AEG protect d. 3000 Specification sheet

3000 D
3010 D
Dunstabzugshaube
Afzuigkap
Hotte aspirante
Cooker Hood
Montage- und Gebrauchsanweisung
Installatie- en gebruiksaanwijzing
Notice d’utilisation et d’installation
Operating and Installation Instructions

63
Contents
Safety warnings 64
fortheuser 64
fortheinstaller 64
Description of the Appliance 66
Extractorversion 66
FilterVersion 66
Hood Operation 67
LEDIndicatorlightsforveryfyingthesaturation of filters 68
Led–IndicatorforgreasefilterD 68
Led- indicator forcharcoal filter E 68
Resettingthesaturationindicator 68
Maintenance and care 69
Metalgreasefilter 69
Openthemetalgreasefilter 69
Charcoalfilter 70
Changingthelightbulb 71
Cleaning 72
Special accessories 72
Technical assistance service 72
Guarantee conditions 73
Technic Details 74
Mountingaccessoriesincluded 74
Electrical connection 74
Safetywarningsfortheelectrician 74
Wall unit mounting 75
Printedonrecycledpaper
AEG - putting words into action

64
Safety warnings
for the user
•Alwayscoverlighted elements, to prevent excessheatfrom
damaging the appliance. In the case of oil, gas and coal fired
cookers it is essential to avoid open flames.
•Also, when frying, keep the deep frying pan on the cooker top/cooker
undercarefulcontrol.
•Thehotoil in the fryingpanmight ignite due tooverheating.
•The risk of self-ignition increases when the oil being used is dirty.
•It is extremely important to note that overheating can cause a fire.
•Never carry out any flambécooking under the hood.
•Always disconnect the unit from the power supply before
carrying out any work on the hood, including replacing the
light bulb (take the cartridge fuse out of the fuse holder or switch off
theautomatic circuit breaker).
•It is very important to clean the hood and replace the filter at
the recommended intervals. Failure to do so could cause
grease deposits to build up, resulting in a fire hazard.
for the installer
•When used as an extractor unit, the hood must be fitted with a
150mmdiameterhose.
•Should there already be a pipe of diameter 125 mm that ducts to the
outside through the walls or roof, it is possible to use the 150/125
mm reduction flange provided. In this case the hood will be slightly
morenoisy.
•When installing the hood, make sure you respect the following
minimum distance from the top edge of the cooking hob/ring
surfaces:
electric cookers 600 mm
gascookers 650 mm
coal and oil cookers 700 mm min.
•ThenationalStandardonfuel-burning systems specifies a maximum
depression of 0.04 bar in such rooms.
•The air outlet must not be connected to chimney flues or combustion
gas ducts. The air outlet must under no circumstances be connected
toventilationductsforroomsinwhichfuel-burningappliancesare
installed.

65
•Itisadvisabletoapplyforauthorizationfromtherelevantcontrolling
authority when connecting the outlet to an unused chimney flue or
combustion gas duct.
The air outlet installation must comply with the regulations laid down
bytherelevantauthorities.
•When the unit is used in its extractor version, a sufficiently large
ventilationholemustbeprovided,withdimensionsthatare
approximately the same as the outlet hole.
•Nationalandregionalbuildingregulationsimposeanumberof
restrictionsonusinghoodsandfuel-burningappliances connected to
a chimney, such as coal or oil room-heaters and gas fires, in the
sameroom.
•Hoods can only be used safely with appliances connected to a
chimneyiftheroomand/orflat(air/environmentcombination)is
ventilatedfromoutsideusingasuitableventilationholeapproximately
500-600cm2 largetoavoidthepossibility of a depression being
createdduringoperationofthehood.
•Ifyouhaveany doubts, contact the relevant controllingauthorityor
buildinginspector’soffice.
•Since the rule for rooms with fuel burning appliances is “outlet hole of
the same size as the ventilation hole”, a hole of 500-600 cm2, which
is to say a larger hole, could reduce the performance of the extractor
hood.
•If the hood is used in its filtering function, it will operate simply and
safelyin the above conditions without the needfor any ofthe
aforementionedmeasures.
•When the hood is used in its extractor function, the following rules
mustbefollowedto obtain optimal operation:
—short and straight outlet hose
—keep bends in outlet hose to a minimum
—never install the hoses with an acute angle, they must
always follow a gentle curve only
—keep the hose as large as possible (preferably the same diameter
as the outlet hole).
•Failure to observe these basic instructions will drastically reduce the
performanceandincreasethenoiselevelsoftheextractorhood.

66
Description of the Appliance
Extractor version
•The hood is supplied as an extractor unit
and can also be used with a filtering
functionbyfitting one charcoal filter
(special accessory).
•Youwill need originalAEG charcoal filter
for this function (see Special Accessories).
•Theair is discharged tothe outside through
a pipe, which must be fitted to connection
flange D. Fig. 1.
•Inordertoobtainthe best performance the
hoseshouldhavea diameter equal to the
outlethole.
Shouldtherealreadybeapipe of diameter
125 mm that ducts to the outside through
the walls or roof, it is possible to use the
150/125mmreductionflangeprovided.In
this case the hood will be slightly more
noisy.
Filter Version
•Theairisfilteredthrough an charcoal filter
and returned to the kitchen through the top
grill of the outlet pipe.
•You will need an original AEG KF20
charcoalfilterforthefilteringfunction.(See
Special Accessories).
•Assemble the deflector (3 parts): the
three parts must be fixed with 2 screws Ø
3.5 13 mm, the extension of the deflector
is adjustable and must correspond to the
width of the chimney flue support, to which
it must be fixed.
Fix the deflector using 4 screws Ø2,9x6.5
mm. Fig. 2.
•Optionally, the position of the chimney
elementscanbechanged.
Whenusingthe hood in the filterversion
the chimney must be fixed at the top, with
the air outlet grill at the side.
Fig. 1
D
=
=
Fig. 2

67
Hood Operation
•Best results are obtained by using a low speed for normal conditions
andhighspeedwhenodoursaremoreconcentrated. Turn the hood
on a few minutes before you start cooking then you will get an
underpressurein the kitchen. It should be lefton after cooking for
about15minutesoruntilallodourshavedisappeared.
The control switches are located on the unit’s front panel:
A- Main switch, hood OFF.
B- Start and choice of motor speed 1-2-3-1-2.........
C- Indicatesspeed1(LED)
D- Indicatesspeed2(LED) and indication of the greasesaturation
forthefilter(flashingindicator).
E- Indicatesspeed3 (LED) and indication of thecharcoalsaturation
forthefilter(flashingindicator).
F- IndicatesIntensivespeed (LED).
G- Intensivespeedon/off.The Intensive speed runsfor5minutes:
Ifthehood is on whentheIntensive speed is activated,thehood
revertstopreviousspeedafter5minutes.
Ifthehood is off when the Intensivespeedisactivated, the hood
will automaticly be turned off after 5 minutes.
To interrupt the Intensive speed, press button A,B or G.
H- Light OFF
I- LightON
Shouldthehood or the controls fail tooperate:disconnectthe power supply
for at least 5 seconds, then turn the hood back on again.
ABCDEFGH I
Fig. 3

68
LED Indicator lights for veryfying the
saturation of filters
This hood is supplied without a charcoal filter. If the hood is to be used
in the recirculation mode with a charcoal filter, the saturation indicator
must be activated as follows:
Depress and hold the B and G buttons simultaneously for 3 seconds.
Initially only the LED indicator signal for the grease filter D is activated,
shortly after the LED indicator for the charcoal filter E will activate, at
this point the saturation detection has been enabled.
To switch off the saturation detection : depress and hold the B and G
buttons for 3 seconds until the LED indicator for the active carbon filter
isflashing.
Led –Indicator for grease filter D
TheLEDindicator for the grease filter willflashwhenit requires
cleaning.
Followthemaintenanceinstructions.
Led - indicator for charcoal filter E
TheLEDindicatorfor the charcoal filter illuminateswhenthefilter
requiresreplacing.
Thisoccursafterabout160workinghoursfromwhentheactivecarbon
filter was first put into operation.
Resetting the saturation indicator
Aftercleaning or replacing the filter depress and hold the Abutton again
for 3 seconds until the grease filter LED D or the charcoal LED E are no
longerflashing.

69
Maintenance and care
•The hood must always be disconnected from the electricity
supply before beginning any maintenance work.
Metal grease filter
•Thepurpose of thegrease filters isto aspirate grease particles which
form during cooking and it must always be used, either in the
externalevacuationorinternalrecyclingfunction.
Attention:themetal grease filters must beremoved and washed,
eitherbyhandor in the dishwasher,everyfourweeks.
Open the metal grease filter
•First, push the metal grease filter stop backwards, then extract the
filter, pulling downwards. Fig. 4.
Hand washing
Soakgreasefiltersforaboutonehour
inhotwaterwithagrease-loosening
cleaner, then rinse offthoroughly with
hotwater. Repeat the process if
necessary.Refitthegrease filters
whenthey are dry.
Dishwasher machine
Place grease filters in dish washer.
Selectmostpowerfulwashing
programmeandhighesttemperature,
at least 65°C. Repeat the process.
Refitthegrease filters when they are
dry.
Whenwashingthemetal grease filter
in the dishwasher a slight
discoloration of the filter can occur,
this does not have any impact on its
performance.
•Cleantheinnerhousingusingahotdetergentsolution only (never
usecausticdetergents,abrasivepowdersorbrushes).
Fig. 4

70
i
g
h
g
g
g
Charcoal filter
•The charcoal filter should only be used if you want to use the hood in
itsfilteringfunction.
•To do this you will need an original AEG charcoal filter (see special
accessories).
•Cleaning/replacing the charcoal filter
Unlikeothercharcoal filters, the LONGLIFE charcoalfiltercan be
cleanedandreactivated. At normal use the filtershouldbe cleaned
everysecondmonth (when using thehood2,5 hours per day, in
avarage). The best way to clean the filter is in the dishwasher. Use
normaldetergentandchoose the highest temperature (65ºC). Wash
the filter separately so that no food parts gets stuck on the filter and
latercauses bad odours. Toreactivatethe charcoal, the filtershould
bedriedin an oven for 10minuteswith a temperature of maximum
100ºC.
After approximately three years of use, the charcoal filter should be
replaced with a new, as the odour reduction capacity will be reduced.
•Mounting
Remove the frame iwhich supports the filter hby turning 90°the two
knobs g, Fig.5. Insert the coal mattress inside the frame and put
all parts back in their place.
•To dismount proceedinreverseorder.
•Alwaysspecifythe hood model code numberandserial number
whenorderingreplacementfilters.Thisinformationisshownonthe
registration plate located on the inside of the unit.
•Thecharcoal filter can be ordered from the AEG technical assistance
service.
Fig. 5

71
Fig. 6
Warning
•Failuretoobserve the instructions on cleaningtheunit and changing
thefilters will cause a firehazard. You are therefore strongly
recommendedtofollowtheseinstructions.
•Themanufacturerdeclinesall responsibility for any damage tothe
motororanyfiredamagelinkedtoinappropriatemaintenanceor
failuretoobserve theabovesafetyrecommendations.
Changing the light bulb
•Disconnect the cooker hood from the main supply.
•Remove the lampcover, use ascrew driver as a lever. Fig. 6.
•Replace the old bulb with a new one of the same type.
•Remountthelamp cover.
•If the light does not come on, make sure the bulb has been inserted
in correctly before contacting the technical assistance service.

72
Cleaning
•Warning:always disconnect the hood from the mains power supply
beforecleaningit.
Neverinsertpointedobjects in the motor’s protective grid.
•Washtheoutside surfaces using a delicatedetergentsolution. Never
usecausticdetergentsorabrasivebrushes or powders.
•Only ever clean the switch panel and filter grille using a damp cloth
anddelicatedetergents.
•It is extremely important to clean the unit and change the filters at
therecommendedintervals. Failure to do sowillcause grease
deposits to build up that could constitute a fire hazard.
Special accessories
CharcoalfilterKF20 942 120600
Technical assistance service
You are welcome to telephone our technical assistance service (see list
oftechnicalassistancecentres)whenever you need information or in the
unlikelyeventofa fault.
When calling, please be ready to specify:
1. The model code number
2. The serial number (E-Nr.)
3. The manufacturing number (F-Nr.)
This information is shown on the registration plate inside the unit
behind the grease filter.
We reserve the right to change specifications and colours as a result of
ourpolicyofcontinuingtechnological development.

73
Guarantee conditions
Guarantee Conditions
AEGofferthefollowingguaranteetothefirstpurchaserofthisappliance.
1. Theguaranteeisvalidfor12monthscommencingwhentheappliance ishandedoverto
thefirstretailpurchaser,whichmustbeverifiedbypurchaseinvoiceorsimilar
documentation.Theguaranteedoesnotcovercommercialuse.
2. Theguaranteecoversall partsorcomponentswhichfailduetofaulty workmanshipor
faultymaterials.Theguaranteedoesnotcoverapplianceswheredefectsorpoor
performanceareduetomisuse,accidentaldamage,neglect,faultyinstallation,
unauthorisedmodificationorattemptedrepair,commercialuseorfailuretoobserve
requirementsandrecommendationssetoutintheinstructionbook.Thisguaranteedoes
notcoversuchpartsaslightbulbs,removableglass-wareorplastic.
3. Shouldguaranteerepairsbenecessarythepurchasermustinformthenearestcustomer
serviceoffice(manufacturer`sserviceorauthorisedagent).AEGreservestherightto
stipulatetheplaceoftherepair(i.e.thecustomer`shome,placeofinstallationorAEG
workshop).
4. Theguaranteeorfreereplacementincludesbothlabourandmaterials.
5. Repairscarriedoutunderguaranteedonotextendtheguarantee
periodfortheappliance.Partsremovedduringguaranteerepairsbecometheproperty
of AEG.
6. Thepurchaser`sstatutoryrightsarenotaffectedbythisguarantee.
European Guarantee
IfyoushouldmovetoanothercountrywithinEuropethenyourguaranteemoveswithyoutoyour
newhomesubjecttothefollowingqualifications:
- Theguaranteestartsfromthedateyoufirstpurchasedyourproduct.
- Theguaranteeisforthesameperiodandtothesameextentforlabourandpartsasexist
inthenewcountryofuseforthisbrandorrangeofproducts.
- Thisguaranteerelatestoyouancannotbetransferredtoanotheruser.
- YournewhomeiswithintheEuropeanCommunity(EC)orEuropeanFreeTradeArea.
- Theproductisinstalledandusedinaccordancewithourinstructionsand isonlyused
domestically,i.e.anormalhousehold.
- Theproductisinstalledtakingintoaccountregulationsinyournewcountry.
BeforeyoumovepleasecontactyournearestCustomerCareCentre,listed below,togivethem
detailsofyournewhome.TheywillthenensurethatthelocalServiceOrganisationisawareof
yourmoveandabletolookafteryouandyourappliances.
France Senlis [phone]
Germany Nürnberg [phone]
Italy Pordenone [phone]
Sweden Stockholm [phone]
UK Slough [phone]

74
Technic Details
Dimensions - extractor version (in cm):
Height x Width x Depht 66-112 x 89,8 x 50
Dimensions - filter version (in cm):
Height x Width x Depht 75,5-122 x 89,8 x 50
Maximum absorbed power: 210 W
Motorabsorption: 1 x 170 W
Lighting: 2 x 20W
Lenghtofthecable:150 cm
Mounting accessories included
1 deflector (3 pieces to assemble)
2 metal screws 3,5 x 13 (to assemble the deflector)
1 chimney support (3 pieces to assemble)
4 metal screws 4 x 8 (to assemble the chimney support)
4 metal screws 3,5 x 9,5 (to affix the deflector to the support)
1reductionflangeØ125-120mm
1supportbracket
5wood-screws 5 x 45 mm (for wall mounting)
5 wall plugs Ø8 mm (for wall mounting)
4 metal screws 2,9 x 6,5 (for chimney flue mounting)
4 metal screws 4 x 35 (to affix the screen to the cooker hood)
2 metal screws 3 x 9 (to affix the frame to the cooker hood)
1allenspanner (for TORX screws)
Electrical connection
Safety warnings for the electrician
Beforeconnectingtheappliancetothepowersupply, check that the volt-
ageindicatedon the rating plate corresponds tothemains power supply
available. Appliancesfittedwith aplugcanbeconnected to anystandard
power socket within easy access.
Shoulditbenecessarytoprovideafixedconnection,thehood must only
be installed by an electrician authorised by the local electricity board.
When installing, an omnipolar disconnector with a distance of at least
3mmbetweencontactsmustbe provided.
Themanufacture declinesallresponsibility formalfunctionsresulting from
failureto comply with the aboveinstructions.
Electrical connection
220-240 V –by means of fixed power cable with plug.
(Fixedconnectionofthe appliance must only becarriedoutbyanauthor-
isedelectrician.)

75
Wall unit mounting - Fig. 7
Firstdecidewhich functioning version is betterfor you.
Ifyou decidetousethehood inexhaustingversionwe suggesttoposition
the upper section of the chimney so that the oulet slots are not visible
onceinstallationhasended, on the contrary if isdecidedto use the hood
inrecyclingversionBESUREthatthesidewithslotsisup(seealso A-B-
C sequence on on Fig. 7).
Assembling the chimney flue support/bracket (3 parts):
The three parts should be fixed with 4 screws, the support extension
isadjustable and should correspond to the internal width of the
telescopic chimney flue.
Assembling the deflector (3 parts –only for filter version):
The three parts should be fixed with 2 screws, the deflector
extension is adjustable and should correspond to the width of the
chimney flue support, to which it is then fixed.
A
B
180°
C - OK!
==
X
X
H
=
=
X
F
F
G
G
Fig. 7

76
•Insert the frame, that holds controls, grease filter and lamps, in the
motor housing using proper rails and fix each other with two 3x9
screws(1-2-3).
•Sign the wall with a center line, this will aid mounting procedure (4),
position the template so that the mid line printed on the template
matches with the center line previously signed, the lower side of the
templatecorrespondsto the lower sideofthe hood once mounted
(5).
•Drill two holes Ø8mm and fix the support bracket with two wall plugs
andscrews(6).
•Hang the hood (7) adjust its position (8-9) and from the inside of the
hoodsignonepointfordefinitivefixing (10),removethe hood and drill
an hole Ø8mm (11), fit a wall plugs, hang the hood again and fix it
definitivelywithascrew(12).
•Drill two holes Ø8mm on the upper side close to the ceilling (13), fit
two wall plugs and fix the chimney support with two screws (14).
In case the hood is to be used in filter version, mount the deflector
Fon the chimney support with four screws 2,9x6,5 and fit an
exhausting pipe (15) to connect deflector to the outlet hole Dof the
hood.
In case the hood is to be used in exhausting version, then the
deflector must not be mounted and fit an exhausting pipe (15) to
connect outlet hole Dof the hood to the outside.
•Makeelectricalconnection (16), but leave the hooddisconnected
fromthehomegeneralelectricpanel.
•Connectlamps and control paneltothe motor housing (17).
•Insertthe vapour screen on themotor housing and fix itwith four
screwsM4x35(18).
Model 3010D has an additional part that can be mounted to the first
part fixed on step 18 before or after this step, choose the
convenience,fixingbetween this two parts must bedonewith four
screws.
•Fix the chimney first up (19a) to the chimney support (19b), then on
thebottom (20a) to theupper side of the frame (20b) usingfour
screws 2,9x6,5.
•Connect the hood the the home general electric panel and check if
the hood work properly.
Wall unit mounting - Fig. 8

77
Fig. 8
20b 12
19b
19b
7
7
4
5
6
89
13 13
14
15
19a
9
8
16
8
9
10
11
20a
20a
20b
19a
17
18
18
18
F
G
H
1
2
3
D
Model3010D

78

79

AEG Hausgeräte GmbH
Postfach 1036
D-90327 Nürnberg
http://www.aeg.hausgeraete.de
© Copyright by AEG LI1M7C Ed. 07/02
