Aeropro RP7495 User manual

1
Heavy Duty 1Air Impact Wrench RP7495
INSTRUCTION MANUAL
Contain:
◎Technical Data
◎Important safety rules
◎Operating Instructions
◎Maintenance
◎Parts List
Heavy Duty 1Air Impact Wrench
Model No.: RP7495 Http://www.aeroprotools.com
IMPORTANT:
Upon receipt of the product,
read and follow all safety rules,
operating instructions before first use it.
And retain this manual forfuture reference.
2016

2
Heavy Duty 1Air Impact Wrench RP7495
※Technical Data
Square drive………………………………………………………………………………………………….…..1”
Capacity Bolt Size …………………………………………………………………………..…...........2”(50mm)
Free speed…………………………………………………………………………………………….…2800rpm
Max torque……………………………………………………………………………….…..2500ft-lb(3480N.m)
Avg.air consumption………………………………………………………………………....43cfm(1225 l/min)
Operating pressure………………………………………………………………………….……...90psi(6.3bar)
Air inlet size…………………………………………………………………………………………...…….1/2”
Air hose………………………………………………………………………………………………….5/8” ID
Weight………………………………………………………………………………………...41.6Lbs(18.9kgs)
※Important Safety Rules
1. Follow all workshop safety rules, regulations, and conditions when using wrench.
2. Do not wear watches, rings bracelets or loose clothing when using air tools.
3. WARNING! Disconnect from air supply before changing accessories or servicing.
4. Maintain the wrench in good condition and replace any damaged or worn parts. Use genuine parts only.
Non-authorised parts may be dangerous.
5. WARNING! Check correct air pressure is maintained and not exceeded. We recommend 90psi.
6. Keep air hose away from heat, oil and sharp edges. Check air hose for wear before each use and ensure that all
connections are secure.
7. Only use impact sockets which are specifically designed for use with an impact wrench.
8. Wear approved safety eye/face shield, ear defenders, and hand protection.
9. WARNING! Due to the possible presence of asbestos dust from brake linings, when working around vehicle
brake systems we recommend you wear suitable respiratory protection.
10. Maintain correct balance and footing. Ensure the floor is not slippery and wear non-slip shoes.
11. Keep children and non essential persons away from the working area.
12. DO NOT use the wrench for a task it is not designed to perform.
13. DO NOT use wrench if damaged or thought to be faulty.
14. DO NOT use wrench unless you have been instructed in its use by a qualified person.
15. DO NOT carry the wrench by the air hose at yourself or others.
16. DO NOT direct air from the air hose at yourself or others.
17. When not in use disconnect from air supply and store in a safe, dry, childproof location.
General safety rules
maintaining, changing accessories on, or working near the assembly power tool for threaded fasteners.
Failure to do so can result in serious bodily injury.
fasteners. Modifications can reduce the effectiveness of
safety measures and increase the risks to the operator.
damaged.
are legibly marked on the tool. The employer/user shall contact the manufacturer to obtain replacement marking
labels when necessary.

3
Heavy Duty 1Air Impact Wrench RP7495
※Operating Instruction
Description
Stable and smooth torque output during operation. Extended anvil to reach into deep tire wells for lug nut removal.
Ergonomic design of the handle, and greatly reduce operating strength. 1” impact wrench is designed for removal of
truck, bus work, truck repair professional, heavy equipment bolts and farm equipment.
Projectile hazards
-velocity projectiles.
t-resistant eye protection during the operation of the assembly power tool for threaded fasteners.
The grade of protection required should be assessed for each use. Ensure that the workpiece is securely fixed.
Entanglement hazards
n result in choking, scalping and/or lacerations if loose clothing, personal
jewellery, neckware, hair or gloves are not kept away from the tool and accessories.
ting drive sockets and drive extensions can easily entangle rubber-coated or metal-reinforced gloves.
-fitting gloves or gloves with cut or frayed fingers.
drives.
Operating hazards
The following apply.
Wear suitable gloves to protect hands.
physically able to handle the bulk, weight and power of the tool.
to absorb the reaction torque are requested, it is recommended to use a suspension arm
whenever possible. If that is not possible, side handles are recommended for straightcase and pistol-grip tools. Reaction
bars are recommended for angle nutrunners. In any case, it is recommended to use a means to absorb the reaction torque
above 4 N·m for straight tools, above 10 N·m for pistol-grip tools, and above 60 N·m for angle nutrunners.
-and-stop device in the case of an interruption of the energy supply.
-ended crow-foot nutrunners.
unscrewing.
Repetitive motions hazards
or other parts of the body.
re whilst
maintaining secure footing and avoiding awkward or off-balanced postures. The operator should change posture during
extended tasks, which can help avoid discomfort and fatigue.
discomfort, pain, throbbing, aching, tingling,
numbness, burning sensations or stiffness, these warning signs should not be ignored. The operator should tell the employer
and consult a qualified health professional.

4
Heavy Duty 1Air Impact Wrench RP7495
Accessory hazards
The following apply.
accessory.
only sizes and types of accessories and consumables that are recommended by the assembly power tool for threaded
fasteners manufacturer.
-wrench-rated sockets in good condition, as poor condition or hand sockets and accessories used with
impact wrenches can shatter and become a projectile.
Workplace hazards
The following apply.
and also of trip hazards caused by the air line or hydraulic hose.
is not
insulated against coming into contact with electric power.
Dust and fume hazards
tools for threaded fasteners can cause ill health (for example,
cancer, birth defects, asthma and/or dermatitis); risk assessment and implementation of appropriate controls for these
hazards are essential.
e use of the tool and the potential for disturbing existing dust.
-filled environment.
ll integral features or accessories for the collection, extraction or suppression of airborne dust or fumes should be
correctly used and maintained in accordance with the manufacturer's instructions.
's instructions and as required by occupational
health and safety regulations.
Noise hazards
tinnitus (ringing, buzzing, whistling or humming in the ears).
⎯
“ringing”.
ction in accordance with employer's instructions and as required by occupational health and safety
regulations.
prevent an unnecessary increase in noise levels.
when the assembly power tool for threaded fasteners is operating.
/inserted tool as recommended in the instruction handbook, to prevent an
unnecessary increase in noise.

5
Heavy Duty 1Air Impact Wrench RP7495
Vibration hazards
he nutrunner sockets.
power tool for threaded fasteners, tell your employer and consult a physician.
Operate and maintain the assembly power tool for threaded fasteners as recommended in the instruction
handbook, to prevent an unnecessary increase in vibration levels.
-fitting sockets or extensions, as this is likely to cause a substantial increase in vibration.
unnecessary increase in vibration levels.
ttings should be used where practicable.
vibration is generally greater when the grip force is higher.
Additional safety instructions for pneumatic power tools
always shut off air supply, drain hose of air pressure and disconnect tool from air supply when not in use, before
changing accessories or when making repairs;
t use quick-disconnect couplings at tool inlet for impact and air-hydraulic impulse wrenches. Use hardened steel
(or material with comparable shock resistance) threaded hose fittings.
s shall be installed and whipcheck safety
cables shall be used to safeguard against possible hose-to-tool and hose-and-hose connection failure.
-control and continuous-rotation tools, the air pressure has a safety critical effect on performance. Therefore,
requirements for length and diameter of the hose shall be specified.
Air supply
1. Ensure wrench air valve (or trigger) is in the “off” position before connecting to the air supply.
2. It will require air pressure of 90psi, and air flow according to specification.
3. WARNING! Ensure the air supply is clean and does not exceed 90psi while operating the wrench. Too high an
air pressure and unclean air will shorten the product life due to excessive wear, and may be dangerous causing
damage or personal injury.
4. Drain the air tank daily. Water in the air line will damage the wrench.
5. Clean air inlet filter weekly.
6. Line pressure should be increased to compensate for unusually long air hoses (over 8 metres). The hose diameter
should be 5/8” I.D.
7. Keep hose away from heat, oil and sharp edges. Check hose for wear, and make certain that all connections are
secure.

6
Heavy Duty 1Air Impact Wrench RP7495
Lubrication
An automatic in-line filter-regulator-lubricator is recommended (Fig4) as it increases tool life and keeps the tool in
sustained operation. The in-line lubricator should be regularly checked and filled with air tool oil.
Proper adjustment of the in-line lubricator is performed by placing a sheet of paper next to the exhaust ports and
holding the throttle open approximately 30 seconds. The lubricator is properly set when a light stain of oil collects on
the paper. Excessive amounts of oil should be avoided.
In the event that it becomes necessary to store the tool for an extended period of time (overnight, weekend, etc.), it
should receive a generous amount of lubrication at that time. The tool should be run for approximately 30 seconds to
ensure oil has been evenly distributed throughout the tool. The tool should be stored in a clean and dry environment.
It is most important that the tool be properly lubricated by keeping the air line lubricator filled and correctly
adjusted. Without proper lubrication the tool will not work properly and parts will wear prematurely.
Use the proper lubricant in the air line lubricator. The lubricator should be of low air flow or changing air flow
type, and should be kept filled to the correct level. Use only recommended lubricants, specially made for
pneumatic applications. Substitutes may harm the rubber compounds in the tools, O-rings and other rubber parts.
IMPORTANT!!!
If a filter/regulator/lubricator is not installed on the air system, air operated tools should be lubricated at least once a
day or after 2 hours work with 2 to 6 drops of oil, depending on the work environment, directly through the male
fitting in the tool housing.
Loading and operation
WARNING: Ensure you read, understand and apply safety instructions before use.
1. Only use impact sockets which are specifically designed for use with impact wrench.
2. Connect the wrench to the air hose .
3. Place the socket over the subject nut and depress the trigger to operate the wrench.
4. To change direction push the button at the top of the handle. Direction of .R. for reverse and “L” for forward
5. The flow of air may be regulated by adjusting flow valve at the base of the handle.
6. Ensure the air supply is clean and does not exceed 90psi while operating the wrench. Too high an air pressure and
unclean air will shorten the product life due to excessive wear, and may be dangerous causing damage or personal
injury.
7. Make children away from the tools and workplaces.
DO NOT use any additional force upon the wrench in order to remove a nut.
DO NOT allow wrench to free run for an extended period of time as this will shorten its life.

7
Heavy Duty 1Air Impact Wrench RP7495
※Maintenance
WARNING: Disconnect wrench from air supply before changing accessories, servicing or performing
maintenance. Replace or repair damaged parts. Use genuine parts only. Non-authorised parts may be dangerous.
1. Lubricate the air wrench daily with a few drops of air tool oil dripped into the air inlet
2 DO NOT use worn, or damaged sockets.
3. Loss of power or erratic action may be due to the following:
a) Excessive drain on the air line. Moisture or restriction in the air pipe. Incorrect size or type of hose
connectors. To remedy check the air supply and follow instructions.
b) Grit or gum deposits in the wrench may also reduce performance. If your model has an air strainer (located
in the area of the air inlet), remove the strainer and clean it.
4. When not in use, disconnect from air supply, clean wrench and store in a safe, dry, childproof location.
※Trouble Shooting
The following form lists the common operating system with problem and solutions. Please read the form
carefully and follow it.
WARNING:If any of the following symptoms appears during your operating, stop using the tool immediately,
or serious personal injury could result. Only a qualified persons or an authorized service center can perform repairs or
replacement of tool.
Disconnect tool from air supply before attempting repair or adjustment. When replacing O-rings or Cylinder,
lubricate with air tool oil before assembly.
PROBLEMS
POSSIBLE CAUSES
REMEDIES
Tool runs at normal speed
but loses under load
Motor parts worn.
■Cam clutch worn or sticking
due to lack of lubricant.
■Lubricating clutch housing.
■ Check for excess clutch oil. Clutch cases need
only be half full. Overfilling
can cause drag on high speed clutch parts, ie. a
typical oiled/lubricated wrench requires 1⁄2
ounce of oil.
GREASE LUBRICATED:NOTE: Heat
usually indicates insufficient grease in chamber.
Severe operating conditions may require more
frequent lubrication.
Tool runs slowly. Air flows
slightly from exhaust
Motor parts jammed with dirt
particles
■Power regulator in closed
position
■Air flow blocked by dirt.
■Check air inlet filter for blockage.
Pour air tool lubricating oil into air inlet as
per instructions.
■Operate tool in short bursts quickly reversing
rotation back and forth where applicable.
Repeat above as needed.
Tools will not run. Air flows
freely from exhaust
■One or more motor vanes
stuck due to material build up.
■ Pour air tool lubricating tool into air inlet.
■Operate tool in short bursts of forward and/or
reverse rotation where applicable.
■ Tap motor housing gently with plastic mallet.
■ Disconnect supply. Free motor by rotating
drive shank manually where applicable
Tool will not shut off
■„O‟ rings throttle valve
dislodged from seat inlet valve.
■Replace „O‟ ring.
Note: Repairs should be carried out by a qualified person.

3
2
145678910
11 12 13 14 15 16
20 21 22 23 24 25 26 27 26 30
28 29
52
51
53 51
32
33
31
34
36
37
38
39
40
41
49
48
47
46
45
44
43
42
250
35
01
02
03
04
05
06
07
08
09
10
11
14
15
16
17
18
19
20
21
22
23
24
27
28
29
30
31
32
33
34
35
36
37
40
41
42
43
44
45
46
47
48
49
50
4
8
4
1
1
1
1
1
1
1
1
1
4
1
1
2
1
1
1
1
1
1
1
1
1
1
4
6
2
1
1
1
1
1
1
1
1
1
5
5
1
1
1
51
52
53
54
1
1
1
1
1
4
2
1
1
2
12
13
25
26
38
39
22
2014/10/16
V3
54
55
55 11
Professional 1" Air Impact Wrench RP7495 Explosive View and Parts list
Issue date:
Version no.:
No. Description Qty.No. Description Qty.No. Description Qty.No. Description Qty.No. Description Qty.
Bolt M8*45
Spring Washer
Nut M8
Head
Washer
O-ring 46*3.55
Shaft sleeve
Overhand volume
O-ring 18*2.65
Drive shaft
Locating ring
Hammer
Cam
Hammer cage
Front Washer
Front Sheath
Handle
Spring washer 6
Bolt M6*22
Bearing
Gun Body
Bearing
Front cap
Rotor
Blade
Pin 6*22
Cylinder
Pin 4*10
Rear cap
Rear Washer
Pin 4*32
Bolt M8*8
O-ring 6*1.8
Reverse Valve bush
O-ring 17*2.65
Steel ball Dw=4
Spring
Reversing valve
Pin 3*7
Pin 3*35
Rotary controller
Bolt M5*16
Spring washer 5
Air inlet plug
O-ring 21.7*2.4
Air inlet Spring
End Cap
Pin
Copper bush
Bolt M8*30
Pin 4*24
Trigger
Sealing cover
Bolt M4*12
Jacket
Note:
If you need spare parts of this model, pls feel free to contact us or the distributor where you bought this tool. Tks!
