AER AM Series User guide

Page 1 of 20 AERCO International, Inc. •100 Oritani Dr. •Blauvelt, New York 10913 •Phone: [phone] PR1 04/08/2014
GF-146-V
TAG-0075_0B
399 / 500 / 750 / 1000
Gas-Fired Boilers and Water Heaters
VENTING APPLICATION GUIDE
Pending
Pending
Natural Gas or Propane
Modulating & Condensing
Boilers and Water Heaters
Applies to the following models:
Boilers
•AM 399B
•AM 500B
•AM 750B
•AM 1000B
Water Heaters
•AM 399W
•AM 500W
•AM 750W
•
AM 1000W
AM 399 Concentric Venting Into Sidewall
Example
04/08/2014

Page 2of 20 AERCO International, Inc. •100 Oritani Dr. •Blauvelt, New York 10913 •Phone: [phone] AM1 04/08/2014
AM Series Venting
Application Guide
GF-146-V
TAG-0075_0B
DISCLAIMER
The information contained in this manual is subject to change without notice from AERCO
International, Inc. AERCO makes no warranty of any kind with respect to this material, including, but
not limited to, implied warranties of merchantability and fitness for a particular application. AERCO
International is not liable for errors appearing in this manual, nor for incidental or consequential
damages occurring in connection with the furnishing, performance, or use of these materials.
AERCO Technical Support:
(Mon–Fri, 8am-5pm EST)
1 [phone]
AERCO Document Conventions
In this document, some types of information are presented as shown in the following examples:
Message Type Example and Description
Notes
NOTE
NOTE messages indicate specific information related to the
surrounding contextual information, and highlighted for special
attention.
Cautions
CAUTION!
CAUTION messages inform of potential problems relating to the
functioning of equipment, safety to persons, harm to the
environment, and/or damage to property or equipment.
Warnings
WARNING!
WARNING messages warn of potential dangerous situations that
may result in serious injury and/or death to persons or animals.
Text is red within a red box.
Instructions
How Instructions are Presented
1. Instructions are shown in a blue box with an underlined title.
2. All text, excepting in accompanying illustrations, is colored blue.
3. All procedures are listed in steps starting with “1.” and using
letters [a), b), c), etc.] indicating sub=steps.
4. Steps that are continued on the next page have a “(Cont.)”
appended to the instruction title.

PR1 04/08/2014 AERCO International, Inc. •100 Oritani Dr. •Blauvelt, New York 10913 •Phone: [phone] Page 3of 20
GF-146-V
TAG-0075_0B
GF
-
146
TAG
-
0075_0B
AM Series Venting
Application Guide
Table of Contents
Table of Contents ..................................................................................... 3
1. CODES, SAFETY, AND VENTING SYSTEMS .................................... 4
1.1. APPLICABLE FEDERAL CODES....................................................................4
1.2. GAS VENT CATAGORIES ...............................................................................5
1.3. CERTIFIED VENTING MATERIALS FOR FLUE PIPE SYSTEMS...................5
1.3.1. OPTION 1: AL29-4C Stainless Steel .........................................................5
1.3.2. OPTION 2: VP1738A Stainless Steel.........................................................5
1.3.3. OPTION 3: Polypropylene..........................................................................5
1.3.4. OPTION 4: PVC/CPVC (Use Schedule 40 or thicker, Single-Wall, Uninsulated
Pipes) 6
1.4. FACTORY SUPPLIED INLET AND VENT CONNECTION COMPONENTS....6
1.4.1. Flue Exhaust Piping Starter Pieces ...........Error! Bookmark not defined.
2. COMBUSTION AIR SYSTEM............................................................. 7
2.1. COMBUSTION AIR REQUIREMENTS.............................................................7
2.2. COMBUSTION AIR PIPE SIZING ..................................................................10
2.3. COMMON COMBUSTION AIR PIPE SIZING.................................................11
3. VENT SYSTEM................................................................................ 13
3.1. VENT INSTALLATION ...................................................................................13
3.2. INSTALLATION PROCEDURE FOR VENTING SYSTEM THROUGH WALLS15
3.3. INSTALLATION PROCEDURE FOR VERTICAL VENTING..........................17
3.4. VENT PIPING SIZE.........................................................................................18
3.5. COMMON VENT PIPING SIZE.......................................................................19

Page 4of 20 AERCO International, Inc. •100 Oritani Dr. •Blauvelt, New York 10913 •Phone: [phone] AM1 04/08/2014
AM Series Venting
Application Guide
GF-146-V
TAG-0075_0B
1. CODES, SAFETY, AND VENTING SYSTEMS
1.1. APPLICABLE FEDERAL CODES
United States:
NFPA 54/ANSI
Z223.1:
National Fuel Gas Code
NFPA/ANSI 211:
Chimneys, Fireplaces, Vents and Solid Fuel Burning Appliances
Canada:
CAN1-B149.1:
Installation Codes for Gas-Burning Equipment
B149.2:
Installation Codes for Gas-Burning Equipment
The above listed codes contain information for gas vented appliances requiring Category II, III
and IV, vent sizing, location, air space clearances to combustibles and safe installation
practices. The gas vent installer must be familiar with the above codes, as well as Local Codes
and Regulations.
WARNING!
All installations of boilers and venting should be done only by qualified
venting systems personnel and in accordance with the manufacturer’s
recommendations. Installing or venting a boiler or any other gas
appliance with improper methods or materials may result in serious
injury or death due to fire or to asphyxiation from poisonous gases
(carbon monoxide is odorless and invisible).
WARNING!
•For correct installation of vent system, read all of these instructions
and refer to the vent pipe manufacturer’s instructions.
•Failure to use the venting system described in this document will
void the manufacturer’s warranty and may result in rapid
deterioration of the venting system, creating a potential health
hazard.
•Faulty vent installation can allow toxic fumes to be released into
living areas. This may cause serious bodily injury or property
damage. Improper assembly may also affect vent performance.
Install separate vents for forced exhaust appliances and natural draft
appliances. A common vent between natural draft and forced
exhaust appliances may cause toxic gases to exhaust through the
natural draft appliance rather than to outside air. Breathing exhaust
gases will cause serious personal injury or death.

PR1 04/08/2014 AERCO International, Inc. •100 Oritani Dr. •Blauvelt, New York 10913 •Phone: [phone] Page 5of 20
GF-146-V
TAG-0075_0B
GF
-
146
TAG
-
0075_0B
AM Series Venting
Application Guide
1.2. GAS VENT CATAGORIES
The AM Series is approved for a Category IV vent configuration as well as for sealed combustion
installations. Make provisions for combustion and ventilation air in accordance with Section 5.3, (Air
for Combustion and Ventilation) of the National Fuel Gas Code -ANSI Z223.1, or Sections 7.2, 7.3, or
7.4 of CAN/CGA B149, Installation Codes, or applicable provisions of the local building codes.
Federal Codes have categorized gas appliances by the vented flue gas pressure and temperature:
•Category I, being a gas appliance that operates with a non-positive vent (or natural drafted vent)
connector with a flue gas pressure and temperature at least 140°F (60°C) above its dew point.
•Category II, being a gas appliance that operates with a non-positive vent (or natural drafted vent)
connector with a flue gas pressure and temperature less than 140°F (60°C) above its dew point.
•Category III, being a gas appliance that operates with a positive vent (fan forced vent) connector
with a flue gas pressure and temperature at least 140°F (60°C) above its dew point.
•Category IV, being a gas appliance that operates with a positive vent (fan forced vent) connector
with a flue gas pressure and temperature less than 140°F (60°C) above its dew point.
•Direct Vent, a gas appliance is constructed and installed so that all air for combustion is derived
directly from the outdoors and all flue gases are discharged to the outdoors.
1.3. CERTIFIED VENTING MATERIALS FOR FLUE PIPE SYSTEMS
Acceptable materials and manufacturers for flue vent pipe systems are listed in Sections 1.3.1 to 1.3.4
(Option #1 to Option #4).
The Vent Pipe Systems in the following section are used for venting gas burning Category IV
appliances. Do not use these vent pipe systems for venting appliances burning fuels such as wood,
coal, oil or kerosene.
Maintain clearances from combustible construction for boiler, vent connector, and steam and hot-
water pipes.
Do not use these vent pipe systems for incinerators of any kind.
Do not vent AM Series systems using the same vent piping as being used for other boiler types, such
as, but not limited to, Benchmark or Modulex boiler systems.
1.3.1. OPTION 1: AL29-4C Stainless Steel
•Security Chimneys International, Secure Seal, SS, SSD, and SSID (available through AERCO)
•Flex-L International Inc., StaR 34 Vent
•Heat-Fab Inc., Saf-T Vent
•Protech System Inc., Fas N Seal Vent
•Metal-Fab Inc., Corr/Guard Vent
•Z-Flex Z-Vent
1.3.2. OPTION 2: VP1738A Stainless Steel
•Van-Packer Company, Inc., Model CS Special Gas Vent
1.3.3. OPTION 3: Polypropylene
•Centrotherm ECO Systems, InnoFlue Single Wall Commercial
•DuraVent, Polypro Commercial

Page 6of 20 AERCO International, Inc. •100 Oritani Dr. •Blauvelt, New York 10913 •Phone: [phone] AM1 04/08/2014
AM Series Venting
Application Guide
GF-146-V
TAG-0075_0B
1.3.4. OPTION 4: PVC/CPVC (Use Schedule 40 or thicker, Single-Wall,
Uninsulated Pipes)
When using Non-Metallic (Plastic) vent systems for Canadian installations, per CSA B149.1, use vent
systems that are certified to the Standard for Type BH Gas Venting Systems, ULC-S636. The plastic
components, primers and glues of the certified vent system must be from a single system
manufacturer and not inter-mixed with other manufacturers vent system parts.
1. PVC
•ASTM F891
•ASTM D2665
•ASTM D1785
•ASTM D2241
2. CPVC
•ASTM D2846
•ASTM F441
•ASTM F442
1.4. FACTORY SUPPLIED INLET AND VENT CONNECTION COMPONENTS
All units are supplied with the appropriately sized PVC starter piece for venting. For starter pieces
intended for polypropylene or AL29-4C venting, contact the vent manufacturer directly.

PR1 04/08/2014 AERCO International, Inc. •100 Oritani Dr. •Blauvelt, New York 10913 •Phone: [phone] Page 7of 20
GF-146-V
TAG-0075_0B
GF
-
146
TAG
-
0075_0B
AM Series Venting
Application Guide
2. COMBUSTION AIR SYSTEM
Air openings to combustion area must not be obstructed. Using Table 3, air openings may be
specified so that adequate combustion air can be maintained.
2.1. COMBUSTION AIR REQUIREMENTS
•Non-Motorized louvers and grilles must be fixed in an open position.
•Minimum screens mesh size shall not be smaller than 1/4” mesh.
Table 3shows the minimum required air openings in square inches freely communicating with the
outdoors for boiler room combustion and ventilation air for each boiler. For multiple boiler installations,
sum the openings for the specific boiler sizes.
Table 3: Minimum Required Air Openings Freely Communicating With the
Outdoors for Boiler Room Combustion & Ventilation Air
Model No.
Two Sealed Combustion or
Vertical Ducts Each having
an opening in sq. in.
(sq.cm) of:
Two Horizontal Ducts Each
having an opening in square
inches of
Single Permanent
Opening
Boilers and Water Heaters
AM 399 100 in2200 in2133 in2
AM 500 125 in2250 in2167 in2
AM 750 188 in2375 in2250 in2
AM 1000 250 in2500 in2333 in2
•The combustion air must be free of chlorine, halogenated hydrocarbons or other chemicals
that can become hazardous when used in gas-fired equipment. Common sources of these
compounds are swimming pools, degreasing compounds, plastic processing, and
refrigerants. Whenever the environment contains these types of chemicals, combustion air
MUST be supplied from a clean area outdoors for the protection and longevity of the
equipment and warranty validation.
•Ventilation of the boiler room must be adequate enough to provide sufficient air to properly
support combustion.
•When combustion air is brought from outside the building, the boiler room shall be provided
with two permanent openings, one commencing 12 inches from the top and one
commencing within 12 inches from the bottom of the room (see Figure 2). The openings
shall communicate directly, or by ducts, freely with the outdoors. One of the following
methods must be made to provide adequate air for ventilation and combustion.
oWhen directly communicating with the outdoors, each opening shall have a minimum free
area of 1 square inch per 4,000 BTU per hour of total input rating of all equipment in the
room.
oWhen communicating with the outdoors by means of vertical ducts, each opening shall
have a minimum free area of 1 square inch per 4,000 BTU per total input rating of all
appliances in the room.

Page 8of 20 AERCO International, Inc. •100 Oritani Dr. •Blauvelt, New York 10913 •Phone: [phone] AM1 04/08/2014
AM Series Venting
Application Guide
GF-146-V
TAG-0075_0B
oIf horizontal ducts are used, each opening and duct shall have a minimum free area of 1
square inch per 2,000 BTU per hour of total input rating of all appliances in the room.
Figure 2: Combustion-Air Makeup-Air Vent Location
•When calculating free area using louvers and grilles, the required size of the openings for
combustion, ventilation, and dilution air shall be based on the total free area of each opening.
•If the free area through a designed louver or grille is known, it shall be used in calculating the
size of the opening required to provide the free area specified.
•If the louver and grille design free areas are not known, the following will be assumed for
wooden louvers a 25 percent free area, and for metal louvers and grilles a 75 percent free
area opening.
•When terminating the combustion air through the roof:
oCombustion air inlet must be 3 ft.below any vent outlet within 10 ft. See Figure 3.
oCombustion air inlet must also face away from the vent outlet. See Figure 3.

PR1 04/08/2014 AERCO International, Inc. •100 Oritani Dr. •Blauvelt, New York 10913 •Phone: [phone] Page 9of 20
GF-146-V
TAG-0075_0B
GF
-
146
TAG
-
0075_0B
AM Series Venting
Application Guide
Figure 3: Combustion Air Roof Termination Locations
•All inlet air ducts must be sealed air tight.
•When using sealed combustion, the combustion air inlet and vent outlet must be located on
the same surface (same wall, roof, etc.). See Figures 4. This is required so that equal pressure
zones are acting on both the air inlet and vent outlet. This makes the installation a balanced
vent system, which helps maintain stable combustion characteristics.
Figure 4: Sealed Combustion Air Inlet and Vent Outlet Locations (Wall & Roof)

Page 10 of 20 AERCO International, Inc. •100 Oritani Dr. •Blauvelt, New York 10913 •Phone: [phone] AM1 04/08/2014
AM Series Venting
Application Guide
GF-146-V
TAG-0075_0B
2.2. COMBUSTION AIR PIPE SIZING
The maximum length is the combined length of straight horizontal and vertical runs, and the equivalent
straight length of fittings. The required lengths for each boiler are shown in Tables 4and 5, below.
Table 4: Required and Maximum Combustion Air Run Lengths
AM 399 AM 500 AM 750 AM 1000
Number of Modules 2 2 3 4
Combustion Air Diameter 4” 6”
Maximum Combustion Air
Equivalent Feet (Meters) 60 ft.
Table 5: Maximum Combustion Air Run Lengths
Model No. Pipe
Diameter
Equivalent Pipe Lengths Examples
Maximum
Length
Equivalent
Ft (m)
Sharp 90°
Elbow
Equiv. Ft (m)
Sweep 90°
Elbow
Equiv. Ft (m)
45° Elbow
Equiv. Ft (m)
AM 399
AM 500
4”
(102 mm)
10 ft.
(3.05 m)
5 ft.
(1.5 m)
5 ft.
(1.5 m)
60 ft.
(30.5 m)
AM 750
AM 1000
6”
(152 mm)
10 ft.
(3.05 m)
5 ft.
(1.5 m)
5 ft.
(1.5 m)
60 ft.
(30.5 m)
The maximum pressure drop of the vent is also 60 equivalent feet (30.5 m). See Section 3.4. Note
that this does NOT mean the allowed combined pressure drop between the vent and combustion air
is 120 equivalent feet (61 m). That is, the vent cannot go above 60 equivalent feet (30.5 m), even if
the combustion air is less than 60 equivalent feet, and vice versa.
Examples:
1. Acceptable:.
A 30 foot length of combustion air pipe and 1 sharp 90° elbow plus two termination 90° elbows
add up to 30 ft.+ 10 ft.+ (2 x 10 ft.) = 60 equivalent ft.
2. NOT Acceptable:
A 30 foot length of combustion air pipe and 2 sharp 90° elbows plus two termination 90°
elbows add up to 30 ft.+ (2 x 10 ft.) + (2 x 10 ft.) = 70 equivalent ft.(excessive legth).

PR1 04/08/2014 AERCO International, Inc. •100 Oritani Dr. •Blauvelt, New York 10913 •Phone: [phone] Page 11 of 20
GF-146-V
TAG-0075_0B
GF
-
146
TAG
-
0075_0B
AM Series Venting
Application Guide
2.3. COMMON COMBUSTION AIR PIPE SIZING
Refer to Figures 6and 7for typical common combustion air inlet installation. The maximum length is
the sum of the equivalent straight length of horizontal runs, vertical runs, and fittings of the
individual combustion air connector and the common combustion air pipe. The required diameter
lengths for a given total BTU/hr.Inputsare shown in Tables 6and 7, below.
Table 6: Typical Common Combustion Air Run Lengths
Total BTU/hr. Input
(up to and
including)
800,000 1,000,000 1,500,000 2,000,000 2,500,000 3,000,000 4,000,000
Common Vent
Diameter 6” 6” 8” 8” 8” 10” 12”
Maximum Vent 
Individual
Connector plus
Common Vent
Equivalent Feet (M)
60 feet
Table 7: Typical Common Combustion Air Run Lengths
Total
BTU/hr
Input
(up to and
including)
Common
Vent
Diameter
Equivalent Common Vent Lengths Examples
Maximum Length 
Individual Connector
plus
Common Vent
Equivalent Ft (m)
Sharp 90°
Elbow
Equiv. Ft (m)
Sweep 90°
Elbow
Equiv. Ft (m)
45° Elbow
Equiv. Ft (m)
WYE or
Termination
Tee or
Rain Cap
Equiv. Ft (m)
800,000 6” 10 feet 5feet 5feet 5 feet 60 feet
1,000,000 6” 10 feet n/a 5 feet 5 feet 60 feet
1,500,000 8” 10 feet n/a 5 feet 5 feet 60 feet
2,000,000 8” 10 feet n/a 5 feet 5 feet 60 feet
2,500,000 8” 10 feet n/a 5 feet 5 feet 60 feet
3,000,000 10” 10 feet n/a 5 feet 5feet 60 feet
4,000,000 12” 10 feet n/a 5 feet 5 feet 60 feet
The chart above shows equivalent pipe lengths of the fittings for the common combustion air pipe.
See section 2.2 for equivalent lengths for fittings for the individual boiler connector.
The maximum equivalent length shown is the sum of the equivalent length of the longest individual
connector plus the equivalent length of the common combustion air pipe. If the maximum
equivalent length exceeds 60 equivalent feet, contact your AERCO sales representative or
AERCO International for design assistance and approval. It is important to use a WYE as a means
to connect the individual combustion air pipe into the common combustion air pipe. This will
ensure the least amount of pressure drop. Do NOT use a TEE, 90°, or 45° elbow.
The maximum pressure drop of the vent is also 60 equivalent feet. Note that this does NOT
mean that the allowed combined pressure drop between the vent and combustion air is 120
equivalent feet. That is, the vent cannot go above 60 equivalent feet, even if the combustion air
is less than 60 equivalent feet, and vice versa.

Page 12 of 20 AERCO International, Inc. •100 Oritani Dr. •Blauvelt, New York 10913 •Phone: [phone] AM1 04/08/2014
AM Series Venting
Application Guide
GF-146-V
TAG-0075_0B
Figure 5: Typical Common Combustion Air Inlet installation Through Roof
Figure 6: Typical Common Combustion Air Inlet installation Through Wall

PR1 04/08/2014 AERCO International, Inc. •100 Oritani Dr. •Blauvelt, New York 10913 •Phone: [phone] Page 13 of 20
GF-146-V
TAG-0075_0B
GF
-
146
TAG
-
0075_0B
AM Series Venting
Application Guide
3. VENT SYSTEM
Correct boiler venting is crucial for proper operation. Being a condensing boiler, combustion gases
are discharged at a very low temperature. It is therefore necessary for the venting system to be
impermeable to combustion products and condensate and to be made of corrosion resistant
materials. Typical Category IV venting and sealed combustion illustrations are shown in Figures 5
and 6. The various funnel joints shall be well sealed and/or equipped with suitable gaskets, in order
to avoid any condensate drain and/or air intake. Ensure that the boiler vent’s section and height
conform to national and local regulations (see Section 1.1 in this guide).
For boilers designed for connection to gas vents or chimneys, vent installations shall be in
accordance with Part 7, Venting of Equipment, of the National Fuel Gas Code, ANSI Z223.1, or
Section 7, Venting Systems and Air Supply for Appliances, of the CAN/CGA B149, Installation
Codes, or applicable provisions of the local building codes.
The vent system for the AM Series must be installed in accordance with AERCO’s installation
instructions described in this guide.
CAUTION!
For Category IV Boilers, the vents must be installed to prevent
accumulation of condensate, and have means provided for drainage of
condensate.
3.1. VENT INSTALLATION
•The boilers covered in this section are design-certified as Category IV for venting, only when
they are installed with manufacturer specified vent system components and installation
practices.
•Install supplied vent pipe starter piece at the boiler vent connector and work toward the vent
cap.
•Vent pipe fittings and connectors serving appliances vented by natural draft shall not be
connected into any portion of mechanical draft systems operating under positive pressure.
•Horizontal runs shall be sloping upwards not less than 1/4 inch per foot
(21 mm/m) from the boiler to the vent termination.
•Horizontal portions of the venting system shall be supported to prevent dips or sags where
condensate could collect.
•Rigidly support vent pipe every 5 feet and at the elbows. Plumber straps may be used.
•ALL vent pipe and fittings must be installed with appropriate air space clearances to
combustibles. These air space clearances apply to indoor or outdoor vents, whether they are
open, enclosed, horizontal or vertical or pass through floors, walls, roofs, or framed spaces.
The appropriate air space clearances should be observed between joists, studs, sub floors,
plywood, drywall, or plaster enclosures, insulated sheathing, rafters, roofing, and any other
combustible material. The minimum air space clearance also applies to electrical wires and
any kind of building insulation. For horizontal runs, keep 4 inch and 6 inch vent piping from
any contact with any combustible material, electric wires, and building materials.

Page 14 of 20 AERCO International, Inc. •100 Oritani Dr. •Blauvelt, New York 10913 •Phone: [phone] AM1 04/08/2014
AM Series Venting
Application Guide
GF-146-V
TAG-0075_0B
Figure 7: Connection of Exhaust Manifold to Flue Exhaust Outlet
Figure 8: Properly Installed Flue and Intake Piping Starter Piece
WARNING!
Do not insulate or otherwise wrap vent pipe or fittings.

PR1 04/08/2014 AERCO International, Inc. •100 Oritani Dr. •Blauvelt, New York 10913 •Phone: [phone] Page 15 of 20
GF-146-V
TAG-0075_0B
GF
-
146
TAG
-
0075_0B
AM Series Venting
Application Guide
Specific installation regulations for side-wall and vertical terminations, respectively, are described in
the following two sections (Sections 3.2 and 3.3).
3.2. INSTALLATION PROCEDURE FOR VENTING SYSTEM THROUGH
WALLS
The minimum distances from adjacent public walkways, adjacent buildings, operable windows and
building openings shall not be less that those values specified in the National Fuel Gas Code, ANSI
Z223.1 and/or CAN/CGA B149, Installation Codes.
Minimum clearance of 4 feet horizontally from, and in no case above or below, unless a 4-foot (1.22
m) horizontal distances is maintained, from electric meters, gas meters, regulators and relief
equipment.
Refer to the notes below and Figure 9, when determining the location of the vent outlet.
a) At least 12 inches above finished grade, or at least 12 inches above the normally expected
snow accumulation level in geographical areas where snow accumulates. With a vent
termination clearance of at least 4 feet from any air openings into a building.
b) In Massachusetts, when side-wall venting is used, the vent termination must be located a
minimum of 4 feet above grade.
c) At least 3 feet (92 cm) above any forced air inlet located within 10 feet.
d) At least 4 feet horizontally from electric meters, gas meters, regulators and relief equipment.
e) For horizontal runs, keep vent pipes away from any combustible material, electric wires, and
building insulation.
f) Do not terminate vent over public walkways or over an area where condensate or vapor could
create a nuisance or hazard or could be detrimental to the operation of regulators, relief
valves, or other equipment.
g) Do not locate the vent termination too close to shrubbery as flue products may stunt growth or
kill them.
h) Some building materials may be affected by flue products expelled near unprotected surfaces.
Sealing or shielding of exposed surfaces with a corrosion resistant material (such as aluminum
sheet) may be required to prevent staining or deterioration.
See the National or Canadian Codes listed at the beginning of these instructions for additional
information on termination location.

Page 16 of 20 AERCO International, Inc. •100 Oritani Dr. •Blauvelt, New York 10913 •Phone: [phone] AM1 04/08/2014
AM Series Venting
Application Guide
GF-146-V
TAG-0075_0B
Figure 9: Determining Location of Vent Outlet

PR1 04/08/2014 AERCO International, Inc. •100 Oritani Dr. •Blauvelt, New York 10913 •Phone: [phone] Page 17 of 20
GF-146-V
TAG-0075_0B
GF
-
146
TAG
-
0075_0B
AM Series Venting
Application Guide
3.3. INSTALLATION PROCEDURE FOR VERTICAL VENTING
WARNING!
Do not insulate or otherwise wrap vent pipe or fittings. Follow the vent
pipe manufacturer’s installation instructions for vertical venting.
WARNING!
•Non-motorized louvers and grilles must be fixed in an open position.
•Minimum screens mesh size shall not be smaller than ¼ inch mesh.
The Vent Termination Must Be Located As Follows:
a. Unit is certified for zero clearance to combustible materials.
b. Combustion air inlet must be 3 feet below any vent outlet that is within 10 feet. See Figure 10.
c. Vertical terminations shall extend at least 3 feet (0.9 m) above the highest point where it passes
through a roof of a building and at least 2 feet (0.6 m) higher than any portion of the building
within a horizontal distance of 10 feet (3 m). Terminations that extend more than 2 feet above
the roof must be laterally supported.
d. Combustion air inlet must also face away from the vent outlet. See Figure 10.
e. Use vent pipe manufacturers vent cap, fire stop, support collar, roof flushing, and storm collar.
LESS THAN 10 FT
(305 CM)
MORE THAN 10 FT
(305 CM)
10 FT
(305 CM)
NOTE:
NO HEIGHT ABOVE RIDGE REQUIRED FOR
VENT TERMINATION WHEN DISTANCE FROM
RIDGE IS MORE THAN 10 FT (305 CM).
IF DISTANCE FROM RIDGE IS LESS THAN 10 FT
(305 CM), TERMINATION MUST BE A MIN. OF 2
FT ABOVE RIDGE.
RIDGE
3 FT (91 CM)
MINIMUM
3 FT (91 CM)
MINIMUM
2 FT (61 CM) MIN.
Figure 10: Vent Termination Locations

Page 18 of 20 AERCO International, Inc. •100 Oritani Dr. •Blauvelt, New York 10913 •Phone: [phone] AM1 04/08/2014
AM Series Venting
Application Guide
GF-146-V
TAG-0075_0B
3.4. VENT PIPING SIZE
The maximum length is the combined length of straight horizontal and vertical runs, and the
equivalent straight length of fittings. The required lengths for each boiler are as shown on Tables 9
and 10.
Table 9: Required and Maximum Combustion Air Run Lengths
AM 399 AM 500 AM 750 AM 1000
Number of
Modules 2 2 3 4
Combustion Air
Diameter
4” 6”
Maximum
Combustion Air
Equivalent Feet
(Meters)
60 ft.
Table 10: Maximum Combustion Air Run Lengths
Model No. Pipe
Diameter
Equivalent Pipe Lengths Examples Maximum
Length
Equivalent
Ft (m)
Sharp 90°
Elbow
Equiv. Ft (m)
Sweep 90°
Elbow
Equiv. Ft (m)
45° Elbow
Equiv. Ft (m)
AM 399
AM 500
4”
(102 mm)
10 ft.
(3.05 m)
5 ft.
(1.5 m)
5 ft.
(1.5 m)
60 ft.
(30.5 m)
AM 750
AM 1000
6”
(152 mm)
10 ft.
(3.05 m)
5 ft.
(1.5 m)
5 ft.
(1.5 m)
60 ft.
(30.5 m)
The maximum pressure drop of the combustion air piping is also 60 equivalent feet. See Section
2.2. Note that this does NOT mean the allowed combined pressure drop between the vent and
combustion air is 120 equivalent feet. That is, the vent cannot go above 60 equivalent feet, even if
the combustion air is less than 60 equivalent feet, and vice versa.
EXAMPLES:
1. A 40 foot length of vent pipe and 1 sharp 90° elbow plus a termination rain cap add up to 40 ft. +
10 ft.+ 10 ft.= 60 equivalent ft.
2. A 30 foot length of vent pipe and 2 sharp 90° elbows plus a termination rain add up to 30 ft.+ (2 x
10 ft.) + 10 ft.= 50 equivalent ft.

PR1 04/08/2014 AERCO International, Inc. •100 Oritani Dr. •Blauvelt, New York 10913 •Phone: [phone] Page 19 of 20
GF-146-V
TAG-0075_0B
GF
-
146
TAG
-
0075_0B
AM Series Venting
Application Guide
3.5. COMMON VENT PIPING SIZE
Refer to Figures 2, 3, 5, and 6 in Section 2 for typical common vent installations. The maximum
length is the sum of the equivalent straight length of horizontal runs, vertical runs, and fittings of the
individual vent connector and the common vent pipe. The maximum length is the combined length
of straight horizontal and vertical runs, and the equivalent straight length of fittings. The required
diameters for a given AM Series total BTU/hr. input are shown in Tables 11 and 12.
Table 11: Typical Common Combustion Air Run Lengths
Total BTU/hr. Input
(up to and
including)
800,000 1,000,000 1,500,000 2,000,000 2,500,000 3,000,000 4,000,000
Common Vent
Diameter 6” 6” 8” 8” 8” 10” 12”
Maximum Vent 
Individual
Connector plus
Common Vent
Equivalent Feet (M)
60 feet
Table 12: Typical Common Combustion Air Run Lengths
Total
BTU/hr
Input
(up to and
including)
Common
Vent
Diameter
Equivalent Common Vent Lengths Examples
Maximum Length 
Individual Connector
plus
Common Vent
Equivalent Ft (m)
Sharp 90°
Elbow
Equiv. Ft (m)
Sweep 90°
Elbow
Equiv. Ft (m)
45° Elbow
Equiv. Ft (m)
WYE or
Termination
Tee or
Rain Cap
Equiv. Ft (m)
800,000
6” 10 feet 5feet 5 feet 5 feet 60 feet
1,000,000
6” 10 feet n/a 5 feet 5 feet 60 feet
1,500,000 8” 10 feet n/a 5feet 5 feet 60 feet
2,000,000
8” 10 feet n/a 5 feet 5 feet 60 feet
2,500,000 8” 10 feet n/a 5 feet 5 feet 60 feet
3,000,000
10” 10 feet n/a 5 feet 5feet 60 feet
4,000,000
12” 10 feet n/a 5 feet 5 feet 60 feet
NOTES:
•The chart above shows equivalent pipe lengths of the fittings for the common vent pipe. See
section 3.4 for equivalent lengths for fittings for the individual boiler connector.
•The maximum equivalent length shown is the sum of the equivalent length of the longest individual
connector plus the equivalent length of the common vent pipe. If the maximum equivalent
length exceeds 60 equivalent ft., contact your AERCO sales representative or AERCO
International for design assistance and approval.
•It is important to use a WYE as a means to connect the individual vent into the common vent pipe.
This will ensure the least amount of pressure drop. Do NOT use a TEE, 90°, or 45° elbow.

Page 20 of 20 AERCO International, Inc. •100 Oritani Dr. •Blauvelt, New York 10913 •Phone: [phone] AM1 04/08/2014
AM Series Venting
Application Guide
GF-146-V
TAG-0075_0B
© AERCO International, Inc., 2014
www.aerco.com
The maximum pressure drop of the combustion air piping is also 60 equivalent feet (30.5 m). See
Section 2.3. Note that this does NOT mean that the allowed combined pressure drop between the
vent and combustion air is 120 equivalent feet. That is, the vent cannot go above 60 equivalent
feet,even if the combustion air is less than60 equivalent feet, and vice versa.
Example:
The vent system of two AM 1000 boilers (2 x 1,000,000 BTU/hr.= 2,000,000 BTU/hr.) consists of 30
foot length of vent pipe and 2 sharp 90° elbows. A termination cap is also installed. Each individual
vent connector consists of 5 ft.straight run and one WYE.
•Common Vent pipe: 30 ft.+ (2 x 10ft) + 5 ft.= 50 equivalent ft.(15.2 m)
•Individual vent connector: 5 ft.+ 5 ft.= 10 equivalent ft.(3.0 m)
•Total Vent equivalent length: 50ft.+ 10 ft. = 60 (18.2 m)
60 equivalent ft.: OK to use 8” Common vent piping and 6” individual connectors.
Change Log:
Date Description Changed By
04/08/2014 Rev-B: Corrected per AM.Curtis Harvey
