AEG DE4003020 User manual

DE4003020 EN User manual

CONTENTS
1. SAFETY INFORMATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
2. SAFETY INSTRUCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
3. PRODUCT DESCRIPTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
4. BEFORE FIRST USE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
5. DAILY USE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
6. CLOCK FUNCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
7. USING THE ACCESSORIES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
8. HELPFUL HINTS AND TIPS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
9. CARE AND CLEANING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
10. WHAT TO DO IF… . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
11. INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
12. GREAT BRITAIN & IRELAND - GUARANTEE/CUSTOMER SERVICE . . . . . . . . . . . . . . . . . 23
13. EUROPEAN GUARANTEE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
FOR PERFECT RESULTS
Thank you for choosing this AEG product. We have created it to give you impeccable
performance for many years, with innovative technologies that help make life simpler –
features you might not find on ordinary appliances. Please spend a few minutes reading to get
the very best from it.
Visit our website for:
Get usage advice, brochures, trouble shooter, service information:
www.aeg.com
Register your product for better service:
www.aeg.com/productregistration
Buy Accessories, Consumables and Original spare parts for your appliance:
www.aeg.com/shop
CUSTOMER CARE AND SERVICE
We recommend the use of original spare parts.
When contacting Service, ensure that you have the following data available.
The information can be found on the rating plate. Model, PNC, Serial Number.
Warning / Caution-Safety information
General information and tips
Environmental information
Subject to change without notice.
2www.aeg.com

1. SAFETY INFORMATION
Before the installation and use of the appliance, careful-
ly read the supplied instructions. The manufacturer is
not responsible if an incorrect installation and use cau-
ses injuries and damages. Always keep the instructions
with the appliance for future reference.
1.1 Children and vulnerable people safety
WARNING!
Risk of suffocation, injury or permanent disability.
• This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they are supervised by an adult or a
person who is responsible for their safety.
• Do not let children play with the appliance.
• Keep all packaging away from children.
• Keep children and pets away from the appliance
when it operates or when it cools down. Accessible
parts are hot.
• If the appliance has a child safety device, we recom-
mend that you activate it.
• Cleaning and user maintenance shall not be made by
children without supervision.
1.2 General Safety
• Only a qualified person must install this appliance
and replace the cable.
• Internally the appliance becomes hot when in opera-
tion. Do not touch the heating elements that are in
the appliance. Always use oven gloves to remove or
put in accessories or ovenware.
• Do not use a steam cleaner to clean the appliance.
• Before maintenance cut the power supply.
ENGLISH 3

• Do not use harsh abrasive cleaners or sharp metal
scrapers to clean the glass door since they can
scratch the surface, which may result in shattering of
the glass.
• To remove the shelf supports first pull the front of the
shelf support and then the rear end away from the
side walls. Install the shelf supports in the opposite
sequence.
• Ensure that the appliance is switched off before re-
placing the lamp to avoid the possibility of electric
shock.
2. SAFETY INSTRUCTIONS
2.1 Installation
WARNING!
Only a qualified person must in-
stall this appliance.
• Remove all the packaging.
• Do not install or use a damaged appli-
ance.
• Obey the installation instruction sup-
plied with the appliance.
• Always be careful when you move the
appliance because it is heavy. Always
wear safety gloves.
• Do not pull the appliance by the han-
dle.
• Keep the minimum distance from the
other appliances and units.
• Make sure that the appliance is instal-
led below and adjacent safe struc-
tures.
• The sides of the appliance must stay
adjacent to appliances or to units with
the same height.
Electrical connection
WARNING!
Risk of fire and electrical shock.
• All electrical connections should be
made by a qualified electrician.
• The appliance must be earthed.
• Make sure that the electrical informa-
tion on the rating plate agrees with
the power supply. If not, contact an
electrician.
• Always use a correctly installed shock-
proof socket.
• Do not use multi-plug adapters and
extension cables.
• Make sure not to cause damage to the
mains plug and to the mains cable.
Contact the Service or an electrician to
change a damaged mains cable.
• Do not let mains cables to come in
touch with the appliance door, spe-
cially when the door is hot.
• The shock protection of live and insu-
lated parts must be fastened in such a
way that it cannot be removed without
tools.
• Connect the mains plug to the mains
socket only at the end of the installa-
tion. Make sure that there is access to
the mains plug after the installation.
• If the mains socket is loose, do not
connect the mains plug.
• Do not pull the mains cable to discon-
nect the appliance. Always pull the
mains plug.
4www.aeg.com

• Use only correct isolation devices: line
protecting cut-outs, fuses (screw type
fuses removed from the holder), earth
leakage trips and contactors.
• The electrical installation must have an
isolation device which lets you discon-
nect the appliance from the mains at
all poles. The isolation device must
have a contact opening width of mini-
mum 3 mm.
2.2 Use
WARNING!
Risk of injury, burns or electric
shock or explosion.
• Use this appliance in a household en-
vironment.
• Do not change the specification of this
appliance.
• Make sure that the ventilation open-
ings are not blocked.
• Do not let the appliance stay unatten-
ded during operation.
• Deactivate the appliance after each
use.
• Be careful, when you open the appli-
ance door while the appliance is in op-
eration. Hot air can release.
• Do not operate the appliance with wet
hands or when it has contact with wa-
ter.
• Do not apply pressure on the open
door.
• Do not use the appliance as a work
surface or as a storage surface.
• Always keep the appliance door
closed when the appliance is in opera-
tion.
• Open the appliance door carefully.
The use of ingredients with alcohol
can cause a mixture of alcohol and air.
• Do not let sparks or open flames to
come in contact with the appliance
when you open the door.
• Do not put flammable products or
items that are wet with flammable
products in, near or on the appliance.
WARNING!
Risk of damage to the appliance.
• To prevent damage or discoloration to
the enamel:
– do not put ovenware or other ob-
jects in the appliance directly on the
bottom.
– do not put aluminium foil directly on
the bottom of the appliance.
– do not put water directly into the hot
appliance.
– do not keep moist dishes and food
in the appliance after you finish the
cooking.
– be careful when you remove or in-
stall the accessories.
• Discoloration of the enamel has no ef-
fect on the performance of the appli-
ance. It is not a defect in the sense of
the warranty law.
• Use a deep pan for moist cakes. Fruit
juices cause stains that can be perma-
nent.
2.3 Care and Cleaning
WARNING!
Risk of injury, fire or damage to
the appliance.
• Before maintenance, deactivate the
appliance and disconnect the mains
plug from the mains socket.
• Make sure the appliance is cold. There
is the risk that the glass panels can
break.
• Replace immediately the door glass
panels when they are damaged. Con-
tact the Service.
• Be careful when you remove the door
from the appliance. The door is heavy!
• Clean regularly the appliance to pre-
vent the deterioration of the surface
material.
• Remaining fat or food in the appliance
can cause fire.
• Clean the appliance with a moist soft
cloth. Only use neutral detergents. Do
not use abrasive products, abrasive
cleaning pads, solvents or metal ob-
jects.
• If you use an oven spray, obey the
safety instructions on the packaging.
• Do not clean the catalytic enamel (if
applicable) with any kind of detergent.
ENGLISH 5

2.4 Internal light
• The type of light bulb or halogen lamp
used for this appliance, is only for
household appliances. Do not use it
for house lighting.
WARNING!
Risk of electrical shock.
• Before replacing the lamp, disconnect
the appliance from the power supply.
• Only use lamps with the same specifi-
cations.
2.5 Disposal
WARNING!
Risk of injury or suffocation.
• Disconnect the appliance from the
mains supply.
• Cut off the mains cable and discard it.
• Remove the door catch to prevent
children and pets to get closed in the
appliance.
3. PRODUCT DESCRIPTION
3.1 General overview
1
2
3
4
5
6
8
9
11
11
1 3 5 6 742 24
1
2
3
4
5
6
10
9
1Knob for the top oven functions
2Power indicator
3Knob for the top oven temperature
4Temperature indicator
5Electronic programmer
6Knob for the main oven functions
7Knob for the main oven temperature
8Heating element
9Oven lamp
10 Fan and rear wall heating element
11 Shelf positions
3.2 Oven accessories
•Oven shelf
For cookware, cake tins, roasts.
•The roasting pan grid
To put in the deep roasting pan.
•Deep roasting pan
To bake and roast or as pan to collect
fat.
4. BEFORE FIRST USE
WARNING!
Refer to the Safety chapters.
4.1 Initial Cleaning
• Remove all parts from the appliance.
• Clean the appliance before first use.
6www.aeg.com

Refer to chapter "Care and
Cleaning".
4.2 Setting the time
You must set the time before you
operate the oven.
When you connect the appliance to the
electrical supply or after a power cut, the
indicator for the Time function flashes.
Press the +or -button to set the correct
time.
After approximately five seconds, the
flashing stops and the display shows the
time of day you set.
When you change the time, you
must not set the Duration or
End function at the same
time.
To use the appliance, push the control
knob. The control knob comes out.
4.3 Preheating
Preheat the empty appliance to burn off
the remaining grease.
Preheat the two ovens. Heat up one
oven at a time.
Set the functions listed below, if applica-
ble.
1. Set the function and the maxi-
mum temperature.
2. Let the appliance operate for one
hour.
3. Set the function and the maxi-
mum temperature.
4. Let the appliance operate for ten mi-
nutes.
5. Set the function and the maxi-
mum temperature.
6. Let the appliance operate for ten mi-
nutes.
Accessories can become hotter than
usually. The appliance can emit an odour
and smoke. This is normal. Make sure
that the airflow is sufficient.
5. DAILY USE
WARNING!
Refer to the Safety chapters.
5.1 Activating and
deactivating the top oven
1. Turn the knob for the top oven func-
tions to an oven function.
2. Turn the knob for the top oven tem-
perature to a temperature.
The power indicator comes on while
the appliance operates.
The temperature indicator comes on
while the temperature in the appli-
ance increases.
3. To deactivate the appliance, turn the
knob for the top oven functions and
the knob for the top oven tempera-
ture to the Off position.
5.2 Activating and
deactivating the main oven
1. Turn the knob for the main oven
functions to an oven function.
2. Turn the knob for the main oven
temperature to a temperature.
The power indicator comes on while
the appliance operates.
The temperature indicator comes on
while the temperature in the appli-
ance increases.
3. To deactivate the appliance, turn the
knob for the main oven functions
and the knob for the main oven tem-
perature to the Off position.
ENGLISH 7

5.3 Cooling fan
When the appliance operates, the cool-
ing fan switches on automatically. If you
switch off the appliance, the cooling fan
continues to operate until the appliance
cools down.
5.4 Top oven functions
Oven function Application
OFF position The appliance is OFF.
Light To light up the oven interior.
Conventional
Cooking To bake and roast on one level
Top Heat
Browning Tor brown bread, cakes and pastries and for bakes.
Base Heat Fin-
ishing To bake cakes with crispy or crusty bases and to pre- serve food.
Economy Grill To grill flat food items in small quantities in the mid-
dle of the grill. To make toasts.
Full Grill To grill flat food items in large quantities. To make
toasts.
5.5 Main oven functions
Oven function Application
OFF position The appliance is OFF.
Light To light up the oven interior.
True Fan To roast or roast and bake the food that requires the
same cooking temperature, using more than one shelf,
without flavour transference.
Fan Controlled
Defrosting To defrost frozen food.
8www.aeg.com

6. CLOCK FUNCTIONS
6.1 Electronic programmer
1 2 3
456
1Function indicators
2Time display
3Function indicators
4Button +
5Selection button
6Button -
Clock function Application
Time of day To set, change or check the time of day.
Minute Minder To set a countdown time. An acoustic signal sounds
after the time period is completed. This function has
no effect on the operation of the oven.
Duration To set how long the appliance must operate.
End To set when the appliance must be deactivated.
You can use Duration and
End at the same time to set
the time when the appliance
must be activated and then de-
activated. First set Duration ,
then End .
6.2 Setting the clock functions
1. Push the Selection button again and
again until the necessary function in-
dicator flashes.
2. To set the time for the Minute Mind-
er , Duration , or End , use
the +or -button.
The related function indicator comes
on.
When the time period is completed,
the function indicator flashes and an
acoustic signal sounds for 2 minutes.
With the functions Duration
and End , the appliance deac-
tivates automatically.
3. Push a button to stop the signal.
6.3 Cancelling the clock
functions
1. Press the Selection button again and
again until the indicator for the nec-
essary function flashes.
2. Press and hold the button "-" until
an acoustic signal sounds.
3. Release the button. The clock func-
tion goes out in some seconds.
ENGLISH 9

7. USING THE ACCESSORIES
WARNING!
Refer to the Safety chapters.
7.1 Inserting the oven accessories
The deep roasting pan and the wire shelf
have side edges. These edges and the
shape of the guide-bars are a special de-
vice to prevent the cookware from slip-
ping.
Put in the slide-in accessories so that the
double side edges are at the back of the
oven and point down to the bottom.
Push the slide-in accessories between
the guide-bars of one of the oven levels.
Installing the wire shelf and the deep
pan together
Put the wire shelf on the deep roasting
pan. Push the deep roasting pan be-
tween the guide-bars of one of the oven
levels.
7.2 Grilling set
The grilling set includes the roasting pan
grid and the deep roasting pan.
You can use the roasting pan grid in two
positions: turned up or down.
To roast larger pieces of meat or poul-
try on one level:
1. Put the roasting pan grid in the
deep roasting pan. The supports of
the roasting pan grid must point up.
2. Put the deep roasting pan in the ap-
pliance and on the necessary shelf
level.
10 www.aeg.com

To grill flat dishes in large quantities
and to toast:
1. Put the roasting pan grid in the
deep roasting pan. The supports of
the roasting pan grid must point
down.
2. Put the deep roasting pan in the ap-
pliance and on the necessary shelf
level.
8. HELPFUL HINTS AND TIPS
WARNING!
Refer to the Safety chapters.
The temperature and baking
times in the tables are guidelines
only. They depend on the rec-
ipes, quality and quantity of the
ingredients used.
CAUTION!
Use a deep baking tray for very
moist cakes. Fruit juices can
cause permanent stains on the
enamel.
8.1 Top oven
The top oven is the smaller of the two
ovens. It has 6 shelf levels. Use is to cook
smaller quantities of food. It gives espe-
cially good results when used to cook
fruitcakes, sweets and savoury flants or
quiche.
8.2 Main oven
The main oven is particularly suitable for
cooking larger quantities of food.
8.3 Baking
General instructions
• Your new oven may bake or roast dif-
ferently to the appliance you had be-
fore. Adapt your usual settings (tem-
perature, cooking times) and shelf lev-
els to the values in the tables.
• With longer baking times, the oven
can be switched off about 10 minutes
before the end of baking time, to use
the residual heat.
When you use frozen food, the trays
in the oven can twist during baking.
When the trays get cold again, the
distortion will be gone.
How to use the Baking Tables
• We recommend to use the lower tem-
perature the first time.
• If you cannot find the settings for a
special recipe, look for the one that is
almost the same.
• Baking time can be extended by 10-15
minutes, if you bake cakes on more
than one level.
• Cakes and pastries at different heights
do not always brown equally at first. If
this occurs, do not change the tem-
perature setting. The differences
equalize during the baking procedure.
ENGLISH 11

Tips on baking
Baking results Possible cause Remedy
The cake is not
browned suffi-
ciently below
Incorrect oven level Put the cake on a lower oven level
The cake sinks
(becomes soggy,
lumpy, streaky)
Oven temperature too
high Use a lower setting
The cake sinks
(becomes soggy,
lumpy, streaky)
Baking time is too
short Set a longer baking time Do not set higher temperatures
to decrease baking times
The cake sinks
(becomes soggy,
lumpy, streaky)
Too much liquid in the
mixture Use less liquid. Look at the mixing times, specially when you use
mixing machines
Cake is too dry Oven temperature too
low Set a higher oven temperature
Cake is too dry Baking time too long Set a shorter baking time
Cake does not
brown equally
Oven temperature too
high and baking time
too short
Set a lower oven temperature and
a longer baking time
Cake does not
brown equally No equal mixture Put the mixture equally on the baking tray
Cake does not
cook in the baking
time set
Temperature too low Use a slightly higher oven tem-
perature setting
8.4 Top oven
8.5 Baking
Shelf Positions are not critical but
ensure that oven shelves are
evenly spaced when more than
one is used (e.g. shelf positions 1
and 3)
Food Temperature
[°C]
Approx Cook
Time
(mins)
Shelf Position
Biscuits 170 - 190 10 - 20 1
Bread 200 - 220 30 - 35 1
Bread rolls/buns 200 - 220 10 - 15 1
Cakes:
- Small & Queen 170 - 180 18 - 25 1
- Sponges 160 - 175 20 - 30 1
12 www.aeg.com

Food Temperature
[°C]
Approx Cook
Time
(mins)
Shelf Position
- Victoria Sand-
wich 160 - 170 18 - 25 1
- Madeira 140 - 150 75 - 90 1
- Rich Fruit 140 - 150 120 - 150 1
- Gingerbread 140 - 150 75 - 90 1
- Meringues 90 - 100 150 - 180 1
- Flapjack 160 - 170 25 - 30 1
- Shortbread 130 - 150 45 - 65 1
Casseroles:
- Beef/Lamb 150 - 170 150 - 180 1
- Chicken 160 - 180 75 - 90 1
Convenience
Foods Follow manufacturer´s instructions.
Fish 170 - 190 20 - 30 1
Fish Pie (Potato
Topped) 190 - 200 20 - 30 1
Fruit Pies, Crum-
bles 190 - 200 30 - 50 1
Milk Puddings 150 - 170 90 - 120 1
Pasta Lasagne
etc. 170 - 180 40 - 50 1
Pastry:
- Choux 180 - 190 30 - 40 1
- Eclairs, Profiter-
oles 180 - 190 30 - 40 1
- Flaky/Puff Pies 210 - 220 30 - 40 1
Shortcrust:
- Mince Pies 190 - 200 15 - 20 1
- Meat Pies 190 - 210 25 - 35 1
- Quiche, Tarts,
Flans 180 - 200 25 - 50 1
Scones 220 - 230 8 - 12 1
Shepard´s Pie 190 - 200 30 - 40 1
Soufflés 180 - 190 20 - 30 1
Vegetables:
- Baked Jacket
Potatoes 180 - 190 60 - 90 1
ENGLISH 13

Food Temperature
[°C]
Approx Cook
Time
(mins)
Shelf Position
- Roast Potatoes 180 - 190 60- 90 1
Yorkshire Pud-
ding:
- Large 200 - 210 25 - 40 1
- Individual 210 - 220 15 - 25 1
Roasting Meat,
Poultry See roasting chart.
8.6 Main oven
8.7 Baking
Shelf Positions are not critical but
ensure that oven shelves are
evenly spaced when more than
one is used (e.g. shelf positions 1
and 3)
Food Temperature
[°C]
Approx Cook Time
(mins)
Biscuits 180 - 190 10 - 20
Bread 190 - 210 30 - 35
Cakes:
- Small & Queen 160 - 170 18 - 25
- Sponges 160 - 170 20 - 25
- Madeira 140 - 160 60 - 75
- Rich Fruit 130 - 140 120 - 150
- Christmas 130 - 140 180 - 270
Fish 160 - 180 20 - 30
Fruit Pies, Crumbles 170 - 180 30 - 50
Milk Puddings 140 - 160 60 - 90
Pastry:
- Choux 180 - 190 30 - 40
- Shortcrust 180 - 190 25 - 35
- Flaky 180 - 190 30 - 40 depends on size
- Puff Follow manufacturer´s instructions; Reduce the tem-
perature for Fan oven by 20°C
Plate Tarts 180 - 190 25 - 45
Quiches/Flans 170 - 180 25 - 45
Scones 210 - 230 8 - 12
14 www.aeg.com

Food Temperature
[°C]
Approx Cook Time
(mins)
Roasting: Meat and
Poultry 160 - 180 see Roasting Chart
8.8 Roasting
Roasting dishes
• Use heat-resistant ovenware to roast
(please read the instructions of the
manufacturer).
• Large roasting joints can be roasted
directly in the deep roasting pan or on
the oven shelf above the deep roast-
ing pan. (If present)
• Roast lean meats in a roasting tin with
a lid. This well keep the meat more
succulent.
• All types of meat, that can be
browned or have crackling, can be
roasted in the roasting tin without the
lid.
8.9 Main oven
8.10 Roasting
Meat Temperature [°C] Cooking Time
Beef/ Beef boned 160 - 180 20-35 minutes per ½ kg
(1lb) and 20-35 minutes
over
Mutton/ Lamb 160 - 180 20-35 minutes per ½ kg
(1lb) and 20-35 minutes
over
Pork/ Veal/ Ham 160 - 180 30-40 minutes per ½ kg
(1lb) and 30-40 minutes
over
Chicken 160 - 180 15-20 minutes per ½ kg
(1lb) and 20 minutes over
Turkey/ Goose 160 - 180 15-20 minutes per ½ kg
(1lb) and 20 minutes over
Duck 160 - 180 25-35 minutes per ½ kg
(1lb) and 25-30 minutes
over
Pheasant 160 - 180 35-40 minutes per ½ kg
(1lb) and 35-40 minutes
over
Rabbit 160 - 180 20 minutes per ½ kg (1lb)
and 20 minutes over
8.11 Grilling
Always use the grilling function with
maximum temperature setting
Always grill with the oven door
closed
ENGLISH 15

Always pre-heat the empty oven
with the grill functions for 5 mi-
nutes.
• Set the shelf in the shelf level
as recommended in the grill-
ing table.
• Always set the pan to collect
the fat into the first shelf level.
• Grill only flat pieces of meat or
fish.
8.12 Grilling
Adjust shelf position and grill
pan grid to suit different thick-
nesses of food
Food Grill Time
(mins in total)
Bacon Rashers 5- 6
Beefburgers 10 - 20
Chicken Joints 20 - 40
Chops
- Lamb 15 - 25
- Pork 20 - 25
Fish - Whole
Trout/ Makarel 10 -12
Fillets - Plaice/Cod 4 - 6
Kebabs 12 - 18
Kidneys - Lamb/Pig 6 - 10
Sausages 20 - 30
Steaks
- Rare 4 - 6
- Medium 6 - 8
- Well Done 12 - 15
Toasted Sandwiches 3 - 4
8.13 Defrosting
• Put the food out of the packaging and
set it on a plate on the oven shelf.
• Do not cover with a plate or bowl. This
can extend the time to defrost very
much.
• Put the oven shelf in the first shelf lev-
el from the bottom.
9. CARE AND CLEANING
WARNING!
Refer to the Safety chapters.
• Clean the front of the appliance with a
soft cloth with warm water and clean-
ing agent.
• To clean metal surfaces use a usual
cleaning agent
• Clean the oven interior after each use.
Thus you can remove dirt more easily
and it does not burn on.
16 www.aeg.com

• Clean stubborn dirt with a special
oven cleaner.
• Clean all oven accessories (with a soft
cloth with warm water and cleaning
agent) after each use and let them dry.
• If you have nonstick accessories, do
not clean them using an aggressive
agents, sharp edged objects or dish-
washer. It can destroy nonstick coat-
ing!
Stainless steel or aluminium ap-
pliances:
Clean the oven door with a wet
sponge only. Dry it with a soft
cloth.
Do not use steel wool, acids or
abrasive materials as they can
damage the oven surface. Clean
the oven control panel with the
same precautions
9.1 Shelf supports
You can remove the shelf supports to
clean the side walls.
Removing the shelf supports
1. Pull the front of the shelf support
away from the side wall.
2
1
2. Pull the rear end of the shelf sup-
port away from the side wall and re-
move it.
Installing the shelf supports
Install the shelf supports in the opposite
sequence.
Valid with telescopic runners:
The retaining pins on the tele-
scopic shelf runners must point
to the front!
9.2 Oven Ceiling
You can fold down the heating element
on the oven ceiling to clean the oven
ceiling easily.
ENGLISH 17

WARNING!
Before you fold down the heat-
ing element switch off the appli-
ance. Make sure that the appli-
ance is cold.
There is a risk of burns!
Folding down the heating element
1. Remove the shelf support rails.
2. Hold the heating element with the
two hands at the front
3. Pull it forwards against the spring
pressure and out along the support
on both sides.
4. The heating element folds down.
The oven ceiling is ready to clean.
Installing the heating element
1. Install the heating element in oppo-
site sequence.
Install the heating element cor-
rectly on the two sides above the
support on the inner wall of the
oven.
2. Insert shelf support rails.
9.3 Door and glass panels
Remove the door to clean it.
A
A
Removing the door
CAUTION!
Be careful when you remove the
door from the appliance. The
door is heavy.
1. Open the door as far as it goes.
2. Fully lift up the clamping levers (A)
on the two door hinges.
45°
3. Close the door until it is at an angle
of approximately 45°.
4. Hold the door with one hand on
each side and pull it away from the
appliance at an upwards angle.
Put the door with the outer side
down on a soft and level surface
to prevent scratches.
5. At this time you can remove the in-
ner glass panels and clean them.
To install the door do the above steps in
the opposite sequence.
18 www.aeg.com

2
B
1
Removing and cleaning the door
glasses
The door has 2, 3 or 4 panels of
glass (the number depends on
the model).
CAUTION!
Rough handling of the glass, es-
pecially around the edges of the
front panel, can cause the glass
to break.
1. Hold the door trim (B) on the top
edge of the door at the two sides
and push inwards to release the clip
seal.
2. Pull the door trim to the front to re-
move it.
3. Hold the door glass panels on their
top edges one by one and pull
them upwards from the guide.
4. Clean the door glass panels.
To install the panels do the above
steps in the opposite sequence. In-
sert the smaller panel first, and then
the larger one.
9.4 Oven lamp
WARNING!
There is a danger of electrical
shock!
Before you change the oven lamp:
• Switch off the oven.
• Remove the fuses in the fuse box or
switch off the circuit breaker.
Put a cloth on the bottom of the
oven for protection of the oven
light and glass cover.
Replacing the oven lamp
1. You can find the lamp glass cover at
the back of the cavity.
Turn the lamp glass cover counter-
clockwise to remove it.
2. Clean the glass cover.
3. Replace the oven lamp with applica-
ble 300°C heat-resistant oven lamp.
Use the same oven lamp type.
4. Install the glass cover.
10. WHAT TO DO IF…
WARNING!
Refer to the Safety chapters.
Problem Possible cause Remedy
The oven does not heat
up. The appliance is deacti- vated. Activate the appliance.
ENGLISH 19

Problem Possible cause Remedy
The oven does not heat
up. The clock is not set. Set the clock.
The oven does not heat
up. The necessary settings are not set. Make sure that the set- tings are correct.
The oven does not heat
up. The fuse in the fuse box is released. Do a check of the fuse. If the fuse is released more
than one time, contact a
qualified electrician.
The oven lamp does not
operate. The oven lamp is defec- tive. Replace the oven lamp.
The display shows 12.00 There was a power cut. Set the clock.
Steam and condensation
settle on the food and in
the oven.
You left the dish in the
oven for too long. Do not keep the dishes in the oven for longer
than 15-20 minutes after
the cooking ends.
If you cannot find a solution to the prob-
lem yourself, contact your dealer or the
service centre.
The necessary data for the service centre
is on the rating plate. The rating plate is
on the front frame of the appliance cavi-
ty.
We recommend that you write the data here:
Model (MOD.) .........................................
Product number (PNC) .........................................
Serial number (S.N.) .........................................
11. INSTALLATION
WARNING!
Refer to the Safety chapters. The built-in unit must meet the stability requirements of DIN
68930.
20 www.aeg.com
