AEP MP2x8i NMEA Buffer User manual

NMEA Buffer
Installation and
user manual
MP2x8i

3
1 Safety information.......................................................................................................................................................................
P 2/9
Contents
2 Description................................................................................................................................................................................... 4
3 Terminal Description.................................................................................................................................................................... 5
4 Technical data.............................................................................................................................................................................. 9
AEP Marine Parts B.V.
Van Hennaertweg 9
2952 CA Alblasserdam
The Netherlands
Telephone: [phone]
Fax: [phone]
Email: [e-mail]
Website: aepmarineparts.com

P 3/9
Do not make any changes to the electrical circuits of the PCB.
1Safety information
Turn off the power at the main switchboard before installing the buffer.
Connecting a lower or higher input voltage may result in product failure or injuries.
The correct input voltage range is 24 VDC (9‐36 VDC).
Make sure that the input voltage is within the input voltage range of the buffer.
Product failure and injuries may be caused when power is tuned on during installation.
When making any changes the hazardous voltage might cause an electrical shock, fire or injuries.

P 4/9
2Description
Figure 2: NMEA Buffer MP2x8i front panel.
Figure 1: NMEA Buffer MP2x8i overview.
The MP2x8i NMEA Buffer has been designed to distribute NMEA or other RS422 signals from one transmitter up to 8 listeners.
The transmitted signal is galvanically isolated from the power supply and all listeners. The unit can operate with signal speed up
to 230400 bps and power supply range from 9 to 36 VDC.
The MP2x8i has two operating modes: Dual Independent Transmission and Single Input Transmission with auto switching, described
on page 6 and 7. When you are using the Single Input Transmission you are able to connect two independent NMEA transceivers
and distribute the main signal to all listeners.

P 5/9
X1: Power and NMEA input connection
1.
PWR + power positive
2.
PWR –power negative
3.
Grounding
4.
NMEA1 + input 1
5.
NMEA1 –input 1
6.
Grounding
7.
NMEA1 + input2
8.
NMEA1 –input 2
X2: Outputs connection
1.
NMEA out 1 A
2.
NMEA out 1 B
3.
NMEA out 2 A
4.
NMEA out 2 B
5.
NMEA out 3 A
6.
NMEA out 3 B
7.
NMEA out 4 A
8.
NMEA out 4 B
X3: Outputs connection
1.
NMEA out 5 A
2.
NMEA out 5 B
3.
NMEA out 6 A
4.
NMEA out 6 B
5.
NMEA out 7 A
6.
NMEA out 7 B
7.
NMEA out 8 A
8.
NMEA out 8 B
SW1: DIP Switch. Configuration switch is used to configure the working mode of the NMEA Buffer. SW1‐1 ON set Single Input
Transmission with auto switching and SW1‐1 OFF set dual Dual Independent Transmission. SW1‐2 is not used in this application.
Table 1: Terminal description.
3Terminal description
Power and signal connection for hardware rev_1.0 and higher.

P 6/9
Auto mode works as a regular buffer with 1 input and 8 outputs. It has automatic switching to input 2 if input 1 stops to receive
the data (signal loss). Automatic switch will occur within approximately 30 seconds after the signal of input 1 is lost. Switching
back to input 1 occurs immediately after signal is restored.
Single input transmission with auto switching:
Figure 3: Single input transmission with auto switching
LED (red) operating mode:
Input 1 LED and input 2 LED will blink simultaneously when the data is received and transmitted to the output.
Power LED: Continuous lit when input power is detected.



P 7/9
Dual input independent transmission mode:
Dual Input Independent Transmission mode works as two independent buffers with 1 input and 4 outputs each. Signals from
input 1 and input 2 are not mixed and independently transmitted to the outputs.
Figure 4: Dual input independent transmission mode
LED (red) operating mode:
Input 1 LED and input 2 LED will blink both (not simultaneously), depending on the transmission time of the input source.
Power LED: Continuous lit when input power is detected.



P 8/9
Figure 5 Component Layout

Galvanic isolation: Power supply 1,5 kVDC, signal input/output up to 5 kVRMS
P 9/9
4 Technical data

Power supply: 24 VDC (9 to 36 VDC)

Power consumption: Typical 0,6 W at 24 VDC


Short circuit output protection

Reversed power supply polarity protection

Over voltage power input protection (up to ±37V)

Number of inputs: 2, selectable

Number of outputs: 8, configurable

Input/output signal speed: Up to 230400 bps

Connection: cable diameter up to 1,5 mm (2,5 mm without ferrule)

Dimensions: 155,5 mm x 68,0 mm x 32,0 mm (L x W x H)
2
Figure 6: Dimensions and views
2

Input signal: 2x RS232 or 2x RS422

Output signal: 8x RS422

Opto‐isolated input
