AeroGT Labs RN200A User manual

Quick start for RN200A mmWave OTA Test System
AeroGT RN200A

1AeroGT ·RN200A 2
AeroGT ·RN200A
Product Overview
Unpacking
01
RN200A has a compact size, large quiet zone, and is an all-in-one mmWave test system. It is mainly used
in 5G wireless devices and mmWave radar transceiver performance test. The test scenario is 󽗊exible
and can be used for desktop testing. As an all-in-one test platform, the RN200A supports many functions:
arbitrary vector signal generation (VSG), arbitrary vector signal analysis (VSA), passive/active antenna
measurement, spectrum analysis, and S21 amplitude/phase measurements, as well as signal quality
analysis. It also can be upgraded to perform mmWave radar/module phase and amplitude calibration and
target simulation. The test software provides a convenient development platform that enable the running of
user-dened tests.
Precautions of Safety
Working Conditions
During the installation and usage of this product, please strictly comply with all electrical safety
regulations of the manufacturer country and local region.
Please make sure that the device is placed stably and rmly in the use environment.
Avoid placing the product in a vibration or high shock environment.
Keep away from the electromagnetic interference when using the product.
Do not place the product in the presence of water or other liquids.
Do not use the product in extremely hot, cold, dusty, corrosive or high humidity environments.
If the product does not work properly, please contact the post-sales service, and do not disassemble
the product in any way (manufacturer does not assume any responsibility for problems caused by
unauthorized repairs).
①
②
③
④
⑤
⑥
⑦
Operating
Temperature 10~30℃
Relative
Humidity <80%
Power
Supply
110V/AC
50/60Hz
Max. DUT
Weight <10kg
Table 1 Hardware Operating Conditions Figure 1 RN200A mmWave OTA Test System
Figure 2 RN200A mmWave OTA Test System Figure 3 110V 10A Power Cord
Figure 4 LAN Cable Figure 5 USB Type-A to USB Type-B Cable
02
When receiving the newly delivered product, check
whether the packing wooden box is in good condition
immediately. Please use tools such as electric drill
or screwdriver to unscrew the wooden box. Rough
unpacking will cause damage to the product. Table 2 List of Attachments
Product Name Quantity
RN200A mmWave OTA Test
System 1
110V 10A Power Cord 1
LAN Cable 1
USB Type-A to USB Type-B Cable 1

3AeroGT ·RN200A 4
AeroGT ·RN200A
03
Dimensions 620mm ×950mm ×700mm
Weight 120kg
Exterior Color Silver
Quiet Zone 200mm ×200mm ×200mm
Table 3 Hardware Introduction
Height 950mm
Width 700mm
Communication
Panel
Figure 6 RN200A mmWave OTA Test System
Communication Panel
Power Button: Power on and off the hardware, after
system booting, the button light turns green.
Signal Indicator: Refer to Table 4 for status description
Instrument Switch: Turn to "Internal Instrument" to use the
built-in test module; turn to "External Instrument" to use an
external test instrument.
Power Port: Power supply, supply the power to the RN200A.
LAN Port: Connect the device to the intranet/internet
through this port, device can be connected with a control
PC via a LAN cable.
External RF Ports: For external instrument connection,
polarization can be switched.
USB Port: Connect the control PC with this device via
this interface, and check the system status if necessary.
Table 4 Description of Signal
Indicator Status
①
①
②
②
③
③
④
④
⑤
⑤
⑥
⑥
⑦
⑦
Indicator
Color Status Description
Red Steady red light
indicates an error
Yellow Blinking yellow light
indicates system booting
Green
Steady green light
indicates that the device
is normal and can work
normally
Blue
Steady blue light
indicates that the
external instrument is
under use
Figure 7 RN200A Communication Panel
Hardware Introduction
Length 620mm

5AeroGT ·RN200A 6
AeroGT ·RN200A
Take the RN200A out of the packing box and place it on a 󽗊at desktop, which should bear more than 120kg.
Open the door and take out the No. 1 cotton
block directly.
First move the No. 3 cotton block to the left
to the empty position, and then take it out.
Pull up the No. 2 cotton block rst and then pull
it out.
First take out the No. 4 cotton block directly,
and then take out the No. 5 cotton block.
①
③
②
④
04 Installation
Connect the power cord of the RN200A. Plug the other end of the power cord into a
power outlet.
Connect the LAN cable to the LAN port of the
RN200A.
Connect the other end of the LAN cable to a
router or network switch, it can also be directly
connected to the LAN port of the system
computer.
⑤ ⑥
⑦ ⑧

7AeroGT ·RN200A 8
AeroGT ·RN200A
05
Use the Built-in Instrument
Check the connection of the power cord
and turn the instrument switch to "Internal
Instrument".
Press the power button, the button light will
turn green; (Note: The system restart interval
is 30s, please ensure a fully powered off
before the system reboot!).
The yellow light of the signal indicator turns
on and 󽗊ashes, indicates that the internal test
module is booting up.
① ②
③ ④ After 20 seconds, the green light is turned on,
indicates that the system has be started up
successfully and can be used normally.
System Power On
Website
Please visit www.generaltest.com for related documentation and technical support.
Send email to [email protected] for problem report, the technical engineer will provide a solution
accordingly and timely.
Email
Contact us directly by ([phone].
Hotline
06
07
Trouble Description Possible Reasons Solutions
Client software can't nd the
RN200A
The RN200A does not startup
normally or the LAN cable is not
connected correctly
The computer and the RN200A are
not congured in the same local
area network
Observe the signal indicator
is abnormal or not and check
the LAN cable connection
Congure the system
computer and RN200A to
the same local area network
Turn table reports error after
RN200A is restarted
Insufcient power shut off for the
turntable controller
Fully power off and wait 30s
before turning power on
Table 5 Trouble Shooting
Trouble Shooting
Technical Support
①①
②②
