Aegis LITHIUMASTER ABL-12035P User manual

FAQ
+ How long will my battery last?
Several factors that affect battery life including weather, temperature, recharge cycles, depth of
discharge (DOD), discharge current, charging current, charging method, vibration and duration of
static use can all have dramatic effects on battery life. A properly maintained battery should last
1000+ charge discharge cycles or three times as long as lead-acid use in similar conditions.
+ Can I use lithium ion batteries with other types of batteries?
No. If different types of batteries are used together, or new batteries are used with old ones, the
difference in characteristics such as voltage, capacity, and/or internal resistance may cause uneven
discharge between the batteries leading to cell damage potentially resultant in fire.
+ Is it okay to use a universal lead acid charger with high enough charging current?
Using a lead acid battery charger is not recommended because they charge at a lower 2.30V to
2.45V per cell in addition to charging in multiple stages with a final float charge setting. This is
distinctly different from the Li-Ion 2-Stage charge profile. Mixing of chargers between chemistries
will result in damage to the battery.
+ Can I connect two of the same Li-ion batteries together for more voltage/ capacity?
Linking our Li-ion batteries in series or parallel connection is NOT RECOMMENDED and may exceed
factory recommended usage parameters. It is recommended to purchase a single battery with the
requisite capacity and discharge characteristics. Our Battery Management System (BMS) is
designed for operations within a singular battery unit and we cannot guarantee operability of
multiple batteries connected together regardless of configuration. If, however, multiple batteries
are required please ensure 1) the batteries are from the same batch 2) the batteries are of the same
make and model and 3) peak discharge is maintained at <0.5C peak.
+ My battery will not charge/discharge?
There are multiple reasons including but not limited to 1) charger failure, 2) external damage to
battery has compromised either the cell pack or BMS, 3) battery voltage has fallen to zero in one or
more cells, 4) there is a connection error within the pack, 5) a malfunction(s) has occurred within
the BMS component(s) or in extreme cases 6) extreme high/low temperatures may be inhibiting
charging efficiency of the cell pack itself.
+ Can I jump start a dead lithium ion battery?
It is not recommended. Li-ion batteries enter an elevated sensitivity state when empty and the
introduction of unmodulated amperage in this state will damage the cell. We highly recommend
using our chargers to recharge a fully discharged Li-ion battery as our chargers have the sensing
circuitry required to modulate charge current to optimally recondition fully discharged batteries.
CONTACT
Aegis Energies, INC. (dba: Aegis Batteries) P: [phone]
985 East Orangefair Ln. E: [email protected]
Anaheim, CA 92801 W: www.lithiummaster.com
WARRANTY
NMC 5-Year and LiFEPO4 10-Year, repairs and/or exchanges may be accepted within 2 Years of purchase and
are subject to 30-day money back guarantee for any initial quality issues originating from Aegis Battery, issues
resultant from negligent and/or abusive use not inclusive. Returns are subject to a 10% Restock Fee + Shipping
Cost Charge. Exchanges are subject to a Shipping Cost Charge as determined by location and level of service.
P/N: ABL-12035P LiFEPO4 LITHIUM IRON PHOSPHATE
USER MANUAL
WARRANTY
CONTACT AND SUPPORT
12V
35AH
420WH
40A MAX DISCHARGE
*Subjects of this content pertains to Aegis Battery Li-ion NMC Batteries for Deep Cycle usage only
and are not representative of any other type, chemistry, make, and/or model of battery thereof.
REV20210927

INTRODUCTION
Thank you for purchasing an Aegis Battery product. It is advised to read and familiarize with the
contents of this manual prior to useas failure to do so may result in degraded battery characteristics.
The model you have purchased is the ABL-012035P 12V, 35Ah rated Li-ion LiFePO4 Battery
featuring enhanced safety, non-toxicity, higher performance and extended service life as compared
with traditional lead-type batteries including but not limited to SLA, AGL and GEL. This battery was
assembled in our ISO 9001 Certified production facilities and as such you can expect performance
and consistency from this product and every other product you may be using or have used.
CONTENTS
+ Aegis Energies (dba: Aegis Battery) Li-ion NMC Battery Pack
+ Model Compatible Charger (If optional Charger was purchased)
+ 1 Copy User Manual
SPECIFICATIONS*
Battery Type
ABS CASE
Voltage (V)
12V
Capacity (Ah)
35Ah
Energy Stored (Wh)
420 Watt-Hours
Weight
8.6 lbs. (3.9 kg)
Dimension (L x W x H)
195 mm x 130 mm x 154 mm
7.7 in. x 5.1 in. x 6.1 in.
Normal Charge Voltage
29.4V
Normal Charge Current
4.0 Amps
Normal Battery Cutoff Voltage
19.6V
Nominal Continuous Discharge Current
20.0 Amps
Maximum Continuous Discharge Current
40.0 Amps
Maximum Peak Pulse Discharge Current
60.0 Amps (5 Seconds)
Charge Temperature
0°C to 45°C
Discharge Temperature
-20°C to 60°C
Operating/Storage Humidity
60±25%R.H
Automatic Battery Protection
Module/System
Low Voltage Disconnect
Over Voltage Disconnect
Short Circuit Protection
Reverse Polarity Protection
Cell Balancing
(*For full specifications, please visit www.lithiummaster.com)
CHARGING
PRIOR TO INITIAL USE, ENSURE BATTERY HAS TAKEN FULL CHARGE AND IS IN A FULLY
CHARGED STATE. OUR BATTERIES MAY NOT BE SHIPPED FULLY CHARGED!
MAKE SURE THE CHARGER’S INDICATOR LIGHT HAS TURNED GREEN AND WAIT FOR 30
MIN. ELAPSE BEFORE UNPLUGGING, CHARGE TIME VARIES FROM MODEL TO MODEL!
When charging your battery, please follow the provided sequence below:
1. Attach Battery Charging Connector to Charger (This will vary depending on your selected
model and configuration of battery)
2. Attach Charger to 110VAC Outlet
3. When Charging you should observe a RED LED Indicator: this indicates that the battery is
currently in the Constant Current (CC) charging phase
4. Wait for a GREEN LED Indicator: this indicates the battery is currently in the Constant Voltage
(CV) charging phase
5. Wait 30 MINUTES before unplugging the Charger from the 110VAC Outlet FIRST and then
disconnecting the Battery from the Charger SECOND
DISCHARGING (STANDARD, SERIES/PARALLEL <0.5C DISCHARGE)
1. Make sure your load accepts 12Vnominal voltage.
2. Ensure the connection between the battery and the load can handle the current draw. Please
consult references for the appropriate wire type.
3. The maximum continuous discharge current is 35A. Please make sure your electrical load
consumes a current less than 35A continuous and 420 watts of power.
4. The battery outputs steady voltage until little capacity remains, do NOT rely on voltage as an
indicator of remaining capacity, Aegis Battery recommends the usage of an In-Line Watt Meter
for conveyance of accurate battery discharge telemetry.
Series: Each battery must be charged separately and given a full charge before connecting in series.
Parallel: Only connect batteries with equal state of charge in parallel. Also, measure the internal
resistance of each battery and only use batteries with closely matched internal resistance of the
same make, model and batch origin. It is highly recommended that resistors be used to achieve
equal internal resistance between batteries and to add fuse(s) to the circuit for safety reasons.
SAFETY GUIDELINES
Please adhere to the following Safety Guidelines in addition to all disclosed information when using
your battery. Any damage incurred as a result of a failure to adhere to the recommended usage
guidelines as collectively disclosed may result in a partial or complete voiding of the warranty as
provided upon purchase of this battery product. Additional Safety Guidelines are as follows.
1. Do not disassemble and/or attempt self-repair
2. Do not short circuit positive and negative terminals
3. Do not use lead acid chargers as they will cause damage to internal hardware
4. Do not dispose in normal refuse bin, recycle this product only at designated facilities
5. For long term storage, fully charge the battery and then discharge to 50% of the full capacity
6. Do not leave the battery unattended for more than 6 months or in the presence of children
7. Do not use the battery in or expose the battery to extreme temperatures
