 of 4
MOUNTING AND MAINTENANCE
INSTRUCTION
Luminaire closure
To close the luminaire, follow the directive from Pic. 10 to Pic. 12.
Fig. 10 Fig. 11 Fig. 12
Lift the upper frame Unlock the hinge and move down the
upper frame
Initial position
LED module extraction
1) Disconnect the LED
connector (C);
2) Loosen the screws (E);
3) Extract the LED
modules.
LED module repositioning
1) Replace in the original
position the LED
modules;
2) Tighten the screws (E);
3) Connect the LED
connector (C).
Gear tray extraction
1) Disconnect the mains
connector (B);
2) Disconnect the LED
connector (C);
3) Loosen the screws (D);
4) Extract the gear tray.
Gear tray repositioning
1) Replace in the original
position the gear tray;
2) Tighten the 2 screws (D);
3) Connect the LED connector
(C);
4) Connect the mains
connector (B).
B
D
C
E
D
SPD MAINTENANCE
The protection device is equipped with system that excludes power supply at the end of life of the luminaire.
If the luminaires switches-off when the system is still fed, the activity of the protection device should be checked looking at signaling
LED.
To check this, use the appropriate tool. For more details contact the manufacturer.
LED ON _ Right functioning of the SPD LED OFF _ End of life SPD, replace the SPD

ITALO 2_IM_ENG - Rev.03 of 27/10/14 Page 4 of 4
MOUNTING AND MAINTENANCE
INSTRUCTION
Side area: 0.86 sq.f / 0.08m2
Base area: 3.22 sq. f / 0.30m2
Form factor: 1.2
Max height of installation: 50' - 15m
Ta 95°C
Use Indoor / Outdoor
ITALO 2 1M – 2M 10.9kg ÷ 11.2kg / 24.69 lbs
ITALO 2 3M – 5M 11.3kg ÷ 11.6kg / 25.57 lbs
ITALO 2 6M – 8M 11.8kg ÷ 12kg / 26.45 lbs
ITALO 2luminaire is
classified under
“EXEMPT GROUP”
according to
photobiologycal
safety standard
IEC/EN 62471.
NO RISK
for the operators and
end users.
NOTE
a) The luminaire can be installed close to flammable surfaces.
b) Class II luminaires must be installed in such a way that it is impossible for any exposed metal part to come in contact with electrical
components.
c) The device has dedesigned in compliance with the current standards; it is necessary that the installation is done properly, according with
the instructions supplied.
d) The present instruction paper has to be kept for any future maintenance operation on the luminaire. Non compliance with the above will
automatically release AEC Illumination from any responsibility.
Protection ground
(only in class I)
L
N
LED
modules
CN2
PSU
WIRING SCHEME
S1
PD
F1
(
o
p
tion
)
L
N
PLM WIRING SCHEME
F Fuse 110Vac 10A (provide the fuse externally if not provided inside the luminaire) PD Protection device
CN Connector PSU Power Supply
S On-load switch CD Control device
Protection ground
(only in class I)
CN1
LED
modules
CN2
PSU
S1
PD
F1
(
o
p
tion
)
CN1
CD
The crossed-out wastebasket symbol on the appliance means that at the end of its useful lifespan, the product must be disposed of separately
from ordinary household wastes. The user is responsible for delivering the appliance to an appropriate collection facility at the end of its useful
lifespan. Appropriate separate collection to permit recycling, treatment and environmentally compatible disposal helps prevent negative impact
on the environment and human health and promotes recycling of the materials making up the product. For more information on available
collection facilities, contact your local waste collection service.
