USER
MANUAL
EN User Manual
Hob
IKE85651IB

FOR PERFECT RESULTS
Thank you for choosing this AEG product. We have created it to give you impeccable
performance for many years, with innovative technologies that help make life simpler –
features you might not find on ordinary appliances. Please spend a few minutes reading
to get the very best from it.
Visit our website to:
Get usage advice, brochures, trouble shooter, service and repair information:
www.aeg.com/support
Register your product for better service:
www.registeraeg.com
Buy Accessories, Consumables and Original spare parts for your appliance:
www.aeg.com/shop
CUSTOMER CARE AND SERVICE
Always use original spare parts.
When contacting our Authorised Service Centre, ensure that you have the following data
available: Model, PNC, Serial Number.
The information can be found on the rating plate.
Warning / Caution-Safety information
General information and tips
Environmental information
Subject to change without notice.
CONTENTS
1. SAFETY INFORMATION................................................................................................ 2
2. SAFETY INSTRUCTIONS.............................................................................................. 4
3. INSTALLATION...............................................................................................................7
4. PRODUCT DESCRIPTION.............................................................................................8
5. DAILY USE......................................................................................................................9
6. HINTS AND TIPS..........................................................................................................14
7. CARE AND CLEANING................................................................................................ 17
8. TROUBLESHOOTING.................................................................................................. 17
9. TECHNICAL DATA....................................................................................................... 19
10. ENERGY EFFICIENCY...............................................................................................19
11. ENVIRONMENTAL CONCERNS................................................................................20
1. SAFETY INFORMATION
Before the installation and use of the appliance, carefully read
the supplied instructions. The manufacturer is not responsible
for any injuries or damage that are the result of incorrect
2 ENGLISH

installation or usage. Always keep the instructions in a safe
and accessible location for future reference.
1.1 Children and vulnerable people safety
•This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning
the use of the appliance in a safe way and understand the
hazards involved. Children of less than 8 years of age and
persons with very extensive and complex disabilities shall
be kept away from the appliance unless continuously
supervised.
•Children should be supervised to ensure that they do not
play with the appliance.
•Keep all packaging away from children and dispose of it
appropriately.
•WARNING: Keep children and pets away from the
appliance when it operates or when it cools down.
Accessible parts become hot during use.
•If the appliance has a child safety device, it should be
activated.
•Children shall not carry out cleaning and user maintenance
of the appliance without supervision.
1.2 General Safety
•WARNING: The appliance and its accessible parts become
hot during use. Care should be taken to avoid touching
heating elements.
•WARNING: Unattended cooking on a hob with fat or oil can
be dangerous and may result in fire.
•NEVER try to extinguish a fire with water, but switch off the
appliance and then cover flame e.g. with a lid or a fire
blanket.
•WARNING: The appliance must not be supplied through an
external switching device, such as a timer, or connected to
a circuit that is regularly switched on and off by a utility.
ENGLISH 3

•CAUTION: The cooking process has to be supervised. A
short term cooking process has to be supervised
continuously.
•WARNING: Danger of fire: Do not store items on the
cooking surfaces.
•Metallic objects such as knives, forks, spoons and lids
should not be placed on the hob surface since they can get
hot.
•Do not use the appliance before installing it in the built-in
structure.
•Do not use a steam cleaner to clean the appliance.
•After use, switch off the hob element by its control and do
not rely on the pan detector.
•If the glass ceramic surface / glass surface is cracked,
switch off the appliance and unplug it from the mains. In
case the appliance is connected to the mains directly using
junction box, remove the fuse to disconnect the appliance
from power supply. In either case contact the Authorised
Service Centre.
•If the supply cord is damaged, it must be replaced by the
manufacturer, an authorized Service or similarly qualified
persons in order to avoid a hazard.
•WARNING: Use only hob guards designed by the
manufacturer of the cooking appliance or indicated by the
manufacturer of the appliance in the instructions for use as
suitable or hob guards incorporated in the appliance. The
use of inappropriate guards can cause accidents.
2. SAFETY INSTRUCTIONS
2.1 Installation
WARNING!
Only a qualified person must
install this appliance.
WARNING!
Risk of injury or damage to the
appliance.
• Remove all the packaging.
• Do not install or use a damaged
appliance.
• Follow the installation instructions
supplied with the appliance.
• Keep the minimum distance from other
appliances and units.
• Always take care when moving the
appliance as it is heavy. Always use
safety gloves and enclosed footwear.
4 ENGLISH

• Seal the cut surfaces with a sealant to
prevent moisture from causing swelling.
• Protect the bottom of the appliance from
steam and moisture.
• Do not install the appliance next to a door
or under a window. This prevents hot
cookware from falling from the appliance
when the door or the window is opened.
• Each appliance has cooling fans on the
bottom.
• If the appliance is installed above a
drawer:
– Do not store any small pieces or
sheets of paper that could be pulled
in, as they can damage the cooling
fans or impair the cooling system.
– Keep a distance of minimum 2 cm
between the bottom of the appliance
and parts stored in the drawer.
• Remove any separator panels installed in
the cabinet below the appliance.
2.2 Electrical Connection
WARNING!
Risk of fire and electric shock.
• All electrical connections should be made
by a qualified electrician.
• The appliance must be earthed.
• Before carrying out any operation make
sure that the appliance is disconnected
from the power supply.
• Make sure that the parameters on the
rating plate are compatible with the
electrical ratings of the mains power
supply.
• Make sure the appliance is installed
correctly. Loose and incorrect electricity
mains cable or plug (if applicable) can
make the terminal become too hot.
• Use the correct electricity mains cable.
• Do not let the electricity mains cable
tangle.
• Make sure that a shock protection is
installed.
• Use the strain relief clamp on the cable.
• Make sure the mains cable or plug (if
applicable) does not touch the hot
appliance or hot cookware, when you
connect the appliance to a socket.
• Do not use multi-plug adapters and
extension cables.
• Make sure not to cause damage to the
mains plug (if applicable) or to the mains
cable. Contact our Authorised Service
Centre or an electrician to change a
damaged mains cable.
• The shock protection of live and insulated
parts must be fastened in such a way that
it cannot be removed without tools.
• Connect the mains plug to the mains
socket only at the end of the installation.
Make sure that there is access to the
mains plug after the installation.
• If the mains socket is loose, do not
connect the mains plug.
• Do not pull the mains cable to disconnect
the appliance. Always pull the mains plug.
• Use only correct isolation devices: line
protecting cut-outs, fuses (screw type
fuses removed from the holder), earth
leakage trips and contactors.
• The electrical installation must have an
isolation device which lets you disconnect
the appliance from the mains at all poles.
The isolation device must have a contact
opening width of minimum 3 mm.
2.3 Use
WARNING!
Risk of injury, burns and electric
shock.
• Remove all the packaging, labelling and
protective film (if applicable) before first
use.
• This appliance is for household (indoors)
use only.
• Do not change the specification of this
appliance.
• Make sure that the ventilation openings
are not blocked.
• Do not let the appliance stay unattended
during operation.
• Set the cooking zone to “off” after each
use.
• Do not put cutlery or saucepan lids on the
cooking zones. They can become hot.
• Do not operate the appliance with wet
hands or when it has contact with water.
• Do not use the appliance as a work
surface or as a storage surface.
• If the surface of the appliance is cracked,
disconnect immediately the appliance
ENGLISH 5

from the power supply. This to prevent an
electrical shock.
• Users with a pacemaker must keep a
distance of minimum 30 cm from the
induction cooking zones when the
appliance is in operation.
• When you place food into hot oil, it may
splash.
WARNING!
Risk of fire and explosion
• Fats and oil when heated can release
flammable vapours. Keep flames or
heated objects away from fats and oils
when you cook with them.
• The vapours that very hot oil releases can
cause spontaneous combustion.
• Used oil, that can contain food remnants,
can cause fire at a lower temperature than
oil used for the first time.
• Do not put flammable products or items
that are wet with flammable products in,
near or on the appliance.
WARNING!
Risk of damage to the appliance.
• Do not keep hot cookware on the control
panel.
• Do not put a hot pan cover on the glass
surface of the hob.
• Do not let cookware boil dry.
• Be careful not to let objects or cookware
fall on the appliance. The surface can be
damaged.
• Do not activate the cooking zones with
empty cookware or without cookware.
• Do not put aluminium foil on the
appliance.
• Cookware made of cast iron, aluminium or
with a damaged bottom can cause
scratches on the glass / glass ceramic.
Always lift these objects up when you
have to move them on the cooking
surface.
• This appliance is for cooking purposes
only. It must not be used for other
purposes, for example room heating.
2.4 Care and cleaning
• Clean the appliance regularly to prevent
the deterioration of the surface material.
• Switch off the appliance and let it cool
down before cleaning.
• Do not use water spray and steam to
clean the appliance.
• Clean the appliance with a moist soft
cloth. Use only neutral detergents. Do not
use abrasive products, abrasive cleaning
pads, solvents or metal objects.
2.5 Service
• To repair the appliance contact the
Authorised Service Centre. Use original
spare parts only.
• Concerning the lamp(s) inside this product
and spare part lamps sold separately:
These lamps are intended to withstand
extreme physical conditions in household
appliances, such as temperature,
vibration, humidity, or are intended to
signal information about the operational
status of the appliance. They are not
intended to be used in other applications
and are not suitable for household room
illumination.
2.6 Disposal
WARNING!
Risk of injury or suffocation.
• Contact your municipal authority for
information on how to dispose of the
appliance.
• Disconnect the appliance from the mains
supply.
• Cut off the mains electrical cable close to
the appliance and dispose of it.
6 ENGLISH

3. INSTALLATION
WARNING!
Refer to Safety chapters.
3.1 Before the installation
Before you install the hob, write down the
information below from the rating plate. The
rating plate is on the bottom of the hob.
Serial number ...........................
3.2 Built-in hobs
Only use the built-in hobs after you assemble
the hob into correct built-in units and work
surfaces that align to the standards.
3.3 Connection cable
• The hob is supplied with a connection
cable.
• To replace the damaged mains cable, use
the cable type: H05V2V2-F which
withstands a temperature of 90 °C or
higher. Contact an Authorised Service
Centre. The connection cable may only be
replaced by a qualified electrician.
3.4 Attaching the seal - Integrated
installation
1. Clean the rabbets in the worktop.
2. Cut the supplied 3x10mm seal stripe into
4 stripes. The stripes must have the
same length as the rabbets.
3. Cut the ends of the stripes at an angle of
45°. They should fit in the corners of the
rabbets accurately.
4. Attach the stripes to the rabbets. Do not
stretch the stripes. Do not bond the ends
of the stripes one over the other.
After you assemble the hob, seal the
remaining gap between the glass ceramic
and the worktop with silicone. Make sure the
silicone does not get under the glass
ceramic.
3.5 Assembly
If you install the hob under a hood, please
see the installation instructions of the hood
for the minimum distance between the
appliances.
min.
50mm
min.
500mm
65 ±1mm
490±1mm
55±1mm
If the appliance is installed above a drawer,
the hob ventilation can warm up the items
stored in the drawer during the cooking
process.
ENGLISH 7

min.
28 mm
Find the video tutorial "How to install your
AEG induction hob flush installation" by
typing out the full name indicated in the
graphic below.
www.youtube.com/electrolux
www.youtube.com/aeg
How to install your AEG induction hob
flush installation
4. PRODUCT DESCRIPTION
4.1 Cooking surface layout
11 1
1
1
2
1Induction cooking surface
2Control panel
8 ENGLISH

4.2 Control panel layout
1 2 4 5 63 10 117
12
8
13
9
Use the sensor fields to operate the appliance. The displays, indicators and sounds tell which
functions operate.
Sensor field Comment
1To activate and deactivate the hob.
2To activate and deactivate Lock or Child Safety Device.
3To show the active zone.
4CountUp Timer indicator.
5Count Down Timer indicator.
6- Timer display: 00 - 99 minutes.
7To activate and deactivate Bridge and to switch between the modes.
8To select Timer functions.
9 / To increase and decrease the time.
10 To activate and deactivate Hob²Hood.
11 To activate and deactivate Pause.
12 To activate PowerBoost.
13 - To set a heat setting: 0 - 9.
5. DAILY USE
WARNING!
Refer to Safety chapters.
5.1 Activating and deactivating
Touch for 1 second to activate or
deactivate the hob.
The control panel comes on after you
activate the hob and goes off after you
deactivate the hob.
5.2 Automatic Switch Off
The function deactivates the hob
automatically if:
ENGLISH 9

• you do not place any cookware on the
hob for 50 seconds,
• you do not set the heat setting for 50
seconds after you place the cookware,
• you spill something or put something on
the control panel for more than 10
seconds (a pan, a cloth). When you hear
the acoustic signal, the hob deactivates.
Remove the object or clean the control
panel.
• the hob gets too hot (e.g. when a
saucepan boils dry). Let the cooking zone
cool down before you use the hob again.
• you do not deactivate a cooking zone or
change the heat setting. After some time,
the hob deactivates.
The relation between the heat setting and
the time after which the hob deactivates:
Heat setting The hob deactivates
after
1 - 2 6 hours
3 - 4 5 hours
5 4 hours
6 - 9 1.5 hours
5.3 Using the cooking zone
CAUTION!
Do not place hot cookware on
the control panel. There is a risk
of damage to the electronic
parts.
Place the cookware in the centre of the
selected zone.
Induction cooking zones adapt to the
dimension of the bottom of the cookware
automatically.
When you place the cookware in the correct
position, the hob recognizes it and the
appropriate control bar comes on. A red
cooking zone indicator appears above the
control bar and indicates the position of the
pot.
Each square on the control panel represents
one cooking zone on the induction cooking
surface. Zone indicators show which cooking
zone is controlled by the appropriate control
bar.
5.4 Heat setting
1. Press the desired heat setting on the
control bar. You can also move your
finger along the control bar to set or
change the heat setting for a cooking
zone.
2. To deactivate a cooking zone, press 0.
Once you place a pot on the cooking zone
and set the heat setting, it remains the same
for 2 minutes after you remove the pot. The
control bar and the cooking zone indicator
blink for 2 minutes. If you place the pot on
the cooking zone again within this time, the
heat setting reactivates. Otherwise the
cooking zone deactivates.
10 ENGLISH

5.5 PowerBoost
This function activates more power for the
appropriate induction cooking zone,
depending on the cookware size. The
function can be activated only for a limited
period of time.
Touch to activate the function for the
cooking zone.
The symbol turns red.
The function deactivates automatically.
For maximum duration values,
refer to "Technical data".
5.6 OptiHeat Control (3 step
Residual heat indicator)
WARNING!
/ / As long as the
indicator is on, there is a risk of
burns from residual heat.
The induction cooking zones produce the
heat necessary for the cooking process
directly in the bottom of the cookware. The
glass ceramic is heated by the heat of the
cookware.
The indicators / / appear when a
cooking zone is hot. They show the level of
the residual heat for the cooking zones you
are currently using.
The indicator may also appear:
• for the neighbouring cooking zones even
if you are not using them,
• when hot cookware is placed on cold
cooking zone,
• when the hob is deactivated but the
cooking zone is still hot.
The indicator disappears when the cooking
zone has cooled down.
5.7 Timer
Count Down Timer
Use this function to specify how long a
cooking zone should operate during a single
cooking session.
First set the heat setting, then set the
function.
1. Touch to activate the function or
change the time.
The timer digits and the indicators
and come on the display. turns red,
and turns white.
If the timer is not set, all indicators disappear
after 4 seconds.
2. Touch or to set the time (00 - 99
minutes).
After 3 seconds, the timer starts to count
down automatically. The indicators , ,
and disappear. stays red.
When the time comes to an end, a signal
sounds and flashes. To stop the signal,
touch .
To deactivate the function: touch . The
indicators and come on. Use or
to set on the display. Alternatively, set
the heat level to 0. As a result, a signal
sounds and the timer is cancelled.
CountUp Timer
You can use this function to monitor how
long a cooking zone operates.
Touch twice to activate the function.
The indicator turns red, the timer starts to
count up automatically.
To deactivate the function: touch . When
the indicators light up, touch .
Minute Minder
You can use this function when the hob is
activated but no cooking zone operates.
To see the control panel, place a pot on a
cooking zone.
1. Touch , until the indicator turns red,
to activate the function.
2. Touch or to set the time.
ENGLISH 11

The function starts automatically after 4
seconds. The indicators , , and
disappear. stays red.
When you set the function, you can remove
the pot.
When the time comes to an end, a signal
sounds and flashes. Touch to stop
the signal.
To deactivate the function: touch . The
indicators and light up. Use or
to set on the display.
The function has no effect on the
operation of any cooking zone.
5.8 Bridge
This function connects two cooking zones
and they operate as one. You can use the
function with large cookware.
1. Place the cookware on two cooking
zones. The cookware must cover the
centres of both zones.
turns white.
2. Touch to activate the function.
3. Set the heat setting.
The cookware must cover the centres of both
zones but not go beyond the area marking.
To deactivate the function, touch . The
cooking zones operate independently.
5.9 Pause
This function sets all cooking zones that
operate to the lowest heat setting.
This function sets the cooking zone to the
lowest heat setting.
When the function is active, and
symbols can be used.
The function does not stop the timer
functions.
Press to activate the function.
The symbol turns red. The heat setting is
lowered to 1.
To deactivate the function: press . The
symbol turns white. The previous heat setting
comes on.
5.10 Lock
You can lock the control panel while the hob
operates. It prevents an accidental change of
the heat setting.
Set the heat setting first.
Touch to activate the function.
The symbol turns red and blinks.
To deactivate the function, touch . The
symbol turns white.
When you deactivate the hob,
you also deactivate this function.
5.11 Child Safety Device
This function prevents an accidental
operation of the hob.
Activate the hob first and do not set the heat
setting.
Touch until it turns red to activate the
function.
The control bars disappear. Deactivate the
hob.
When you deactivate the hob,
the function is still active.
To deactivate the function for only one
cooking time: Activate the hob with .
comes on. Touch until it turns white. The
12 ENGLISH

control bars appear. Set the heat setting
within 50 seconds. You can operate the hob.
When you deactivate the hob with the
function is still active.
To deactivate the function permanently:
Activate the hob and do not set the heat
setting. Touch until it turns white. The
control bars appear. Deactivate the hob.
5.12 OffSound Control
(Deactivating and activating the
sounds)
Deactivate the hob first.
1. Touch for 3 seconds to activate the
function.
The display comes on and goes out.
2. Touch for 3 seconds.
or comes on.
3. Touch of the timer to choose one of
the following:
• - the sounds are off
• - the sounds are on
4. Wait until the hob deactivates
automatically to confirm your selection.
When the function is set to you can hear
the sounds only when:
• you touch
• Minute Minder comes down
• Count Down Timer comes down
• you put something on the control panel.
5.13 Hob²Hood
It is an advanced automatic function which
connects the hob to a special hood. Both the
hob and the hood have an infrared signal
communicator. Speed of the fan is defined
automatically on the basis of the mode
setting and temperature of the hottest
cookware on the hob. You can also operate
the fan from the hob manually.
For most of the hoods, the
remote system is originally
deactivated. Activate it before
you use the function. For more
information refer to the hood
user manual.
Operating the function automatically
To operate the function automatically set the
automatic mode to H1 - H6. The hob is
originally set to H5. The hood reacts
whenever you operate the hob. The hob
recognizes the temperature of the cookware
automatically and adjusts the speed of the
fan.
Activating the light
You can set the hob to activate the light
automatically whenever you activate the hob.
To do so set the automatic mode to H1 - H6.
The light on the hood
deactivates 2 minutes after
deactivating the hob.
Automatic modes
Auto‐
matic
light
Boiling1) Frying2)
Mode H0 Off Off Off
Mode H1 On Off Off
Mode H23) On Fan speed
1
Fan speed
1
Mode H3 On Off Fan speed
1
Mode H4 On Fan speed
1
Fan speed
1
Mode H5 On Fan speed
1
Fan speed
2
Mode H6 On Fan speed
2
Fan speed
3
1) The hob detects the boiling process and acti‐
vates the fan speed in accordance with the au‐
tomatic mode.
2) The hob detects the frying process and acti‐
vates the fan speed in accordance with the au‐
tomatic mode.
3) This mode activates the fan and the light and
does not rely on the temperature.
Changing the automatic mode
1. Deactivate the appliance.
2. Touch for 3 seconds.
The display comes on and goes off.
3. Touch for 3 seconds.
ENGLISH 13

4. Touch a few times until comes on.
5. Touch of the Timer to select an
automatic mode.
When you finish cooking and deactivate the
hob, the hood fan may still operate for a
certain period of time. After that time the
system deactivates the fan automatically and
prevents you from an accidental activation of
the fan for the next 30 seconds.
To operate the hood directly on
the hood panel deactivate the
automatic mode of the function.
Operating the fan speed manually
You can also operate the fan from the hob
manually.
Touch when the hob is active.
This deactivates automatic operation of the
function and allows you to change the fan
speed manually.
When you press , you raise the fan speed
by one. When you reach an intensive level
and press again, you set the fan speed to
0 which deactivates the hood fan. To start
the fan again with the fan speed 1 touch .
To activate an automatic
operation of the function,
deactivate the hob and activate it
again.
5.14 Power management
If multiple zones are active and the
consumed power exceeds the limitation of
the power supply, this function divides the
available power between all cooking zones.
The hob controls heat settings to protect the
fuses of the house installation.
• Cooking zones are grouped according to
the location and number of the phases in
the hob. Each phase has a maximum
electricity loading of 3680 W. If the hob
reaches the limit of maximum available
power within one phase, the power of the
cooking zones will be automatically
reduced.
• For cooking zones that have a reduced
power, the control panel shows the
maximum possible heat settings. The heat
setting may be 0 when the other pots
consume the maximum available power.
As a result, you cannot activate any other
zone.
• If a higher heat setting is not available
reduce it for the other cooking zones first.
• The activation of the function depends on
the number and size of pots.
Refer to the illustration for possible
combinations in which power can be
distributed among the cooking zones.
6. HINTS AND TIPS
WARNING!
Refer to Safety chapters.
6.1 Cookware
For induction cooking zones a
strong electro-magnetic field
creates the heat in the cookware
very quickly.
Use the induction cooking zones with
suitable cookware.
• The bottom of the cookware must be as
thick and flat as possible.
• Ensure pan bases are clean and dry
before placing on the hob surface.
• In order to avoid scratches, do not slide or
rub the pot across the ceramic glass.
Cookware material
14 ENGLISH

•correct: cast iron, steel, enamelled steel,
stainless steel, multi-layer bottom (with a
correct marking from a manufacturer).
•not correct: aluminium, copper, brass,
glass, ceramic, porcelain.
Cookware is suitable for an induction hob
if:
• water boils very quickly on a zone set to
the highest heat setting.
• a magnet pulls on to the bottom of the
cookware.
Cookware dimensions
• Induction cooking zones adapt to the
dimension of the bottom of the cookware
automatically.
• The cooking zone efficiency is related to
the diameter of the cookware. The
cookware with a diameter smaller than the
minimum receives only a part of the
power generated by the cooking zone.
• For both safety reasons and optimal
cooking results, do not use cookware
larger than indicated in "Cooking zones
specification". Avoid keeping cookware
close to the control panel during the
cooking session. This might impact the
functioning of the control panel or
accidentally activate hob functions.
Refer to "Technical data".
6.2 The noises during operation
If you can hear:
• crack noise: cookware is made of different
materials (a sandwich construction).
• whistle sound: you use a cooking zone
with a high power level and the cookware
is made of different materials (a sandwich
construction).
• humming: you use a high power level.
• clicking: electric switching occurs.
• hissing, buzzing: the fan operates.
The noises are normal and do not indicate
any malfunction.
6.3 Öko Timer (Eco Timer)
To save energy, the heater of the cooking
zone deactivates before the count down
timer sounds. The difference in the operation
time depends on the heat setting level and
the length of the cooking operation.
6.4 Examples of cooking
applications
The correlation between the heat setting of a
zone and its consumption of power is not
linear. When you increase the heat setting, it
is not proportional to the increase of the
consumption of power. It means that a
cooking zone with the medium heat setting
uses less than a half of its power.
The data in the table is for
guidance only.
Heat setting Use to: Time
(min)
Hints
1 Keep cooked food warm. as neces‐
sary
Put a lid on the cookware.
1 - 2 Hollandaise sauce, melt: butter, choco‐
late, gelatine.
5 - 25 Mix from time to time.
1 - 2 Solidify: fluffy omelettes, baked eggs. 10 - 40 Cook with a lid on.
2 - 3 Simmer rice and milkbased dishes,
heat up ready-cooked meals.
25 - 50 Add at least twice as much liquid as
rice, mix milk dishes halfway through
the procedure.
3 - 4 Steam vegetables, fish, meat. 20 - 45 Add a couple of tablespoons of liquid.
ENGLISH 15

Heat setting Use to: Time
(min)
Hints
4 - 5 Steam potatoes. 20 - 60 Use max. ¼ l of water for 750 g of po‐
tatoes.
4 - 5 Cook larger quantities of food, stews
and soups.
60 - 150 Up to 3 l of liquid plus ingredients.
6 - 7 Gentle fry: escalope, veal cordon bleu,
cutlets, rissoles, sausages, liver, roux,
eggs, pancakes, doughnuts.
as neces‐
sary
Turn halfway through.
7 - 8 Heavy fry, hash browns, loin steaks,
steaks.
5 - 15 Turn halfway through.
9 Boil water, cook pasta, sear meat (goulash, pot roast), deep-fry chips.
Boil large quantities of water. PowerBoost is activated.
6.5 Hints and Tips for Hob²Hood
When you operate the hob with the function:
• Protect the hood panel from direct
sunlight.
• Do not spot halogen light on the hood
panel.
• Do not cover the hob control panel.
• Do not interrupt the signal between the
hob and the hood (e.g. with the hand, a
cookware handle or a tall pot). See the
picture.
The hood in the picture is only exemplary.
Other remotely controlled
appliances may block the signal.
Do not use any such appliances
near to the hob while Hob²Hood
is on.
Cooker hoods with the Hob²Hood function
To find the full range of cooker hoods which
work with this function refer to our consumer
website. The AEG cooker hoods that work
with this function must have the symbol .
16 ENGLISH

7. CARE AND CLEANING
WARNING!
Refer to Safety chapters.
7.1 General information
• Clean the hob after each use.
• Always use cookware with a clean base.
• Scratches or dark stains on the surface
have no effect on how the hob operates.
• Use a special cleaner suitable for the
surface of the hob.
• Use a special scraper for the glass.
7.2 Cleaning the hob
•Remove immediately: melted plastic,
plastic foil, sugar and food with sugar,
otherwise, the dirt can cause damage to
the hob. Take care to avoid burns. Use a
special hob scraper on the glass surface
at an acute angle and move the blade on
the surface.
•Remove when the hob is sufficiently
cool: limescale rings, water rings, fat
stains, shiny metallic discoloration. Clean
the hob with a moist cloth and a non-
abrasive detergent. After cleaning, wipe
the hob dry with a soft cloth.
•Remove shiny metallic discoloration:
use a solution of water with vinegar and
clean the glass surface with a cloth.
8. TROUBLESHOOTING
WARNING!
Refer to Safety chapters.
8.1 What to do if...
Problem Possible cause Remedy
You cannot activate or operate
the hob.
The hob is not connected to an elec‐
trical supply or it is connected incor‐
rectly.
Check if the hob is correctly connected
to the electrical supply.
The fuse is blown. Make sure that the fuse is the cause of
the malfunction. If the fuse is blown
again and again, contact a qualified
electrician.
You touched 2 or more sensor fields
at the same time.
Touch only one sensor field.
Pause operates. Refer to "Daily use".
There is water or fat stains on the
control panel.
Clean the control panel.
You cannot select the maximum
heat setting for one of the cook‐
ing zones.
You cannot activate one of the
cooking zones.
The other zones consume the maxi‐
mum available power.
Your hob works properly.
Reduce the heat setting of the other
cooking zones connected to the same
phase. Refer to "Power management".
ENGLISH 17

Problem Possible cause Remedy
An acoustic signal sounds and
the hob deactivates.
An acoustic signal sounds when
the hob is deactivated.
You put something on one or more
sensor fields.
Remove the object from the sensor
fields.
The hob deactivates. You put something on the sensor
field .
Remove the object from the sensor
field.
Residual heat indicator does not
come on.
The zone is not hot because it oper‐
ated only for a short time or the sen‐
sor is damaged.
If the zone operated sufficiently long to
be hot, speak to an Authorised Service
Centre.
Hob²Hood does not work. You covered the control panel. Remove the object from the control
panel.
You use a very tall pot which blocks
the signal.
Use a smaller pot, change the cooking
zone or operate the hood manually.
The sensor fields become hot. The cookware is too large or you put
it too near to the controls.
Put large cookware on the rear zones,
if possible.
There is no sound when you
touch the panel sensor fields.
The sounds are deactivated. Activate the sounds. Refer to "Daily
use".
comes on. Child Safety Device or Lock oper‐
ates.
Refer to "Daily use".
The control bar blinks. There is no cookware on the zone or
the zone is not fully covered.
Put cookware on the zone so that it
fully covers the cooking zone.
The cookware is unsuitable. Use suitable cookware. Refer to "Hints
and tips".
The diameter of the bottom of the
cookware is too small for the zone.
Use cookware with correct dimen‐
sions. Refer to "Technical data".
and a number come on. There is an error in the hob. Deactivate the hob and activate it
again after 30 seconds. If comes on
again, disconnect the hob from the
electrical supply. After 30 seconds,
connect the hob again. If the problem
continues, speak to an Authorised
Service Centre.
You can hear a constant beep
noise.
The electrical connection is incor‐
rect.
Disconnect the hob from the electrical
supply. Ask a qualified electrician to
check the installation.
8.2 If you cannot find a solution...
If you cannot find a solution to the problem
yourself, contact your dealer or an
Authorised Service Centre. Give the data
from the rating plate. Make sure, you
operated the hob correctly. If not the
servicing by a service technician or dealer
will not be free of charge, also during the
warranty period. The information about
guarantee period and Authorised Service
Centres are in the guarantee booklet.
18 ENGLISH

9. TECHNICAL DATA
9.1 Rating plate
Model IKE85651IB PNC 949 597 352 00
Typ 61 D5A 04 AA 220 - 240 V / 400 V 2N 50 - 60 Hz
Induction 7.35 kW Made in: Germany
Ser.Nr. ................. 7.35 kW
AEG
9.2 Cooking zones specification
Cooking zone Nominal power
(maximum heat
setting) [W]
PowerBoost [W] PowerBoost
maximum dura‐
tion [min]
Cookware diame‐
ter [mm]
Left front 2300 3200 10 125 - 210
Left rear 2300 3200 10 125 - 210
Middle front 2300 3200 10 210 - 240
Right front 2300 3200 10 125 - 210
Right rear 2300 3200 10 125 - 210
The power of the cooking zones can be
different in some small range from the data in
the table. It changes with the material and
dimensions of the cookware.
For optimal cooking results use cookware no
larger than the diameter in the table.
10. ENERGY EFFICIENCY
10.1 Product Information*
Model identification IKE85651IB
Type of hob Built-In Hob
Number of cooking zones 1
Number of cooking areas 2
Heating technology Induction
Diameter of circular cooking zones (Ø) Middle front 24.0 cm
Length (L) and width (W) of the cooking area Left L 37.9 cm
W 22.0 cm
Length (L) and width (W) of the cooking area Right L 37.9 cm
W 22.0 cm
ENGLISH 19

Energy consumption per cooking zone (EC electric
cooking)
Middle front 190.6 Wh / kg
Energy consumption of the cooking area (EC electric
cooking)
Left 186.8 Wh / kg
Energy consumption of the cooking area (EC electric
cooking)
Right 186.8 Wh / kg
Energy consumption of the hob (EC electric hob) 187.3 Wh / kg
* For European Union according to EU
66/2014. For Belarus according to STB
2477-2017, Annex A. For Ukraine according
to 742/2019.
EN 60350-2 - Household electric cooking
appliances - Part 2: Hobs - Methods for
measuring performance.
The energy measurements referring to the
cooking area are identified by the markings
of the respective cooking zones.
10.2 Energy saving
You can save energy during everyday
cooking if you follow below hints.
• When you heat up water, use only the
amount you need.
• If it is possible, always put the lids on the
cookware.
• Before you activate the cooking zone put
the cookware on it.
• Put the smaller cookware on the smaller
cooking zones.
• Put the cookware directly in the centre of
the cooking zone.
• Use the residual heat to keep the food
warm or to melt it.
11. ENVIRONMENTAL CONCERNS
Recycle materials with the symbol . Put
the packaging in relevant containers to
recycle it. Help protect the environment and
human health by recycling waste of electrical
and electronic appliances. Do not dispose of
appliances marked with the symbol with
the household waste. Return the product to
your local recycling facility or contact your
municipal office.
20 ENGLISH
*
