Lochinvar POWER-FIN PB/PF 502 Application guide

PB1-PF1-RP-04
37
12
8
13
14
2
5
35
44
45
30
31
32
33
34
Power-Fin®
Heating Boilers & Hot Water Supply Boilers
PB/PF 502 thru 1302
Replacement Parts List
PARTS & SERVICE DEPARTMENT
Nashville, Tennessee
615-889-8900 • Fax: [phone]
www.Lochinvar.com
43
1

22
20
18
17
21
19
40
10
11
38
26
41
9
24
23
42
27
7
15
36
39
25
40
28
29
19
20
16
21
3
4
2
6
46
CONTROL PANEL ASSEMBLY
GAS TRAIN ASSEMBLIES
F9
M9
HEAT EXCHANGER ASSEMBLY
2 of 4
PB1-PF1-RP-04

3 of 4
PB1-PF1-RP-04
ITEM
NO.
PART
NO. DESCRIPTION MODEL NO.
CONTROLS & GAUGES
1 RLY2114 CONNECTION BOARD ALL
2 RLY2210 BOARD, CONTROL ,USER INTERFACE ALL
3 RLY2100 BOARD, CONTROL, MAIN ALL
4 RLY2706 PUMP RELAY ALL
5 FAN3727 FAN, COMBUSTION AIR ALL
6 SWT2006 ON / OFF SWITCH ALL
7 TST2032 THERMOSTAT SENSOR ALL
8 GTP2900 GAUGE, TEMP AND PRESSURE PB
9 HLC2510 THERMOSTAT, HI LIMIT 200 DEGREE PF
10 HLC2701 THERMOSTAT, HI LIMIT W/ AUTO RESET ALL
11 PLT3400 IGNITOR, HOT SURFACE ALL
12 RLV2001 RELIEF VALVE, PRESSURE ONLY PB 502-1002
12 RLV2003 RELIEF VALVE, PRESSURE ONLY PB 1302
12 RLV2007 RELIEF VALVE, TEMPERATURE & PRESSURE PF
13 WTR2040 FLOW SWITCH ALL
14 PRS2431 SWITCH, LOW AIR 502 - LP - F9
14 PRS2432 SWITCH, LOW AIR 502 - NAT - F9
14 PRS2433 SWITCH, LOW AIR 752 - LP - F9
14 PRS2434 SWITCH, LOW AIR 752 - NAT - F9
14 PRS2435 SWITCH, LOW AIR 1002 - LP - F9
14 PRS2436 SWITCH, LOW AIR 1002 - NAT - F9
14 PRS2437 SWITCH, LOW AIR 1302-F9
14 PRS30002 SWITCH, LOW AIR BEFORE D08 502 - LP - M9
14 PRS20008 SWITCH, LOW AIR AFTER D08 502 - LP - M9
14 PRS30001 SWITCH, LOW AIR BEFORE D08 502 NAT & 752-1302-M9 NAT/LP
14 PRS20006 SWITCH, LOW AIR AFTER D08 502 NAT & 752-1302-M9 NAT/LP
GAS TRAIN ASSEMBLIES
15 BNR3713 BURNER 502
15 BNR3714 BURNER 752
15 BNR3715 BURNER 1002
15 BNR3716 BURNER 1302
16 VAL3417 VALVE, GAS 502-M9
16 VAL3418 VALVE, GAS 752-M9
16 VAL3419 VALVE, GAS 1002-M9
16 VAL3420 VALVE, GAS 1302-M9
17 VAL2131 VALVE, GAS DIAPHRAM 1" 502-F9 NAT & LP
17 VAL2132 VALVE, GAS DIAPHRAM 1 1/4" 752-1002-1302 - NAT & LP - F9
18 VAL2133 VALVE, MAIN GAS 1" 502- NAT - F9
18 VAL2727 VALVE, MAIN GAS 1" 502 - LP - F9
18 VAL2134 VALVE, MAIN GAS 1 1/4" 752-1002-1302 - NAT - F9
18 VAL2726 VALVE, MAIN GAS 1 1/4" 752-1002-1302 - LP - F9
19 VAL2722 VALVE, VENTURI 502-M9
19 VAL2723 VALVE, VENTURI 752-1002-M9
19 VAL2724 VALVE, VENTURI 1302-M9
19 MAN2149 VALVE, VENTURI ALL F9
20 GAC2029 GAS COCK 502
20 GAC2030 GAS COCK 752-1002-1302
21 VAL2207 VALVE, BALL ALL 502
21 VAL2208 VALVE, BALL 752-1002-F9 & 752-1002-1302-M9
22 ORF2762 ORIFICE, BURNER 502 - NAT - F9
22 ORF2763 ORIFICE, BURNER 752 - NAT - F9
22 ORF2764 ORIFICE, BURNER 1002 - NAT - F9
22 ORF2765 ORIFICE, BURNER 1302 - NAT - F9
22 ORF2766 ORIFICE, BURNER 502 - LP- F9
22 ORF2767 ORIFICE, BURNER 752 - LP - F9
22 ORF2768 ORIFICE, BURNER 1002 - LP - F9
22 ORF2769 ORIFICE, BURNER 1302 - LP -F9
PLEASE HAVE MODEL NUMBER AND SERIAL NUMBER WHEN ORDERING PARTS

©-9/09-Printed in U.S.A.
4 of 4
PB1-PF1-RP-04
ITEM
NO.
PART
NO. DESCRIPTION MODEL NO.
HEAT EXCHANGER ASSEMBLIES
23 HEX3228 HEAT EXCHANGER (HLW) PF502
23 HEX3236 HEAT EXCHANGER (H) PB502
23 HEX3229 HEAT EXCHANGER (HLW) PF752
23 HEX3237 HEAT EXCHANGER (H) PB752
23 HEX3230 HEAT EXCHANGER (HLW) PF1002
23 HEX3238 HEAT EXCHANGER (H) PB1002
23 HEX3231 HEAT EXCHANGER (HLW) PF1302
23 HEX3239 HEAT EXCHANGER (H) PB1302
24 JKH2016 V BAFFLE (20 REQ.) 502
24 JKH2017 V BAFFLE (20 REQ.) 752
24 JKH2018 V BAFFLE (20 REQ.) 1002
24 JKH2019 V BAFFLE (20 REQ.) 1302
25 JKP6569 V BAFFLE STRAP (3 REQ.) ALL
26 TST2300 HIGH LIMIT BULBWELL ALL
27 TST2306 THERMOSTAT BULBWELL 3/8" ALL
28 DRV4003 DRAIN PIPE ASSEMBLY ALL
29 WTR3718 HEAT EXCHANGER FLANGE ALL
JACKET / DOOR ASSEMBLIES
30 FAN3027 JACKET TOP, WITH VENTILATION FAN ALL
31 JKH6742 JACKET, OUTER FRONT UPPER LEFT ALL
32 JKH6738 JACKET, OUTER FRONT LOWER 502
32 JKH6739 JACKET, OUTER FRONT LOWER 752
32 JKH6740 JACKET, OUTER FRONT LOWER 1002
32 JKH6741 JACKET, OUTER FRONT LOWER 1302
33 JKH5086 JACKET, OUTER RIGHT 502
33 JKH5087 JACKET, OUTER RIGHT 752
33 JKH5088 JACKET, OUTER RIGHT 1002
33 JKH5089 JACKET, OUTER RIGHT 1302
34 JKH6989 JACKET, OUTER LEFT 502
34 JKH6990 JACKET, OUTER LEFT 752
34 JKH6991 JACKET, OUTER LEFT 1002
34 JKH6992 JACKET, OUTER LEFT 1302
MISCELLANEOUS
35 FAN2027 FAN, VENTILATION ALL
36 MSC2731 BURNER SIGHT GLASS ALL
37 FIL2001 AIR FILTER ALL
38 GKT2012 IGNITOR GASKET ALL
39 GKT2033 FLANGE GASKET ALL
40 GKT2034 BURNER/BLOWER GASKET ALL
41 GKT2079 BURNER/ HEX GASKET ALL
42 GKT2705 HEX/DIVIDER PANEL GASKET ALL
43 MSC2975 CONDENSATE TRAP ALL
44 RLY2902 RELAY, LOUVER ALL
45 TST3012 FLUE SENSOR ALL
46 WTR2530 LOW WATER CUT-OFF, MANUAL RESET (OPTIONAL) PRIOR TO H08H00211095 ALL
46 WTR30000 LOW WATER CUT-OFF, MANUAL RESET (OPTIONAL) BEGINNING H08H00211095 ALL
46 WTR2528 LOW WATER CUT-OFF, AUTO RESET (OPTIONAL) PRIOR TO H08H00211095 ALL
46 WTR30001 LOW WATER CUT-OFF, AUTO RESET (OPTIONAL) BEGINNING H08H00211095 ALL
- WTR2222 LOW WATER CUT-OFF PROBE (OPTIONAL) ALL
- WTR20000 LOW WATER CUT-OFF BOOT (OPTIONAL) ALL
- FUS2001 FUSE, 3.15A 5 X 22MM ALL
- FUS2002 FUSE, 5A 5 X 22MM ALL
- FUS2003 FUSE, 1.6A 5 X 20MM ALL
- PUM3013 PUMP ALL PF
- GKT2053 JACKET GASKET ALL
- GKT30000 GASKET, PVC 1/4 X 5/8 X 25' ALL
- KIT3115 KIT, OUTDOOR AIR RESET ALL
- KIT3109 KIT, ALARM ON ANY FAILURE WITH BELL ALL
- KIT3110 KIT, MANUAL RESET LOW WATER CUTOFF PRIOR TO H08H00211095 ALL
- KIT30041 KIT, MANUAL RESET LOW WATER CUTOFF BEGINNING H08H00211095 ALL
- KIT40020 KIT, TANK SENSOR ALL PF
- KIT40021 KIT, SYSTEM SENSOR ALL PB
PLEASE HAVE MODEL NUMBER AND SERIAL NUMBER WHEN ORDERING PARTS
