AEG COMPETENCE E2191-4-A Operation manual

COMPETENCE E2191-4
Built-In Electric Oven
User information

2
Dear Customer,
Please read this user information carefully and keep it to refer to later.
Please pass the user information on to any future owner of the appli-
ance.
The following symbols are used in the text:
1Safety instructions
Warning! Information that affects your personal safety.
Important! Information that prevents damage to the appliance.
3Useful tips and hints
2Environmental information

3
Contents
Operating Instructions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Safety instructions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Description of the Appliance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
General Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Control Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Oven Features. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Oven Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Before using for the first time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Setting and changing the current time. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Initial Cleaning. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Using the Hob . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Setting the heat setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Operating the Oven . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Switching the Oven On and Off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Oven Functions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Inserting the shelf and roasting pan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Attaching/Removing the Grill Pan Handle . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Clock Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Switching Off the Time Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Usage, Tables and Tips . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Cooking Table. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Baking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Baking Tables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Table: Desserts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Frozen Ready Meals Table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Roasting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Table: Meat, roasting, casseroles. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Table: Roasting, casseroles, au gratin. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Grill sizes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Grilling table. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Defrosting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Defrosting table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Making Preserves . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

4
Cleaning and care . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Outside of the appliance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Oven interior . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Shelf Support Rails . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Oven Lighting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Oven Roof. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Oven Door. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Oven Door Glass. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
What to do if … . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Electrical Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Installation Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Safety information for the installer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Warranty conditions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
Service and Spare Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55

5
Operating Instructions
1Safety instructions
5This appliance conforms with the following EU Directives:
–73/23/EEC dated 19.02.1973 Low Voltage Directive
–89/336/EEC dated 03.05.1989 EMC Directive inclusive of Amending
Directive 92/31/EEC
–93/68/EEC dated 22.07.1993 CE Marking Directive
Electrical safety
•This appliance must be connected by a qualified electrician only.
•In the event of a fault or damage to the appliance: take the fuses out
or switch off.
•Repairs to the appliance must only be carried out by qualified
service engineers. Considerable danger may result from improper re-
pairs. If repairs become necessary, please contact your local Service
Force Centre.
Child Safety
•Never leave children unsupervised when the appliance is in use.
Safety whilst Using
•This appliance is intended to be used for cooking, roasting and baking
food in the home.
•Take care when connecting electric appliances to sockets nearby. Do
not allow connecting leads to come into contact with or to catch be-
neath the hot oven door.
•Warning: Risk of burns! The interior of the oven becomes hot dur-
ing use.
•Using ingredients containing alcohol in the oven may create an alco-
hol-air mixture that is easily ignited. In this case, open the door care-
fully. Do not have embers, sparks or naked flames in the vicinity when
opening the door.

6
How to avoid damage to the appliance
•Do not line the oven with aluminium foil and do not place baking
trays, pots, etc. on the oven floor, as the heat that builds up will dam-
age the oven enamel.
•Fruit juices dripping from the baking tray will leave stains, which you
will not be able to remove. For very moist cakes, use a deep tray.
•Do not put any strain on the oven door when open.
•Never pour water directly into the oven when it is hot. This could
cause damage to the enamel and discoloration.
•Rough handling, especially around the edges of the front panel, can
cause the glass to break.
•Do not store any flammable materials inside the oven. These could ig-
nite when the oven is switched on.
•Do not store any moist foods inside the oven. This could damage the
oven enamel.
Disposal
2Packaging material
The packaging materials are environmentally friendly and can be recy-
cled. The plastic components are identified by markings, e.g. >PE<,
>PS<, etc. Please dispose of the packaging materials in the appropriate
container at your local waste disposal facilities.
2Old appliance
The symbol Won the product or on its packaging indicates that this
product may not be treated as household waste. Instead it shall be
handed over to the applicable collection point for the recycling of elec-
trical and electronic equipment. By ensuring this product is disposed of
correctly, you will help prevent potential negative consequences for the
environment and human health, which could otherwise be caused by
inappropriate waste handling of this product. For more detailed infor-
mation about recycling of this product, please contact your local city
office, your household waste disposal service or the shop where you
purchased the product.
1Warning: Before disposing of old appliances please make them inoper-
able so that they cannot be a source of danger.
To do this, disconnect the appliance from the mains supply and re-
move the mains cable from the appliance.

7
Description of the Appliance
General Overview
Control Panel
Full glass
door
Control panel
Door
handle
Oven Power Indicator Temperature Pilot Light
Oven Functions Temperature selector
Control Knobs
Control Knobs

8
Oven Features
Oven steam outlet
The steam from the oven is
chanelled directly upwards via the
duct at the back of the cooking sur-
face.
Top heat and heating elements
Oven lighting
Fan heating element
Fan
Bottom heat
Shelf positions
Oven shelf runners, removable

9
Oven Accessories
Shelf
For dishes, cake tins, items for
roasting and grilling.
Baking Shelf
For baking or for collecting fat
Grill pan with handle
Support for the grill tray as a col-
lecting vessel for fat
Grill tray
Insert for the grill pan for grilling
smaller amounts of food

10
Before using for the first time
Setting and changing the current time
3The oven only operates when the time has been set.
When the appliance has been con-
nected to the electrical supply or
when there has been a power cut,
the function indicator Time
flashes automatically.
1. To change the time that has already
been set, press the Selection but-
ton repeatedly, until the function
indicator Time flashes.
2. Set the current time using the or
button.
After approx. 5 seconds, the flash-
ing stops and the clock displays the
time of day set.
The appliance is now ready to use.
3The time can only be changed if
neither of the automatic functions
(Cook time or End time ) have
been set.

11
Initial Cleaning
Before using the oven for the first time you should clean it thoroughly.
1Caution: Do not use any caustic, abrasive cleaners! The surface could
be damaged.
3To clean any metal front panels use commercially available cleaning
agents.
1. Turn the oven function switch to oven lighting .
2. Remove all accessories and the shelf support rails and wash them with
warm water and washing up liquid.
3. Then wash out the oven with warm water and washing-up liquid and
dry.
4. Wipe the front of the appliance with a damp cloth.

12
Using the Hob
3Also refer to the operating instructions for your built-in hob. It con-
tains important information on ovenware, operation, cleaning and care.
Heat settings
•You may select the heat settings within the range of settings 1-9.
•Intermediate positions may be selected between settings 2 and 7.
1 = lowest heat setting
9 = highest heat setting
2Switch the cooking zone off approx. 5-10 minutes before cooking is
finished to make use of the residual heat. This saves electricity.
3The cooker has retractable control knobs.
Press the control knob to use it. The control knob will then pop up.
Control Knobs
front left rear left rear right front right

13
Setting the heat setting
1. Turn the relevant control knob for
the ring you require to the desired
power setting.
2. To end the cooking process, turn back
to the Off position.
3It remains lit after the ring is turned
off if there is any residual heat in the
ring.

14
Operating the Oven
3The oven is equipped with retractable buttons for “Oven functions”
and “Temperature selection”. To use, press the relevant button.
The button then pops out.
Switching the Oven On and Off
1. Turn the oven functions control knob to the desired function.
2. Turn the temperature control knob to the desired temperature.
The power indicator is lit while the oven is on.
The temperature power indicator is lit while the oven is heating up.
3. To turn the oven off, turn the oven functions and temperature control
knob back to the OFF position.
3Cooling fan
The fan switches on automatically in order to keep the appliance’s sur-
faces cool. When the oven is switched off, the fan continues to run to
cool the appliance down, then switches itself off automatically.
Temperature Pilot Light
Oven Functions Temperature selector
Oven Power Indicator

15
Oven Functions
The oven has the following functions:
Oven function Use Heating element/
fan
Oven Light With this function you can light
up the oven interior, e.g. for
cleaning.
---
Pizza Setting For baking on up to two oven
levels.
Set the oven temperatures 20-40
°C lower than when using Con-
ventional.
Top heat, bottom-
heat, fan
Ventitherm ® Fan
Operated Cooking
For baking on up to three oven
shelves at the same time.
Set the oven temperatures 20-40
°C lower than when using Con-
ventional.
Ring element, fan
Conventional
Cooking
For baking and roasting on one
oven level.
Top heat, bottom
heat
Base Heat Finish-
ing
For baking cakes with crispy or
crusty bases.
Bottom heat
Fan Controlled
Defrosting
For defrosting e. g. gateaux and
flans, butter, bread, fruit or other
frozen foods.
Fan
Single Economy
Grill
For grilling flat food items ar-
ranged in the middle of the grill
and for toasting.
Grill
Full Width Dual
Grill
For grilling flat food items in
large quantities and for toasting.
Grill, top heat
Rotitherm Roast-
ing
For roasting larger joints of meat
or poultry on one oven shelf.
The function is also suitable for
browning and gratinating.
Grill, top heat, fan

16
Inserting the shelf and roasting pan
3Anti-tip device
All insertable components have a small curved indentation on their left
and right edges. This indentation serves as an anti-tip device and must
always point towards the back of the oven.
Inserting roasting pan:
The anti-tip device must point to-
wards the back of the oven.
Inserting the shelf:
Insert the shelf so that the two
guide bars point upwards. The anti-
tip device must point downwards
and be at the back of the oven inte-
rior.
Inserting the shelf and the roast-
ing pan:
When using the shelf and the roast-
ing pan together, insert the shelf’s
anti-tip device exactly into the in-
dentations in the tray.

17
Attaching/Removing the Grill Pan Handle
The handle is particularly useful for removing the grill pan and tray
more easily from the hot oven.
Attaching the handle
Insert the handle at an angle from
above into the recess in the side of
the grill pan (1) press and hold the
release button, lift the handle gen-
tly and then lower it (2) let go of
the release button.
1Warning: Risk of burning!
Important: Check that the handle is
securely attached!
Removing the handle
Press the release button on the top
of the handle (1) and lift up the
handle (2) to remove it.
1Important: Never leave the handle
in the heated oven! Overheating
can cause the handle to deform or
break, and may cause an injury.

18
Clock Functions
Countdown
To set a countdown. A signal sounds after the time has elapsed.
This function does not affect the operation of the oven.
Cook time
To set how long the oven is to be in use.
End time
To set when the oven is to switch off again.
Time
To set, change or check the time
(See also section “Before Using for the First Time”).
Selector Button Button
Button
Time display Function IndicatorsFunction Indicators

19
3How to use the clock functions
•When a function has been selected, the corresponding function indi-
cator flashes for approx. 5 seconds. During this time the desired times
can be set using the or button.
•When the desired time has been set, the function indicator flashes for
approx. another 5 seconds. After that the function indicator is then
lit. The set time begins to run.
•Press any of the buttons to stop the acoustic signal.
•The desired oven function and temperature can be selected before or
after the clock functions Cook time and End time are set.
•When the cooking time has ended, turn the oven function and tem-
perature dial back to the OFF position.
2Switching Off the Time Display
By switching off the time display you can save energy.
Switching off the time display
Hold down any two buttons until the display becomes dark
(approx. 10 seconds).
Switching on the time display
Hold down any two buttons until the time reappears in the display (ap-
prox. 10 seconds).
3The display can only be switched off if none of the clock functions
Cook time End time or Countdown are in use.

20
Countdown
1. Press Selection button repeated-
ly, until the function indicator
Countdown flashes.
2. Using the or button, set the
required Countdown (max. 2 hours
30 minutes).
After approx. 5 seconds, the display
shows the remaining time.
The function indicator
Countdown will light up.
When the time has elapsed, the
function indicator flashes and an
acoustic signal sounds for
2minutes.
Press any button to switch off the
signal.
This manual suits for next models
1
Table of contents
Other AEG Oven manuals

AEG
AEG Competence 312 B User manual

AEG
AEG B 601 DG User manual

AEG
AEG Competence 5150 B User manual

AEG
AEG PREFERENCE B 81005 User manual

AEG
AEG BXP6000B User manual

AEG
AEG BEB351010M User manual

AEG
AEG BPS551020M User manual

AEG
AEG BP5023001 User manual

AEG
AEG KEK442910M User manual

AEG
AEG COMPETENCE KB9820E User manual
Popular Oven manuals by other brands

Tricity Bendix
Tricity Bendix BD 985 Operating and installation instructions

Teka
Teka HKL-840 Simplified instructions for use

Bosch
Bosch HBG7542 1 Series User manual and installation instructions

Meireles
Meireles MF 9800 X instruction manual

Caple
Caple C2150SS/WH instruction manual

Gaggenau
Gaggenau BO 270 instruction manual
