AEG BD541P User manual

USER
MANUAL
EN User Manual
Oven
BD541P
BPK556220M
BPK55622YM

CONTENTS
1. SAFETY INFORMATION......................................................................................2
2. SAFETY INSTRUCTIONS.................................................................................... 4
3. PRODUCT DESCRIPTION...................................................................................7
4. CONTROL PANEL................................................................................................8
5. BEFORE FIRST USE............................................................................................9
6. DAILY USE........................................................................................................... 9
7. CLOCK FUNCTIONS..........................................................................................12
8. USING THE ACCESSORIES..............................................................................14
9. ADDITIONAL FUNCTIONS.................................................................................17
10. HINTS AND TIPS..............................................................................................18
11. CARE AND CLEANING.................................................................................... 36
12. TROUBLESHOOTING......................................................................................40
13. ENERGY EFFICIENCY.....................................................................................44
FOR PERFECT RESULTS
Thank you for choosing this AEG product. We have created it to give you
impeccable performance for many years, with innovative technologies that help
make life simpler – features you might not find on ordinary appliances. Please
spend a few minutes reading to get the very best from it.
Visit our website to:
Get usage advice, brochures, trouble shooter, service and repair information:
www.aeg.com/support
Register your product for better service:
www.registeraeg.com
Buy Accessories, Consumables and Original spare parts for your appliance:
www.aeg.com/shop
CUSTOMER CARE AND SERVICE
Always use original spare parts.
When contacting our Authorised Service Centre, ensure that you have the
following data available: Model, PNC, Serial Number.
The information can be found on the rating plate.
Warning / Caution-Safety information
General information and tips
Environmental information
Subject to change without notice.
1. SAFETY INFORMATION
Before the installation and use of the appliance, carefully
read the supplied instructions. The manufacturer is not
www.aeg.com2

responsible for any injuries or damage that are the result
of incorrect installation or usage. Always keep the
instructions in a safe and accessible location for future
reference.
1.1 Children and vulnerable people safety
•Do not let children play with the appliance.
•Keep all packaging away from children and dispose of
it appropriately.
•WARNING: Keep children and pets away from the
appliance when it operates or when it cools down.
Accessible parts become hot during use.
•If the appliance has a child safety device, it should be
activated.
•Children shall not carry out cleaning and user
maintenance of the appliance without supervision.
1.2 General Safety
•Only a qualified person must install this appliance and
replace the cable.
•WARNING: The appliance and its accessible parts
become hot during use. Care should be taken to avoid
touching heating elements.
•Always use oven gloves to remove or put in
accessories or ovenware.
•Before carrying out any maintenance, disconnect the
appliance from the power supply.
•WARNING: Ensure that the appliance is switched off
before replacing the lamp to avoid the possibility of
electric shock.
•Do not use the appliance before installing it in the
built-in structure.
•Do not use a steam cleaner to clean the appliance.
•Do not use harsh abrasive cleaners or sharp metal
scrapers to clean the glass door since they can
scratch the surface, which may result in shattering of
the glass.
ENGLISH 3

•If the mains power supply cable is damaged, it must
be replaced by the manufacturer, its Authorised
Service Centre or similarly qualified persons to avoid
an electrical hazard.
•Excessive spillage must be removed before the
pyrolytic cleaning. Remove all parts from the oven.
•To remove the shelf supports first pull the front of the
shelf support and then the rear end away from the
side walls. Install the shelf supports in the opposite
sequence.
•Use only the food sensor (core temperature sensor)
recommended for this appliance.
2. SAFETY INSTRUCTIONS
2.1 Installation
WARNING!
Only a qualified person must
install this appliance.
• Remove all the packaging.
• Do not install or use a damaged
appliance.
• Follow the installation instructions
supplied with the appliance.
• Always take care when moving the
appliance as it is heavy. Always use
safety gloves and enclosed footwear.
• Do not pull the appliance by the
handle.
• Install the appliance in a safe and
suitable place that meets installation
requirements.
• Keep the minimum distance from
other appliances and units.
• Before mounting the appliance, check
if the oven door opens without
restraint.
• The appliance is equipped with an
electric cooling system. It must be
operated with the electric power
supply.
Cabinet minimum
height (Cabinet under
the worktop minimum
height)
600 (600) mm
Cabinet width 550 mm
Cabinet depth 605 (580) mm
Height of the front of
the appliance
594 mm
Height of the back of
the appliance
576 mm
Width of the front of
the appliance
549 mm
Width of the back of
the appliance
548 mm
Depth of the appli‐
ance
567 mm
Built in depth of the
appliance
546 mm
Depth with open door 1017 mm
Ventilation opening
minimum size. Open‐
ing placed on the bot‐
tom rear side
550 x 20 mm
Mains supply cable
length. Cable is
placed in the right
corner of the back
side
1500 mm
Mounting screws 4 x 12 mm
www.aeg.com4

2.2 Electrical connection
WARNING!
Risk of fire and electric
shock.
• All electrical connections should be
made by a qualified electrician.
• The appliance must be earthed.
• Make sure that the parameters on the
rating plate are compatible with the
electrical ratings of the mains power
supply.
• Always use a correctly installed
shockproof socket.
• Do not use multi-plug adapters and
extension cables.
• Make sure not to cause damage to
the mains plug and to the mains
cable. Should the mains cable need to
be replaced, this must be carried out
by our Authorised Service Centre.
• Do not let mains cables touch or
come near the appliance door or the
niche below the appliance, especially
when it operates or the door is hot.
• The shock protection of live and
insulated parts must be fastened in
such a way that it cannot be removed
without tools.
• Connect the mains plug to the mains
socket only at the end of the
installation. Make sure that there is
access to the mains plug after the
installation.
• If the mains socket is loose, do not
connect the mains plug.
• Do not pull the mains cable to
disconnect the appliance. Always pull
the mains plug.
• Use only correct isolation devices: line
protecting cut-outs, fuses (screw type
fuses removed from the holder), earth
leakage trips and contactors.
• The electrical installation must have
an isolation device which lets you
disconnect the appliance from the
mains at all poles. The isolation
device must have a contact opening
width of minimum 3 mm.
• Fully close the appliance door before
you connect the mains plug to the
mains socket.
• This appliance is supplied with a main
plug and a main cable.
2.3 Use
WARNING!
Risk of injury, burns and
electric shock or explosion.
• This appliance is for household use
only.
• Do not change the specification of this
appliance.
• Make sure that the ventilation
openings are not blocked.
• Do not let the appliance stay
unattended during operation.
• Deactivate the appliance after each
use.
• Be careful when you open the
appliance door while the appliance is
in operation. Hot air can release.
• Do not operate the appliance with wet
hands or when it has contact with
water.
• Do not apply pressure on the open
door.
• Do not use the appliance as a work
surface or as a storage surface.
• Open the appliance door carefully.
The use of ingredients with alcohol
can cause a mixture of alcohol and
air.
• Do not let sparks or open flames to
come in contact with the appliance
when you open the door.
• Do not put flammable products or
items that are wet with flammable
products in, near or on the appliance.
WARNING!
Risk of damage to the
appliance.
• To prevent damage or discoloration to
the enamel:
– do not put ovenware or other
objects in the appliance directly
on the bottom.
– do not put aluminium foil directly
on the bottom of cavity of the
appliance.
– do not put water directly into the
hot appliance.
– do not keep moist dishes and
food in the appliance after you
finish the cooking.
– be careful when you remove or
install the accessories.
ENGLISH 5

• Discoloration of the enamel or
stainless steel has no effect on the
performance of the appliance.
• Use a deep pan for moist cakes. Fruit
juices cause stains that can be
permanent.
• This appliance is for cooking
purposes only. It must not be used for
other purposes, for example room
heating.
• Always cook with the oven door
closed.
• If the appliance is installed behind a
furniture panel (e.g. a door) make
sure the door is never closed when
the appliance operates. Heat and
moisture can build up behind a closed
furniture panel and cause subsequent
damage to the appliance, the housing
unit or the floor. Do not close the
furniture panel until the appliance has
cooled down completely after use.
2.4 Care and cleaning
WARNING!
Risk of injury, fire, or
damage to the appliance.
• Before maintenance, deactivate the
appliance and disconnect the mains
plug from the mains socket.
• Make sure the appliance is cold.
There is the risk that the glass panels
can break.
• Replace immediately the door glass
panels when they are damaged.
Contact the Authorised Service
Centre.
• Be careful when you remove the door
from the appliance. The door is
heavy!
• Clean regularly the appliance to
prevent the deterioration of the
surface material.
• Clean the appliance with a moist soft
cloth. Use only neutral detergents. Do
not use abrasive products, abrasive
cleaning pads, solvents or metal
objects.
• If you use an oven spray, follow the
safety instructions on its packaging.
2.5 Pyrolytic cleaning
WARNING!
Risk of Injury / Fires /
Chemical Emissions
(Fumes) in Pyrolytic Mode.
Do not start the Pyrolysis if
the Plus Steam button is
pressed in.
• Before carrying out a Pyrolitic self-
cleaning function or the First Use
please remove from the oven cavity:
– any excess food residues, oil or
grease spills / deposits.
– any removable objects (including
shelves, side rails etc., provided
with the product) particularly any
non-stick pots, pans, trays,
utensils etc.
• Read carefully all the instructions for
Pyrolytic cleaning.
• Keep children away from the
appliance while the Pyrolytic cleaning
operates.
The appliance becomes very hot and
hot air is released from the front
cooling vents.
• Pyrolytic cleaning is a high
temperature operation that can
release fumes from cooking residues
and construction materials, as such
consumers are strongly advised to:
– provide good ventilation during
and after each Pyrolytic cleaning.
– provide good ventilation during
and after the first use at maximum
temperature operation.
• Unlike all humans, some birds and
reptiles can be extremely sensitive to
potential fumes emitted during the
cleaning process of all Pyrolytic
Ovens.
– Remove any pets (especially
birds) from the vicinity of the
appliance location during and
after the Pyrolytic cleaning and
first use maximum temperature
operation to a well ventilated
area.
• Small pets can also be highly
sensitive to the localized temperature
changes in the vicinity of all Pyrolytic
Ovens when the Pyrolytic self
cleaning program is in operation.
www.aeg.com6

• Non-stick surfaces on pots, pans,
trays, utensils etc., can be damaged
by the high temperature Pyrolytic
cleaning operation of all Pyrolytic
Ovens and can be also a source for
low level harmful fumes.
• Fumes released from all Pyrolytic
Ovens / Cooking Residues as
described are not harmful to humans,
including children, or persons with
medical conditions.
2.6 Internal lighting
WARNING!
Risk of electric shock.
• Concerning the lamp(s) inside this
product and spare part lamps sold
separately: These lamps are intended
to withstand extreme physical
conditions in household appliances,
such as temperature, vibration,
humidity, or are intended to signal
information about the operational
status of the appliance. They are not
intended to be used in other
applications and are not suitable for
household room illumination.
• Use only lamps with the same
specifications.
2.7 Service
• To repair the appliance contact the
Authorised Service Centre.
• Use original spare parts only.
2.8 Disposal
WARNING!
Risk of injury or suffocation.
• Disconnect the appliance from the
mains supply.
• Cut off the mains electrical cable
close to the appliance and dispose of
it.
• Remove the door catch to prevent
children or pets from becoming
trapped in the appliance.
3. PRODUCT DESCRIPTION
3.1 General overview
1
2
3
4
5
2 3 5
8
14 11
9
10
641
12
7
13
1Control panel
2Knob for the heating functions
3Power lamp / symbol
4Display
5Control knob (for the temperature)
6Temperature indicator / symbol
7Plus Steam
8Socket for the food sensor
9Heating element
10 Lamp
11 Fan
12 Shelf support, removable
13 Cavity embossment
14 Shelf positions
ENGLISH 7

3.2 Accessories
Wire shelf
For cookware, cake tins, roasts.
Baking tray
For cakes and biscuits.
Grill- / Roasting pan
To bake and roast or as a pan to collect
fat.
Food Sensor
To measure the temperature inside food.
4. CONTROL PANEL
4.1 Buttons
Sensor field / Button Description
To set the MINUTE MINDER. Hold it for more than 3 sec‐
onds to turn on or turn off the oven lamp.
To set a clock function.
To check the oven temperature or the temperature of the
core temperature sensor (if applicable). Use only while a
heating function operates.
To turn on the True Fan Cooking PLUS function.
4.2 Display
A B
DG EF C
A. Timer / Temperature
B. Heat-up and residual heat indicator
C. Food Sensor (selected models only)
D. Door lock (selected models only)
E. Hours / minutes
F. Demo Mode
G. Clock functions
www.aeg.com8

5. BEFORE FIRST USE
WARNING!
Refer to Safety chapters.
Set the time before you use the oven.
5.1 Initial Cleaning
Step 1 Step 2 Step 3
Remove all accessories and
removable shelf supports
from the oven.
Clean the oven and the ac‐
cessories with a soft cloth,
warm water and a mild de‐
tergent.
Place the accessories and
the removable shelf supports
in the oven.
5.2 Initial preheating
Preheat the empty oven before the first use.
Step 1 Remove all accessories and removable shelf supports from the oven.
Step 2 Set the maximum temperature for the function: .
Let the oven operate for 1 h.
Step 3 Set the maximum temperature for the function: .
Let the oven operate for 15 min.
The oven can emit an odour and smoke during preheating. Make sure that the room is
ventilated.
6. DAILY USE
WARNING!
Refer to Safety chapters.
6.1 Retractable knobs
To use the appliance press the knob.
The knob comes out.
6.2 Heating functions
Oven func‐
tion
Application
Off position
The oven is off.
Fast Heat Up
To decrease the heat-up
time.
ENGLISH 9

Oven func‐
tion
Application
True Fan
Cooking / True
Fan Cooking
PLUS
To bake on up to three
shelf positions at the
same time and to dry
food.
Set the temperature 20 -
40 °C lower than for Con‐
ventional Cooking.
To add humidity during
the cooking. To get the
right colour and crispy
crust during baking. To
give more juiciness dur‐
ing reheating.
Pizza Function
To bake pizza. To make
intensive browning and a
crispy bottom.
Conventional
Cooking
To bake and roast food
on one shelf position.
Bottom Heat
To bake cakes with
crispy bottom and to pre‐
serve food.
Defrost
To defrost food (vegeta‐
bles and fruit). The de‐
frosting time depends on
the amount and size of
the frozen food.
Moist Fan
Baking
This function is designed
to save energy during
cooking. When you use
this function, the temper‐
ature in the cavity may
differ from the set tem‐
perature. The residual
heat is used. The heating
power may be reduced.
For more information re‐
fer to "Daily Use" chap‐
ter, Notes on: Moist Fan
Baking.
Oven func‐
tion
Application
Grill
To grill thin pieces of food
and to toast bread.
Turbo Grilling
To roast large meat joints
or poultry with bones on
one shelf position. To
make gratins and to
brown.
Pyrolysis
To turn on the pyrolytic
cleaning of the oven. This
function burns off residu‐
al dirt in the oven.
The lamp may turn off
automatically at a
temperature below 60 °C
during some oven functions.
6.3 Notes on: Moist Fan
Baking
This function was used to comply with
the energy efficiency class and
ecodesign requirements according to EU
65/2014 and EU 66/2014. Tests
according to EN 60350-1.
The oven door should be closed during
cooking so that the function is not
interrupted and the oven operates with
the highest energy efficiency possible.
When you use this function the lamp
automatically turns off after 30 sec.
For the cooking instructions
refer to "Hints and tips"
chapter, Moist Fan Baking.
For general energy saving
recommendations refer to
"Energy Efficiency" chapter,
Energy Saving.
www.aeg.com10

6.4 How to set: Heating
function
Step 1 Turn the knob for the heating
functions to select a heating
function.
Step 2 Turn the control knob to select
the temperature.
The lamp turns on when the
oven operates.
Step 3 Turn the knob for the heating
functions to the off position to
turn off the oven.
6.5 Setting the function: True
Fan Cooking PLUS
This function increases humidity during cooking.
WARNING!
Risk of burns and damage to the appliance.
Step 1 Make sure that the oven is cold.
Step 2 Fill the cavity embossment with
tap water.
The maximum capacity of
the cavity embossment is 250
ml. Do not refill the cavity em‐
bossment during cooking or
when the oven is hot.
Step 3 Set the function: .
Press: . The indicator turns on. It works only with the function: True Fan
Cooking PLUS.
Step 4 Turn the control knob for the temperature to set temperature.
Step 5 Preheat the empty oven for 10 min to create humidity.
Step 6 Put food in the oven.
Refer to "Hints and tips" chapter. Do not open the oven door during cooking.
Step 7 Turn the knob for the heating functions to the off position to turn off the oven.
- press to turn off the oven. The indicator turns off.
Step 8 After the function ends, carefully open the door. Released humidity can cause
burns.
Step 9 Make sure that the oven is cold. Remove the remaining water from the cavity
embossment.
6.6 Fast Heat Up
The fast heat up decreases the heat up
time.
Do not put food in the oven
when the Fast heat up
operates.
1. Turn the knob for the oven functions
to set the fast heat up.
ENGLISH 11

2. Turn the knob for the temperature to
set the temperature.
The signal sounds when the oven is at
the set temperature.
3. Set an oven function.
6.7 Heat-up indicator
When the oven function operates, the
bars in the display appear one by one
when the temperature in the oven
increases, and disappear when it
decreases.
7. CLOCK FUNCTIONS
7.1 Clock functions table
Clock function Application
Time of Day
To show or change the time of day. You can change
the time of day only when the oven is off.
Duration
To set the length of cooking. Use only when a heating
function is set.
End Time
To set the oven turn-off time. Use only when a heating
function is set.
Time Delay
Combination of functions: Duration, End Time.
Minute Minder
To set a countdown time. This function has no effect on
the operation of the oven.
Minute Minder - can be set at any time, also if the oven
is off.
7.2 How to set: Time of day
After the first connection to the mains,
wait until the display shows: hr, 12:00.
12 - flashes.
Step 1 Turn the knob for the temperature to set the hour.
Step 2 - press to confirm.
The display shows the set hour and: min. 00 - flashes.
Step 3 Turn the knob for the temperature to set the minutes.
Step 4 - press to confirm.
The display shows the set time.
- press repeatedly to change the time of day. - flashes in the display.
www.aeg.com12

7.3 How to set function:
Duration
Step 1 Set a heating function.
Step 2 - press repeatedly. - starts to flash.
Step 3 Turn the control knob to set the minutes. - press to confirm.
Step 4 Turn the knob for the temperature to set the hour. - press to confirm.
When the set time ends the signal sounds for 2 min. Time setting flashes in
the display. The oven turns off automatically.
Step 5 Press any button to stop the signal.
Step 6 Turn the knob for the heating functions to the off position.
7.4 How to set function: End
Time
Step 1 Set a heating function.
Step 2 - press repeatedly. - starts to flash.
Step 3 Turn the knob for the temperature to set the hour. - press to confirm.
Step 4 Turn the knob for the temperature to set the minutes. - press to confirm.
At the set end time the signal sounds for 2 min. The time setting flashes in the
display. The oven turns off automatically.
Step 5 Press any button to stop the signal.
Step 6 Turn the knob for the heating functions to the off position.
7.5 How to set function: Time
Delay
Step 1 Set a heating function.
Step 2 - press repeatedly. - starts to flash.
Step 3 Turn the knob for the temperature to set the minutes for the function: Duration.
Press: .
Step 4 Turn the knob for the temperature to set the hour for the function: Duration.
Press: .
The display shows: .
ENGLISH 13

Step 5 Turn the knob for the temperature to set the hour for the function: End Time.
Press: .
Step 6 Turn the knob for the temperature to set the minutes for the function: End
Time.
Press: .
The display shows: the set temperature, , .
Oven turns on automatically later on, works for the set Duration time and
stops at the set End Time.
At the set End Time the signal sounds for 2 min. The time setting flashes in
the display. The oven turns off.
Step 7 Press any button to stop the signal.
Step 8 Turn the knob for the heating functions to the off position.
7.6 How to set function:
Minute Minder
Minute minder can be both set when the
oven is turned on and off.
Step 1
- press repeatedly. , 00 - flash.
Step 2 Turn the knob for the temperature to set the seconds and then the minutes.
When the time you set is longer than 60 min, hr flashes in the display.
Step 3 Set the hours.
Minute Minder - starts automatically after 5 sec.
After 90% of the set time the signal sounds.
Step 4 When the set time ends the signal sounds for 2 min. 00:00, - flash in the
display. Press any button to stop the signal.
8. USING THE ACCESSORIES
WARNING!
Refer to Safety chapters.
8.1 Core temperature sensor
The core temperature sensor measures
temperature inside the food. When the
food is at the set temperature, the oven
turns off.
There are two temperatures to be set:
• the oven temperature (minimum
120 °C),
• the food core temperature.
CAUTION!
Use only the core
temperature sensor supplied
and the original replacement
parts.
For the best cooking results:
• Ingredients should be at room
temperature.
• Core temperature sensor cannot be
used for liquid dishes.
• During cooking the core temperature
sensor must remain in the dish and
the plug in the socket.
www.aeg.com14

• Use recommended food core
temperature settings. Refer to "Hints
and tips" chapter.
Every time you put the core
temperature sensor in the
socket, you need to set the
core temperature time again.
You cannot select the
duration and end time.
The oven calculates the
approximate cooking time, it
may change during cooking.
Food categories: meat,
poultry and fish
1. Set the oven function and
temperature.
2. Insert the tip of the core temperature
sensor into the centre of meat or fish,
in the thickest part if possible. Make
sure that at least 3/4 of the core
temperature sensor is inside of the
dish.
3. Put the plug of the core temperature
sensor into the socket located in the
front frame of the appliance.
The display shows the core temperature
sensor symbol.
When you use the core temperature
sensor for the first time, the default core
temperature is 60 °C.
While flashes, you can use the knob
for the temperature to change the default
core temperature. The display shows the
symbol of the core temperature sensor
and the default core temperature.
4. Press to save the new core
temperature, or wait 10 seconds for
the setting to be saved automatically.
The new default core temperature is
displayed during the next use of the core
temperature sensor.
When the food is at the set core
temperature, the default core
temperature and flashes. An
acoustic signal sounds for 2 minutes.
5. Press any button or open the oven
door to stop the acoustic signal.
6. Remove the core temperature sensor
plug from the socket and remove the
dish from the appliance.
WARNING!
There is a risk of burns as
the core temperature sensor
becomes hot. Be careful
when you unplug it and
remove it from the dish.
Food category: casserole
1. Set the oven function and
temperature.
2. Place half of the ingredients in a
baking dish.
3. Insert the tip of the core temperature
sensor exactly in the centre of the
casserole.The core temperature
sensor should be stabilized in one
place during baking. Use a solid
ingredient to achieve that. Use the
rim of the baking dish to support the
silicone handle of the core
temperature sensor. The tip of the
core temperature sensor should not
touch the bottom of a baking dish.
ENGLISH 15

4. Cover the core temperature sensor
with the remaining ingredients.
5. Put the plug of the core temperature
sensor into the socket located in the
front frame of the appliance.
The display shows the core temperature
sensor symbol.
6. Press to save the new core
temperature, or wait 10 seconds for
the setting to be saved automatically.
The new default core temperature is
displayed during the next use of the core
temperature sensor.
When the food is at the set core
temperature, the default core
temperature and flashes. An
acoustic signal sounds for 2 minutes.
7. Press any button or open the oven
door to stop the acoustic signal.
8. Remove the core temperature sensor
plug from the socket and remove the
dish from the appliance.
WARNING!
There is a risk of burns as
the core temperature sensor
becomes hot. Be careful
when you unplug it and
remove it from the dish.
Changing the temperature
during the cooking
You can change the temperature at any
time during the cooking:
1. Press :
• one time - the display shows the
set core temperature which
changes every 10 seconds to the
current core temperature.
• two times - the display shows the
current oven temperature which
changes every 10 seconds to the
set oven temperature.
• three times - the display shows
the set oven temperature.
2. Use the knob for the temperature to
change the temperature.
8.2 Inserting accessories
A small indentation at the top increases
safety. The indentations are also anti-tip
devices. The high rim around the shelf
prevents cookware from slipping of the
shelf.
www.aeg.com16

Wire shelf:
Push the shelf between the guide bars
of the shelf support.
Baking tray / Deep pan:
Push the baking tray / deep pan be‐
tween the guide bars of the shelf sup‐
port.
Wire shelf and baking tray / deep pan
together:
Push the baking tray / deep pan be‐
tween the guide bars of the shelf sup‐
port and the wire shelf on the guide bars
above.
9. ADDITIONAL FUNCTIONS
9.1 Using Child lock
When the Child lock is on the oven
cannot be turned on accidentally.
1. Ensure the knob for the heating
functions is in the off position.
2. , - press and hold at the same
time for 2 seconds.
The signal sounds. SAFE , - appear
on the display. The door is locked.
- the symbol appear on
the display also when
Pyrolysis function operates.
To turn off the Child Lock, repeat the
step 2.
9.2 Using function lock
You can turn on the Function Lock
function only when the oven works.
When the Function lock is on the
temperature and time settings cannot be
changed accidentally.
1. Select an oven function and set it
according your preferences.
2. Press and hold and at the
same time for 2 seconds.
ENGLISH 17

The signal sounds. Loc appears on the
display for 5 seconds.
Loc appears on the display
when you turn the knob for
the temperature or press any
button when the Function
lock is on.
When you turn the knob for the oven
functions, the oven stops.
When you turn off the oven while the
Function Lock is on, the Function Lock
switches automatically to the Child Lock.
Refer to "Additional functions" chapter,
Using the Child Lock.
If the Pyrolysis function
operates, the door is locked
and appears on the
display.
To turn off the Function Lock, repeat step
2.
9.3 Residual heat indicator
When you turn off the oven, the display
shows the residual heat indicator if
the temperature in the oven is more than
40 °C.Turn the knob for the temperature
left or right to check the oven
temperature.
9.4 Automatic switch-off
For safety reasons the oven turns off
after some time, if a heating function
works and you do not change any
settings.
(°C) (h)
30 - 115 12.5
120 - 195 8.5
200 - 245 5.5
250 - maximum 3
After an automatic switch-off, press any
button to operate the oven again.
The Automatic switch-off does not work
with the functions: Light, Food Sensor,
Duration, End Time.
9.5 Cooling fan
When the oven operates, the cooling fan
turns on automatically to keep the
surfaces of the oven cool. If you turn off
the oven, the cooling fan can continue to
operate until the oven cools down.
10. HINTS AND TIPS
WARNING!
Refer to Safety chapters.
10.1 Cooking recommendations
The temperature and cooking times in the tables are guidelines only. They depend on the
recipes and the quality and quantity of the ingredients used.
Your oven may bake or roast differently to the oven you had before. The tables below
show recommended settings for temperature, cooking time and shelf position for specific
types of the food.
If you cannot find the settings for a special recipe, look for the similar one.
10.2 Inner side of the door
On the inner side of the door you can
find:
• the numbers of the shelf positions.
• information about the oven functions,
recommended shelf positions and
temperatures for dishes.
www.aeg.com18

10.3 True Fan Cooking PLUS
Use the second shelf position.
Use 150 ml of water.
Use a baking tray.
CAKES /
PASTRIES /
BREADS
(°C) (min)
Cookies /
Scones /
Croissants
150 - 180 10 - 20
Focaccia 200 - 210 10 - 20
Pizza 230 10 - 20
Bread rolls 200 20 - 25
Bread 180 35 - 40
Plum cake /
Apple pie /
Cinnamon
rolls, baked in
a cake mould
160 - 180 30 - 60
Use 200 ml of water.
FROZEN READY
MEALS (°C) (min)
Pizza 200 -
210
10 -
20
Croissants 170 -
180
15 -
25
Lasagne 180 -
200
35 -
50
Use 100 ml of water.
Set the temperature to 110 °C.
FOOD REGEN‐
ERATION (min)
Bread rolls 10 - 20
FOOD REGEN‐
ERATION (min)
Bread 15 - 25
Focaccia 15 - 25
Meat 15 - 25
Pasta 15 - 25
Pizza 15 - 25
Rice 15 - 25
Vegetables 15 - 25
Use 200 ml of water.
Use a glass baking dish.
ROASTING (°C) (min)
Roast beef 200 50 - 60
Chicken 210 60 - 80
Roast pork 180 65 - 80
10.4 Baking
For the first baking, use the lower
temperature.
You can extend the baking time by 10 –
15 minutes if you bake cakes on more
than one shelf position.
Cakes and pastries at different heights
do not always brown equally. There is no
need to change the temperature setting if
an unequal browning occurs. The
differences equalize during baking.
Trays in the oven can distort during
baking. When the trays are cold again,
the distortions disappear.
ENGLISH 19

10.5 Tips on baking
Baking results Possible cause Remedy
The bottom of the cake
is not baked sufficiently.
The shelf position is incor‐
rect.
Put the cake on a lower shelf.
The cake sinks and be‐
comes soggy or streaky.
The oven temperature is too
high.
Next time set slightly lower oven
temperature.
The oven temperature is too
high and the baking time is
too short.
Next time set a longer baking time
and lower oven temperature.
The cake is too dry. The oven temperature is too
low.
Next time set higher oven temper‐
ature.
The baking time is too long. Next time set shorter baking time.
The cake bakes un‐
evenly.
The oven temperature is too
high and the baking time is
too short.
Next time set a longer baking time
and lower oven temperature.
The cake batter is not even‐
ly distributed.
Next time spread the cake batter
evenly on the baking tray.
The cake is not ready in
the baking time speci‐
fied in a recipe.
The oven temperature is too
low.
Next time set a slightly higher
oven temperature.
10.6 Baking on one shelf level
BAKING IN TINS
(°C)
(min)
Flan base -
short pastry,
preheat the
empty oven
True Fan Cooking 170 - 180 10 - 25 2
Flan base -
sponge cake
mixture
True Fan Cooking 150 - 170 20 - 25 2
Ring cake /
Brioche
True Fan Cooking 150 - 160 50 - 70 1
Madeira cake /
Fruit cakes
True Fan Cooking 140 - 160 70 - 90 1
Cheesecake Conventional Cooking 170 - 190 60 - 90 1
www.aeg.com20
